PEERLESS PRS-EXA Guide

1 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
R
This product is intended for use with UL
Listed products and must be installed by a
qualified professional installer.
Installation and Assembly:
Projector Ceiling/Wall Mount
Installed to
Ceiling
Installed to Wall
(PRS-EXC models are not
wall mountable due to its
extensive reach)
3215 W. North Ave. • Melrose Park, IL 60160 • [phone] or [phone] • Fax: [phone] • www.peerlessmounts.com
Maximum UL Load Capacity:
25 lb (11.3 kg)
Models:PRS-EXA, PRS-EXA-S, PRS-EXA-W
PRS-EXB, PRS-EXB-S, PRS-EXB-W
PRS-EXC, PRS-EXC-S, PRS-EXC-W
Features:
• Continuouschanneldesignforuninterrupteddroplengthorwallextensionadjustments
• Safety catch designed into extension to ensure user and equipment safety
• Internalcablemanagementwithinchannelsforclean,clutter-freeappearance
• IncludesPRS Series projector mount for precise image alignment

2 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Note: Read entire instruction sheet before you start installation and assembly.
Tools Needed for Assembly
•studfinder ("edge to edge" stud finder is recommended)
•drill
•phillipsscrewdriver
•1/4" bit for concrete and cinder block wall
• Donotbegin to install your Peerless product until you have read and understood the instructions and warnings
containedinthisInstallation Sheet. If you have any questions regarding any of the instructions or warnings, please
callPeerlesscustomercareat1-800-865-2112.
• This product should only be installed by someone of good mechanical aptitude, has experience with basic building
construction, and fully understands these instructions.
• Makesure that the supporting surface will safely support thecombined load of the equipment and all attached hard-
wareandcomponents.
• Neverexceed the Maximum ULLoadCapacity.See page1.
• If mounting to wood ceiling/wall studs, make sure that mounting screws are anchored into the center of the studs. Use
ofan "edge to edge" stud finder is highly recommended.
• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
• Tightenscrewsfirmly, butdonotovertighten.Overtighteningcandamagetheitems,greatlyreducingtheirholding
power.
• Thisproductisintendedfor indooruseonly. Use ofthisproductoutdoorscouldleadto product failureandpersonalinjury.
• Thisproductwasdesignedandintendedtobemountedtothefollowingsupportingsurfacescheckedbelowwiththe
hardware included in this product as specified in the installation sheet.To mount this product to an alternative support-
ing surface, contact Peerless customer care at 1 800 865-2112.
• This product was designed to be installed on the following ceiling/wall construction only;
CEILING/WALLCONSTRUCTION ADDITIONALHARDWAREREQUIRED
xWoodStud None
xWoodJoist None
xSolidConcrete None
xCinderBlock None
MetalStud Do not attach except with Peerless accessory kit for metal studs;
Contact Customer Service for Peerless accessory kit for metal studs.
Brick ContactCustomerService
Otherorunsure? ContactCustomer Service
WARNING
•openendwrench
•5/32" bit for wood stud or joist
•level
•8mmopen end wrench
Table of Contents
Parts List...........................................................................................................................................................................3-4
InstallingOuterChannel toCeilingPlate...............................................................................................................................5
Installation to Wood Joist Ceiling or Wood Stud Wall ...........................................................................................................6
InstallationtoSolidConcreteCeilingorConcrete/CinderBlockWalls ..................................................................................7
InstallingInnerChannelandRoutingCables .........................................................................................................................8
InstallingProjectorMount ................................................................................................................................................9-10
Attaching Adapter Plate to Projector.............................................................................................................................. 10-11
ProjectorAlignment ............................................................................................................................................................12
Adjusting Mount Extension................................................................................................................................................. 13
InstallingCableCovers........................................................................................................................................................13

