Parker SciLog DINCon Assembly instructions

SciLog®DINCon®, DINPres®,
& DINTemp®Modules
Installation, Operating & Maintenance Instructions

2
Parker Hannifin Corporation has a continuous policy of product development and although the Company reserves the right to
change specification, it attempts to keep customers informed of any alterations. This publication is for general information only and
customers are requested to contact your local Parker Sales Representative for detailed information and advice on a product’s
suitability for specific applications. All products are sold subject to the company’s Standard conditions of sale.
SciLog®and DINCon®, DINPres®, and DINTemp®, are registered trademarks of
Parker Hannifin Corporation.

3
Contents
Introduction.................................................................................................................................6
Calibration ..................................................................................................................................6
Warranty.....................................................................................................................................7
Standards ...................................................................................................................................7
Installation & Start-Up.................................................................................................................7
Maintenance & Cleaning.............................................................................................................7
DIN Module Specifications..........................................................................................................8
Sensor Specifications .................................................................................................................9
SciCon Sensors..........................................................................................................................9
SciPres Sensors .........................................................................................................................9
SciTemp Sensors .....................................................................................................................10
Installation ................................................................................................................................11
Operating Instructions...............................................................................................................14
Modbus Register List................................................................................................................16
DINCon Registers.....................................................................................................................16
DINPres Registers....................................................................................................................20
DINTemp Registers ..................................................................................................................25
Reference Information ..............................................................................................................29

4
Precautions
READ this manual BEFORE operating or servicing this equipment.
FOLLOW these instructions carefully.
SAVE this manual for future reference.
DO NOT allow untrained personnel to operate, clean, inspect, service or tamper with
this equipment.
ALWAYS DISCONNECT this equipment from the power source before cleaning or
performing maintenance.
Contact your local Parker Division for parts, information and service.
WARNING
DISCONNECT ALL POWER TO THIS UNIT BEFORE INSTALLING,
SERVICING, CLEANING OR REMOVING THE FUSE. FAILURE TO DO
SO COULD RESULT IN BODILY HARM AND/OR PROPERTY DAMAGE.
CAUTION
OBSERVE PRECAUTIONS FOR HANDLING ELECTROSTATIC
SENSITIVE DEVICES.
WARNING
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS
EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND
ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO
OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.
WARNING
FOR CONTINUED PROTECTION AGAINST SHOCK HAZARD, CONNECT
TO PROPERLY GROUNDED OUTLET ONLY. DO NOT REMOVE THE
GROUND PRONG.
CAUTION
USE ONLY CLASS 2 LISTED EXTERNAL 24 VDC POWER SUPPLY WITH
THESE DEVICES.

5
Précautions
LISEZ ce manual AVANT de faire fonctionner ou d’entretenir cet équipment.
SUIVEZ attentivement ces instructions.
CONSERVEZ ce manuel pour future référence.
NE LAISSEZ PAS du personnel non qualifié utiliser, nettoyer, inspecter, entretenir, réparer ou
manipuler cet équipement.
DÉBRANCHEZ TOUJOURS cet équipement de la source de courant avant de nettoyer ou
d’exécuter l’entretien.
APPELEZ PARKER pour pièces détachées, renseignements et entretien.
ATTENTION
DÉBRANCHEZ TOUT COURANT DE CETTE UNITÉ AVANT DE FAIRE
L’INSTALLATION, D’EFFECTUER L’ENTRETIEN, LE NETTOYAGE OU
AVANT DE RETIRER LE FUSIBLE. NE PAS OBSERVER CES
PRÉCAUTIONS RISQUERAIT DE CAUSER DES BLESSURES
CORPORELLES OU/ET D’ENDOMMAGER L’ÉQUIPEMENT.
PRUDENCE
SOYEZ PRUDENT LORSQUE VOUS MANIPULEZ DES APPAREILS
SENSIBLES À L’ÉLECTROSTATIQUE.
ATTENTION
ONLY PERMIT QUALIFIED PERSONNEL TO SERVICE THIS
EQUIPMENT. EXERCISE CARE WHEN MAKING CHECKS, TEST AND
ADJUSTMENTS THAT MUST BE MADE WITH POWER ON. FAILING TO
OBSERVE THESE PRECAUTIONS CAN RESULT IN BODILY HARM.
ATTENTION
POUR ASSURER UNE PROTECTION CONTINUE CONTRE UNE
DÉCHARGE ÉLECTRIQUE, BRANCHEZ UNIQUEMENT SUR UNE PRISE
CORRECTEMENT RELIÉE Á LA TERRE. NE RETIREZ PAS LA FICHE DE
TERRE.
PRUDENCE
N'UTILISER QUE DE L'ALIMENTATION ÉLECTRIQUE 24 VDC
EXCLUSIVE DE CLASSE 2 AVEC CES DISPOSITIFS.

