Paramount Fitness HPS-C-PC User manual

ANSI Z83.26-2007/CSA 2.37-2007 Gas-Fired Outdoor Infrared Patio Heaters
RR
ITEM#: PH-T-107-SS, PH-T-107-MK GS
MODEL # HPS-C-PC
Patio Heater Manual
IMPORTANT
Read this manual carefully before
assembling, using or servicing this
heater. Keep this manual for future
reference.
For customer service, parts
or warranty issues:
call 1-800-561-5550 or e-mail
[email protected]om

1
Contents
General Safety Information....................................... 1
Contents Breakdown .............................................
Package Contents ..................................................
4
4
Assembly..................................................................
Portable Heater Location.........................................
5
7
7
7
7
8
Testing for Leakage ...............................................
7
Procedure for Leakage Test .................................
8
Turning ON the Heater ..........................................
Turning the Heater and Pilot Light OFF..................
.
9
Troubleshooting......................................................
Maintenance...........................................................
9
Storage...................................................................
Service....................................................................
9
Warranty.................................................................
General Safety Information
This manual contains important information about the
assembly, operation and maintenance of this patio heater.
General safety information is presented in these first few
pages and is also located throughout the manual.
Keep this manual for future reference and to educate
new users of this product. This manual should be read in
conjunction with the labeling on the product.
Safety precautions are essential when any mechanical
or propane fueled equipment is involved. These
precautions are necessary when using, storing, and
servicing. Using this equipment with the respect and
caution demanded will reduce the possibilities of personal
injury or property damage.
The following symbols shown below are used extensively
throughout this manual. Always heed these precautions,
as they are essential when using any mechanical or
fueled equipment.
DANGER
DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates an imminently hazardous situation
which, if not avoided, could result in death or serious injury.
DANGER
WARNING
CAUTION
CAUTION indicates an imminently hazardous situation which,
if not avoided, may result in minor or moderate personal injury,
or property damage.
WARNING: For Outdoor Use Only
WARNING
DANGER
Failure to comply with the precautions and instructions
provided with this heater can result in death, serious bodily injury
and property loss or damage from hazards of fire,explosion,
burn, asphyxiation, and/or carbon monoxide poisoning.
Only persons who can understand and follow the instructions
should use or service this heater.
Improper installation, adjustment, alteration, service or maintenance
can cause property damage, injury or death. Read the installation,
operation and maintenance instructions thoroughly before installing
or servicing this equipment.
DAN
G
E
R
C
ARB
O
N M
O
N
O
XIDE HAZAR
D
Thi
s app
li
ance can pro
d
uce car
b
on
mo
n
o
xi
de
whi
c
h h
as
n
o
odo
r.
U
s
i
n
g
i
t
i
n an enc
l
ose
d
space can
kill
y
ou
.
N
ever use t
hi
s app
li
ance
i
n an enc
l
ose
d
sp
ace such as a cam
p
er, tent or home
.
FO
R Y
O
UR
S
AFETY
I
f you smell gas:
1.
S
hut o
f
f gas to the appliance.
f
f

([WLQ
J
XLVKDQ
\
RSHQÀDPH

3
. I
f
odor continues, keep away
f
rom the appliance and
immediatel
y
call
y
ou
g
as supplier or
f
ire department.
D
o not store or use
g
asoline or other
f
lammabl
e
v
apors and liquids in the vicinit
y
of this or an
y
o
t
h
er app
li
ance
.
A
n LP-c
y
linder not connected
f
or use shall not be
s
tored in the vicinity of this or any other appliance.