3 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
extendable outer channel (B) inner channel (C) cable cover (Q)
Model# length part# part# part#
PRS-EXA 8.69" - 12.79" 055-1779 055-1778 055-1809-2
PRS-EXA-S 8.69" - 12.79" 055-4779 055-4778 055-4809-2
PRS-EXA-W 8.69" - 12.79" 055-2779 055-2778 055-2809-2
PRS-EXB 12.69" - 20.69" 055-1776 055-1775 055-1809-1
PRS-EXB-S 12.69" - 20.69" 055-4776 055-4775 055-4809-1
PRS-EXB-W 12.69" - 20.69" 055-2776 055-2775 055-2809-1
PRS-EXC 19.14" - 32.9" 055-1770 055-1769 055-1809
PRS-EXC-S 19.14" - 32.9" 055-4770 055-4769 055-4809
PRS-EXC-W 19.14" - 32.9" 055-2770 055-2769 055-2809
OUTER CHANNEL, INNER CHANNEL AND CABLE COVER
PART NUMBER CHART
Parts List
PRS-EXA
PRS-EXB
PRS-EXA-S
PRS-EXB-S
PRS-EXA-W
PRS-EXB-W PRS-EXC PRS-EXC-S PRS-EXC-W
Description Qty. Part
#
Part
#
Part
#
Part
#
Part
#
Part
#
A
projector mount assembly 1 055-0604 055-0605 055-0606 055-0604 055-0605 055-0606
Badapter plate 1 055-0619 055-0620 055-0621 055-0619 055-0620 055-0621
C#14 x 2.5 phillips hex head wood screw 2 5S1-015-C03 5S1-015-C04 5S1-015-C04 5S1-015-C03 5S1-015-C04 5S1-015-C04
Dconcrete anchor 2 590-0097 590-0097 590-0097 590-0097 590-0097 590-0097
E#10-32 x 1/4" socket pin screw 1 520-1196 520-2196 520-2196 520-1196 520-2196 520-2196
F1/4" flat washer 6 540-1078 540-1078 540-1078 540-1078 540-1078 540-1078
GM3 x 8 mm socket pin serrated washer head screw 4 510-1004 510-2004 510-2004 510-1004 510-2004 510-2004
HM4 x 10 mm socket pin serrated washer head screw 4 510-1060 510-2060 510-2060 510-1060 510-2060 510-2060
IM5 x 10 mm socket pin serrated washer head screw 4 510-1126 510-2063 510-2063 510-1126 510-2063 510-2063
JM6 x 10 mm socket pin serrated washer head screw 4 510-1066 510-2066 510-2066 510-1066 510-2066 510-2066
K
#6 flat washer 4 540-1025 540-2025 540-2025 540-1025 540-2025 540-2025
L4 mm security t-wrench 1 560-1718 560-1718 560-1718 560-1718 560-1718 560-1718
M2 mm security allen wrench 1 560-1097 560-1097 560-1097 560-1097 560-1097 560-1097
A
A
ceiling plate 1 055-1773 055-4773 055-2773 055-1773 055-4773 055-2773
BB outer channel 1 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
CC inner channel 1 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART
DD clamp plate 1 055-1771 055-4771 055-2771 055-1771 055-4771 055-2771
EE vertical mounting plate 1 055-1796 055-4796 055-2796 055-1796 055-4796 055-2796
FF horizontal mounting plate 1 055-1787 055-4787 055-2787 N/A N/A N/A
GG M5 x 16 mm socket pin screw 2 520-1161 520-2161 520-2161 520-1161 520-2161 520-2161
HH M6 x 12 mm socket pin screw 2 520-1050 520-2050 520-2050 520-1050 520-2050 520-2050
II M6 x 10 mm socket pin screw 4 520-1066 520-2066 520-2066 520-1066 520-2066 520-2066
JJ M5 x 10 mm socket pin screw 4 520-1063 520-2063 520-2063 520-1063 520-2063 520-2063
K
K
serrated locknut 2 530-1027 530-2042 530-2042 530-1027 530-2042 530-2042
LL cable cover 2 SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART SEE CHART

4 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
I
Note: Actual parts may appear slightly different than illustrated.
C
D
EFJ
K
G H
AA BB
CC DD
EE FF
GG HH II JJ KK
LL
A B
M
L

5 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Install Outer Channel to Ceiling Plate
Attachouter channel (BB) toceiling plate (AA)using
four M6 x 10 mm socket pin screws (II) as shown.
Tighten screws with 4 mm security wrench (L).
AA
BB
II
1

