Paramount Fitness LIP 10 A TGG User manual

R
US
Establishing a burner ignition for the FIRST time
or after changing the cylinder tank may take up to
2-3 minutes in order for the gas to purge through
the feeder lines.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately
call gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapours or liquids
in the vicinity of this or any other
a
pp
liance.
WARNING: For outdoor use only.
PATIO HEATER INSTRUCTION MANUAL
Model #. LIP 10 A TGG
Item #. LIP-10-TGG-HS,
PH-S-112 MK, PH-S-112-OR
PH-S-112-GR, PH-S-119 BU
For cus tomer service, parts
or warranty issues:
Call 1-800-561-5550
or e-mail [e-mail]
!
FOR OUTDOOR USE ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR REFERENCE

TABLE OF CONTENTS
GENERAL DESCRIPTION.................................3-4
PRECAUTIONS........................................................5
TOOLS & PARTS REQUIRED................................6
ASSEMBLY INSTRUCTIONS............................7-9
GAS REQUIREMENTS & LEAK TESTS.........9-10
HEATER LOCATION......................................10-11
OPERATION & STORAGE............................11-12
TROUBLESHOOTING.........................................13
STORAGE & MAINTENANCE............................14
WARRANTY & SERVICE.....................................15
** IMPORTANT NOTICE***
Do NOT return to place of purchase!!!
Please contact our Toll Free Hotline: [phone]
for customer service and warranty issues
e-mail: [e-mail]
Hotline hours: Mon. to Fri. 7:00am - 5:00pm ( P.S.T.)
** WARNING **
Improper operation, installation, adjustment,
alteration, servicing or maintenance can cause
severe property damage and/or serious damage
and/or serious injury or death. Please read the
installation, operating and maintenance instruc-
tions thoroughly before installing, operating or
servicing this appliance.
** For Your Safety **
If you smell gas :
1.
2.
If odor continues, immediatly call your gas3.
supplier
** For Your Safety **
Do NOT store or use gasoline or other
or any other appliance.
Establishing a burner ignition for the FIRST time or
after changing the cylinder tank may take up to 2-3
minutes in order for the gas to purge through the
feeder lines.
If stored indoors, detach and leave cylinder outdoors.
NOTE : 20 lb., 5 Gallon LPG tank is not included.

GENERAL DESCRIPTION - 3
** IMPORTANT NOTICE***
Establishing a burner ignition for the FIRST time or after changing the cylinder tank may take up to
2-3 minutes in order for the gas to purge through the feeder lines.
***NOTICE***
During the FIRST TIME use only
A patio/deck & garden heater of operation with LPG (Liquid Propane Gas). For connection/working pressure
information & lighting instructions, see the appliance data plate labels and this manual.
MAIN COMPONENTS
1. Cylinder base, 18’’ dia.
2. Tank housing
3. Main Post
4. Post support bracket assembly
5. Base of control housing
6. Intake screen
7. Burner base
8. Emitter Flame screen
10. Gas valve controller
11. Ignitor button
12. Gas inlet supply hose
13. Gas Regulator
14. Wheel Assembly
4
12

GENERAL DESCRIPTION - 4
CONSTRUCTION CHARACTERISTICS
Color: Brushed matte nish on stainless steel models. (Powder coat nish on steel models)
Casings: Base material on Deluxe Models feature stainless steel. (Galvanized sheet metal on steel models)
The burner is controlled using a positive lock, on/o gas control valve. The gas supply is controlled from gas
cylinder valve. The burner & burner assembly components are constructed from stainless steel. Emission of
infrared heat is assisted by the aluminum reector hood.
SAFETY Feature : This appliance has built in ‘’gas cut o’’ switch that shuts o the gas supply to the heater
assembly head any time the Burner Unit is tilted beyond 18 degrees or burner ame is extinguished.
Technical Data
Operating pressure with gas : 11’’WC (water column) (2.75 Kpa)
Inlet gas supply pressure : Min. 5 psi, Max. – 150 psi
Max. Heat rating : BTU 46,000
Low setting rating : BTU 17,500
Radiant Heat Range : 14 ft. To 16 ft. Diameter
Fuel Type : Liquid Propane Gas
Cylinder Size : Standard Industry 20 lb. Cylinder (5 gal. Cylinder capacity)
Consumption Rate : Approx. 10 hrs. at highest setting
Gross Weight : 53 lbs.
Certications : CSA
Gas Pressure Main Orice
Water Column Diameter in mm
11’’ (2.75 Kpa) 1.8
MADE IN CHINA
** WARNING **
Improper operation, installation, adjustment,
alteration, servicing or maintenance can cause
severe property damage and/or serious damage
and/or serious injury or death. Please read the in-
stallation, operating and maintenance instructions
thoroughly before installing, operating or servic-
ing this appliance.
WARNING !