DANGER
• EXPLOSION - FIRE HAZARD
• Keep solid combustibles, such as building materials,
paper or cardboard, a safe distance away from the heater
as recommended by the instructions.
• Provide adequate clearances around air openings into
the combustion chamber.
• Never use the heater in spaces which do or may contain
volatile or airborne combustibles, or products such as
gasoline, solvents, paint thinner, dust particles or unknown
chemicals.
• During operation, this product can be a source of
ignition. Keep heater area clear and free from combustible
materials, gasoline, paint thinner, cleaning solvents and
other flammable vapors and liquids. Do not use heater in
areas with high dust content. Minimum heater clearances
from combustible materials: three (3) feet from the sides &
two (2) feet from the top.
WARNING
We cannot foresee every use which may be made of our
heaters.
Check with your local fire safety authority if you have
questions about heater use.
Other standards govern the use of fuel gases and heat
producing products for specific uses. Your local authorities
can advise you about these.
If no local codes exist, follow National Fuel Gas Code,
ANSI Z223.1. In Canada, installation must conform to local
codes. If no local codes exist, follow the current National
standards of CANADA CAN/CGA-B 149.2.
DANGER
• CARBON MONOXIDE HAZARD
• This heater is a combustion appliance. All combustion
appliances produce carbon monoxide (CO) during the
combustion process. This product is designed to produce
extremely minute, non-hazardous amounts of CO if used
and maintained in accordance with all warnings and
instructions. Do not block air flow into or out of the heater.
• Carbon Monoxide (CO) poisoning produces flu-like
symptoms, watery eyes, headaches, dizziness, fatigue and
possibly death. You can't see it and you can't smell it. It's
an invisible killer. If these symptoms are present during
operation of this product get fresh air immediately!
• For outdoor use only .
• Never use inside house, or other unventilated or
enclosed areas.
• This heater consumes air (oxygen). Do not use in
unventilated or enclosed areas to avoid endangering
your life.
CAUTION
• SERVICE SAFETY
• Keep all connections and fittings clean. Make sure
propane cylinder valve outlet is clean.
• During set up, check all connections and fittings for leaks
using soapy water. Never use a flame.
• Use as a heating appliance only. Never alter in any way or
use with any device.
WARNING
• BURN HAZARD
• Never leave heater unattended when hot or in use.
•Keepoutofreachofchildren.
WARNING
Certain materials or items, when stored under the heater,
will be subjected to radiant heat and could be seriously
damaged.
2

3
WARNING
• This product is fueled by propane gas. Propane gas is
invisible, odorless, and flammable. An odorant is normally
added to help detect leaks and can be described as a
“rotten egg” smell. The odorant can fade over time so
leaking gas is not always detectable by smell alone.
• Propane gas is heavier than air and leaking propane will
sink to the lowest level possible. It can ignite by ignition
sources including matches, lighters, sparks or open flames
ofanykindmanyfeetawayfromtheoriginalleak.Useonly
propane gas set up for vapor withdrawal.
• Propane gas should be stored or used in compliance with
local ordinances and codes or with ANSI/NFPA 58. Turn off
propane when not in use. WARNING
DANGER
• EXPLOSION - FIRE HAZARD
• Never store propane near high heat, open flames, pilot
lights, direct sunlight, other ignition sources or where
temperatures exceed 120 degrees F (49°C).
• Propane vapors are heavier than air and canaccumulate
in low places. If you smell gas, leave the area immediately.
• Never install or remove propane cylinder while heater is
lighted, near flame, pilot lights, other ignition sources or
while heater is hot to touch.
• This heater is red hot during use and can ignite
flammables too close to the burner. Keep flammables at
least 3 feet from sides & 2 feet from top. Keep gasoline and
other flammable liquids and vapors well away from heater.
• The propane cylinder must always be stored outdoors in a
well ventilated space out of reach of children.Never store
propane cylinder in an enclosed area (house, garage, etc.).
If heater is to be stored indoors, disconnect the propane
cylinder for outdoor storage.
•Children and adults should be alerted to the
hazards of high surface temperatures. Stay away
from these surfaces to avoid burning skin or igniting
clothing.
•Young children should be carefully supervised
when in the vicinity of the heater.
•Clothing or any other flammable materials
should not be hung from the heater, or placed on
or near the heater.
•Any guard or protective device removed for
servicing the appliance must be replaced prior
to placing back in service.
•Installation and repair should be done by a qualified
service person. The heater should be inspected
before use and annually by a qualified service person.
More frequent cleaning may be required as necessary.
It is imperative that the control compartment, burners,
and circulating air passageway of the appliance be
kept clean.
WARNING
California Proposition 65
Combustion by products produced when using
this product contain chemicals known to the state
of California to cause cancer, birth defects, and
other reproductive harm.