6
Introduction
You will find the SciLog®DINCon, DINPres and DINTemp Modules and sensors easy to use. The state-
of-the-art hardware and software design of the SciLog®DIN Module and sensor combination allows you
to measure and document the conductivity, pressure or temperature of many filtration / separation
processes. With proper maintenance, the SciLog®DIN Modules will provide many years of excellent
service and performance.
Please read the following instructions carefully!
Inspections: Remove the products carefully from the shipping container. Check the contents against
the purchase order to verify that all parts are included and undamaged.
Please do the inspection now, even if the products are not used immediately. Many carriers must
receive damage claims within seven days of delivery. Please retain all packing material so unit may be
shipped safely, if necessary.
Customer Service: Parker Bioscience customer service: If assistance is required, please contact us at:
Parker Hannifin Corporation
Bioscience & Water Filtration
2340 Eastman Avenue
Oxnard, California, USA 93030
toll free: 877 784 2234
phone: [phone]
fax: [phone]
email: [email protected]
www.parker.com/dhsingleuse
Parker Hannifin Manufacturing Ltd
Bioscience Engineering Filtration
Durham Road
Birtley, Co. Durham
DH3 2SF, England
phone [phone]
fax [phone]
email: [email protected]
www.parker.com/dhsingleuse
Parker customer service personnel will be able to serve you more efficiently if you have the following
information:
Serial number and model name of the equipment
Installation procedure being used
Concise list of symptoms
List of operating procedures and conditions in use when problem arose
Calibration
The SciLog®DIN Modules are calibrated devices, and are calibrated with test equipment that is
traceable to SI through NIST.
A Calibration Certificate is included with each unit, and has a one year expiration date.
It is highly recommended that the Module be calibrated on an annual basis or more often if your
Metrology Department deems it necessary.
Parker Bioscience provides this Calibration Service, complete with a new certificate, showing the “as
found” and “as left” data.
Contact your local Parker Bioscience representative.

7
Warranty
Country specific information can be found at: www.parker.com/termsandconditions
Standards
EN 61326-1:2006, Class B
EN 61010-1:2010 Ed.3+ C1; C2
Conforms to UL STD 61010-1:2012 Ed.3+ R: 29Apr2016
Certified to CSA STD C22.2 No 61010-1-12:2012 Ed.3+U1;U2
Caution: The maximum recommended pressure for the sensors is 60 psi.
If this is exceeded, problems with leakage and functionality can occur.
Installation & Start Up
Installation of the SciLog
®
DINCon
®
DINPres
®
, and DINTemp
®
Modules must be carried out only by
trained personnel in accordance with the relevant regulations and this operations manual.
Make sure that the technical specifications and input ratings of the SciLog
®
sensors are observed. See
the appropriate Sensor Specifications page.
The protection provided by this equipment may be impaired if the SciLog
®
sensors are used in a
manner inconsistent with this manual or for purposes not specified by the manufacturer.
Maintenance & Cleaning
The SciLog
®
DIN Modules are maintenance free. The single-use SciLog
®
sensors come pre-calibrated
from the factory and require no maintenance.
To remove dust, dirt and stains, the outer surfaces of the DIN Modules may be wiped using a soft, non-
fluffing cloth moistened with water. If required, you may also use a mild detergent or 2-propanol.
The single-use sensors may be sanitized with 0.1 Molar NaOH, or 2-propanol. They may be autoclaved
up to 2 times, or gamma-irradiated with exposure up to 45 kGy.