GENERAL DESCRIPTION - 5
PRECAUTIONS – SAFETY FIRST! PLEASE READ THE FOLLOWING SAFETY RULES
Do nott use this space heater in an explosive atmosphere. Keep heater away from areas where gasoline or
other ammable liquids or vapors are strored.
Prior to use, check for damaged parts such as hoses, regulators, pilot, or burner.t
Do nott attempt to alter unit in any manner. (EXAMPLE : Using the heater without the top canopy reector or
radiant screen.) Do not shorten the burner post assembly.
Heater must always be placed on a stable, solid level surface.t
Always maintain proper clearance to combustible materials. (Top : 36’’, sides : 24’’)t
Always ensure there is ample fresh air ventilation. For outdoor use ONLY.t
Never replace or substitute the regulator with any regulator other than an original factory supplied replace-t
ment or UL listed regulator.
Do nott clean heater with cleaners that are combustible or corrosive.
Do nott paint radiant screen, control panel, or top canopy reector.
All leak tests should be done with a soapy solution. NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS.t
The LP tank should be completely turned o at the cylinder valve when the heater is not in use.t
The LP regulator/hose assembly shall be kept completely inside cylinder housing.t
Children and adults should be aware fo the hazards of high surface temperatures and should use extreme cau-t
tion and keep proper distance away from main heater unit to avoid burns or clothing ignition.
Young children should be carefully supervised when they are in the area of the heater.t
Clothing or other ammable materials should not be hung from the heater, or placed on or near the heater.t
Any guard or other protective device removed for servicing the heatert must be replaced prior to operatingt
the heater.
Installation and repair should be done by a qualied service person. The heater should be inspected beforet
use and at least annually by a qualied service person. More frequent cleaning may be required. It is impera-
tive that control compartment, burner and air circulation passageways of the heater be kept clean & clear of
debris, insects, spider webs, etc.
Keep the appliance area clear and free of combustion materials, gasoline and other ammable vapors andt
liquids.
Do not obstruct the ow of combustion and ventilation air.t
Keep the ventilation opening of the cylinder housing enclosure free and clear of debris.t
Save these instructions! Retain in a safe place for future reference.t
At least once a year, the unit should be inspected for the presence of spiders, spider webs, or other insects.
The burner area is a common spider haven and can damage the heater and render it unsafe for use.
Check the heater immediatly if any of the following exists :
1. The smell of gas in conjunction with extreme yellow tipping of the burner ames.
2. The heater does not reach maximum temperature.
3. The burner makes a popping noise during use (a slight popping noise is normal when the burner is extinguished).
** THINK SAFETY **
After appliance shut down.
Do NOT touch or move unit for at least 30 minutes. This allows for proper cooling of heater components.

GENERAL DESCRIPTION - 6
For questions, replacement parts, service help or other assistance,
please call the Customer Service Hotline!
TOOLS AND PARTS NEEDED FOR ASSEMBLY
NOTE : 20 Pound, 5 Gallon Capacity – Standard LPG Tank/Cylinder is NOT
supplied.
Tools Needed :
Adjustable Wrench1.
Phillips Head Screwdriver (#2 or #3 blade)2.
Spray Bottle of Soapy Water or Paint Brush and Soapy Water3.
(to check for leaks)
Parts Supplied:
t
1 pc. 18’’ Cylinder Baset
LPG Tank housing unitt
34’’ Support Post Component (2 pc. component see Fig. B-2.t
Post Support Brackets (3 each)t
LPG Gas Regulator with Hoset
t
Fig. A - 4 ea. – M6 x 10mm bolts for Burner Assemply & Upper Postt
Fig. B-1 - 6 ea. – M6 x 35mm long bolts with M6 nuts and washers fort
Post & Brackets
Fig. B-2 - 4ea.-M6x10mm bolts for pole assembly
Fig. C- 3 ea. – M8 x 16mm bolts for Post Bracket to Cylindert
Base
t
t
unit
Fig. F- 6ea. -M6 x 25mm bolts to attach wheel assembly brackets.t
Fig. D
Fig. E
D, E
FB2
B1, C

