BT50 Luxx Installation Manual
Please read this manual before installing this product.

2
Thank you for purchasing the BT50Luxx
Before installing, be sure to thoroughly read these instructions.
Warranty for this product is 2 years from date of purchase, however warranty will be
void if:
• The unit is tampered with, damaged or modified in anyway.
• Reverse camera cable is cut or modified in any way (If applicable).
• Reverse camera is subjected to over voltage (if applicable).
• The Navigation SD card is damaged or tampered with in any way (this
includes installing foreign mapping or software onto the SD card).
• The installation of 3rd party apps that may cause harm to the unit.
• Warranty Terms
The BT50Luxx is covered for 2 years and includes:
• Defective Equipment • Defective Cables
Not Covered under warranty:
• Abuse
• Improper installation
• Alteration to Cables (includes cutting of any cables)
• Accidents
• Water damage
• Improper use
• Labour
• Postage and Handling
If you have any questions concerning the installation, warranty or the operation of the unit,
please contact Polaris on 1300 555 514.
We hope that you enjoy the BT50Luxx
Warranty details

3
 The wiring and installation of this unit requires special technical skill and experience.
If you do not feel confident installing this product or do not have the level of skill
necessary, please contact Polaris on 1300 555 514 so we can refer to a recommended
installer.
 This unit is designed to be used in a vehicle with a 12 volt battery and a negative
grounding. Before installing this unit to a recreational vehicle, bus, or truck, make sure
the battery voltage is appropriate for this unit to be used.
 To avoid short circuit in the electrical system, ensure that the negative battery cable is
disconnected before installation.
 To avoid possibility of shorting out the electrical circuit in the unit, never connect the
battery wire directly to the vehicle battery.
Always secure all wirings with cable clamps or adhesive tape to prevent short circuit.
 Please make sure all wiring connections and speaker wires are well insulated.
 When pulling the dash apart, please use quality trim tools to avoid damaging your
dash.
 Please do NOT cut any plugs off of any Polaris cameras. Doing so will void your
warranty! If you need to blend other brand cameras into our system, please call Polaris
on 1300 555 514 so we can refer you to a recommended dealer who has the skill and
experience in performing this type of work.
 If there is something you are not 100% sure about when installing this unit, please give
our experienced technicians a call on 1300 555 514.
Installation Notes

4
1. Use trim tool to remove air
con control panel
2. Pull Air conditioning panel
out.
3. Unplug harness and set air
con panel aside
4. Use trim tool to remove
fascia panel
5. Gently pull fascia out 6. Unplug button panel and set
aside
7. Remove 2 screws holding
OEM screen in place
8. Unplug harness and set
screen aside
9. Remove 2 screws holding
the CD housing in place
10. Unplug harness and set
CD housing aside
Removing your panel

5
Other wiring
• Hazard Switch extension cable
• 2 x USB retention adaptors > plug these into the cabled USB’s to retain your glove box USB
and one USB in your panel (if required).
• External Bluetooth microphone: unit does have internal microphone but you can run the
external microphone if you like. Normally mounted on steering wheel or top of drivers side
panel
• External GPS Antenna: Please mount this on top of your dash with the black side facing the sky
• Speaker: Only used if you have OEM sensors and want to retain the sound. Note: If this doesn't
work, unplug the red/white adaptor on main harness and plug in without adaptor.
• Reverse Camera cable with purple wire: NOT USED—use Plug H for reverse Camera
Wiring Diagram

6
Wiring Diagram: Reverse Camera
Head
REVERSE
TRIGGER
WIRE
REVERSE FOUND IN
ORIGINAL HARNESS
(COLOUR MIGHT
DIFFER FROM
BRANDS AND
MODELS)
Acc+
CUT AND TAPE OFF WIRES AS
NOT NEEDED IN THIS SET UP
RCA PLUGS INTO
CAMERA INPUT FOUND
ON HEAD UNIT
CONSTANT CAMERA AND TRIGGER
DIAGRAM 1
Head
REVERSE TRIGGER
WIRE
POWER FROM REVERSE
LIGHTS
RCA PLUGS INTO CAM-
ERA INPUT FOUND ON
HEAD UNIT
RCA CAMERA WITH REVERSE TRIGGER ONLY
DIAGRAM 2

7
Head
REVERSE TRIGGER WIRE
Acc+
CUT
AND
TAPE
OFF
WIRES
AS NOT
NEEDED
IN THIS
SET UP
RCA PLUGS
INTO
CAMERA
INPUT
IF NO REVERSE TRIGGER IS FOUND PLEASE FOLLOW THE SECOND DIAGRAM, IF YOU WOULD LIKE A
CONSTANT CAMERA AS WELL, A TRIGGER MUST BE BROUGHT FROM REVERSE LIGHT
(POWER TO
CAMERA)
DIAGRAM 3
Wiring Diagram: Reverse Camera (cont.)

8
1. Remove clips from original fascia panel... 2. Attach clips to new fascia panel
Prepare the fascia

9
1. Make sure all of your wiring is plugged into the back of the head unit and all of your cables are tucked
away neatly before securing the unit in place.
Install the new head unit and fascia
2. Rest unit in place, test all
features first and gently push
fascia panel back into position
3. Plug the air conditioning
control harnesses into the
back of the Air con panel
4. Gently push air
conditioning controls back in.
If you have any questions regarding the installation of the unit, please call 1300 555 514 and speak with
one of our installers.
