Polycom G7500 Service manual

ADMINISTRATOR GUIDE 2.0 | May 2019 | 3725-85854-001A
Polycom® G7500

Copyright© 2019, Polycom, Inc. All rights reserved. No part of this document may be reproduced,
translated into another language or format, or transmitted in any form or by any means, electronic or
mechanical, for any purpose, without the express written permission of Polycom, Inc.
6001 America Center Drive
San Jose, CA 95002
USA
Trademarks Polycom®, the Polycom logo and the names and marks associated with Polycom products
are trademarks and/or service marks of Polycom, Inc. and are registered and/or common law marks in the
United States and various other countries.
All other trademarks are property of their respective owners. No portion hereof may be reproduced or
transmitted in any form or by any means, for any purpose other than the recipient's personal use, without
the express written permission of Polycom.
End User License Agreement By installing, copying, or otherwise using this product, you acknowledge
that you have read, understand and agree to be bound by the terms and conditions of the End User
License Agreement for this product. The EULA for this product is available on the Polycom Support page
for the product.
Patent Information The accompanying product may be protected by one or more U.S. and foreign
patents and/or pending patent applications held by Polycom, Inc.
Open Source Software Used in this Product This product may contain open source software. You may
receive the open source software from Polycom up to three (3) years after the distribution date of the
applicable product or software at a charge not greater than the cost to Polycom of shipping or distributing
the software to you. To receive software information, as well as the open source software code used in
this product, contact Polycom by email at [email protected] (for video products) or
OpenSourceV[email protected] (for voice products).
Disclaimer While Polycom uses reasonable efforts to include accurate and up-to-date information in this
document, Polycom makes no warranties or representations as to its accuracy. Polycom assumes no
liability or responsibility for any typographical or other errors or omissions in the content of this document.
Limitation of Liability Polycom and/or its respective suppliers make no representations about the
suitability of the information contained in this document for any purpose. Information is provided "as is"
without warranty of any kind and is subject to change without notice. The entire risk arising out of its use
remains with the recipient. In no event shall Polycom and/or its respective suppliers be liable for any
direct, consequential, incidental, special, punitive or other damages whatsoever (including without
limitation, damages for loss of business profits, business interruption, or loss of business information),
even if Polycom has been advised of the possibility of such damages.
Customer Feedback We are striving to improve our documentation quality and we appreciate your
feedback. Email your opinions and comments to [email protected].
Polycom Support Visit the Polycom Support Center for End User License Agreements, software
downloads, product documents, product licenses, troubleshooting tips, service requests, and more.

Contents
Before You Begin................................................................................................6
Getting Help........................................................................................................................ 6
The Polycom Community......................................................................................... 6
Related Documentation............................................................................................6
Documentation Feedback........................................................................................ 6
Getting Started................................................................................................... 7
Polycom G7500 Overview...................................................................................................7
Powering the System On and Off........................................................................................8
Navigating the System........................................................................................................ 8
Access the System Web Interface............................................................................8
Place a Call from the System Web Interface............................................................8
End a Content Session from the System Web Interface.......................................... 9
Setting Up the System..................................................................................... 10
System Back Panel Ports..................................................................................................10
LED Status Indicators for the G7500 System....................................................................11
Complete System Setup................................................................................................... 12
Managing Peripheral Devices........................................................................................... 12
Pairing IP Peripheral Devices to the System..........................................................12
IP Microphones...................................................................................................... 14
Polycom Microphone IP Adapter............................................................................16
Polycom Bluetooth Remote Control....................................................................... 18
Configuring General Settings......................................................................... 21
Name the System and Room............................................................................................ 21
Provide Contact Information..............................................................................................21
Set the Date and Time...................................................................................................... 22
Set the System Location................................................................................................... 22
Set the Local Interface Language..................................................................................... 23
Configure Sleep Settings.................................................................................................. 23
Send Usage Data to Polycom........................................................................................... 23
Using a Provisioning Service..........................................................................25
Register the System with a Provisioning Service..............................................................25
Download a Template Configuration File.......................................................................... 26
Polycom, Inc. 1