STEP 1
Wheel Assembly
Use M6 x 25mm bolts to attach wheel assembly brackets.
1-1 Place the 3 post mounting brackets on the Cylinder Base as shown.
1-2 Use 3-M8 x 16mm bolts to secure brackets to the base.
STEP 2
2-1 Place the short upright support onto the top of the post brackets, aligning
pre-drilled holes as shown.
2-2 Use 6-M6 x 35mm bolts, washers & nuts to attach post to post brackets.
Tighten securely.
2-3 Put the long pole onto the base of support post and use 4-M6x10mm bolts
STEP 3
Carefully, slide the tank cover over the post and onto the cylinder base. Tank
ASSEMBLY INSTRUCTIONS - 7
For questions, replacement parts, service help or other assistance,
please call the Customer Service Hotline!
1
2
2-3
3

ASSEMBLY INSTRUCTIONS - 8
** IMPORTANT NOTICE***
Do NOT return to place of purchase!!!
Please contact our Toll Free Hotline: [phone]
for customer service and warranty issues
e-mail: [e-mail]
Hotline hours: Mon. to Fri. 7:00am - 5:00pm ( P.S.T.)
STEP 4
4-1 Carefully insert gas inlet hose completely through the post
resting heater head unit on the support post.
4-2 Make sure both components are level and aligned with
holes of the support post with the holes at the bottom of the
head unit. Attach using 4-M6 x 10mm bolts. Use a Phillips head
screwdriver to tighten securely
STEP 5
through the pre-drilled holes. Attach using washers and cap
nuts.
5-2 Position the round center component over the remaining
exposed studs at the center and attach using washers and cap
nuts. Tighten securely.
STEP 6
threaded bolts located on the top of the head unit.
secure with wing nuts.
For questions, replacement parts, service help or
other assistance, please call the Customer Service Hotline!
**IMPORTANT NOTICE**
Establishing a burner ignition for the FIRST time or after changing the cylin-
der tank may take up to 2-3 minutes in order for the gas to purge through
the feeder lines.
4-2
4-1
5-1
5-2

INSTRUCTIONS - 9
STEP 7
7-1 Raise the tank housing cover and place on the post plate as
illustrated. ( Figure 1)
inlet hose.
not to overtighten.
7-4 Place LP gas tank into cylinder base.
7-5 Connect the regulator with the LPG gas tank. Note: left hand
thread direction – Hand tighten securely using quick connect turn
knob. Do not overtighten. Note: Left hand thread direction
GAS REQUIREMENTS & LEAK TESTING
NEVER CONNECT AN UNREGULATED GAS SUPPLY TO THE HEATER
PRECAUTIONS
Periodically check the whole system for leaks or if the smell of gas is detected.t
t
Never leak test while smoking.t
t
company.
For best results, the heater must be checked with a full cylinder.t
Do not use the heater until all connections have been leak tested and are sound.t
Only those parts recommended by the manufacturer should be used. Substitution can void the warranty.t
GAS REQUIREMENTS
Maximum inlet pressure to propane regulator must not exceed 125 P.S.I.t
A minimum supply pressure of 11.0 W.C. is required for the purpose of input adjustment for propane gas.t
The pressure regulator and hose assembly supplied with the appliance MUST be used. Replacement pressuret
The installation must conform with local codes, or in the absence of local codes, with National Fuel Gas code,t
ANSI/NFPA 58 or ANSI Z233.1-1998. (Canada – CAN/CGA-B149.1 & 2-M86)
Safety First !!!
Inspect the gas hose before each use of the appliance.t
The hose/regulator assembly must be REPLACED prior to thet
appliance being put into operation if there is evidence of exces-
sive abrasion or wear, or if the hose is damaged.
Any replacement assembly must meet original equipmentt
** For Your Safety **
If you smell gas :
3. If odor continues, immediatly
call your gas supplier
(Figure 1)

