Pentair Fleck 5800 XTR User guide

FLECK
5800 XTR
INSTALLER
MANUAL
WATER PURIFICATION

Installer Manual Fleck 5800 - XTR - Table of content
2 / 122 Ref. MKT-IM-006 / B - 16.01.2018
Table of content
1. Generalities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1. Scope of the documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2. Release management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3. Manufacturer identifier, product . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4. Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5. Abbreviations used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6. Norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.1. Applicable norms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.6.2. Available certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.7. Procedure for technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.8. Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.9. Limitation of liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1. Safety pictograms definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2. Serial label location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3. Hazards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.3.1. Personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.3.2. Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4. Hygiene and sanitization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4.1. Sanitary issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.4.2. Hygiene measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1. Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.1. Performance flow rate characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2. Outline drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3. Description and components location . . . . . . . . . . . . . . . . . . . . . . . 14
3.4. System regeneration cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.4.1. Downflow regeneration cycle (5-cycles operation) . . . . . . . . . . . . . . . . 16
3.4.2. Upflow regeneration cycle (5-cycles operation). . . . . . . . . . . . . . . . . . . 18
3.4.3. Variable Refill/Brining regeneration cycle (5-cycles operation). . . . . . 20
3.4.4. Filter cycle (3-cycles operation) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.5. Configurations for downflow softener, upflow softener and filter 24
3.5.1. Downflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.5.2. Upflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.5.3. Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.6. Options available on the valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Installer Manual Fleck 5800 - XTR - Table of content
Ref. MKT-IM-006 / B - 16.01.2018 3 / 122
4. System sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
4.1. Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.1.1. Injector/DLFC/BLFC-Valve configuration . . . . . . . . . . . . . . . . . . . . . . . 26
4.2. Sizing a softener (single unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.2.1. Parameters to be considered. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.2.2. Determining the required volume of resin . . . . . . . . . . . . . . . . . . . . . . 28
4.2.3. Resin exchange capacity and capacity of the unit . . . . . . . . . . . . . . . . 29
4.2.4. Valve configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.2.5. Cycle time calculation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.3. Salt amount definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.4. 1650 Injector flow rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
5.1. Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.2. Safety notices for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.3. Installation environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.3.1. General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5.3.2. Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.3.3. Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.3.4. Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.4. Integration constraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.5. Valve connection to piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.5.1. Top-mounted valve installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.6. Block diagram and configuration example . . . . . . . . . . . . . . . . . . 43
5.7. Regeneration types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.8. Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
5.9. By-passing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.10. Drain line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.11. Overflow line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
5.12. Brine line connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Installer Manual Fleck 5800 - XTR - Table of content
4 / 122 Ref. MKT-IM-006 / B - 16.01.2018
6. Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.1. Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.2. Touchscreen controller quick start . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.2.1. Format screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.2.2. Assistance name screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.2.3. Assistance phone screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.2.4. Assistance interval screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.2.5. Day and time screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.2.6. User assistance screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.2.7. Settings screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
6.2.8. Master setting screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.3. Master setting programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.4. Master setting reference chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
6.4.1. Format screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.4.2. USB connection for field programming . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.4.3. Valve screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6.4.4. Regeneration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
6.4.5. Relay output screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
6.4.6. Meter screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.4.7. Settings review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.4.8. Remote Regeneration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.4.9. Chlorine generation screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.4.10. Non-factory setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
6.5. Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
6.5.1. Error log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
6.6. Resetting the controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
7. Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
7.1. Water filling, draining and waterproofness inspection . . . . . . . . .89
7.1.1. Activating the softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
7.2. Sanitization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
7.2.1. Disinfection of water softeners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
7.2.2. Sodium or calcium hypochlorite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
7.2.3. Electro chlorination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Installer Manual Fleck 5800 - XTR - Table of content
Ref. MKT-IM-006 / B - 16.01.2018 5 / 122
8. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
8.1. Display during operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
8.2. Display during regeneration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
8.3. Controller operation during programming . . . . . . . . . . . . . . . . . . 92
8.4. Manual regeneration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.5. Operation during a power failure . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.6. Remote lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
8.7. Sleep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
9. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
9.1. Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.1.1. Use original spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.1.2. Use original approved lubricants. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.1.3. Maintenance instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.2. Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.2.1. Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.2.2. Replacing the controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
9.2.3. Replacing the controller motor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
9.2.4. Power head disassembly/replacement. . . . . . . . . . . . . . . . . . . . . . . . . 98
9.2.5. Replacing the piston and/or the brine valve . . . . . . . . . . . . . . . . . . . . 100
9.2.6. Cleaning the injector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
9.2.7. Cleaning the BLFC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
9.2.8. Replacing the optical sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
9.2.9. Replacing the seals and spacers cartridges. . . . . . . . . . . . . . . . . . . . 104
10. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105
10.1. Error detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.2. Error alerts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
11. Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
11.1. Power head parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
11.2. Valve parts list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
11.3. Safety brine valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
11.4. Safety brine valves list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
11.5. Bypass valve assembly list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
11.5.1. Plastic bypass (no yoke) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
11.5.2. 1" BSP female stainless steel bypass . . . . . . . . . . . . . . . . . . . . . . . . 116
11.6. Plastic turbine meter assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 118
12. Scrapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120