6 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Installation to Wood Joist Ceilings or Wood Stud Walls
NOTE: Wall installation with models PRS-EXC, PRS-EXC-S and PRS-EXC-W is not available.
Use a stud finder to locate the edges of the stud or joist. Use of an edge-to-edge stud finder is highly
recommended. Based on its edges, draw a vertical line down the stud's or joist’s center. Place ceiling/wall plate
(AA) on wall or ceiling as a template, making sure that the two mounting slots are on the centerline.
For ceiling installation: Opening on outer channel (BB) indicates front of mount. Use the correct mounting slots
on the ceiling/wall plate depending on ceiling joist orientation as shown in figure 2.1 and figure 2.2. Mounting slots
on ceiling plate allow for 45° (±22.5) of rotation before securing to joist.
For wall installation: Opening on outer channel (BB) indicates top of mount.
Mark the center of the two mounting holes. Drill two 5/32" (4 mm) dia. holes 2-1/2" (65 mm) deep. Secure
ceiling/wall plate (AA) to wood stud or joist using two #14 x 2-1/2" wood screws (C) and two 1/4" washers (F)
as shown.
Skip to step 3
• Installermustverifythatthesupportingsurfacewillsafelysupportthecombinedloadoftheequipmentandallattached
hardwareandcomponents.
• Tightenwoodscrewssothatceiling/wallplateisfirmlyattached,butdonotovertighten.Overtighteningcandamage
thescrews,greatlyreducingtheirholdingpower.
• Never tighten in excess of 80 in. • lb (9 N.M.).
• Make sure that mounting screws are anchored into the center of the stud or joist. The use of an "edge to edge" stud
finderishighlyrecommended.
• Hardwareprovidedisforattachmentofmountthroughstandardthicknessdrywallorplasterintowoodstudsorjoists.
Installersareresponsibletoprovidehardware for other types ofmountingsituations (notULapproved).
WARNING
2
AA
C
BB
OPENINGONOUTER
CHANNEL(BB)INDICATES
TOPOFMOUNT
fig. 2.3
WOOD
JOIST
fig. 2.2
C
AA
OPENINGONOUTERCHANNEL(BB)
INDICATESFRONTOFMOUNT
C
AA
BB
BB
WOOD
STUD
fig. 2.1
CEILINGINSTALLATION WALLINSTALLATION
(EXCEPT FOR PRS-EXC MODELS)
MOUNTING
SLOTSALLOW
FORROTATION
BEFORE
SECURINGTO
JOIST
FF
F

7 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Installation to Concrete Ceilings or Concrete/Cinder Block Walls
• Always attach concrete expansion anchors directly to
load-bearingconcrete.
• Neverattachconcreteexpansionanchorstoconcrete
coveredwithplaster, drywall,orotherfinishingmate-
rial.Ifmountingtoconcretesurfacescoveredwitha
finishingsurfaceisunavoidable,the finishing surface
must be counterbored asshownbelow. Besure
concreteanchorsdonotpullawayfromconcrete
whentighteningscrews.Ifplaster/drywallisthicker
than 5/8" (16 mm), custom fasteners must be sup-
pliedbyinstaller(notULapproved).
WARNING
NOTE: Wall installation with models PRS-EXC,
PRS-EXC-S and PRS-EXC-W is not available.
Place ceiling/wall plate (AA) on ceiling or wall as a
template. Note: Place ceiling/wall plate according to
positionofopeninginouter channel (BB)as shown in
figure 2.4. or figure 2.5. Drill two 1/4" (6 mm) dia. holes
to a minimum depth of 2.5" (64 mm). Attach ceiling/
wallplate(AA)usingtwoconcreteanchors(D),two
#14 x 2.5" wood screws (C) and two 1/4" washers (F)
asshowninfigure2.6.Tightenwoodscrews(C)until
ceiling/wallplate(AA) is firmly attached.
CUTAWAYVIEW
INCORRECT
concrete
plaster/
drywall
CORRECT
concrete
plaster/
drywall
• Tighten wood screws firmly,butdonotovertighten.
Overtighteningcandamagethescrews,greatly
reducingtheirholdingpower.
• Never tighten in excess of 80 in • lb (9 N.M.).
WARNING
2
AA
AA
concrete
surface
1
3
2
D
Drill holes and insert anchors (D).
Place plate (AA) over anchors (D) and secure with washers
(F) and screws (C).
Tighten all fasteners.
AA
D
C
• When installing Peerless wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual concrete
thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid
part of the block, generally 1" minimum from the side of the block. Cinder block must meetASTM C-90 specifications.
It is suggested that a standard electric drill on slow setting is used to drill the hole instead of a hammer drill to avoid
breakingoutthebackoftheholewhenenteringavoidorcavity.
• Concrete must be 2000 psi density minimum. Lighter density concrete may not hold concrete anchor.
• Installermustverifythatthesupportingsurfacewillsafelysupportthecombinedloadoftheequipmentandallattached
hardwareandcomponents.
WARNING
D
BB AA
C
C
BB
AA
D
OPENINGONOUTER
CHANNEL(BB)INDICATES
FRONTOFMOUNT
CONCRETE
CEILING
CONCRETE
WALL
CINDER
BLOCK
WALL
OPENINGONOUTER
CHANNEL(BB)
INDICATESTOPOF
MOUNT
fig. 2.4
fig. 2.5
fig.
2.6
CEILING
INSTALLATION
WALL INSTALLATION
(EXCEPTFOR
PRS-EXC MODELS)
F
F
F