PROPANE CYLINDER TANK
The heater comes equipped with a hose assembly for hook-up to a standard propane gas tank. The propanet
tank is NOT included.
A dented, rusted or damaged propane tank may be hazardous and should be checked by your tank supplier.t
Never use a propane tank with a damaged valve connection.
The propane tank must be constructed and marked in accordance with the specications for LP gas cylin-t
ders per the US Department of Transportation (DOT).
The propane tank must be designed to provide for vapor withdrawal from the operating cylinder.t
Never connect an unregulated propane tank to the heater.t
LEAK TESTING
Gas connections on the heater are gas tested at the factory prior to shipment. A complete gas tightnesst
check must be performed at the installation site due to potential shipment irregularities or excessive pres-
sure being applied to the heater as well as to check nal installation of components by the consumer.
TO LEAK TEST
Make a soapy solution of one part liquid detergent and one part water. The soap solution can be appliedt
with a spray bottle, brush, or rag. Soap bubbles will appear where a leak is present.
Make certain the safety control valve is in the OFF position (at the control panel of the head unit).t
Turn the gas supply ON at the propane cylinder valve. Apply/spray several drops on the regulator hose tot
gas inlet hose connection, and the regulator to tank cylinder connection. (Small bubbles indicate a leak)
If a leak is present, turn OFF the gas supply, loosen and then re-tighten and leaking ttings, turn gas supplyt
ON again and recheck. Repeat as needed.
INSTRUCTIONS - 10
LOCATING HEATER FOR USE
BE CAREFUL : When certain material or items are left under the heater
while in use, they will be subjected to radiant heat and could be
seriously damaged!
The heater is primarely for heating of outdoor patios, decks, spas,t
pools and outdoor home working areas.
This unit is designed for RESIDENTIAL use only!t
Always ensure that adequate fresh air ventilation is provided. Followt
the MINIMUM spacing tolerances as indicated AT ALL TIMES!
The installation must conform with local codes, or in the absencet
of local codes, with National Fuel Gas code, ANSI/NFPA 58 or ANSI
Z233.1-1998. (Canada – CAN/CGA-B149.1 & 2-M86)
The heater must be placed on stable, level, rm ground.t
Never operate in an explosive atmosphere. Keep away from areast
where gasoline or other ammable liquids or vapors are stored or
used.
In very strong winds, turn o the heater, turn o the gas cylinder valve and remove the heat reector hood.
Then move the heater to a sheltered location. Do not move heater while it is still hot.

STEP 8 : OPERATION & STORAGE
8 -1 OPERATION
1. Open the gas cylinder valve
3. Depress control knob and then push the RED ignitor button to ignite the
main burner. Repeat until main burner ignites. Keep the control knob fully
depressed for an additional 30 seconds after burner ignites and then release.
turn the control knob counter clockwise.
6. Wait 5 minutes before re-lighting the unit
NOTE : Main burner may also be lit using a MATCH
Caution: Be aware of gas build-up when lighting with a match - especially after
holding down control knob. If you smell gas, WAIT 5 minutes for gas to dissipate
before lighting.
Manual Lighting: place a match through any of the large holes at the bottom of
the burner unit while following the lighting procedures above.
WARNING : Read the installation, operation, and maintenance instructions
thoroughly. BEFORE operating, installing or servicing this equipment, improper
use, adjustment, service and/or maintenance can cause serious injury or
damage to your property.
Minimum Clearance to adjacent combustible surfaces is as follows :
Sides – 24’’ Top – 36’’
The Gas Supply Must be turned OFF at the LP Gas Cylinder when this
appliance is not in use.
OPERATION & STORAGE - 11
** NOTICE **
During the FIRST TIME use
only. It is normal to expe-
rience a small amount of
smoke coming from the re-
coating applied during the
manufacturing process.
Calibration Mark
Ignitor
button
OFF
Large
Flame
Small
Flame
** Think Safety**
After appliance shuts
down Do NOT touch or
move unit for at least
30 minutes. This allows
proper cooling of the
heater components.

INSTRUCTIONS - 12
BURNER OPERATION
The burner head unit emitter screen will burn bright red when operatingt
normally. The heat generated is VERY INTENSE. Note : It is normal for some
discoloration of the emitter screen after use.
The burner ame will normally show blue with yellow tip ames (see g.).
Should you notice the ame to be predominatly yellow or producing thick
black smoke, this is an indication of air ow obstruction. Shut the unit o
and check burner and passageways for debris, insects, spider webs and
excessive carbon build up. Clean as needed.
t
HINT : Use a can of compressed air or an air compressor to blow out burner
and gas valve areas in the head unit. Spray liberally through vent holes and
manual lighting holes.
8-2 SAFETY HINTS
1. Closing the gas cylinder
Always completely close the gas valve of the gas cylinder after use and for storage.
2. Removing the regulator and hose
Remove the regulator and the hose by turning the nut clockwise.
3. Checking the threads for damage
Check the threads on the cylinder bottle valve for damage. If you suspect damage, replace the unit.
WARNING
AFTER SHUTTING OFF APPLIANCE WAIT 5 MINUTES
BEFORE RE-LIGHTING.
There is a built-in safety system designed to prevent
immediate re-lighting after use.
WARNING !WARNING !
When storing the heater, the connection between the propane tank and the heater must be disconnected and
the propane tank removed from the enclosure and stored outdoors in a well ventilated area and/or in accor-
*** FOR YOUR SAFETY ***
Do NOT store or use gasoline or other liquids or
vicinity of this or any other appliance.