This outdoor/tabletop heater requires some assembly.Check over the contents to make sure all the
parts are available for assembly.
Contents:
1. Finial
2. Reflector cap
3. Nuts (qty. 3)
4. Reflector
5. Washers (qty. 6)
6. Reflector spacers (qty. 3)
7. Emitter
8. M6X60 bolt (qty. 1)
9. Nuts (qty. 4)
10. Wire guard
11. Access panel
12. Base
13. Ring weight
14. M6X20 bolts (qty. 4)
15. 3/16" Stainless bolts (qty. 4)
16. Post with burner assembly
17. 3/16" Stainless bolts (qty. 4)
18. Heater housing 19. Bolt M5X8 / Nut M5 / washer (qty. 1)
Tools required for assembly:
1. Phillips screwdriver
2. Adjustable wrench
3. Spray bottle with soap solution for leak test
Contents Breakdown
Package Contents
4
Finial
Reflector
Washers (qty. 6)
Emitter
M6X60 bolt (qty. 1)
Wire guard
Access panel
Base
Ring weight
M6X20 bolts (qty. 4)
Reflector spacers (qty. 3)
3/16" Stainless bolts
(qty. 4)
Post with burner
assembly
Heater housing
3/16" Stainless bolts
(qty. 4)
Reflector cap
Nuts (qty. 3)
1
2
3
Nuts (qty. 4)
9
4
5
6
7
8
11
10
12
13
14
15
16
17
18
Bolt M5X8 / Nut M5
/ washer (qty. 1)
19

5
Assembly
STEP 1:
Attach post with burner
assembly onto heater
housing, using 4pcs 3/16"
Stainless bolts and M5X8
bolt / Nut M5/ washer, Keep
the access panel open.
For additional assistance or service,
please call: 888-775-1330.
STEP 2:
Attach ring weight to
base, using 4pcs
M6X20 bolts.
STEP 4:
Insert ends of wire
guard into holes in
the post with burner
assembly flange and
put 3pcs washers into
the top of support bolt.
STEP 3:
Put 3pcs reflector spacers into the hole in
emitter using 3pcs nuts to firm the reflector
spacers inside of the emitter.Put M6X60
bolt through the emitter hole into the top
of the emitter,using 1pc nut to firm the bolt.
Attach emitter assembly to post using 4pcs
bolts and washers.
STEP 5:
Attach reflector to emitter
assembly,using 3pcs nuts.
STEP 6:
Put reflector cap through the
M6X60 bolt using finial to firm it.