8
Hardware
Specifications – All Modules
Dimensions W: 0.875¨ (2.2 cm); Height 4.0¨ (10.2 cm); D: 4.75¨ (12.1 cm)
Weight 0.3 lb. (0.14 Kg)
Enclosure Molded Plastic
Electrical
Power 24 VDC, 250 mA. Use only Class 2 External Power Supply
Battery CR1632, used for internal clock, not user serviceable
I/O Port Top 8 pin Terminal Block, numbered from rear:
1: +24 VDC 2: 24 VDC Return 3: N/C 4: Signal GND (COM)
5: RS-232 RX 6: RS-232 TX 7: RS-485 A 8: RS-485 B
I/O Port – 2 RJ45, Ethernet Connection
I/O Port - 3 USB Connection
Software
I/O Port
Bottom
8 Pin Sensor Connection, DINCon has 1, DINPres and
DINTemp have 3.
DISPLAY Power Status LED, Sensor Status LED’s
Modbus Modbus RTU via RS-232
Modbus RTU via RS-485
Modbus RTU via USB
Modbus TCP via Ethernet
Environmental
Temperature 4 – 60° C
Altitude Up to 2000 Meters
IP Rating IP20, Indoor dry environments, unit is wipe-down only
Rel. Humidity 0 – 95%
Voltage Fluctuation allowed: +/- 10%
Pollution Degree: 2

9
Specifications – Sensors
SciCon:
Power 5 VDC provided by DINCon® Module
Fluid Connections
Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,
3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover
(‘Ladish’) Sanitary.
Wetted Materials
Polysulphone meets USP Class VI and FDA 21
CFR 177.1520, all wetted materials made with
animal-free compounds.
Sensor Type 4-Electrode Conductivity Cell, gold plated pins.
Conductivity Range 1 μS/cm to 200 mS/cm; Resolution: 0.1 μS/cm.
Accuracy High: ± 0.25 mS in the 0.1 - 200 mS range;
Low: ± 3 μS in the 0 - 100 μS range
Temperature Range 4-50° C
Temperature Accuracy +/- 0.5° C
Temperature Probe Thermistor
Pre-Calibration 0.10 M KCI Solution, 12.88 mS at 25.0° C
Sensor Microchip EPROM, Stores Sensor ID, and
Calibration Factor.
Sensor Connector & Cables Lockable and Waterproof.
SciPres:
Power 5 VDC provided by DINPres® Module
Fluid Connections
Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,
3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover
(‘Ladish’) Sanitary.
Wetted Materials
Polysulphone meets USP Class VI and FDA 21
CFR 177.1520, all wetted materials made with
animal-free compounds.
Sensor Type Medical grade, silicone piezoresistive sensing
element with on-chip temperature compensation.
Sensor Isolation
Insoluble silicone dielectric gel isolates sensing
element from process solution. The gel is a non-
toxic, non-allergenic elastomeric system.
Pressure Range -5 to 60 psi (-0.34 to 4.14 bar).

10
Accuracy
+/- 0.30 psi at -5 to 30 psi for 2 point calibrated
sensors (can be improved to -5 to 60 psi with 3
point calibration, also available)
Resolution 0.01 psi
Temperature Range 0 to 60 °C (32 to 140 °F).
Sensor Microchip EPROM, Stores Sensor ID, and
Calibration Factor.
Sensor Connector & Cables Lockable and Waterproof.
SciTemp:
Power 5 VDC provided by DINTemp® Module
Fluid Connections
Choice of five sizes: Luer, 3/8” Barb, 1/2” Barb,
3/4” Tri-Clover (TC) Sanitary and 1” Tri-Clover
(‘Ladish’) Sanitary.
Wetted Materials
Polysulphone meets USP Class VI and FDA 21
CFR 177.1520, all wetted materials made with
animal-free compounds.
Sensor Type Thermistor, Epoxy coated, 2252 Ω
Temperature Range -40 to +150° Celsius
Accuracy +/- 0.10° Celsius in the 4.0 to 70° Celsius range.
Resolution 0.01 ° Celsius
Sensor Microchip EPROM, Stores Sensor ID, and
Calibration Factor.
Sensor Connector & Cables Lockable and Waterproof.