TROUBLESHOOTING - 13
PROBLEM PROBABLE CAUSE SOLUTION
Main Burner Will Not Light Gas valve may be OFF
Fuel tank empty
Air in supply system
Loose connection
Ignitor fails
Gas pressure low with valve open full
New cylinder or 1st time ignition
Turn the gas valve ON
Clean or replace orice
Purge air from lines. Open gas lines &
press control knob in for 2-3 min.
Replace battery or use match to light
burner
Replace cylinder or regulator
Purge air from lines
Replace hose/regulator assembly
Low Burner Flame Pressure is low
Tank is low on fuel
Gas hose is kinked
Control knob at max
Replace cylinder tank
Fill LPG tank
Check & straighten or replace
Check for obstruction at passageways or
Burner Unit
Thick black smoke
Clean components as needed
Blockage in burner head unit
Thoroughly clean burner
** IMPORTANT NOTICE***
Do NOT return to place of purchase!!!
Please contact our Toll Free Hotline: [phone]
for customer service and warranty issues
e-mail: [email protected]
Hotline hours: Mon. to Fri. 7:00am - 5:00pm ( P.S.T.)

INSTRUCTIONS - 14
CUSTOMER SERVICE
ATTENTION : Consumer ... Please use the customer information listed below for any questions concerning
assembly, care information, warranty issues and/or replacement parts.
To ensure your satisfaction and maintain high standards for quality and workmanship, we want to hear from
you should you have any questions or comments. You can contact : J&R Home Products at 1-800-561-5550
[email protected]
Again, thank you for selecting our product line!
STORAGE & MAINTENANCE
STORAGE :
During the season :
Control knob must be in OFF positiont
Propane cylinder valve must be closed completelyt
Patio heater must be upright and sheltered from any harsh weather conditions (i.e. strong winds, rain, heavyt
mist, snow, dust & debris)
Control knob must be in OFF positiont
Disconnect LPG cylinder and store in a well ventilated OUTDOOR area where the temperature will not ex-t
ceed 125 degrees F.
Appliance should be upright and sheltered from outside weather conditions (i.e. rain, snow, hail, winds, dust,t
debris).
It is recommended that the ‘’head components’’ be wrapped or covered to protect against debris, dust andt
insects clogging air and gas passageways. Suggestion : use a poly trash can liner or polytarp material.
MAINTENANCE :
Outside metal surface – Clean with warm soapy water and soft rags or paper towels. Do NOT use abrasive ort
corrosive cleaning agents. Be careful NOT to wet the burner or pilot ignition assemblies. Do NOT spray water
or cleaning agents directly onto head components as severe damage may result.
t
-t
Possible signs of obstructed air and gas passageways :
Heat glow on head component is very UNEVEN1.
2.
Heating output (BTU) is noticeably reduced3.
Crackling or popping noises coming from heating components4.
NOTE : Locations near the ocean or saltwater will require more maintenance and frequent checking of components.
er.