8 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Installing Inner Channel and Routing Cables
3Note: Becertainholesoninnerchannel(CC)faceinthesamedirectionofopeningonouterchannel(BB).
Note:Cablesmustberemovedfromprojectorbeforeroutingthroughchannels.Ifcablesarenotremovablefrom
projector,routingthroughchannelsisnotan option.
Guideprojectorcablesintoopeningsinchannelstheninsertinnerchannel(CC) into outer channel (BB)asshownin
figure3.1or3.3.
Position inner channel (CC) to the desired extended position and secure using two M6 x 12 mm socket pin
screws (HH) through clampplate(DD) and into inner channel (CC)asshowninfigure3.2or3.4.
CEILINGINSTALLATION WALL INSTALLATION
(EXCEPT FOR PRS-EXC MODELS)
OPENING
HOLES
BB
CC
fig. 3.4
fig. 3.3
HH
DD
BB
CC
OPENING
BB
CC
HOLES
GUIDE
CABLESIN
CHANNELS
fig. 3.1
fig. 3.2
HHDD
BB
CC

9 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Installing Projector Mount
4Installing PRS projector mount with ceiling installation: Attach vertical mounting plate (EE) to PRS projector
mount (A) using two M5 x 16 mm socket pin screws (GG), two flat washers (F) and two locknuts (KK) as shown in
figure4.1.
Installing PRS projector mount with wall installation: Position PRS projector mount (A) to the orientation
shown in figure 4.2 and attach to horizontal mounting plate (FF) using two M5 x 16 mm socket pin screws (GG),
twoflat washers (F) and two locknuts (KK).
Note: Placing screws (GG) and washers (F) through slots on inside of PRS projector mount and attaching
horizontal mounting plate from the bottom can make installation easier as shown in figure 4.3.
CEILINGINSTALLATION KK
FGG
EE
HOLEINDICATES
FRONTOFMOUNT
WALLINSTALLATION
(EXCEPT FOR EXC MODELS)
HOLEINDICATES
FRONTOFMOUNT
KK
F
GG
FF
fig. 4.1 fig. 4.2
fig. 4.3 PLACESCREWS(GG)AND
WASHERS(F)FIRST
GG
F
AA
A
5Ceilinginstallation:Insertverticalmountingplate(EE)intoinnerchannel(CC)withprojectormount(A)
inthecorrectorientationshowninfigure5.1.Secureverticalmountingplatetoinnerchannelusingfour
socket pin screws (JJ) as shown in figure 5.2.
fig. 5.1
CC
EE
HOLE
INDICATES
FRONTOF
MOUNT
A
fig. 5.2
JJ
EE
CC

10 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Wall installation: Insert horizontal mounting plate (FF) into inner channel (CC) as shown in figure 5.3. Secure
horizontal mounting plate to inner channel using four socket pin screws (JJ) as shown in figure 5.4.
5
fig. 5.3
FF
CC
HOLEINDICATES
FRONTOFMOUNT
fig. 5.4
FF
JJ CC
GenericProjector
Placeprojectorupsidedown.Locateadapterplate(B)withnotchfacingforwardasclosetoprojectorcenterof
gravity as possible without covering any mounting holes. Loosen channels with 4 mm security allen wrench (I),
and if there are only three mounting holes remove fourth channel. Using one channel for each mounting
hole, position feet ofchannels over mounting holes as shown below. Important:Ifprojectordoesnothaveatleast
three mounting holes, do not use this adapter plate.
Note:Someprojectorshavefeetwhichcanberemovedandthecorrespondingthreaded insert can be used for a
mountinghole.
Note:Oncechannelsareinpositionretightenfasteners.
*Notchindicatesfrontofprojector.
Note:Theprojectoryouareinstalling may differ in appearance fromthesampleillustratedbelow.
*
Mounting
hole
6
Channel
FootofChannel
Attaching Adapter Plate to Projector
B