11
Installation:
Overview:
The DINCon, DINPres, and DINTemp Modules are designed to be installed as part of a
control system inside a control cabinet that has a 24 VDC source available and has
Modbus communication protocol capability.
The DIN Modules are installed on standard DIN rail. They are usually mounted with the
red locking tab located at the bottom of the unit. This places the Power and
Communication connections at the top of the Module and the Sensor connections at the
bottom.
Wiring Power and Communication:
Connect 24 Volts DC, 250 mA power to Pins 1 (+) and 2 (-) of the 8 pin terminal block.
(Note - pin 1 is at the rear.)
All data acquisition is via Modbus registers in either RTU or ASCII. The available
physical layers are RS-232, RS-485, Ethernet and USB. The recommended physical
layer for installation of multiple units is Modbus/RTU over RS-485 with Modbus/TCP via
Ethernet a close second.
For RS-232, connect to the following: Pin 4 = Signal Ground, Pin 5 = RX, Pin 6 = TX.
For RS-485, connect to the following: Pin 4 = Signal Ground, Pin 7 = B, Pin 8 = A.
For Ethernet connect an Ethernet cable to the provided RJ45 jack.
For USB connect to the provided USB Type A jack.

12
Connecting Sensors:
All Sensors, SciCon for use with the DINCon Module, SciPres for use with the DINPres
Module and SciTemp for use with the DINTemp Module are disposable flow through
sensors that are purchased separately from Parker and come Pre-Calibrated.
The Sensors connect to a provided cable that has a watertight connector on the sensor
end and an 8 pin connector on the other end that plugs into a matching port on the
bottom of the Module. The DINCon has only one port, and uses only one SciCon
Sensor. The DINPres and DINTemp have 3 ports, can support up to 3 SciPres or
SciTemp Sensors, and they are referred to as P1 – P3 or T1 – T3 beginning with P1
and T1 at the rear, or the closest connector to the DIN rail.
Pin 1: +24VDC
Pin 2: Common
Pin 3: Not
Pin 4: Si
g
nal
Pin 5: RS-232 RX
Pin 6: RS-232 TX
Pin 7: RS-485
A
Pin 8: RS-485 B
USB
RJ45 Ethernet
DIN Rail

13
When powered up and connected the Sensor Status LEDs on the front of the Module
are colored as follows:
Green = Connected
Red = Disconnected
Yellow = Connected but not calibrated.
If the LED shows Yellow, it’s time to replace the affected Sensor with a new one.
Connecting the wrong type of Sensor to the module also results in a Yellow indication.
Sensor 1
Sensor 2
Sensor 3
DIN Rail locking clip

14
Operating Instructions:
Modbus Overview:
The Parker DIN modules communicate via the Modbus protocol. All data is transferred
using the Modbus holding registers. The default connection is RS-485 at 115,200 baud,
8 bits, even parity and one stop bit.
Note: If parity setting (register 109) is changed to “none” then two stop bits must be
used.
The default Modbus mode is RTU. The Default Modbus addresses (register 105) for the
various Modules are:
DINCon: 10
DINPres: 20
DINTemp: 30
Four physical layer interfaces are available for DIN Module communications:
RS232 – Modbus/RTU or Modbus/ASCII
RS485 – Modbus/RTU or Modbus/ASCII
Ethernet - Modbus/TCP
USB - Modbus/RTU or Modbus/ASCII
The active Modbus interface is selected by connecting to the modules built-in web
server. Connect using an Ethernet patch cable and a hub on your network, or directly to
the unit with an Ethernet crossover cable. The default IP addresses are 192.168.0.142
for the DINCon, 192.168.0.143 for the DINPres, and 192.168.0.144 for the DINTemp. It
may be necessary to create a new connection, or modify and existing one. Make any
changes required to configuration and click on “Submit” to save them to the module.
Any changes made via this interface require a power cycle of the module to take effect.

15
Modbus register definitions are listed below for each type – DINCon, DINPres, and
DINTemp.
For floating point values the DIN modules use the standard IEEE-754 format.
The Modbus address and communication parameters for a module can be changed by
writing to registers 104-109 as a block (at the same time).
The Modules contain a Real Time Clock that will be set to the current date and the end
users time zone prior to shipment from Parker. If re-setting the Real Time Clock is
needed, the data must also be written in one continuous Modbus multi-register write
operation to registers 130-137.
The DINPres Module has a selectable Data Refresh Rate, with the default of 13
milliseconds being raw data. (Register 143) If the default setting is not used, a
conditioned signal is provided.
The Sensors have individual ID numbers and calibration information stored in, and
printed on them. Values relating to the ID numbers can be found in registers 201-206
for Sensor 1, 241-246 for Sensor 2 and 281-286 for Sensor 3. (Note: The first letter of
this ID number, a “C”, “S” or “T”, is not in any of the registers.)
Units and Alarm Limits:
The Modules provide the ability to set the desired Units for the outputs, as well as
appropriate High and Low Alarm Limits. The alarms are absolute and not dependent
upon signal direction. (i.e. The signal does not have to be above the low alarm limit
value first to trip it.) The register list in section C below lists the available units for each
Module. All Alarm Limits default to 0.0 and are thereby initially disabled.
DINCon:
Conductivity Units: Default: µS Register 140
Temperature Units: Default: ⁰C Register 143
Conductivity Limits: Low: Registers 160-161
High: Registers 162-163
Temperature Limits: Low: Registers 164-165
High: Registers 166-167
DINPres:
Pressure Units: Default: psi Register 140
P1 Pressure Limits: Low: Registers 160-161
High: Registers 162-163
P2 Pressure Limits: Low: Registers 164-165
High: Registers 166-167
P3 Pressure Limits: Low: Registers 168-169
High: Registers 170-171