.
IMPORTANT
For questions, concerns or problems with our product please
email our customer service department:
[email protected] or call 1-800-561-5550.
DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE.
WARRANTY
This product is inspected, tested and carefully packaged to minimize the chance of
damage during shipment. If a part (excluding light bulbs and fuses*) within one year from
the date of purchase proves to be defective in material or fabrication under normal
use, the part will be repaired or replaced. The Company’s obligation under the warranty
is to replace or repair defective parts at our discretion. Any expenses or damage resulting
from the installation, removal or transportation of the product will be the responsibility
of the owner and are not covered by this warranty. The owner assumes all other risks
arising from the use or misuse of the product. The warranty will be void if the product
damage or failure is deemed by the Company to be caused by accident,
alteration, misuse, abuse, incorrect installation or removal, or connection to an incorrect
power source by the owner. The Company neither assumes, nor authorizes any person or
entity to assume for it any obligation or liability associated with its products.
Light bulbs and fuses are not covered under this warranty. If you have any questions
regarding the warranty or service, please call our toll free number: 1-800-561-5550.
Customer Service
JR Home Products
Unit 1 - 5628 Riverbend Drive, Burnaby BC, V3N 0C1
Toll Free: 1-800-561-5550
E-mail: [email protected]
Warranty Registration Information Form / Formulaire d’enregistrement de la garantie
Registration can be completed online at www.jrhome.com or by mailing this form.
Name / Nom:
Street / Adress:
City / Ville:
Province / Province:
Postal Code / Code postal:
Daytime Phone # / No téléphone jour:
Evening Phone # / No téléphone soir:
E-Mail Address / Courriel:
Product/Produit:
Place of Purchase / Lieu de l’achat:
Date of Purchase / Date de l’achat:
Model # / No de modèle:
Serial # / Numéro de série:
You MUST register your product to receive
warranty service.
For warranty service, contact J&R Home
Products at the address, phone numbers listed
below within 30 days of purchase. Be sure to
have your sales receipt and original date of
purchase. All warranty service will be
coordinated by
J&R Home Products service center.
Vous DEVEZ enregistrer votre produit pour vous
prévaloir de la garantie.
Afin de faire valoir la garantie, communiquez
avec J&R Home Products à l’adresse et aux
numéros indiqués ci-dessous dans les 30 jours
suivant la date d’achat. Ayez en main votre reçu
et la date d’achat. Toutes les demandes liées
aux garanties seront traitées par le centre de
service de J&R Home Products.
Please mail to / Veuillez poster le tout à : Parts & Service Department, J&R Home Products Ltd. Unit 1 - 5628 Riverbend Drive, Burnaby BC, V3N 0C1 Toll Free Ph. 1.800.561.5550
You MUST register your product to receive warranty service.

Réussir l’allumage du brûleur la PREMIÈRE
FOIS ou après le changement de la bonbonne
peut prendre de 2 à 3 minutes, car le gaz doit
s’écouler dans les tubes d’alimentation.
Pour le service à la clientèle, les
pièces ou les questions relatives à la
garantie, veuillez appeler le
1-800-561-5550, ou envoyez un
CHAUFFERETTE DE PATIO MANUEL D’UTILISATION
POUR UTILISATION EXTÉRIEURE SEULEMENT
LIRE LE PRESENT MANUEL AVANT DE FAIRE FONCTIONNER
VEUILLEZ CONSERVER CE MANUEL POUR RÉFÉRENCE FUTURE
Ré
u
s
s
ir
F
O
I
S
o
u
a
p
e
u
t
p
r
en
s
’
é
c
o
u
P
ou
pi
è
c
es
ga
1-
80
C
H
A
UFFER
E
T
T
E
D
E
P
A
P
P
T
A
I
O
M
ANUE
L
D
U
R
US
POUR VOTRE SÉCURITÉ
Si une odeur de gaz est perceptible :
1. couper l’alimentation en gaz de
l’appareil;
2. éteindre toute flamme vive;
3. si l’odeur persiste, appeler
immédiatement le fournisseur
de gaz.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser
d’essence ou d’autres gaz ou
liquides inflammables à proximité
de cet appareil ou de tout autre.
AVERTISSEMENT
Utilisation à l’extérieur seulement.
!
Modéle no : LIP 10 A TGG
Numéro D'article : LIP-10-TGG-HS,
PH-S-112 MK, PH-S-112-OR
PH-S-112-GR, PH-S-119 BU
courriel à [email protected]

