Parker TGA 102-118 User manual

TGA 102-118 16-50 Bar
TGH 104-118 100-420 Bar
TGS 214-232 16-100 Bar
TGE302-326 16-100 Bar
14/02/2022 Rev. 05
cod: 398H271902
Microfilter for Technical Gases
EN Operating Instructions

EN | Operating Instructions
TG-Filter 1
Index
1. General information 2
Warranty notes ......................................................................................................... 2
Notes on these operating instructions ..................................................................... 2
2. For your own safety 4
Intended use ............................................................................................................ 4
Hazard areas on the lter ......................................................................................... 5
Safety notes on specic operating phases .............................................................. 5
3. Assembly Drawings 7
4. Storing filters and filter elements 11
Storing lter elements and cartridges .................................................................... 11
5. Filter installation 12
Requirements and preparatory activities................................................................ 12
Installation .............................................................................................................. 12
6. Maintenance intervals and work 14
Maintenance tasks ................................................................................................. 15
7. Correcting faults 21
Procedure following a pressure blow ..................................................................... 21
Insufcient ltration capacity.................................................................................. 21
8. Technical information 22
Filter types.............................................................................................................. 22
Specication of elements....................................................................................... 26
9. Spare parts and options 27
Spare part ordering ................................................................................................ 27
Available options .................................................................................................... 27

EN | Operating Instructions General information
2 TG-Filter
1. General information
Warranty notes
In the following cases, the warranty shall be void:
◊ If corrosion and malfunctions occur due to aggressive substances in the gas and
in the environment.
◊ If the lter is not used in accordance with its intended use.
◊ If the lter is not serviced as specied in these operating instructions.
◊ If spare parts not matching the quality of genuine parts are used.
◊ If the lter is operated with other media than those indicated on the type label.
◊ If modications not approved by the manufacturer are made to the lter.
◊ When an ATEX-compliant lter was not properly integrated in the local equipo-
tential bonding system.
Notes on these operating instructions
The present operating instructions contain important information on the safe and
economic operation of lter series TGA1, TGH1, TGS2 and TGE3 for technical
gases.
Layout conventions
▶Work steps that you have to carry out one after the other are numbered.
◊ Lists are marked by a small box.
This symbol accompanies information relevant to explosion protection
as per ATEX (94/9/EEC).
Warning!
These safety notes warn against damage to machines or equipment
and help you to avoid such damage.
Danger!
These danger notes with a grey background warn against personal in-
jury and/or danger to life and limb; danger notes help you to avoid dan-
gerous or life-threatening situations for yourself and/or third parties.
Target group of these operating instructions
The present operating instructions address all persons who work with and on the
lter. We assume that these persons are specialized staff, e.g. tters or electricians
or appropriately instructed staff.
We assume the following:
◊ There are appropriate operating instructions for the application intended by the
operator.
◊ The staff has been instructed how to handle the used gas and is aware of the
involved risks and the general danger prevention measures.
◊ The staff have basic experience in handling pneumatic devices.

EN | Operating Instructions General information
TG-Filter 3
Notes on handling operating instructions
These operating instructions must be continuously available at the site where the
lter is used. We recommend to prepare a copy and to keep the same in a safe
and freely accessible place next to the lter. Keep the original document in a safe
place.

EN | Operating Instructions For your own safety
4 TG-Filter
2. For your own safety
Note:
When carrying out any work on the filters comply with all applicable
national accident prevention regulations!
Intended use
A lter of the series described here must be exclusively used for ltering the gas
noted on the lter’s type label. The technical data specied on the type plate must
be observed and complied with. Any operation at conditions other than those
indicated on the type label is regarded as not intended. Please contact the manu-
facturer if you plan to use the lter for gases other than those indicated on the type
label.
ATEX-compliant lters as per CE Ex II 2G marking must be operated in
zone 1 and zone 2 only.
ATEX-compliant lters are conductive. The operator must make sure con-
ductivity is maintained under all circumstances. He must also make sure
that the conductivity is not impaired by any attachment parts. The con-
ductivity must be tested and approved after each service assignment.
To ensure proper preliminary ltration, a strainer lter must be installed
upstream of any C, CF or CSF lter element. Operation of C, CF or CSF
lter elements is regarded as not intended if these conditions are not met.
Obvious improper use
Danger when explosive gases are ltered!
Filters not marked with an ATEX code on the type label must not be used
to lter explosive gases or for operation in an explosive environment.
Hazard caused by hot surfaces!
The media that flow through the filter can have a temperature of up
to 80 °C. Do not touch hot surfaces. Note the operating instructions
issued by the operator.
Impermissible maloperation
◊ ltering instable gases (e.g. acetylene).
◊ ltering liquids
◊ conveying solid, dustlike goods.

