Polaris 2879719 User manual

-1-
P/N 9924942 Rev 01 02/14
Before you begin, read these instructions twice and check to be sure all parts and tools are accounted for. The
following instructions contain details required to install the contents of this kit.
P/N 2879719
EXTENSION FOR “GLACIER
PRO ATV” PLOW FRAME KIT
Application
GLACIER PRO ATV PLOW FRAME (PN 2879630)
16
18
2
1
4
14
5
14
315 12
6
8
6
9
8
9
2
11
17
10
10 13
3
13
7
15
5

-2-
P/N 9924942 Rev 01 02/14
Kit Contents:
Ref Qty Part Description Part Number
1* 1 Ø16 mm x 30 mm Clevis Pin -
2* 2 Ø3 x 25 mm cotter Pin -
3* 2 M10-1.5 x 50 mm Hexagonal Bolt -
4* 2 M10-1.5 x 120 mm Hexagonal Bolt -
5* 4 M10-1.5 Hexagonal Nylon Nut -
6* 8 M6-1.0 Hexagonal Nylon Nut -
7** 1 M8-1.25 Hexagonal Nylon Nut -
8* 4 M6-1 x 25 mm Socket Head Cap Screw -
9* 4 M6-1 x 18 mm Socket Head Cap Screw -
10 2 Warning Decal -
11* 1 Ø16 mm x 70 mm Clevis Pin -
12 1 Extension Frame -
13 2 Extension Clamp -
14 2 Extension Plate -
15* 2 Frame Sleeve -
16 1 Hook Up Extension -
17 1 Spring -
18** 1 Winch Link -
1 Instructions 9924942
Item marked (*) are included in Hardware Kit PN 2205215.
Item marked (**) are included in Link Kit PN 2205463.
Tools Required:
10 mm, 15 mm and 17 mm Open-End Wrenches and Sockets
5 mm Allen Key, and Long Nose Pliers
APPROXIMATE ASSEMBLY TIME: 30 minutes
IMPORTANT: Your Polaris accessory is exclusively designed to work with Glacier Pro ATV Plow
System. Before beginning, please read these instructions and make sure that all parts and tools
are at your disposal. Keep these instructions for future reference or for any information requests. To
facilitate installation, make sure that your plow system is clean and free of debris.

-3-
P/N 9924942 Rev 01 02/14
INSTALLATION INSTRUCTIONS:
PUSH FRAME EXTENSION:
WINCH LINK ASSEMBLY:
1. Position push frame (PN 2879630)
under the extension. Figure 1. Insert
two frame sleeves inside the rear
mounting holes of the frame. Fasten
the extension using two M10-1.5 x 50
mm hex. Bolts and two M10-1.5 hex.
Nylon nuts.
2. Position and fasten the two extension
clamps using two M10-1.5 x 120
mm hex. Bolts and two M10-1.5 hex.
Nylon nuts.
Figure 1
Figure 2
3. The original winch link must be
replaced by the new longer winch link
and M8-1.25 hex. Nylon nut supplied
with the extension kit.
a. Install winch link with nylon nut
until only two threads are showing
after the nut. Figure 2.
b. Lift the frame using the winch until
the winch stops itself (if you use
a winch with an automatic stop
switch) or until the winch hook
comes into contact with the roller
fairlead.
c. Try to lift the blade by hand. If the
blade can be lifted, the nut must
be tightened. Tighten until the
blade is at the maximum height
(maximum height is reached when
the stoppers on the extension
frame are in contact with the plates
of the quick-attach mechanism).
Hex Bolts
Hex Bolt
Hex
Bolt
Extension Clamp
Extension Clamp
Nylon Nuts
Nylon Nut
Nylon Nuts
Frame Sleeve
Frame Sleeve
Winch Link
Stopper for max
Lifting Height
IMPORTANT: Polaris winch must be installed rst. It is strongly suggested that your ATV front
suspension setup be changed to the stiffest setting.

-4-
P/N 9924942 Rev 01 02/14
HOOK UP ASSEMBLY:
HOOK UP EXTENSION ASSEMBLY:
4. Refer to the mount plate installation guide for instructions. Hook up assembly must be assembled to
extension brackets instead of push frame brackets.
5. If there is a tension spring with steel cable and eyebolt assembly in your mount plate kit, replace the
original tension spring by the new spring supplied in the extension kit. Refer to your mount plate installation
guide to get installation instructions.
Hook up extension for Sportsman XP mount plate kit (P/N 2879632):
6. Remove four M6-1 x 18 mm socket
head cap screws, four M6-1.0 hex.
Nylon nuts and two half lock plates
from the hook up. Figure 3.
7. Fasten the hook up extension and
extension plates using four M6-1
x 25 mm socket head cap screws,
four M6-1 x 18 mm socket head cap
screws and eight M6-1.0 hex. Nylon
nuts. Figure 4.
There are two different congurations depending on the vehicle. Position the hook up extension in the correct
conguration according to the vehicle.
Figure 3
Figure 4
Socket
Head Cap
Screws
Socket
Head Cap
Screws
Socket
Head Cap
Screws
Socket
Head Cap
Screws
Socket
Head Cap
Screws Extension Plates
Positioned inside
both Parts
Nylon
Nuts
Nylon Nuts

-5-
P/N 9924942 Rev 01 02/14
Hook up extension for Sportsman Non-XP mount plate kit (P/N 2879633):
6. Remove four M6-1 x 18 mm socket
head cap screws and four M6-1.0
hex. Nylon nuts. Keep the two half
lock plates from the hook up; they
must be reinstalled. Figure 5.
7. Fasten the hook up extension and
extension plates using four M6-1
x 25 mm socket head cap screws,
four M6-1 x 18 mm socket head cap
screws and eight M6-1.0 hex. Nylon
nuts. Figure 6.
Figure 5
Figure 6
Socket
Head Cap
Screws
Keep Half
Lock Plates
Keep Half Lock Plates
in place (supplied in
the mount plate kit)
Extension plates
positioned outside
of hook up extension
and inside of hook up
Nylon
Nuts
Socket
Head Cap
Screws
Socket Head
Cap Screws
Socket Head
Cap Screws
Socket
Head Cap
Screws
Nylon Nuts

-6-
P/N 9924942 Rev 01 02/14
SPARE KITS
REF. DESCRIPTION Hardware Kit
(2205215)
Winch Link Kit
(2205463)
1 Ø16 mm x 30 mm clevis pin 1x
2 Ø3 x 25 mm cotter pin 2x
3 M10-1.5 x 50 mm hexagonal bolt 2x
4 M10-1.5 x 120 mm hexagonal bolt 2x
5 M10-1.5 hexagonal nylon nut 4x
6 M6-1.0 hexagonal nylon nut 8x
7 M8-1.25 hexagonal nylon nut 1x 1x
8 M6-1 x 25 mm socket head cap screw 4x
9 M6-1 x 18 mm socket head cap screw 4x
10 Warning decal
11 Ø16 mm x 70 mm clevis pin 1x
12 Extension frame
13 Extension clamp
14 Extension plate
15 Frame sleeve 2x
16 Hook up extension
17 Spring 1x
18 Winch link 1x