TABLE DES MATIÈRES
DESCRIPTION GÉNÉRALE...............................3-4
MISES EN GARDE..................................................5
OUTILS ET PIÈCES REQUIS.................................6
DIRECTIVES DE MONTAGE.............................7-9
EXIGENCES QUANT AU COMBUSTIBLE
ET ÉPREUVE..................................................... 9-10
EMPLACEMENT DU RADIATEUR.............10-11
FONCTIONNEMENT ET RANGEMENT...11-12
DÉPANNAGE.........................................................13
ENTREPOSAGE ET ENTRETIEN.......................14
GARANTIE ET SERVICE......................................15
** AVIS IMPORTANT***
Ne pas retourner ce produit à l’endroit où il a été acheté!!
Veuillez composer notre numéro d’assistance sans frais : 1-800-561-5550
pour accéder au service à la clientèle et obtenir des réponses à vos questions sur la garantie
Courriel : [e-mail]
Horaire du service d’assistance : lundi au vendredi. 7:00am - 5:00pm ( P.S.T.)
** Avertissement**
Le montage, l’installation, le réglage, la modi-
cation, le service ou l’entretien inadéquats de
ce radiateur peuvent causer d’importants dom-
mages matériels, des préjudices importants, des
blessures ou la mort. Veuillez lire attentivement
les présentes directives d’installation, d’utilisation
et d’entretien avant de monter, d’installer ou
d’entretenir cet appareil.
** Pour votre sécurité **
Si une odeur de gaz est perceptible :
1. couper l’alimentation en gaz de1.
l’appareil;
2. éteindre toute amme vive;2.
3. si l’odeur persiste, appeler immédi-3.
atement le fournisseur de gaz.
** Pour votre sécurité **
Ne pas entreposer ni utiliser d’essence ou
d’autres gaz ou liquides inammables à
proximité de cet appareil ou de tout autre.
Réussir l’allumage du brûleur
la PREMIÈRE FOIS ou après le
changement de la bonbonne
peut prendre de 2 à 3 min-
utes, car le gaz doit s’écouler
dans les tubes d’alimentation.
Si l’appareil est entreposé à l’intérieur, désaccouplez
la bonbonne et laissez-la à l’extérieur.
Conservez ce guide dans vos dossiers pour consulta-
tion ultérieure.
NOTE : la bonbonne de 20 lb (5 gallons) de GPL n’est
pas comprise.

12
4
DESCRIPTION GÉNÉRALE - 3
** AVIS IMPORTANT***
Réussir l’allumage du brûleur la PREMIÈRE FOIS ou après le changement de la bonbonne peut
prendre de 2 à 3 minutes, car le gaz doit s’écouler dans les tubes d’alimentation.
***AVIS***
À la PREMIÈRE utilisation seulement, il est normal de remarquer une petite quantité de fumée
protecteur appliqué au cours de la fabrication.
données sur les raccords et à la pression de service et aux directives d’allumage, consultez la plaque
signalétique de l’appareil et le présent guide.
PRINCIPAUX COMPOSANTS
Socle d’un diamètre 46 cm1.
Cache-bouteille2.
Colonne principale3.
Ensemble des supports de
montage de la colonne
4.
Colonne5.
Grille d’entrée d’air6.
Base du brûleur7.
Écran rayonnant8.
9.
Bouton de commande du gaz10.
Bouton d’allumage11.
Tuyau d’alimentation en gaz12.
Détendeur13.
Ensemble de roulettes14.

DESCRIPTION GÉNÉRALE - 4
Caractéristiques de construction
Couleur : Dans le cas des modèles en acier inoxydable, le ni est mat et brossé; dans le cas des modèles en acier,
le ni est un revêtement de poudre.
Enveloppe : Le matériau de base des modèles de luxe est l’acier inoxydable. (Les modèles en acier se composent
de feuilles de métal galvanisé).
Le brûleur est commandé par un bouton de commande du gaz marche-arrêt à verrouillage par engagement.
L’alimentation en gaz est réglée au robinet de la bonbonne. Le brûleur et les pièces de l’ensemble brûleur sont
faits d’acier inoxydable. La dissipation de la chaleur par rayonnement est favorisée au moyen du dôme réecteur
en aluminium.
DISPOSITIF DE SÉCURITÉ : Cet appareil comprend un interrupteur de coupure de l’alimentation du gaz intégré qui
coupe l’alimentation en gaz de la tête de radiateur chaque fois que le brûleur s’incline au-delà de 18 degrés ou
que la amme du brûleur s’éteint.
Données techniques
Pression de service avec le gaz : 11 pouces de colonne d’eau ou 2,75 kPa
Pression d’admission du gaz : min. de 5 psi; max. de 150 psi
Production max. de chaleur : BTU 46,000
Production au réglage min. : BTU 17,500
Plage de dissipation de la
chaleur par rayonnement : diamètre de 4,3 m à 4,9 m
Type de combustible : gaz propane liquide
Dimension de la bonbonne : norme de l’industrie, bonbonne de 20 lb et d’une capacité de 5 gallons
Durée : environ 10 heures au point maximal
Poids brut : 53 lbs.
Homologations : CSA
Pression du gaz : 11 po de colonne d’eau (2,75 kPa)
Diamètre de l’orice principal en mm : 11,8
Fabriqué en Chine
** Avertissement**
Le montage, l’installation, le réglage, la modication,
le service ou l’entretien inadéquats de ce radiateur
peuvent causer d’importants dommages matériels,
des préjudices importants, des blessures ou la mort.
Veuillez lire attentivement les présentes directives
d’installation, d’utilisation et d’entretien avant de
monter, d’installer ou d’entretenir cet appareil.
MISE EN GARDE !