EN | Operating Instructions For your own safety
TG-Filter 5
Hazard areas on the filter
Symbol Hazard area
Warning against overpressure
The entire lter is pressurised during operation. Relieve all pressure before
starting any work on the lter.
Warning against explosive atmosphere/explosive gas
Only lters with the appropriate ATEX code must be used in a potentially
explosive environment and for ltering explosive gases. The lters must be
connected to the customer’s equipotential bonding system (local equipo-
tential bonding).
Beware of critical gases
The ltered gas could be hazardous. Keep appropriate notes on hazardous
substances at hand and heed them when working with critical gases.
Beware of hot surfaces
The ltered gas can be very hot and thus heat up the lter’s surfaces. Do
not touch hot surfaces. Wait until the surfaces have cooled down before
starting work on the lter
Safety notes on specific operating phases
Notes on critical gases
All explosive, ammable and poisonous gases of uid groups 1+2 as per pressure
equipment directive 2014/68/EU are referred to as critical gases.
◊ The release of a critical gas can pose a considerable risk to man and environ-
ment and must therefore be prevented by all means:
— The operator must implement appropriate safety precautions.
— Flush the respective pipe section and the lter with an inert gas prior to all
work that could result in critical gas being released. Then depressurise the lter
and carry out the work.
— .. Verify the absence of an explosive atmosphere (in line with the oper-
ator’s Directives); if necessary, cancel the EX zone rst. Start work only
after applying these measures.
◊ Make sure to heed the notes on hazardous substances for the used gas when
ltering a critical gas!
Notes on transportation and installation
◊ The transportation — in particular of larger build type lters — may be carried
out by specialist personnel only.
◊ Filters damaged during transportation must not be installed.
◊ Store lters, lter elements and cartridges in the unopened original packing in a
clean, dry place until they are used.

EN | Operating Instructions For your own safety
6 TG-Filter
Notes on filter operation
◊ Do not perform any unapproved conversions and modications on the lters.
Non-approved modications will endanger the operational safety and may cause
damage or personal injury.
For ATEX-compliant lters:
— Filters for explosive gases as per ATEX must be earthed. Establish an
appropriate local equipotential bonding. Test and document the conduc-
tivity.
— For installation under explosion group IIC:
Make sure when attaching decals or other markings that the area they
cover does not exceed a total contiguous area of 20 cm2!
— Make sure when painting that the permissible coat thickness does not
exceed the limits stipulated for the area of application.
— The control of electronic accessories for ATEX-compliant lters must
be intrinsically safe.
◊ Avoid sudden pressure uctuations on pressure build-up and de-pressurization.
If the pressure builds up or drops, too quickly, this may cause damage to the
lter.
◊ When using accessories with an external power supply, there is a hazard from
electrical voltage. Heed the notes given in the operating instructions for the ac-
cessories. Work on electrical components only when they are deenergised.
Notes on maintenance
◊ Always maintain the prescribed service intervals. If these are not complied with,
the lter may not function correctly and the manufacturer does not accept any
liability whatever for any possible consequences.
◊ Repairs and maintenance should be carried out by specialist personnel only.
Use only suitable tools when working in an explosive environment.
Notes on disassembly and disposal
◊ Flush the entire system, including the lter, with inert gas before disassembling
lters used for ltering critical gases. Depressurise and disassemble the lter
only then.
◊ The lter housing and elements might be contaminated by substances held back
in the lter. Filters used for the ltering of critical gases might contain explosive,
ammable or poisonous substances. Therefore always read the material safety
data sheet of the respective gas. Dispose of all components of the lter accord-
ing to the applicable statutory regulations.

