Parkside 331417-1907 User manual

4 Ah Battery PAPK 12 B1
IAN 331417_1907
AKKU 4 Ah
Bedienungsanleitung
4 Ah Battery
Operating instructions
ACCU 4 Ah
Gebruiksaanwijzing

GB/IE/NI Operating instructions Page 1
NL/BE Gebruiksaanwijzing Pagina 21
DE/AT/CH Bedienungsanleitung Seite 41
Before reading, unfold the page containing the illustrations
and familiarise yourself with all functions of the device.
Vouw vóór het lezen de pagina met de afbeeldingen
open en maak u vertrouwd met alle functies van het
apparaat.
Klappen Sie vor dem Lesen die Seite mit den Ab-
bildungen aus und machen Sie sich anschließend mit
allen Funktionen des Gerätes vertraut.

A

Charging
times
Charging
currents
2 Ah
Battery pack
PAPK 12 A1
2 Ah
Battery pack
PAPK 12 A2
4 Ah
Battery pack
PAPK 12 B1
max. 2.4 A
Charger
PLGK 12 A1
60 min
2.4 A
60 min
2.4 A
120 min
2.4 A
max. 4.5 A
Charger
PLGK 12 B2
60 min
2.4 A
45 min
3.5 A
60 min
4.5 A

12V max.
10,8V
All Parkside tools and the chargers PLGK 12 A1 /
B2 of the X12V Team series are compatible with
the PAPK 12 A1 / A2 / B1 battery pack.

PAPK 12 B1 GB│IE│NI │ 1 ■
Contents
Introduction........................2
Intended use............................. 2
Features ................................ 3
Package contents ......................... 3
Technical specifications .................... 3
General safety instructions ...........5
Extended safety guidelines.................. 7
Charging the battery pack
(see fig. A) .........................8
Maintenance and storage ............9
Kompernass Handels GmbH warranty 10
Service ...........................14
Importer .........................14
Disposal..........................15
Notes on the EC Declaration of
Conformity .......................17
Ordering a replacement battery......18
Telephone ordering ...................... 19

PAPK 12 B1■ 2 │ GB│IE│NI
Introduction
Congratulations on the purchase of your new
appliance. You have chosen a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all of the operating and
safety instructions. Use the product only as described
and for the range of applications specified. Please
also pass these operating instructions on to any
future owner.
Intended use
This rechargeable battery is suitable for:
This rechargeable battery is not intended for com-
mercial use. Any other usage of or modification to
the appliance is deemed to be improper and carries
a significant risk of accidents. The manufacturer
accepts no responsibility for damage attributable to
misuse.

PAPK 12 B1 GB│IE│NI │ 3 ■
Features
Battery pack
Release buttons
Red charge control LED
Green charge control LED
High-speed charger (not supplied)
Package contents
1 battery
1 set of operating instructions
Technical specifications
PAPK 12 B1
Type LITHIUM ION
Rated voltage 12 V (DC)
Capacity 4000 mAh/48 Wh
Cells 6
Use only X12V Team Series high-speed battery
chargers to charge the battery pack:
(not supplied)

PAPK 12 B1■ 4 │ GB│IE│NI
High-speed battery charger PLGK 12 B2
INPUT
Rated current 220–240 V ∼,
50–60 Hz
(AC)
Rated power consumption 75 W
OUTPUT
Rated voltage 12 V (DC)
Rated current 4500 mA
Charging time approx. 60 min
Fuse (internal) 3.15 A
T3.15A
Protection class II/ (double insulation)
ATTENTION!
► This charger can only charge the following
batteries: PAPK 12 A1/PAPK 12 A2,
PAPK 12 B1.
► A current list of battery compatibility can be
found at www.lidl.de/Akku.

PAPK 12 B1 GB│IE│NI │ 5 ■
General safety
instructions
WARNING!
■Read all safety warnings and all instructions.
Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for
future reference.
a) Charge a rechargeable battery unit using only
the charger recommended by the manufacturer.
Chargers are often designed for a particular type
of rechargeable battery unit. There is the danger
of fire if other types of rechargeable battery units
are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.

PAPK 12 B1■ 6 │ GB│IE│NI
c) When they are not being used, store recharge-
able battery units away from paperclips, coins,
keys, nails, screws or other small metal objects
that could cause the contacts to be bridged.
Short-circuiting the contacts of a rechargeable
battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens, avoid
contact with the fluid. If contact occurs, flush
the affected area with water. Seek additional
medical help if any of the fluid gets into your
eyes. Escaping battery fluid may cause skin
irritation or burns.
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries.
Protect the rechargeable battery from
heat; for example, from continuous
exposure to sunlight, fire, water and
moisture.
There is a risk of explosion.

