Polaris NG60 User manual

NG60
User Manual
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 1

2
Thank you for purchasing the Polaris NG60 Reversing System
Before operation, be sure to thoroughly read these instructions.
Keep these instructions with your vehicle records for future reference.
Warranty for this product is 3 years from date of purchase, however warranty will be voided if:
• The unit is tampered with, damaged or modified in any way.
• Reverse camera cable is cut or modified in any way.
• Reverse camera is subjected to over voltage.
Warranty Terms
The NG60 is covered for 3 years and includes:
• Defective Equipment • Defective Cables
Not Covered under warranty:
• Abuse • Improper installation
• Alteration to cables (this includes cutting of any cables) • Remote control batteries
• Accidents • Water Damage • Improper use • Labour
If you have any questions concerning the installation, warranty or the operation of the unit,
please contact Polaris on 1300 555 514.
We hope that you enjoy the Polaris NG60.
INDEX
Wiring Diagram ................................................. Page 3
Reverse Camera ................................................ Page 4
Rear View Cameras ........................................... Page 5
Settings ............................................................. Page 6
Remote Control ................................................. Page 7
Specifications .................................................... Page 8
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 2

3
Reverse Camera
Cam 1
Cam 2
Cam 3
Reverse (Green)
GND (Black)
Acc+ (Red)
Plugs into back of monitor
Wiring Notes:
• The NG60 has 4 camera inputs but is designed for one camera to be triggered when
reverse gear is engaged.
• Whichever camera you want to trigger when reverse gear is engaged, please make
sure you plug it into the reverse camera input.
• You can still access Cam 1, 2 & 3 whilst in reverse, please see page 4 for instructions
on how to do this.
• If you don't wish for a camera to activate whilst in reverse, then simply plug your
camera into either Cam 1, 2 or 3 as you can view these cameras whilst driving.
• Cam 1, 2 & 3 can be accessed at any time whilst driving forward, please see
page 5 for instructions on how to do this.
• The NG60 is 12-32Volt and is built into the monitor.
• If you are only wiring up one camera to engage when in reverse please run the
Acc+ (red) along with the reverse trigger wire (green) directly to your reverse lights.
This way the monitor will power down when drive is activated. If you add an
additional camera(s) at a later stage, please run the ACC+(red) to accessories
power so you can access the additional camera(s) whilst driving.
If you have any questions in regards to the wiring of this unit, please contact
Polaris on 1300 555 514
Wiring Diagram
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 3

4
The NG60 is designed to have one reverse camera and 3 additional cameras
wired up.
When you put the vehicle into reverse, the reverse camera will activate and
override the screen that you were originally on.
If you wish to view any of the other cameras whilst in reverse, touch the screen
and it will bring up the below options in the top right hand corner:
Choose your desired camera.
Camera Functionality
Reverse Camera
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 4

5
If you don't wish for a camera to activate whilst in reverse, then simply plug
your camera into either Cam 1, 2 or 3.
If you have 3 cameras plugged into the NG60 you can view any of these
cameras while driving.
Simply touch the screen to bring up the below options in the top right
hand corner and choose the appropriate camera that you wish to view.
Alternatively, you can also touch
the home icon which will take you
to the main menu and give you the
3 camera options.
Camera Functionality
Rear View Cameras
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 5

6
If you touch anywhere on the screen you will see the following icon in the top
right hand corner: Touch this icon to enter into the main menu.
Touch the settings icon to enter into the settings feature:
Settings menu:
Settings
Brightness, colour and contrast
Adjust to your desired setting
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 6

7
Remote Control
Functionality
Will switch to camera 1
Will switch to camera 2
Will switch to camera 3
Will power the
monitor on
Will power the
monitor off
The remote will only allow you to select the different cameras whilst driving.
NG60 User Manual_NG60 User Manual 1/06/2017 12:33 pm Page 7

8
Specifications
Monitor Specs
Monitor: 6.2"Anti Glare Capacitive Touch Screen
Resolution: 800x480 pixels
Display Method: Digial TFT LCD Monitor
Operating Temperature: Minus 10°C to 60°C
Power input: DC12V-32V
Video form: PAL/NTSC
OSD Language: English
Power Consumption 0.5A
IR Sensor Yes - for remote control
Wiring Harness
Wiring: Universal wiring harness with 4 camera inputs
Multi Camera support: Yes, 4 camera inputs with Polaris configuration 4 pin DIN plugs
Reverse Trigger: yes, reverse camera trigger wire
Ideal camera setup: Reverse camera (triggers when vehicle is in reverse) / Cam 1 / Cam 2 / Cam 3
Reverse Gear Camera Accessibility: Can still access Cam 1, Cam 2 & Cam 3 whilst in Reverse gear.
Rear Vision Camera Accessbility: Can only access Cam 1, Cam 2 & Cam 3 whilst driving forward
Miniature Camera Specs
Image device: 1/3" CMOS PC1099
Cable length: 7 metres
Pixel Size: 5.00μm * 7.4μm
Effective Pixels: 976 (H)* 496 (V)
Lens Angle 170° degree wide angle
Minimum Illumination 0.1 Lux/F
Sensitivity: 11.4 [V/Lux.sec]
TV Lines: 600 TV Lines
Format: NTSC
Power Consumption: 360 [mW] @ Dynamic / 484 [μW] @ Standby
Operating Temperature: Minus 20°C to 85°C, RH95% MAX
IP Rating: IP67
General Information
Warranty Period: 3 years from date of purchase
Model No. NG60
Accessories Included:
6.2"Anti Glare Capacitive Touch Screen
Universal wiring harness with four camera inputs
Miniature Camera with 7 metre cable
Dash mount with 3m stick pad