16
DINTemp:
Temperature Units: Default: ⁰C Register 140
T1 Temperature Limits: Low: Registers 160-161
High: Registers 162-163
T2 Temperature Limits: Low: Registers 164-165
High: Registers 166-167
T3 Temperature Limits: Low: Registers 168-169
High: Registers 170-171
Hardware Calibration:
The factory hardware calibration data is available as read only values and is only
performed on new modules with a special test fixture at the time of manufacture.
User Calibration of the Sensors:
If User Custom Calibration of a Sensor is desired, it can be accomplished by adjusting
the Cal Concentration, Cal Temperature or Cal Pressure values, and setting the proper
Start Bit in the appropriate User Cal Status Register.
Custom Calibration of SciPres and SciTemp Sensors is rare, and it is only
recommended on the SciCon Sensors if a much lower Cal Concentration is desired.
(12.88 mS is standard, and functions with satisfactory results.)
Factory Calibration of SciPres Sensors:
The DINPres reads and utilizes calibration data from SciPres Sensors that have been
calibrated to two points, 0 and 30 psi, or three points, 0, 54 and 6 psi depending upon the
type of stock purchased. It has also been equipped a Max Pressure Watchdog feature.
The Max Pressure Watchdog feature records in the sensor’s memory the maximum
pressure seen by the sensor while it is connected to the DINPres. The maximum
recommended pressure for the sensors is 60 psi. If this is exceeded, problems with
leakage and functionality can occur. This value is available in the appropriate register;
see the list in the next section.
Please Note: If the company Metrology Department tests the Sensors using a regulated
air source, care must be taken to avoid hi inrush pressure. Much like inrush current in
electronics, if the valve to the regulator is opened too fast, this can expose the Sensor to
higher pressures than the regulator is set for. This will be reflected in the Max Pressure
value, and may risk damage to the sensor if this is done near the 54 psi calibration point
or above. existing factory two or three point calibration. This can be reset or cleared if desired.

17
Modbus Register List:
DINCon Register List:
ADDRESS ACCESS FORMAT VALUE Default
90-99 R ASCII String DINCon Serial Number
100 R 16 bit Model Number 0
0 = DINCon
101-102 R IEEE Float Software Version
103 R/W 16 bit Reset Control
bit 0 = System Reset
bit 1 = Reset to Defaults
bit 2 = Alarm Reset
104-105 R/W 16 bit Modbus Address
104 must be set to 0xa55a (hex) 0xa55a
registers 104-109 must be written as a block
105 contains Modbus address 10
106 R/W 16 bit Modbus Mode 0
0 = RS485 RTU
1 = RS485 ASCII
2 = RS232 RTU
3 = RS232 ASCII
4 = USB RTU
5 = USB ASCII
6 = TCP
107 R/W 16 bit Modbus Baud Rate (115200 default) 8
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 28800
6 = 38400
7 = 57600
8 = 115200
108 R/W 16 bit Modbus Serial Word Length ( 7 or 8) 8
109 R/W 16 bit Modbus Serial Parity (Even, 1 Stop Bit default) 2
0 = none, 2 Stop Bits
1 = odd, 1 Stop Bit
2 = even, 1 Stop Bit
110 R/W 16 bit TCP Address P1 192
111 TCP Address P2 168