PAPK 12 B1 GB│IE│NI │ 7 ■
Extended safety guidelines
■Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or pose
a risk of injury.
■Do not expose a battery to fire or excessively
high temperatures. Fire or temperatures in excess
of 130°C (265°F) can cause an explosion.
■Follow all instructions regarding charging and
never charge the battery or the cordless tool
outside the temperature range given in the
operating instructions.
Incorrect charging or charging outside of the
permissible temperature range can destroy the
battery and increase the risk of fire.

PAPK 12 B1■ 8 │ GB│IE│NI
Charging the battery pack
(see fig. A)
CAUTION!
► Always unplug the appliance before you remove
the battery pack from or connect the battery
pack to the charger.
NOTE
► Never charge the battery pack if the ambient
temperature is below 10°C or above 40°C.
If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The storage climate
should be cool and dry and the ambient tem-
perature should be between 0°C and 50°C.
♦ Insert the battery pack into the high-speed
charger .
♦ Insert the power plug into the socket. The charge
control LED lights up red.
♦ The green charge control LED indicates that
charging is complete and the battery pack is
ready for use.

PAPK 12 B1 GB│IE│NI │ 9 ■
♦ Push the battery pack into the appliance.
♦ Switch the high-speed charger off for at least
15 minutes between successive charging pro-
cesses. Also disconnect the power plug from the
mains power socket.
Maintenance and storage
■ If you do not intend to use the battery for an ex-
tended period, remove it from the appliance and
store it in a clean, dry place out of direct sunlight.
■ If a lithium-ion battery is to be stored for an
extended period, the charge level should be
checked regularly. The optimum charge level is
between 50% and 80%. The optimum storage
environment is cool and dry.
■Never try to repair damaged batteries.
Maintenance of batteries should only be carried
out by the manufacturer or an approved customer
service centre.

PAPK 12 B1■ 10 │ GB│IE│NI
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from the
date of purchase. If this product has any faults, you,
the buyer, have certain statutory rights. Your statutory
rights are not restricted in any way by the warranty
described below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will be
required as proof of purchase.
If any material or manufacturing fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you or
refund the purchase price (at our discretion). This war-
ranty service requires that you present the defective
appliance and the proof of purchase (receipt) within
the three-year warranty period, along with a brief
written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product
will either be repaired or replaced by us. The repair
or replacement of a product does not signify the
beginning of a new warranty period.

PAPK 12 B1 GB│IE│NI │ 11 ■
Warranty period and statutory claims for
defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accord-
ance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product parts
subject to normal wear and tear or to fragile parts
which could be considered as consumable parts
such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been
damaged, improperly used or improperly main-
tained. The directions in the operating instructions
for the product regarding proper use of the product
are to be strictly followed. Uses and actions that are
discouraged in the operating instructions or which
are warned against must be avoided.

PAPK 12 B1■ 12 │ GB│IE│NI
This product is intended solely for private use and
not for commercial purposes. The warranty shall be
deemed void in cases of misuse or improper han-
dling, use of force and modifications/repairs which
have not been carried out by one of our authorised
Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
overtime
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(e.g.IAN12345) available as proof of purchase.

PAPK 12 B1 GB│IE│NI │ 13 ■
■ You will find the item number on the type plate on
the product, an engraving on the product, on the
front page of the operating instructions (below
left) or on the sticker on the rear or bottom of the
product.
■ If functional or other defects occur, please contact
the service department listed either by tele-
phone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be provid-
ed to you. Ensure that you enclose the proof of
purchase (till receipt) and information about what
the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to
the Lidl service page (www.lidl-service.com) where
you can open your operating instructions by entering
the item number (IAN) 123456.

PAPK 12 B1■ 14 │ GB│IE│NI
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
IAN 331417_1907
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

PAPK 12 B1 GB│IE│NI │ 15 ■
Disposal
The packaging protects the appliance
from damage during transport. The
packaging materials have been selected
for their environmental friendliness and
disposal attributes, and are therefore recyclable.
Returning the packaging into the material cycle
conserves raw materials and reduces the amount of
waste generated. Dispose of packaging materials
that are no longer needed in accordance with
applicable local regulations.
Do not dispose of batteries in
your normal household waste!
Defective or worn-out rechargeable
batteries must be recycled according to
Directive 2006/66/EC. Take the battery pack and/
or appliance to a nearby collection facility.
Please consult your local authorities regarding suit-
able disposal of worn-out power tools/battery packs.