11 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
Attach adapter plate (B) to projector using one screw (G, H, I, or J) for each channel as shown below. Tighten all
screws, while keeping the center of gravity. Be sure that adapter plate (B) is straight.Adjust the feet of the
channels to keep the adapter plate level. Tighten all screws with 4 mm security allen wrench (L) while keeping the
center of gravity. If M3 x 8 mm screws (G) are used, tighten using 2 mm security allen wrench (M).
Note: Projectors will require different size screws for mounting. Use a combination of screws (G, H, I, or J) and
foot adjustment that will result in channels of adapter plate (B) fitting tightly against projector. Important: In order
to properly engage the threads in the mounting holes, the screw must be turned at least 3 full turns.
Note: Ifusingscrew(G),placewasher(K)betweenscrew(G)andfootofchannel.
• It is the responsibility of the installer to ensure that the
projectorisproperlyventilated.Feetofchannelsare
usedto raise the mount off the projector surface.
CAUTION
G, H, I,
or J
7
B
FOOTOFCHANNEL
Slide connection block with projector into projector mount assembly (A) as shown. Push in and tighten captive screw
to secure projector to projector mount assembly (A).
CONNECTIONBLOCK
A
CAPTIVESCREW
FRONTOFMOUNT
• Always use an assistant or mechanical lifting equipment to safely lift and position the projector.
WARNING
8
FRONTOF
MOUNT
Attaching Adapter Plate to Projector
EE or FF

12 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
To adjust yaw (swivel): Loosen screw on projector mount assembly (A) indicated below until projector mount
can be rotated. Rotate mount to desired position and retighten screw.
To adjust pitch (forward and backward tilt): Using 4 mm security t-wrench (L) (security adjustment models)
oraphillipsscrewdriver (non-securityadjustmentmodels),loosentwoscrewsforpitchadjustmentonprojector
mount assembly (A) indicated below. Tilt mount to desired position and retighten screws.
To adjust roll (side to side tilt): Using 4 mm security t-wrench (L) (security adjustment models) or a phillips
screwdriver(non-securityadjustmentmodels),loosentwoscrewsforrolladjustmentonprojectormount assem-
bly (A) indicated below. Tilt mount to desired position and retighten screws.
Projector Alignment
20°(±10°)SWIVEL
SWIVEL ADJUSTMENT
TOP VIEW
10
MOUNTASSEMBLY
NOTSHOWNFOR
CLARITY
IMPORTANT: For security installations, insert one #10-32 x 1/4" socket pin screw (E) through projector mount
assembly (A) and into connection block as shown. Tighten screw with 4mm security t-wrench (L).
9
CONNECTIONBLOCK
A
E
A
SCREWSFORPITCH
ADJUSTMENT
SCREWFORSWIVELSTOP
SCREWSFORROLL
ADJUSTMENT
• Do not loosen adjustment screws to the point they become disengaged from the mount. Weight of the projector should
besupportedincaseofaccidentaldisengagement.
WARNING

13 of 13 ISSUED:04-24-08 SHEET#:055-9256-1
Visit the Peerless Web Site at www.peerlessmounts.com For customer care call 1-800-865-2112 or 708-865-8870.
11
CEILINGINSTALLATION WALL INSTALLATION
(EXCEPT FOR EXC MODELS)
DD DD
Adjusting Mount Extension
• On ceiling installations, clamp plate adjustment screws support weight of projector when fully tightened. Weight of the
projector will need to be supported if clamp plate screws are loosened.
WARNING
While supporting the weight of the projector, loosen clamp plate screws half a turn and position projector to the
desired extended position. Retighten clamp plate screws securely.
CLAMPPLATE
SCREWS
CLAMPPLATE
SCREWS
Cutcablecovers (LL)to the length of inner channel (CC) and outer channel (BB)openings,leavingspaceforcablesif
routedthrough channels. Snap cable covers (LL)intoopeningsasshown.
12
CABLES
CUT TO
LENGTH OF
OPENING
LL
CUT TO
LENGTH OF
OPENING
LL
CABLES
CEILINGINSTALLATION WALL INSTALLATION
(EXCEPT FOR EXC MODELS)
CUT TO
LENGTH OF
OPENING
LL
CUT TO
LENGTH OF
OPENING
LL BB
CC
BB
CC
Install Cable Covers
©2008,PeerlessIndustries,Inc.Allrightsreserved.
Allotherbrandandproductnamesaretrademarksorregisteredtrademarksoftheirrespectiveowners.