Gas Tank Assembly
Provided with a listed overfilling prevention device.
The cylinder used must include a collar to protect the cylinder valve.
Never connect an unregulated propane cylinder to the heater.
Turn off the control knob of the burner.Fix the 1.02 lb.
propane cylinder to the regulator(rotate the propane cylinder
clockwise toward the regulator connecting untill tighten it).
Provided with a cylinder connection device compatible with the
connection for the appliance.
A dented, rusted or damaged propane cylinder may be hazardous
and should be checked by your cylinder supplier. Never use a
propane cylinder with a damaged valve connection.
The propane cylinder must be constructed and marked in
accordance with the specifications for LP gas cylinders of the
U.S. Department of Transportation (DOT). or the Standard for
Cylinders, Spheres and Tubes for Transportation of Dangerous
Goods and Commission, CAN/CSA-B339.
You must provide propane gas and propane cylinder .
Use a standard 1.02 lb. propane cylinder only.
Storage of an appliance indoors is permissible only if the
cylinder is disconnected and removed from the appliance.
A cylinder must be stored outdoors in a well-ventilated area
out of the reach of children. A disconnected cylinder must
have dust caps tightly installed and must not be stored in a
building, garage or any other enclosed area.
Standard 1.02 lb. tank
orientation to provide
vapor withdrawal
6
Close the door plate and lock it with the handle.
The cylinder be disconnected when the appliance is not use.
Replacement pressure regulator must be that specified by the
appliance manufacturer.The pressure regulator and hose assembly
supplied with the appliance must be used.
Storage of an appliance indoors is permissible only if the cylinder
is disconnected and removed from the appliance.
An appliance may be installed with shelter no more inclusive than:
(a) With walls on all sides,but with no overhead cover.
(b) Within a partial enclosure which includes an overhead cover
and no more than two side walls. These side walls may be
parallet, as in a breezeway, or at right angles to each other.
(c) Within a partial enclosure which includes an overhead cover
and three side walls, as long as 30 percent or more of the
horizontal periphery of the enclosure is permanently open.
The pressure regulator supplied with the appliance must
be used.
Only a cylinder marked “propane” can be used.
Certain materials or items, when stored under the heater,
will be subjected to radiant heat and could be seriously
damaged.
The installation must conform with local codes, or in the
absence of local codes,with National Fuel Gas Code,
ANSI Z223.1/NFPA54, Natural Gas and Propane Installation
Code, CSA B149.1, or Propane Storage and Handling
Code, B149.2. (a) Do not store a spare LP-gas cylinder under or near this appliance;
(b) Never fill the cylinder beyond 80 percent full;
STEP 7:
Rotate regulator toward
opening in housing.
Line up threads on gas
cylinder with those on
the regulator.
Insert and rotate cylinder
clockwise until tight.
STEP 8:
Close access panel.

7
1. This portable heater is intended for outdoor use only.
Always ensure that adequate fresh air ventilation is
provided.
1. Perodically check the whole gas system for leaks.
2. Immediately check for leaks if an odor of gas is detected.
3. Extinguish all open flames during testing or when an odor
of gas is detected.
4. Never smoke while performing the leak test.
5. If you cannot stop a leak, unscrew and remove the cylinder
from the heater.
6. The heater must be checked with a full propane cylinder.
DO NOT use the heater until you have performed a leak
test on all the connections and verified that your unit does
not leak.
7. Use only manufacturer recommended replacement parts.
Substitution may void the warranty.
1. Turn on the valve on the gas supply cylinder completely.
2. Firmly press down and turn the variable control knob
approximately 45°(counter anti-clockwise).
3. Press down the variable control knob and hold for 20
seconds. while holding down the variable control knob,
press the igniter button several times until the pilot flame
comes on. Release the variable control knob after the
pilot flame lights.
4. If the pilot does not light, repeat step 2 to 3.
Note: If a new tank has just been connected, please allow at
least one minute for the air in the gas pipeline to purge out
through the pilot hole.
5. After the flame comes on, leave the variable control knob at
minimum position for about 5 minutes, then switch to a desire
temperature position.
1. Turn control knob to “PILOT” position.
2. Press down lightly and turn to “OFF” position.
3.Turn the gas tank off completely.
4. A 5 min. complete shut off period is needed before the
appliance is relighted.
Variable Control Knob
2. Always maintain proper clearance to combustible.
materials, i.e. top 24 inches and sides 36 inches
minimum.
3. The heater must be put on a strong and stable table.
4. Never operate the heater in an explosive atmosphere
like in areas where gasoline or other flammable liquids
or vapors are stored.
Gas connections on this heater are leak tested at the
factory prior to shipment. Possible mishandling of this
appliance during shipping may impair product integrity.
A complete leakage test must be performed again at the
installation site. Please follow the procedure below.
1. Make a soap solution of one part liquid detergent and
one part water. The soap solution can be applied to
hoses and connections with a spray bottle, brush or rag.
2. Make sure that the safety control valve is in the "OFF"
position.
3. Turn the cylinder valve ON and check for soap bubbles
forming on and around connections and hoses. If bubbles
appear, there is a leak present.
4. If a leak is present, remove the gas cylinder immediately,
tighten any leaking fittings, replace the gas cylinder, and
recheck.
Portable Heater Location
Turning ON the Heater
Turning the Heater and Pilot Light OFF
Procedure for Leakage Test
Testing for Leakage
O
L
t
o
l
iP
IH
O
L
t
o
l
i
P
I
H
O
L
t
oli
P
IH
CEILING
24”
36”
WALL