18
112 TCP Address P3 0
113 TCP Address P4 142
114 R/W 16 bit TCP Mask P1 255
115 TCP Mask P2 255
116 TCP Mask P3 255
117 TCP Mask P4 0
118 R/W 16 bit TCP Gateway P1 192
119 TCP Gateway P2 168
120 TCP Gateway P3 0
121 TCP Gateway P4 1
130 R/W 16 bit RTCC Control
bit0: Set Clock Values
Registers 130-137 must be written as a block
131 R/W 16 bit Day of Week (1-7)
132 R/W 16 bit Month
133 R/W 16 bit Day
134 R/W 16 bit Year
135 R/W 16 bit Hour (24)
136 R/W 16 bit Minute
137 R/W 16 bit Second
140 R/W 16 bit Conductivity Units 0
0 = uS
1 = mS
2 = ppm KCl
3 = ppm NaCl
4 = ppm 442
141-142 R/W IEEE Float
Cal Concentration (default 12.88mS)
(Only change for use with a Custom Calibration) 12.88
143 R/W 16 bit Temperature Units 0
0 = C
1 = F
144-145 R/W IEEE Float
Cal Temperature (default 25.0C)
(Only change for use with a Custom Calibration) 25.0
150 R 16 bit Conductivity Status
bit0 = disconnected
bit1 = uncalibrated
bit2 = low alarm
bit3 = high alarm
151-152 R IEEE Float Conductivity Value
153 R 16 bit Temperature Status
bit0 = disconnected
bit1 = uncalibrated
bit2 = low alarm

19
bit3 = high alarm
154-155 R IEEE Float Temperature Value
160-161 R/W IEEE Float Conductivity Alarm Limit - Low 0.0
162-163 R/W IEEE Float Conductivity Alarm Limit - High 0.0
164-165 R/W IEEE Float Temperature Alarm Limit - Low 0.0
166-167 R/W IEEE Float Temperature Alarm Limit - High 0.0
180 R/W IEEE Float Temperature Reference 25.0
182 R/W IEEE Float Temperature Coefficient 1.90
184 R/W IEEE Float Temperature Offset
186 R/W 16 bit Temperature Comp. Disabled if NZ 0.0
201 R/W 16 bit Sensor ID Type
0 = Luer
1 = 3/8" Barb
2 = 1/2" Barb
3 = 3/4" TC
4 = 1" TC
100 = Cal Fixture
202 R/W 16 bit Sensor ID Material
0 = Polypropylene
1 = Polysulfone
203 R/W 16 bit Sensor ID Month
204 R/W 16 bit Sensor ID Year
205 R/W 16 bit Sensor ID Lot
206 R/W 16 bit Sensor ID Unit Number
208 R/W IEEE Float Sensor Temperature Offset (TO)
210 R/W IEEE Float Sensor Cal Factor (CCF)
220 R/W 16 bit Sensor Custom Cal Status
bit 0 = Invalid
bit 2 = Start Cal
bit 6 = Cal in Progress
bit 7 = Write Cal Data
221 R/W IEEE Float Sensor Custom Temperature Offset (CTO)
223 R/W IEEE Float Sensor Custom Cal Factor (CCF)

20
DINPres Register List:
ADDRESS ACCESS FORMAT VALUE DEFAULT
90-99 R ASCII String DINPres Serial Number
100 R 16 bit Model Number 1
1 = DINPres
101-102 R IEEE Float Software Version
103 R/W 16 bit Reset Control
bit 0 = System Reset
bit 1 = Reset to Defaults
bit 2 = Alarm Reset
104-105 R/W 16 bit Modbus Address
104 must be set to 0xa55a 0xa55a
registers 104-109 must be written as a block
105 contains Modbus address 20
106 R/W 16 bit Modbus Mode 0
0 = RS485 RTU
1 = RS485 ASCII
2 = RS232 RTU
3 = RS232 ASCII
4 = USB RTU
5 = USB ASCII
6 = TCP
107 R/W 16 bit Modbus Baud Rate (115200 Default) 8
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 28800
6 = 38400
7 = 57600
8 = 115200
108 R/W 16 bit Modbus Serial Word Length (7 or 8) 8
109 R/W 16 bit Modbus Serial Parity (Even, 1 Stop Bit default) 2
0 = none, 2 Stop Bits
1 = odd, 1 Stop Bit
2 = even, 1 Stop Bit
110 R/W 16 bit TCP Address P1 192
111 TCP Address P2 168
112 TCP Address P3 0
113 TCP Address P4 143