DESCRIPTION GÉNÉRALE - 5
MISES EN GARDE, LA SÉCURITÉ D’ABORD!
PRIÈRE DE LIRE LES CONSIGNES DE SÉCURITÉ SUIVANTES
Ne pas faire fonctionner le radiateur dans un environnement explosif. Toujours le tenir à distance des lieuxt
d’entreposage d’essence ou d’autres liquides inammables, ainsi que des corps dégageant de telles vapeurs.
Avant toute utilisation, s’assurer qu’aucune pièce n’est endommagée, notamment les tuyaux, le détendeur, le dispositift
de veilleuse et le brûleur.
NE JAMAIS TENTER de modier l’appareil. PAR EXEMPLE, en utilisant le radiateur sans l’écran rayonnant ou le dômet
réecteur. Ne pas raccourcir la colonne du brûleur.
Toujours faire reposer l’appareil sur une surface stable, solide et de niveau.t
Respecter en tout temps les dégagements minimaux préconisés par rapport aux matériaux combustibles (supérieur :t
91 cm, latéraux : 61 cm)
Toujours assurer un apport susant en air pour la ventilation. Utiliser EXCLUSIVEMENT à l’extérieur.t
Ne jamais remplacer le détendeur par un détendeur autre que celui fourni par le fabricant de l’appareil ou qu’un dé-t
tendeur homologué UL.
Ne pas nettoyer le radiateur avec des détergents inammables ou corrosifs.t
Ne pas peindre l’écran rayonnant, le panneau de commande ou le dôme réecteur.t
Les épreuves d’étanchéité doivent être réalisées en utilisant une solution savonneuse. NE JAMAIS UTILISER UNEt
FLAMME VIVE À CETTE FIN.
Toujours fermer le robinet de la bonbonne de gaz lorsque le radiateur n’est pas utilisé.t
PENSEZ SÉCURITÉ!t
Après la fermeture de l’appareil…t
Attendre au moins 30 minutes avant de toucher ou de déplacer l’appareil. Ce délai est nécessaire pour que les élé-t
ments chauants aient le temps de refroidir.
L’ensemble détendeur et tuyau exible de GPL doit être inséré complètement à l’intérieur du cache-bouteille.t
Enfants et adultes doivent être conscients du risque lié à la température élevée de certaines surfaces et s’en tenir suf-t
samment à l’écart pour éviter les brûlures ou d’enammer leurs vêtements.
Les jeunes enfants doivent être étroitement surveillés lorsqu’ils se trouvent à proximité du radiateur.t
Ne jamais suspendre de vêtements ou des tissus inammables au radiateur, les laisser sur ce dernier ou à proximité.t
Tout écran ou autre dispositif protecteur retiré pour procéder à l’entretien du radiateur doit être remis en place avantt
d’allumer l’appareil.
L’installation et les réparations doivent être eectuées par un technicien qualié. Le radiateur doit être inspecté avantt
toute utilisation pour vérier si un nettoyage est nécessaire. Un tel nettoyage est requis au moins une fois par an. Des
nettoyages plus fréquents peuvent être nécessaires. Il est impératif de garder le panneau de commande, le brûleur et
les bouches de circulation d’air du radiateur propres et exempts de saletés, d’insectes, de toiles d’araignée et autres.
Ne laisser aucun matériau combustible, tel que de l’essence, des liquides inammables ou des corps dégageant det
telles vapeurs, à proximité de l’appareil.
Ne pas gêner la circulation de l’air nécessaire à la combustion et à la ventilation.t
Veiller à laisser les bouches d’aération du cache-bouteille dégagées et exemptes de saleté.t
Conservez ces directives! Rangez-les en lieu sûr pour consultation ultérieure!t
Au moins une fois par année, s’assurer de l’absence d’araignées, de toiles d’araignée et d’insectes dans l’appareil. Il
est courant que la zone du brûleur serve de refuge aux araignées; ces dernières peuvent endommager le brûleur et
rendre son utilisation risquée.
Inspecter immédiatement le radiateur dans les cas suivants :
Odeur de gaz accompagnée d’une forte coloration jaune de la pointe des ammes dans le brûleur;1.
Incapacité du brûleur à atteindre la température maximale;2.
Émission de petits crépitements au niveau du brûleur pendant l’utilisation (cependant, un léger crépitement3.
juste après l’extinction du brûleur est normal).