Troubleshooting
If the problem is: And this condition exists: Then do this
Pilot won’t light
Cylinder valve is closed Open valve
Blockage in orifice or pilot tube Clean or replace orifice or pilot tube
Air in gas line
Open gas line and bleed it (pressing control
knob in) for not more than 1 - 2 minutes or until
you smell gas
Low gas pressure with cylinder valve
fully open Turn cylinder valve OFF and replace cylinder
Note: Heater operates at
reduced efficiency below 40ºF
(5ºC)
Igniter fails Use match to light pilot; obtain new igniter and
replace
Pilot won’t stay lit
Dirt built up around pilot Clean dirt from around pilot
Connection between gas valve and
pilot assembly is loose Tighten connection and perform leak check
Thermocouple is not operating correctly Replace thermocouple
Burner won’t light
rednilycecalperdnaFFOevlavrednilycnruTwolsierusserpsaG
egakcolbraelCecifironiegakcolB
Control knob is not in ON position Turn control knob to ON
Burner flame is low
rednilycecalperdnaFFOevlavrednilycnruTwolsierusserpsaG
Outdoor temperature is less than 40ºF
and tank is less than 1/4 full Use a full cylinder
egakcolbrofsecifirodnarenrubkcehCNOyllufbonklortnoC
Carbon build-up Dirt or film on reflector and burner screen Clean reflector and burner screen
Thick black smoke Blockage in burner Remove blockage and clean burner inside and
outside
8
Maintenance
WARNING
FOR YOUR SAFETY:
• Do NOT touch or move heater for at least 45 minutes
after use.
• Reflector is hot to the touch.
• Allow reflector to cool before touching.
To enjoy years of outstanding performance from your
heater, make sure you perform the following maintenance
activities on a regular basis:
Air flow must be unobstructed. Keep controls, burner,
and circulating air passageways clean. Signs of possible
blockage include:
a. Keeping the appliance area clear and free from combustible
materials , gasoline and other flammable vapors and liquids.
b. Not obstructing the flow of combustion and ventilation air.
Keep exterior surfaces clean.
Use warm soapy water for cleaning. Never use
flammable or corrosive cleaning agents.
While cleaning your unit, be sure to keep the area around the
burner and pilot assembly dry at all times. Do not submerge the
control valve assembly. If the gas control is submerged in water,
do NOT use it. It must be replaced.
c.Keeping the ventilation opening(s) of the cylinder enclosure
free and clear from debris.
Normal Abnormal