EN | Operating Instructions Assembly Drawings
TG-Filter 7
3. Assembly Drawings
TGA 102–118, 16 bar and 25–50 bar
Item Description
1 Locking screw
2 Upper housing
3 Filter element O-ring
4 Housing O-ring
5 Threaded rod
6 Filter element
7 Lower housing
8 16 bar Manual drain HV01-TG
- 25, 50 bar: Manual drain EV05-TG
- 16 bar ATEX: Manual drain EV05-TG
Optional
ADifferential pressure gauge
HZD80/50RTGS with adapter block
BEarthing lug
(for ATEX-compliant lters)
—Condensate drain 11LD (16–25 bar)

EN | Operating Instructions Assembly Drawings
8 TG-Filter
TGH 104-118, 100–420 bar
Item Description
1 Locking screw
2 O-ring
3 Upper housing
4 Threaded rod
5 Filter element O-ring
6 Filter element
7 Housing O-ring
8 Lower housing
9 Double nipple
10 Manual drain EV05-TG
Optional
ADifferential pressure gauge
HZD80/50RTGS
BEarthing lug (only for AT-
EX-compliant lters)

EN | Operating Instructions Assembly Drawings
TG-Filter 9
TGS 214-232, 16 bar
Item Description
1 Upper housing
2 Flat seal, housing
3 Filter element
4Manual drain EV05-TG
through EV08-TG
5 Lower housing
Optional
A
Differential pressure gauge
HZD80/50RTGS with connec-
tion pipes
B
Earthing lug and connection
bore (only for ATEX-compliant
lters)
—Condensate drain 11LD (up to
TGS 218, 16–25 bar)

EN | Operating Instructions Assembly Drawings
10 TG-Filter
TGE 302-326, 16–100 bar
Item Description
1 Locking screw
2 Upper housing
3 Filter element
4 Housing O-ring
5 Lower housing
6 Lock ring
7 Double nipple
8 Manual drain EV05-TG
Optional
A
Differential pressure gauge
HZD80/50RTGS with con-
nection pipes
BEarthing lug (only for AT-
EX-compliant lters)
—Condensate drain 11LD
(16–25 bar)

EN | Operating Instructions Storing filters and filter elements
TG-Filter 11
4. Storing filters and filter elements
The storage space must meet the following conditions when the lter is to be
stored for a longer period:
◊ The lter must not be stored out of doors.
◊ The storage space must be dry.
◊ The storage space must be free of dust, or the lter must be packed dustproof.
◊ The storage space must feature an ambient temperature of at least +1 °C.
Caution:
When you want to store the filter for a longer period (e.g. several
months), you must check the threads for well running from time to time
to prevent corrosion
Storing filter elements and cartridges
▶Store lters and cartridges in the unopened original packing until they are used.
For storage space requirements, see the previous section.

EN | Operating Instructions Filter installation
12 TG-Filter
5. Filter installation
The lters are supplied in a ready to operate condition and can be installed directly
into the pipe system. To prevent transport damage, any ordered options come
separately packed. These accessories must be tted to the lter before commis-
sioning and in accordance with the respective instructions supplied.
Also heed the information provided in the ancillary documents coming
with the accessories when installing ATEX-compliant accessories!
The control of electronic accessories for ATEX-compliant lters must be
intrinsically safe.
Requirements and preparatory activities
◊ As a rule, the lters should always be used in the pipe system at the point with
the lowest temperature.
◊ Ensure that the pipeline system is free of any contamination and clean it before
installing the lter, if necessary.
◊ To ensure larger particles are safely trapped, a suitable strainer lter must be
installed upstream of any C, CF or CSF lter element.
◊ A safety device for maintaining the maximum working pressure and the permis-
sible gas temperature must be available. This safety device must prevent that
limit values are exceeded.
◊ A suitable pressure relief device and a condensate drain must be installed for
the lter. This safety device must prevent critical gas from escaping into the
atmosphere.
Danger due to release of a critical gas!
The release of a critical (explosive, flammable, poisonous) gas
from the network can constitute a considerable risk for man and
environment.
Therefore heed the following before working on filters for critical
gases
— flush the pipe section in question with inert gas
— have the notes on hazardous substances for the used gas ready
— take appropriate protection measures
— verify the absence of an explosive atmosphere
Installation
▶Before installing the lter:
— ush the pipe section in question with inert gas if necessary
— and depressurise the system.
▶Check lter for possible transport damage. Do not t a damaged lter.
▶If necessary, t a bracket or pipe support. Construct the support device such
that it can bear the weight of a lter completely lled with liquid.
▶Heed the ow direction when installing the lter in the pipeline! The gas must
ow through the lter in the direction of the arrow on the upper housing only.

