HX SERIES USER GUIDE
1. Series HX Compressed Air Filters
Parker’s HX-Series lters represent the most advanced coalescing lter technologies of today. Due to the breadth of
this series product line, they are very versatile and the types of applications they will work in is nearly limitless.
The lters are offered with ve basic types of lter media:
Fine Coalescers: Remove liquid and tiny solid contaminants from compressed air. Types 4C, 6C, XF
Bulk or Pre-coalescers: Remove large quantities of liquid contaminants / tiny solids. Types 7CP, 8C, 10C
Water Separator: Remove bulk liquids from compressed air. Type WS
Particulate: Remove larger solid contaminants from compressed air. Type 3P
Adsorber: Remove oil vapor from compressed air. Type A
The lters are supplied with either manual drains or auto drains as well as differential pressure gauges or plugged
gauge ports. Differential pressure gauges are standard on lters beginning with bowl size “C” and larger. They are
optional on “B and BH” sizes. See 2.1 below for part number breakdown.
All HX-Series lters are designed to minimize operating differential pressure which will result in low operating costs. A
number of innovations in both housing design and lter element design combine to result in low energy consumption
and operating costs. They are detailed in the HX-Series general brochure. See Section 9 for accessories.
1.1 Scope of Delivery
These lters are supplied in a ready to operate condition and can be installed directly into the compressed
air system. Some of the accessories mentioned later in this manual are supplied in separate packages and
should be installed according to their own instruction sheets.
2. Product Identification / Part Number Breakdown
2.1 HX Series Filter Assemblies
HX 6CN 3 C Y
Series Thread Conn. Bowl Size Element Type Accessories
HX N-NPT 1 = 1/4” A 4C N = No Accessories, Manual Drain
15 = 3/8” B 6C A = Auto Drain
2 = 1/2” B, BH 8C G = Diff. Pressure Gauge
3 = 3/4” BH, C 10C Y = Auto Drain and Diff. Pressure Gauge
4 = 1” C, D 7CP Note:
G and Y options not available
on HXN1A versions.
5 = 1-1/4” D, E XF
6 = 1-1/2” D, E WS
8 = 2” E, F, G 3P
10 = 2-1/2” H A
12 = 3” H, J
Examples: HXN1A-6CN, HXN2BH-WSA, HXN12J-XFX, HXN8G-6CG

5
HX SERIES USER GUIDE
3. Intended Use
The information on the product label must be observed. Non-observance of the data given there is regarded as
improper use. The lters are suitable for ltering compressed air and other non-ammable inert gases, such as
nitrogen.
3.1 Impermissible Applications
The ltration of liquids is not permitted. HX-Series lters must NEVER be used for ltration of explosive,
ammable, or noxious gases (including natural gas). Modications to HX-Series pressure vessels and
elements will endanger operational safety and may cause damage or personal injury and are not permitted.
4. Filter Installation and Maintenance Personnel
These operating instructions are intended for specialists charged with the installation, operation, and maintenance
of compressed air lters. Such persons must be trained in and have basic working knowledge of handling pressure
devises.
5. Safety Instructions
5.1 Hazard due to a sudden release of pressure!
Never remove any parts of the lter, or manipulate the lter in any way, as long as the lter is pressurized. A
sudden release of pressure may cause serious injuries. BE SURE TO DEPRESSURIZE THE FILTER before
carrying out any work on the lter. Verify that the housing has been depressurized using a gauge known to be
in good working order.
6C HX C K
Element Type Series Bowl Size Kit
4C HX A K = Kit
6C B
8C BH
10C C
7CP D
XF E
WS F
3P G
A H
J
2.2 HX Series Replacement Elements
Examples: 6CHXAK, WSHXBHK, XFHXJK, 6CHXGK

11
HX SERIES USER GUIDE
Part number Description
4CHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
6CHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
XFHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
7CPHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
8CHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
10CHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
3PHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
AHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
WSHXAK Replacement element kit for HXN1A-HXN12A housings (includes element, housing o-ring, and lube)
4CHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
6CHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
XFHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
7CPHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
8CHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
10CHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
3PHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
AHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
WSHXBK Replacement element kit for HXN1B-HXN12B housings (includes element, housing o-ring, and lube)
4CHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
6CHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
XFHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
7CPHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
8CHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
10CHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
3PHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
AHXBHK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
WSHXBBK Replacement element kit for HXN1BH-HXN12BH housings (includes element, housing o-ring, and lube)
4CHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
6CHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
XFHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
7CPHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
8CHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
10CHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
3PHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
AHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
WSHXCK Replacement element kit for HXN1C-HXN12C housings (includes element, housing o-ring, and lube)
4CHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
6CHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
XFHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
7CPHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
8CHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
10CHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
3PHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
AHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
WSHXDK Replacement element kit for HXN1D-HXN12D housings (includes element, housing o-ring, and lube)