9
.Gas odor with extreme yellowtipping of flame.
.Heater does NOT reach the desired temperature.
.Heater glow is excessively uneven.
.Heatermakes popping noises.
.Spiders and insects can nest in burner or orifices.
This dangerous condition can damage heater and
render it unsafe for use. Clean burner holes by using
aheavy-duty pipe cleaner. Compressed air may help
clear away smaller particles.
.Carbondeposits may create a fire hazard. Clean
domeand burner screen with warm soapy water if
any carbon deposits develop.
Note: Inasalt-airenvironment (suchasnear an ocean),
corrosion occurs morequickly than normal. Frequently
check for corroded areas and repair them promptly.
TIP:
Usehigh-quality automobile wax to help maintain the
appearance of your heater. Apply to exterior surfaces from
the pole down. Do not apply to emitter screen or domes.
Storage
Between uses:
.Turn Control Knob OFF.
.Disconnect LP source.
.Store heater upright in an area sheltered from direct
contact with inclement weather (such as rain, sleet,
hail, snow, dustanddebris).
.If desired, cover heater to protect exteriorsurfaces
and to help prevent build up in air passages.
Note: Wait until heater is cool before covering.
During periods of extended inactivity or when
transporting:
.Turn Control Knob OFF.
.Disconnect LP source and move to a secure,
well-ventilated locationoutdoors.
.Store heater upright in an area sheltered from direct
contact with inclement weather (such as rain, sleet,
hail, snow, dustanddebris).
.If desired, cover heater to protect exterior surfaces
and to help prevent build up in air passages.
.Never leave LP cylinder exposed to direct sunlight or
excessive heat.
Note: Wait until heater is coolbefore covering.
Service
Repair to gas passages and associated components
should be done only by a qualified service person.
Caution: Always allow heater to cool before
attempting service.

.
IMPORTANT
For questions, concerns or problems with our product please
email our customer service department:
[email protected] or call 1-800-561-5550.
DATED PROOF OF PURCHASE REQUIRED FOR WARRANTY SERVICE.
WARRANTY
This product is inspected, tested and carefully packaged to minimize the chance of
damage during shipment. If a part (excluding light bulbs and fuses*) within one year from
the date of purchase proves to be defective in material or fabrication under normal
use, the part will be repaired or replaced. The Company’s obligation under the warranty
is to replace or repair defective parts at our discretion. Any expenses or damage resulting
from the installation, removal or transportation of the product will be the responsibility
of the owner and are not covered by this warranty. The owner assumes all other risks
arising from the use or misuse of the product. The warranty will be void if the product
damage or failure is deemed by the Company to be caused by accident,
alteration, misuse, abuse, incorrect installation or removal, or connection to an incorrect
power source by the owner. The Company neither assumes, nor authorizes any person or
entity to assume for it any obligation or liability associated with its products.
Light bulbs and fuses are not covered under this warranty. If you have any questions
regarding the warranty or service, please call our toll free number: 1-800-561-5550.
Customer Service
JR Home Products
Unit 1 - 5628 Riverbend Drive, Burnaby BC, V3N 0C1
Toll Free: 1-800-561-5550
E-mail: [email protected]
Warranty Registration Information Form / Formulaire d’enregistrement de la garantie
Registration can be completed online at www.jrhome.com or by mailing this form.
Name / Nom:
Street / Adress:
City / Ville:
Province / Province:
Postal Code / Code postal:
Daytime Phone # / No téléphone jour:
Evening Phone # / No téléphone soir:
E-Mail Address / Courriel:
Product/Produit:
Place of Purchase / Lieu de l’achat:
Date of Purchase / Date de l’achat:
Model # / No de modèle:
Serial # / Numéro de série:
You MUST register your product to receive
warranty service.
For warranty service, contact J&R Home
Products at the address, phone numbers listed
below within 30 days of purchase. Be sure to
have your sales receipt and original date of
purchase. All warranty service will be
coordinated by
J&R Home Products service center.
Vous DEVEZ enregistrer votre produit pour vous
prévaloir de la garantie.
Afin de faire valoir la garantie, communiquez
avec J&R Home Products à l’adresse et aux
numéros indiqués ci-dessous dans les 30 jours
suivant la date d’achat. Ayez en main votre reçu
et la date d’achat. Toutes les demandes liées
aux garanties seront traitées par le centre de
service de J&R Home Products.
Please mail to / Veuillez poster le tout à : Parts & Service Department, J&R Home Products Ltd. Unit 1 - 5628 Riverbend Drive, Burnaby BC, V3N 0C1 1.800.561.5550
You MUST register your product to receive warranty service.