Installer Manual Fleck 5800 - XTR - Generalities
6 / 122 Ref. MKT-IM-006 / B - 16.01.2018
1. Generalities
1.1. Scope of the documentation
The documentation provides the necessary information for appropriate use of the product. It informs
the user to ensure efficient execution of the installation, operation or maintenance procedures.
The content of this document is based on the information available at the time of publication. The
original version of the document was written in English.
For safety and environmental protection reasons, the safety instructions given in this documentation
must be strictly followed.
This manual is a reference and will not include every system installation situation. The person
installing this equipment should have:
• training in the Fleck series, XTR controllers and water softener installation;
• knowledge of water conditioning and how to determine proper controller settings;
• basic plumbing skills.
This document is available in other languages on www.pentairaquaeurope.com/product-finder/
product-type/control-valves.
1.2. Release management
1.3. Manufacturer identifier, product
Manufacturer: PENTAIR
20580 Enterprise Avenue
Brookfield, WI 53045
USA
Product: Fleck 5800 - XTR
1.4. Intended use
The device is intended to be used for domestic applications only and it is purpose-built for water
treatment.
Revision Date Authors Description
A02.11.2016 BRY/ESA First edition.
B16.01.2018 BRY/FLA Address change, chapter 6 updates, add. cleaning
BLFC procedure.

Installer Manual Fleck 5800 - XTR - Generalities
Ref. MKT-IM-006 / B - 16.01.2018 7 / 122
1.5. Abbreviations used
BLFC ....................................................... Brine Line Flow Controller
BV............................................................ Brine Valve
DF............................................................ Down Flow
DLFC ....................................................... Drain Line Flow Controller
Inj ............................................................ Injector
QC............................................................ Quick Connect
Regen ...................................................... Regeneration
S&S ......................................................... Seals & Spacers
SBV.......................................................... Safety Brine Valve
TC ............................................................ Time Clock
UF............................................................ Up Flow
1.6. Norms
1.6.1. Applicable norms
Comply with the following guidelines:
• 2006/42/EC: Machinery Directive;
• 2014/35/UE: Low Voltage Directive;
• 2014/30/UE: Electromagnetic compatibility;
• 2011/65/CE: Restriction of use of certain hazardous substances in electrical and electronic
equipment (RoHS);
• UNI EN ISO9001 (certificate no. 95.022 SSG ICS).
Meets the following technical standards:
• EN 55014-1;
• EN 55014-2;
• EN 61000-6-1;
• EN 61000-6-2;
• EN 61000-6-3;
• EN 61000-6-4;
• EN 61010-1.
1.6.2. Available certificates
•CE;
•DM174;
•ACS.
Access to all certifications:

