Partner OT-310 User manual

OT-310
PARTNER-TECH Europe GmbH, Fasanenweg 25, 22145 Hamburg, Germany
Tel: [phone], Fax: [phone]
www.partner-tech.eu, E-Mail: [e-mail]
Version 1.0
Page 1of 617 September 2014
Modell: OT-310
FTP Folder Login
ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310

Page 2of 6
Index of contents
What kind of Touch is it?........................................................................................................3
Which maximum capacity of micro SD-card support OT-310?................................................3
How can I configure the scanner (BCR)?................................................................................3
What interface uses the MSR / IC-Card reader?.....................................................................3
How can I configure the MSR?...............................................................................................3
Which standard supports the IC-card reader?........................................................................4
Where can I find information about NFC?...............................................................................4
What RFID-standards are supported by NFC-module? ..........................................................4
Where can I get SDK’s for OT-310?.......................................................................................4
How can I update firmware of OT-310?..................................................................................4
Has the OT-310 Google Play Certification?............................................................................5
Which USB-Ethernet-adaptor supports OT-310?....................................................................5
How can I enter the “system recovery” menu?........................................................................5
Do I require any drivers for Windows XP / POSReady 2009, if I want to connect OT-310 via
USB-cable at my PC as Media device (MTP)? .......................................................................5
How can I set the OT-310 back to factory default?.................................................................6
Where can I find driver for fastboot or debugging mode of OT-310?.......................................6

Page 3of 6
Where can I find the manuals?
You can download all manuals under the following links.
User Manual: ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/Manual/OT-310_UserManual-
0808.pdf
What kind of Touch is it?
Touch-Panel type: Capacitive (Multi-touch, 5 fingers)
Which maximum capacity of micro SD-card support OT-310?
Maximum size: 32GB
NOTE: Bigger sized micro SD-cards may work, but they are not tested.
How can I configure the scanner (BCR)?
There is a configuration utility available, described at the manual, page 53:
ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/Manual/OT-310_UserManual-
0808.pdf#page=57
What interface uses the MSR / IC-Card reader?
Interface: USB
How can I configure the MSR?
There is a configuration utility available, described at the manual, page 55:
ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/Manual/OT-310_UserManual-
0808.pdf#page=59

Page 4of 6
Which standard supports the IC-card reader?
- ISO 7816 Class A, B & C
- T=0 T=1 protocol
- I2C Memory Card
Where can I find information about NFC?
You can get information’s about the NFC-module from this data-sheet:
ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/Specification/OT-3xx_NFC_specs.pdf
What RFID-standards are supported by NFC-module?
It supports:
- ISO 14443-A
oMIFARE Classic
oMIFARE Ultralight
oMIFARE DESFire (read only)
- ISO 14443-B
- ISO 15693
- FeliCa open Tag
Where can I get SDK’s for OT-310?
Scanner / BCR: ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/SDK/OT-
310_BCR_SDK_V2.5_for_R06Cv6.zip
IC-Card reader: ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/SDK/OT-
310_ICC_SDK_v1.0_for_R06Cv6.zip
MSR: ftp://ftp.partner-tech.eu/Mobile/OT-3xx/OT-310/SDK/OT-
310_MSR_SDK_v1.0_for_R06Cv6.zip
NFC: http://developer.android.com/intl/zh-
tw/guide/topics/connectivity/nfc/index.html
How can I update firmware of OT-310?
Please follow the instructions of this document:
Information will be follow soon, if a new OS is available.

Page 5of 6
Has the OT-310 Google Play Certification?
Yes, the OT-310 does. Please check at Google webpage under brand name “Partner”:
https://support.google.com/googleplay/android-developer/answer/1727131?hl=en#P
Which USB-Ethernet-adaptor supports OT-310?
Yes, OT-310 is supporting USB-Ethernet-adaptors, which can be plugged at the OT-310
itself or at the USB communication cradle. It’s support following chipsets:
ASIX:
- AX8817x
- AX88178
- AX88178A
- AX88772
RealTek:
- RTL8150
How can I enter the “system recovery” menu?
Turn off the OT-310, press and hold the volume key - and press the power button.
The OT-310 will vibrate, release the volume key - and you will enter into this menu.
Do I require any drivers for Windows XP / POSReady 2009, if I want to connect
OT-310 via USB-cable at my PC as Media device (MTP)?
There is no specific driver required, but your Windows XP / POSReady 2009 OS has to fulfil
the following requirements:
- Service Pack 3
- Windows Media Player 11
Otherwise the MTP-driver won’t be installed.
Windows 7 does already have the driver on board.

Page 6of 6
How can I set the OT-310 back to factory default?
There are two ways available:
1. The Android function, which is implemented at the OS:
Got to Menu ==> Settings ==> Backup & reset ==> Factory data reset ==> check
- “Erase enterprise folder”
- “Erase SD card”
==> Reset phone.
If you don’t check both options, it can happen that some data won’t be erased at the
OT-310.
After this process is finished, the OT-310 will reboot automatically.
2. The “system recovery” menu:
Enter the system recovery menu like described above, navigate to “wipe data/factory
reset” and confirm with the power button.
After this process is finished, the OT-310 will reboot automatically.
Where can I find driver for fastboot or debugging mode of OT-310?
Start OT-310 and connect it via USB cable at your Windows PC. Set “USB Mass Storage
device (UMS)”as USB mode at OT-310. After the successfully installation of the drivers you
will find a new CD-drive at “My Computer”. If you access it, you will find the driver for both
modes.
Alternately can you download it from our ftp-server here: ftp://ftp.partner-tech.eu/Mobile/OT-
3xx/OT-310/Driver/OT-310_driver_fastboot_Debugging-mode_Win7_Win8.zip