Configuring Network Settings.........................................................................27
Configuring Wired LAN Settings....................................................................................... 27
Obtain IPv4 Address Settings Automatically.......................................................... 27
Configure IPv4 Address Settings Manually............................................................ 27
Configure DNS Settings Manually..........................................................................28
Configure Wired LAN Options................................................................................ 28
Configure Wi-Fi Settings................................................................................................... 31
Configure Network Quality Settings.................................................................................. 32
Configure H.323 Settings.................................................................................................. 34
Configure SIP Settings......................................................................................................36
Enable Point-to-Point Call Escalation to a RealPresence DMA Conference Call............. 39
Wireless Devices...............................................................................................................40
Securing the System........................................................................................41
Managing System Access.................................................................................................41
Local Accounts....................................................................................................... 41
Enable External Authentication.............................................................................. 44
Configure System Access Settings........................................................................ 45
Enable Command-Line API Access Over SSH...................................................... 46
Enable Command-Line API Access Over Telnet....................................................46
Disable Command-Line API Access...................................................................... 46
Configure the System Web Interface Port Lock..................................................... 47
Configure the SSH Port Lock................................................................................. 47
Locking the Telnet Port...........................................................................................48
Configure Serial Port Settings................................................................................ 48
Disable USB 3.0 Ports............................................................................................49
PKI Certificates................................................................................................................. 49
Create a Certificate Signing Request..................................................................... 50
Configure Certificate Validation Settings................................................................ 51
Install a Certificate..................................................................................................52
View a Certificate....................................................................................................52
Delete a Certificate.................................................................................................52
Certificate Revocation............................................................................................ 53
Disable the Security Code.................................................................................................54
Limit or Disable the Ability to Save Content...................................................................... 55
Encryption......................................................................................................................... 55
Configure Call Encryption.......................................................................................55
Configure Minimum TLS.........................................................................................56
H.460 Firewall/NAT Traversal........................................................................................... 56
Configure the System for H.460 Firewall/NAT Traversal........................................56
Contents
Polycom, Inc. 2

Web Proxies......................................................................................................................58
View Connections to the System...................................................................................... 60
Port Usage........................................................................................................................ 61
Configuring Call Settings................................................................................ 65
Configure Call Settings..................................................................................................... 65
Configure Dialing Options................................................................................................. 66
Set Call Answering Mode..................................................................................................67
Set Preferred Call Speeds................................................................................................ 67
Configure the Recent Calls List.........................................................................................68
Clear Recent Calls............................................................................................................ 68
Configuring Audio Settings.............................................................................69
Configure General Audio Settings.....................................................................................69
Audio Input........................................................................................................................ 70
Configure IP Microphones......................................................................................71
Configuring the Microphone Adapter......................................................................71
Polycom Acoustic Fence........................................................................................ 71
Configure 3.5 mm and HDMI Audio Input.............................................................. 73
Audio Output..................................................................................................................... 74
Configure Audio Output Settings............................................................................74
Using 3.5 mm Audio Output................................................................................... 75
Audio I/O Specifications.................................................................................................... 75
Configuring Video and Camera Settings........................................................76
HDMI Connections............................................................................................................ 76
Configure Monitor Settings................................................................................................77
Configure a Touch Monitor................................................................................................ 78
Configure Camera Settings...............................................................................................79
Configure Video Input Settings......................................................................................... 80
Video Codec Capabilities.................................................................................................. 84
H.265 High Efficiency Video Coding.......................................................................84
H.264 Advanced Video Coding.............................................................................. 85
Setting Up a Directory......................................................................................87
Register with the Polycom Global Directory Server.......................................................... 87
Register with an LDAP Directory Server........................................................................... 87
Managing Contacts and Favorites.................................................................................... 89
Registering with a Calendaring Service.........................................................90
Contents
Polycom, Inc. 3

Configure a Calendaring Service...................................................................................... 90
Sharing Content............................................................................................... 93
Customizing the Local Interface..................................................................... 94
Change the Home Screen Background Image................................................................. 94
Restore the Default Background Image............................................................................ 94
Customize the Address Bar.............................................................................................. 94
Display Meetings or Favorites on the Home Screen.........................................................95
Configure Dual Monitor Display Settings.......................................................................... 95
System Maintenance........................................................................................97
Activating System Features.............................................................................................. 97
Unlock System Settings.................................................................................................... 98
Updating Software.............................................................................................................98
Updating Software in the System Web Interface....................................................99
Update Software with a USB Flash Drive.............................................................101
Update Polycom HDCI Cameras..........................................................................101
Downgrading Software....................................................................................................102
Restart the System..........................................................................................................102
Reset System Settings....................................................................................................103
Factory Restore the System............................................................................................103
Factory Restore a Table Microphone.............................................................................. 104
Factory Restore a Ceiling Microphone............................................................................104
Factory Restore a Microphone Adapter.......................................................................... 106
SNMP Reporting............................................................................................................. 106
Configure SNMP.................................................................................................. 107
Download MIBs.................................................................................................... 109
Troubleshooting............................................................................................. 110
Checking System Status................................................................................................. 110
Paired IP Peripheral Device is Disconnected.................................................................. 111
View Call Statistics.......................................................................................................... 112
LED Status Indicators for the System LAN Ports............................................................ 112
Check Provisioning Results.............................................................................................113
Logs.................................................................................................................................113
Consolidated System and Peripheral Device Logs.............................................. 113
Configure Log Preferences...................................................................................114
Configure Log Level..............................................................................................115
Download Logs.....................................................................................................115
Contents
Polycom, Inc. 4