Installer Manual Fleck 5800 - XTR - Generalities
8 / 122 Ref. MKT-IM-006 / B - 16.01.2018
1.7. Procedure for technical support
Procedure to follow for any technical support request:
ACollect the required information for a technical assistance request.
→ Product identification (see 2.2. Serial label location, page 9 and 9.1. Recommendations,
page 95);
→ Problem description of the device.
BPlease refer to the "Troubleshooting" chapter, page 105. If the problem persists contact your
supplier.
1.8. Copyright
© 2018 Pentair International Sàrl All rights reserved.
1.9. Limitation of liability
Pentair Quality System EMEA products benefit, under specific conditions, from a manufacturer
warranty that may be invoked by Pentair’s direct customers. Users should contact the vendor of this
product for applicable conditions and in case of a potential warranty claim.
Any warranty provided by Pentair regarding the product will become invalid in case of:
• improper installation, improper programming, improper use, improper operation and/or
maintenance leading to any kind of product damages;
• improper or unauthorized intervention on the controller or components;
• incorrect, improper or wrong connection/assembly of systems or products with this product and
vice versa;
• use of a non-compatible lubricant, grease or chemicals of any type and not listed by the
manufacturer as compatible for the product;
• failure due to wrong configuration and/or sizing.
Pentair accepts no liability for equipment installed by the user upstream or downstream of Pentair
products, as well as for process/production processes which are installed and connected around or
even related to the installation. Disturbances, failures, direct or indirect damages that are caused by
such equipment or processes are also excluded from the warranty. Pentair shall not accept any
liability for any loss or damage of profits, revenues, use, production, or contracts, or for any indirect,
special or consequential loss or damage whatsoever. Please refer to the Pentair List Price to know
more about terms and conditions applicable to this product.

Installer Manual Fleck 5800 - XTR - Safety
Ref. MKT-IM-006 / B - 16.01.2018 9 / 122
2. Safety
2.1. Safety pictograms definition
2.2. Serial label location
Note
Ensure that the serial label and the safety tags on the device are completely legible and
clean. If necessary, replace them with new tags and put them in the same places.
2.3. Hazards
All the safety and protection instructions contained in this document must be observed in order to
avoid temporary or permanent injury, damage to property or environmental pollution.
At the same time, any other legal regulations, accident prevention and environmental protection
measures, as well as any recognized technical regulations relating to appropriate and risk-free
methods of working which apply in the country and place of use of the device must be adhered to.
Any non-observation of the safety and protection rules, as well as any existing legal and technical
regulations, will result in a risk of temporary or permanent injury, damage to property or
environmental pollution.
Caution
Warns of a risk of minor injury or major
material damage to the device or
environment.
Warning
Warns against serious personal injury
and damage to health.
Danger
Warns against serious personal injury or
death.
Mandatory
Standard or measure to apply.
Note
Comment
Prohibition
Restriction to be observed.
Valve type
Serial number
BLFC flow rate
Piston type
DLFC flow rate
Injector size

Installer Manual Fleck 5800 - XTR - Safety
10 / 122 Ref. MKT-IM-006 / B - 16.01.2018
2.3.1. Personnel
Only qualified and professional personnel, based on their training, experience and instruction as well
as their knowledge of the regulations, the safety rules and operations performed, are authorized to
carry out necessary work.
2.3.2. Material
The following points must be observed to ensure proper operation of the system and the safety of
user:
• be careful of high voltages present on the transformer (100 - 240 V);
• do not put your fingers in the system (risk of injuries with moving parts and shock due to electric
voltage).
2.4. Hygiene and sanitization
2.4.1. Sanitary issues
Preliminary checks and storage
• Check the integrity of the packaging. Check that there is no damage and no signs of contact with
liquid to make sure that no external contamination occurred;
• the packaging has a protective function and must be removed just before installation. For
transportation and storage appropriate measures should be adopted to prevent the
contamination of materials or objects themselves.
Assembly
• Assemble only with components which are in accordance with drinking water standards;
• after installation and before use, perform one or more manual regenerations in order to clean
the media bed. During such operations, do not use the water for human consumption. Perform a
disinfection of the system in the case of installations for treatment of drinking water for human
use.
Note
This operation must be repeated in the case of ordinary and extraordinary maintenance. It
should also be repeated whenever the system remains idle for a significant time.
2.4.2. Hygiene measures
Disinfection
• The materials used for the construction of our products meet the standards for use with potable
water; the manufacturing processes are also geared to preserving these criteria. However, the
process of production, distribution, assembly and installation, may create conditions of bacterial
proliferation, which may lead to odor problems and water contamination;
• it is therefore strongly recommended to sanitize the products. See 7.2. Sanitization, page 90;
• maximum cleanliness is recommended during the assembly and installation;
• for disinfection, use Sodium or Calcium Hypochlorite and perform a manual regeneration.

