Parker F55 Series Installation and maintenance instructions

Introduction
Follow these instructions when installing, operating, or servicing
the product.
Application Limits
These products are intended for use in general purpose
compressed air systems only.
Maximum Recommended Pressure Drop:
kPa PSIG bar
Particulate Filter 70 10 0.7
With Plastic Bowl
kPa PSIG bar
Operating Pressure Maximum 1034 150 10.0
Operating Temperature Range 4°C to 49°C
(40°F to 120°F)
With Zinc Bowl
kPa PSIG bar
Operating Pressure Maximum 2068 300 21.0
Operating Temperature Range 4°C to 66.0°C
(40°F to 150°F)
With Zinc Bowl with Wrap Around Sight Gauge
kPa PSIG bar
Operating Pressure Maximum 1723 250 17.0
Operating Temperature Range 4°C to 49°C
(40°F to 120°F)
ANSI Symbols
Pneumatic Division
Richland, Michigan 49083
269-629-5000
Installation & Service Instructions
IS-F55
F55 Series Particulate Filter
ISSUED: September, 2005
Doc. #ISF55, ECN #050388, Rev. 1
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
• Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
• Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
• Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
• Medium must be moisture-free if ambient temperature is below
freezing.
• Service according to procedures listed in these instructions.
• Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
• After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
• Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS
CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY DAMAGE.
This document and other information from The Company, its subsidiaries and
authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any failure
and review the information concerning the product or systems in the current
product catalog. Due to the variety of operating conditions and applications
for these products or systems, the user, through its own analysis and testing,
is solely responsible for making the final selection of the products and systems
and assuring that all performance, safety and warning requirements of the
application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by The
Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR INCLUSION
IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE THESE PRODUCTS.
CONTACT YOUR LOCAL REPRESENTATIVE.
!
!
CAUTION
Polycarbonate bowls, being transparent and tough, are ideal for use with
Filters and Lubricators. They are suitable for use in normal industrial
environments, but should not be located in areas where they could be subjected
to direct sunlight, an impact blow, nor temperatures outside of the rated
range. As with most plastics, some chemicals can cause damage.
Polycarbonate bowls should not be exposed to chlorinated hydrocarbons,
ketones, esters and certain alcohols. They should not be used in air systems
where compressors are lubricated with fire-resistant fluids such as phosphate
ester and di-ester types.
Metal bowls are recommended where ambient and/or media conditions are
not compatible with polycarbonate bowls. Metal bowls resist the action of
most such solvents, but should not be used where strong acids or bases are
present or in salt laden atmospheres. Consult the factory for specific
recommendations where these conditions exist.
TO CLEAN POLYCARBONATE BOWLS USE MILD SOAP AND WATER
ONLY! DO NOT use cleansing agents such as acetone, benzene, carbon
tetrachloride, gasoline, toluene, etc., which are damaging to this plastic.
Bowl guards are recommended for added protection of polycarbonate bowls where
chemical attack may occur.
Filter
w/Manual Drain

F55 Series Particulate Filter IS-F55
Installation
Before installing, blow out pipe line to remove scale and other
foreign matter. This unit has DRYSEAL pipe threads; use pipe
compound or tape sparingly to male threads only. Install units in
pipe line so that flow is in direction indicated by arrows on faces
of body. Install as near as possible to equipment being serviced.
Maintenance
To maintain maximum filtering efficiency, and to avoid excessive
pressure drop, the filter must be kept clean. On standard filters,
open drain cock (turn clockwise) periodically and drain off any
bowl accumulation before it reaches level of lower baffle. Bowl
drainage is automatic in the “Auto Drain” model; however, manual
draining can also be done. A visible coating of dirt or condensate
on the filter element surface, or an excessive pressure drop, is
an indication that cleaning is necessary.
Bowl Seal
Body
Filter
Element
Bowl (Hand Tighten)
Bowl Guard
Deflector
(Vane Plate)
Element
Retainer
O-Ring
Manual Drain
(Finger Tighten)
Cleaning
To clean, it is not necessary to remove filter from the line.
Disassembly is simple and does not require tools. Use the
drawing on the reverse side of this sheet as a guide. Before
disassembly, shut off air supply and depressurize filter. Clean
all parts, except plastic bowl, with alcohol and blow out filter
body before reassembly. Wash filter element in alcohol and
blow out from the inside. Plastic bowls must be cleaned with
household soap only.
“Auto Drain” Operation
Auto Drain filters are equipped with a float actuated device
which automatically ejects liquid contaminants. If supplied in Kit
Form, Part No. RK602MD, the Auto Drain can be installed by
simply removing the bowl and then the bowl draincock. Insert
the Auto Drain in place of the removed draincock and reassemble
the unit in reverse order.
Kits Available
Product Bowl
Description Number Type
Bowl Kits*
Polyurethane BKF55B B
Zinc BKF55D D
Zinc with Wrap Around Sight Gauge BKF55W W
Element Kits
5 Micron EK55G B, D, W
40 Micron EK55J B, D, W
Repair Kit
(Deflector, Element Retainer) RKF55 B, D, W
Auto Drain Repair Kit
(Float Assembly, Body O-Ring, RK602MD B, D, W
Disc Assembly, Lever Pin,
Piston “V” Seal, Body “Y” Seal,
Top Retaining Ring,
Bottom Retaining Ring,
Filter Screen, Strainer)
* Bowl Kits include bowl gasket.
Lightly grease with provided lubricant.
Inspect for nicks, scratches, and surface imperfections.
If present, reduced service life is probable and future
replacement should be planned.
Clean with lint-free cloth.
Lever Pin
Disc Assembly
Float Assembl
y
Vee Seal
Strainer
Housing
Vee Seal
O-Ring
Body