Transfer Logs to a USB Flash Drive..................................................................... 116
Configure Remote Logging...................................................................................116
Sample Log File....................................................................................................117
Audio Tests......................................................................................................................118
Fix Polycom Acoustic Fence Issues................................................................................119
Issues When the System is Sleeping or Waking............................................................. 119
Test the Call Experience................................................................................................. 120
Test Connection with Another System............................................................................ 120
Run a Trace Route..........................................................................................................120
LDAP Directory Server Ignores the Minimum TLS Version Setting................................ 120
Checking the Web Proxy Configuration.......................................................................... 121
Contents
Polycom, Inc. 5

Before You Begin
Topics:
▪Getting Help
This guide helps you understand how to configure and manage your Polycom G7500 system.
This guide covers the following products:
▪ Polycom G7500 system (Model: P011)
▪ Polycom Microphone IP Adapter (Model: P012)
▪ Polycom IP Table Microphone (Model: P013)
▪ Polycom IP Ceiling Microphone (Model: P014)
Getting Help
For information about installing, configuring, using, and administering Polycom products, see Documents
& Software at Polycom Support.
The Polycom Community
The Polycom Community gives you access to the latest developer and support information.
Participate in discussion forums to share ideas and solve problems with your colleagues. To register with
the Polycom Community, simply create a Polycom online account. When logged in, you can access
Polycom support personnel and participate in developer and support forums to find the latest information
on hardware, software, and partner solutions topics.
Related Documentation
In addition to this guide, the following documentation further describes Polycom endpoints and
peripherals used in video conferencing. The Release Notes might include known issues or limitations
related to interoperability with Polycom endpoints.
For more information, see the Polycom Documentation Library or Polycom Support.
▪Polycom G7500 User Guide
▪Polycom G7500 Release Notes
▪Polycom G7500 Configuration Parameter Reference Guide
▪Polycom G7500 Command-Line API Reference Guide
Documentation Feedback
We welcome your feedback to improve the quality of Polycom documentation.
You can email Documentation Feedback for any queries or suggestions related to this documentation.
Polycom, Inc. 6

Getting Started
Topics:
▪Polycom G7500 Overview
▪Powering the System On and Off
▪Navigating the System
The Polycom G7500 system provides video-conferencing capabilities and collaboration tools for any size
meeting space or room.
Polycom G7500 Overview
The Polycom G7500 system is an all-in-one video conferencing and content-sharing solution.
The G7500 system provides the following features and capabilities:
▪ Placing and joining video calls
▪ Viewing and joining scheduled calendar meetings
▪ Managing contacts, call lists, and directories
▪ Creating a favorites list
▪ Sharing content
▪ Collaborating by electronic whiteboarding
Related Links
Video Codec Capabilities on page 84
Administrator Features and Capabilities
The G7500 system provides the following features and capabilities:
▪ Scalability for various room sizes
▪ Remote access for managing standalone systems
▪ Provisioning with Polycom RealPresence Resource Manager to support single system, small
business, and large multisite enterprise deployments
▪ SNMP reporting and remote logging
▪ Industry-standard security techniques, including 802.1X authentication
▪ Polycom platform on-premises infrastructure and management solutions
▪ Standards-based video conferencing
▪ Customizable home screen and monitor layouts
Polycom, Inc. 7

Powering the System On and Off
The G7500 system turns on when you plug it into a power source. The system doesn’t have a power
button, so you must unplug the power cable to turn it off.
Don’t power off the system during maintenance activities (for example, while a software update is in
progress).
Related Links
Restart the System on page 102
Navigating the System
You can navigate the G7500 system using the system web interface.
Access the System Web Interface
Access the G7500 system web interface to perform administrative tasks.
The system web interface enables you to do the following actions:
▪ Finish setting up your system.
▪ Remotely configure and manage your system. Unlike the local interface, you can configure every
setting through the system web interface.
▪ Control certain user functions of the system (such as placing calls and ending content sessions).
▪ Manage contacts.
Procedure
1. Enter the system IP address in a browser.
When setting up your system, the onscreen instructions display the IP address to use.
2. Enter the user name (the default is admin).
3. Enter the password (the default is the last six characters of your system’s serial number).
Related Links
Complete System Setup on page 12
Place a Call from the System Web Interface
The G7500 system web interface gives you many of the same calling features and controls that are in the
local interface.
You can also place video and audio-only calls directly from the Dashboard.
Procedure
1. In the system web interface, go to Place a Call.
2. Do one of the following:
▪ Select Dial to manually dial a number or name.
▪ Select Contacts to search local and directory contacts to call.
▪ Select Favorites to search contacts marked as Favorites.
▪ Select Recent to select a number or name you’ve called in the past.
Getting Started
Polycom, Inc. 8