Installer Manual Fleck 5800 - XTR - Description
Ref. MKT-IM-006 / B - 16.01.2018 11 / 122
3. Description
3.1. Technical specifications
Design specifications/ratings
Valve body ............................................... Fiber-reinforced polymer
Rubber components ............................... EP/EPDM/silicone
Valve material certification .................... DM174, ACS, EC
Weight (valve with controller)................. 2 kg (max)
Recommended operating pressure ....... 1.4 - 8.6 bar
Maximum inlet pressure ........................ 8.6 bar
Hydrostatic test pressure....................... 20 bar
Water temperature................................. 1 - 43°C
Ambient temperature ............................. 0 - 52°C
Flow rates (3.5 bar inlet - valve only)
Continuous (Δp = 1 bar) .......................... 4.7 m3/h
Peak (Δp = 1.7 bar).................................. 6.1 m3/h
Cv*........................................................... 5.4 gpm
Kv*........................................................... 4.67 m3/h
Maximum backwash (Δp = 1.8 bar) ........ 3.8 m3/h
*Cv : Flow rate in gpm across the valve at a pressure drop of 1 psi at 60°F.
*Kv : Flow rate in m3/h across the valve at a pressure drop of 1 bar at 16°C.
Valve connections
Tank Thread............................................ 2½" - 8NPSM
Inlet/Outlet.............................................. ¾" or 1"
Riser tube ............................................... 26.7 mm O.D., 1.05" tube
Drain line ................................................ ½" O.D.
Brine line (1650)...................................... ⅜"
Electrical
Transformer input voltage ..................... 100 to 240 VAC
Input supply frequency ........................... 50 to 60 Hz
Transformer output voltage ................... 12 VDC
Motor input voltage................................. 12 VDC
Controller input voltage.......................... 12 VDC
Controller max. power consumption .... 6 W
Protection rating..................................... IP 22
Power supply .......................................... 100 to 240 VAC, 50/60 Hz, 0.8 A, Class II
Transient overvoltages ........................... Within the limits of category II
Pollution Degree..................................... 3
Temporary overvoltages must be limited in duration and in frequency.

Installer Manual Fleck 5800 - XTR - Description
12 / 122 Ref. MKT-IM-006 / B - 16.01.2018
Environmental conditions
• Indoor use only;
• temperature from 0°C to 52°C;
• maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative
humidity at 40°C;
• mains supply voltage fluctuations up to ±10% of the nominal voltage.
3.1.1. Performance flow rate characteristics
The graph shows the pressure drop created by the valve itself at different flow rates. It allows to
predetermine the maximum flow rate going through the valve depending on the system settings (inlet
pressure etc). It also allows to determine the valve pressure drop at a given flow rate, and therefore
to evaluate the system pressure drop vs flow rate.
PRESSURE DROP
Flow rate (m3/h]
Pressure differential (bar)
Backwash
Service

Installer Manual Fleck 5800 - XTR - Description
Ref. MKT-IM-006 / B - 16.01.2018 13 / 122
3.2. Outline drawing

Installer Manual Fleck 5800 - XTR - Description
14 / 122 Ref. MKT-IM-006 / B - 16.01.2018
3.3. Description and components location
Touch screen
Brine line
Injector block
Drain line
Piston
Outlet
Mixing device
Inlet
Meter
Brine valve
Controller

Installer Manual Fleck 5800 - XTR - Description
Ref. MKT-IM-006 / B - 16.01.2018 15 / 122
PAGE INTENTIONALLY LEFT BLANK

Installer Manual Fleck 5800 - XTR - Description
16 / 122 Ref. MKT-IM-006 / B - 16.01.2018
3.4. System regeneration cycle
Note
This valve allows to do down flow or up flow regenerations.
3.4.1. Downflow regeneration cycle (5-cycles operation)
Service — normal use
Untreated water is directed down through the resin bed and up through the riser tube. The hardness
ions attach themselves to the resin and are removed from the raw water being exchanged on the resin
beads against sodium ions. The water is conditioned as it passes through the resin bed.
Backwash — cycle C1
The flow of water is reversed by the valve and directed down through the riser tube and up through
the resin bed. During the backwash cycle, the bed is expanded and debris is flushed to the drain, while
the media bed is remixed.
Brine draw & slow rinse — cycle C2
The controller directs water through the brine injector and brine is drawn from the brine tank. The
brine is then directed down through the resin bed and up through the riser tube to the drain. The
hardness ions are replaced by sodium ions and are sent to the drain. The resin is regenerated during
the brine cycle. Afterwards the slow rinse phase starts.
Rapid rinse — cycle C3
The valve directs water down through the resin bed and up through the riser tube to the drain. Any
residual brine is rinsed from the resin bed, while the media bed is recompacted.
Brine tank refill — cycle C4
Water is directed to the brine tank, at a rate controlled by the refill controller [BLFC], to create brine
for the next regeneration. During brine refill, treated water is already available at the valve outlet.