EN | Operating Instructions Filter installation
TG-Filter 13
▶The lter must always be tted vertically.
▶Ensure that there is sufcient space below the lter so it can be easily disassem-
bled (see dimension D in the Technical Data).
▶For ATEX-compliant lters:
— Filters for explosive gases as per ATEX must be earthed. For
this purpose, the lters are tted with earthing lugs ex factory (see
also the overview drawings). Establish an appropriate local equi-
potential bonding. Test and document the conductivity.
— Make sure when attaching decals or other markings that the
area they cover does not exceed a total contiguous area of 20
cm2!
— Make sure when painting that the permissible coat thickness
does not exceed the limits stipulated for the area of application.
▶When installing differential pressure gauge HZDE80/...:
Establish electrical connection.
▶Re-pressurize pipe section and check for leaks.
When installing a filter with TKM or TKA cartridge
Beware of damage due to wrong flow direction!
Heed the flow direction when installing the filter in the pipeline!
The gas must flow through the filter in the direction of the arrow on
the upper housing only. The intended flow direction for a cartridge
is from bottom to top.
A reversed air flow through the cartridge can damage the car-
tridge.
▶Also heed the general information on lter installation in the previous “Installa-
tion” section.
▶Install a lter with cartridge so that the gas ow is from bottom to top.
Wear debris can exit from the cartridge, contaminate the downstream gas network
or degrade the gas quality.
▶Prevent any contamination of the downstream gas network by installing a suita-
ble particle lter.

EN | Operating Instructions Maintenance intervals and work
14 TG-Filter
6. Maintenance intervals and work
Hazard due to a sudden release of pressure!
Never remove any parts of the filter, or manipulate the same in any
way, for as long as the filter is still pressurised! A sudden escape
of pressure may cause serious injuries.
Depressurise the filter before carrying out any work on the filter.
Danger due to release of a critical gas!
The release of a critical (explosive, flammable, poisonous) gas
from the network can constitute a considerable risk for man and
environment.
Therefore heed the following before working on filters for critical
gases
— flush the pipe section in question with inert gas
— have the notes on hazardous substances for the used gas ready
— take appropriate protection measures
— verify the absence of an explosive atmosphere
Maintenance intervals
Maintenance
interval
Component/series Action 12345
Manual drain valve Drain condensate x
Entire lter Clean x
Earthing lugs Retighten x
TGA1, TGH1,TGE series: Housing Check well running of threads x
C, CF, CSF, HTNX Replace the lter element x
Housing Replace O-ring or at seal x
TGA1, TGH1 series:
TKA, TKM, CS, OX, SG cartridge
Renew cartridge
1 = Daily
2 = Weekly
3 = Every 6 months
4 = Every year (regardless of operating hours), at the latest with a
differential pressure of 0.35 bar (0.6–0.8 bar for a high pressure lter)
5 = Depending on the load or to be determined by measuring

EN | Operating Instructions Maintenance intervals and work
TG-Filter 15
Maintenance tasks
Preparations
Make the following preparations before performing maintenance on lters.
▶When critical gases are fed:
Flush the pipe section in question and the lter with inert gas.
▶Verify the absence of an explosive atmosphere (in line with the
operator’s Directives); if necessary, cancel the EX zone rst. Start
work only then.
▶All gases:
— Block gas supply to the lter.
— Depressurise the lter housing. Make sure the pressure has been positively
relieved.
— Allow lter to cool down
Start work only when these condition are met.
Drain condensate
Draining may be necessary several times a day, depending on the amount of con-
densate produced.
▶Take appropriate measures to prevent the gas from escaping into the atmos-
phere.
▶Drain the collected condensate at regular intervals and properly dispose of it.
Clean filter
ATEX-compliant filters
Dust that has collected on the lter can pose a potential risk. It is
therefore vital to regularly clean the lter. The cleaning interval depends
on the dust concentration in the ambient air. The higher the dust con-
centration, the more frequently must the lter be cleaned.
Beware of static charges!
Never use dry cloths to clean ATEX-compliant filters! A static
charge could build up due to the friction. This could represent an
ignition source.
Therefore: Make sure to clean the filter with a moist cloth only!
▶Clean the lter with a moist cloth at regular intervals to prevent the
formation of hazardous dust agglomerations.
▶Moisten the cloth with water only, wring out thoroughly, do not use
any detergents!
Filters not intended for an ATEX environment
▶Clean the lter with a moist cloth once a week.
▶Moisten the cloth with water only, wring out thoroughly, do not use any deter-
gents!