Installer Manual Fleck 5800 - XTR - Description
Ref. MKT-IM-006 / B - 16.01.2018 17 / 122
Note
For illustration purpose only. Always verify inlet and outlet marking on the valve.
From brine
tank
C2
BRINE DRAW & SLOW RINSE
C1
BACKWASH
SERVICE
NORMAL USE
C4
BRINE REFILL
Valve
SERVICE
NORMAL USE
C3
RAPID RINSE
Outlet
Drain
Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
To brine tank
Drain
Drain

Installer Manual Fleck 5800 - XTR - Description
18 / 122 Ref. MKT-IM-006 / B - 16.01.2018
3.4.2. Upflow regeneration cycle (5-cycles operation)
Service — normal use
Untreated water is directed down through the resin bed and up through the riser tube. The hardness
ions attach themselves to the resin and are removed from the raw water being exchanged on the resin
beads against sodium ions. The water is conditioned as it passes through the resin bed.
Brine draw & slow rinse — cycle C1
The controller directs water through the brine injector and brine is drawn from the brine tank. The
brine is then directed down through the riser tube and up through the resin bed to the drain. The
hardness ions are replaced by sodium ions and are sent to the drain. The resin is regenerated during
the brine cycle. Then the slow rinse phase starts.
Backwash — cycle C2
The flow of water is reversed by the valve and directed down through the riser tube and up through
the resin bed. During the backwash cycle, the bed is expanded and debris is flushed to the drain, while
the media bed is remixed.
Rapid rinse — cycle C3
The controller valve directs water down through the resin bed and up through the riser tube to the
drain. Any residual brine is rinsed from the resin bed, while the media bed is recompacted.
Brine tank refill — cycle C4
Water is directed to the brine tank, at a rate controlled by the refill controller [BLFC], to create brine
for the next regeneration. During brine refill, treated water is already available at the valve outlet.

Installer Manual Fleck 5800 - XTR - Description
Ref. MKT-IM-006 / B - 16.01.2018 19 / 122
Note
For illustration purpose only. Always check for inlet and outlet marking on the valve.
From brine
tank
C2
BACKWASH
C1
BRINE DRAW & SLOW RINSE
SERVICE
NORMAL USE
C4
BRINE REFILL
Valve
SERVICE
NORMAL USE
C3
RAPID RINSE
Outlet
Drain
Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
Valve
Outlet Inlet
To brine tank
Drain
Drain

Installer Manual Fleck 5800 - XTR - Description
20 / 122 Ref. MKT-IM-006 / B - 16.01.2018
3.4.3. Variable Refill/Brining regeneration cycle (5-cycles operation)
Service — normal use
Untreated water is directed down through the resin bed and up through the riser tube. The hardness
ions attach themselves to the resin and are removed from the raw water being exchanged on the resin
beads against sodium ions. The water is conditioned as it passes through the resin bed.
Brine tank refill — cycle C1
Water is directed to the brine tank, at a rate controlled by the refill controller [BLFC], to create brine
for the next regeneration. Refill duration is calculated by the controller on the basis of real resin
consumption. During brine refill, treated water is available at the valve outlet.
Service — cycle C2
After the refill, the valve comes back in to service position and stays as long as needed for brine
saturation.
Brine draw & slow rinse — cycle C3
The valve directs water through the brine injector and brine is drawn from the brine tank. The brine
is then directed down through the riser tube and up through the resin bed to the drain. The hardness
ions are replaced by sodium ions and are sent to the drain. The resin is regenerated during the brine
cycle. Then the slow rinse phase starts.
Backwash — cycle C4
The flow of water is reversed by the valve and directed down through the riser tube and up through
the resin bed. During the backwash cycle, the bed is expanded and debris is flushed to the drain, while
the media bed is remixed.
Rapid rinse — cycle C5
The valve directs water down through the resin bed and up through the riser tube to the drain. Any
residual brine is rinsed from the resin bed, while the media bed is recompacted.