EN | Operating Instructions Maintenance intervals and work
16 TG-Filter
Retighten the earthing lugs on ATEX-compliant filters
The earthing lugs on ATEX-compliant lters can loosen over the time.
The conductivity may then be impaired.
▶Tighten the earthing lugs every 6 months.
Replacing filter element and housing O-ring
Replace the lter element every year, but at the latest with a differential pressure of
0.35 bar (0.6–0.8 bar for a high pressure lter). Also replace the housing O-ring.
Beware of damage due to inexpert handling!
Never use unsuitable tools to open and close the filter housings.
Never apply the tool to the thread area. The exerted force could
crush the thread; it would then be impossible to open the filter
again.
Use a suitable open-ended spanner to open and close the filter if
possible. Apply the open-ended spanner to the square at the hous-
ing bottom. Use a similarly suitable tool, e.g. a strap wrench if an
open-ended spanner cannot be used. Apply the tool clearly below
the thread.
TGA and TGH filters
▶Make the same preparations as described in sec-
tion on page 15.
▶Unscrew the lower housing and remove it.
▶Unscrew the lter element with the O-ring and
discard it.
▶Discard the housing O-ring.
▶Insert a new lter element with O-ring and
hand-tighten the lter element.
▶Insert a new housing O-ring.
▶Apply a thin coat of grease on the housing threads
before assembly if necessary. Use only TG 1
thread grease unless any other grease has been
agreed upon in the order!
▶Make sure during assembly that
— the O-rings are properly seated
— the grease does not come into contact with
O-rings and sealing surfaces.
▶Both housing parts have marking arrows.
▶Connect both housing parts again and hand-tight-
en them until the marking arrows match.
▶Close the manual drain valve again.
▶For ATEX-compliant lters:
Ensure conductivity, test and document it.

EN | Operating Instructions Maintenance intervals and work
TG-Filter 17
▶Check the housing for tightness.
TTGS filters
Depending on its size, a lter housing can accom-
modate up to 10 lter elements. The following
description applies to a single lter element per
housing, but equally to several ones as well.
▶Make the same preparations as described in sec-
tion on page 15.
▶Unscrew and remove the nuts on the lower hous-
ing.
▶Remove the lower housing or swing it aside.
▶Remove at seal.
▶Unscrew and remove the lter element.
▶Insert a new lter element with O-ring and
hand-tighten the lter element.
▶Insert new at seal.
▶Make sure the O-ring and the at seal are properly
seated.
▶Assemble upper and lower housing and tighten
the screws again.
▶Close the manual drain valve again.
▶For ATEX-compliant lters:
Ensure conductivity, test and document it.
▶Check the housing for tightness.

EN | Operating Instructions Maintenance intervals and work
18 TG-Filter
TGE filters
▶Make the same preparations as described in sec-
tion on page 15.
▶Open the lock ring with a hook wrench and take
the lower housing out of the cap.
▶Turn the lter element so that it is in release posi-
tion, using the click-lock device, and remove the
lter element.
▶Remove the housing O-ring and replace it with a
new one.
▶Insert new lter element and lock it in place.
▶Apply a thin coat of grease on the housing threads
before assembly if necessary. Use only TG 1fn
thread grease unless any other grease has been
agreed upon in the order!
▶Make sure during assembly that
— the O-rings are properly seated
— the grease does not come into contact with
O-rings and sealing surfaces.
▶Insert the lower housing into the cap again and
fasten it with the lock ring.
▶For ATEX-compliant lters:
Ensure conductivity, test and document it.
▶Check the housing for tightness.
