Pride Mobility PURSUIT User manual

*INFMANU3890*
PURSUIT

Copyright © 2012
Pride Mobility Products Corp.
INFMANU3890/Rev B/February 2012
SAFETY GUIDELINES
NOTE: This owner’s manual is compiled from the latest specifications and product information avail-
able at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in this
manual and the product you have purchased. The latest/current version of this manual is available on
our website.
Pride Provider: _____________________________________________________________________
Address: __________________________________________________________________________
Phone Number:__________________________
Purchase Date: __________________________ Serial Number: ___________________________
WARNING! An authorized Pride Provider or qualified technician must perform the initial
setup of this scooter and must perform all of the procedures in this manual.
The symbols below are used throughout this owner's manual and on the scooter to identify warnings and
important information. It is very important for you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage, or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at
any time or in any circumstances. Performing a prohibited action can cause personal
injury and/or equipment damage. On the product, this icon is represented as a black
symbol with a red circle and a red slash.
INTENDED USE
The intended use of the Pride Mobility Products device is to provide mobility to persons limited to a seated
position that have the capability of operating a powered scooter.
Please fill out the following information for quick reference:

3
Pursuit www.pridemobility.com
CONTENTS
I. INTRODUCTION .......................................................................................................................4
II. SAFETY ........................................................................................................................................5
III. YOUR SCOOTER .....................................................................................................................19
IV. BATTERIES AND CHARGING ..........................................................................................24
V. OPERATION .............................................................................................................................29
VI. COMFORT ADJUSTMENTS ..............................................................................................31
VII. DISASSEMBLY AND ASSEMBLY ...................................................................................33
VIII.BASIC TROUBLESHOOTING ...........................................................................................35
IX. CARE AND MAINTENANCE ..............................................................................................37
APPENDIX I - SPECIFICATIONS ...............................................................................................40

4www.pridemobility.com Pursuit
I. INTRODUCTION
SAFETY
Welcome to Pride Mobility Products Corporation (Pride). The product you have purchased combines
state-of the-art components with safety, comfort, and styling in mind. We are confident the design features
will provide you with the conveniences you expect during your daily activities. Understanding how to
safely operate and care for this product should bring you years of trouble free operation and service.
Read and follow all instructions, warnings, and notes in this manual and all other accompanying literature
before attempting to operate this product for the first time. In addition, your safety depends upon you, as
well as your provider, caretaker, or healthcare professional in using good judgement.
If there is any information in this manual which you do not understand, or if you require additional assis-
tance for setup or operation, please contact your authorized Pride Provider. Failure to follow the instruc-
tions, warnings, and notes in this manual and those located on your Pride product can result in
personal injury or product damage and will void Pride’s product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter, or modify this product
or remove or render inoperable or unsafe any guards, shields, or other safety features of this product; fail,
refuse, or neglect to install any retrofit kits from time to time provided by Pride to enhance or preserve the
safe use of this product.
SHIPPING AND DELIVERY
Before using your scooter, make sure your delivery is complete as some components may be individually
packaged. If you do not receive a complete delivery, please contact your authorized Pride Provider imme-
diately. Where damage has occurred during transport, either to the packaging or content, please contact
the delivery company responsible.
INFORMATION EXCHANGE
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear
about the safety and reliability of your new scooter, and about the service you received from your autho-
rized Pride Provider. Please notify us of any change of address, so we can keep you apprised of important
information about safety, new products, and new options that can increase your ability to use and enjoy
your scooter. Please feel free to contact us at the address below:
Pride Mobility Products Corporation
Attn.: Customer Care Department
182 Susquehanna Avenue
Exeter, PA 18643-2694
[email protected]
1-800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact
us and we will be glad to send you a new one immediately.

5
Pursuit www.pridemobility.com
II. SAFETY
PRODUCT SAFETY SYMBOLS
The symbols below are used on the scooter to identify warnings, mandatory actions, and prohibited
actions. It is very important for you to read and understand them completely.
Pinch/Crush points created during assembly.
Corrosive chemicals contained in battery.
EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.
Explosive conditions exist!
Read and follow the information in the owner’s manual.
Maximum seating weight.

6www.pridemobility.com Pursuit
II. SAFETY
Place unit on level ground and stand to one side when changing from drive mode
to freewheel mode or freewheel mode to drive mode.
Locked and in drive mode.
Unlocked and in freewheel mode.
Do not remove anti-tip wheels.
Wear safety goggles.
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive
conditions.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.

7
Pursuit www.pridemobility.com
II. SAFETY
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access.
Do not connect an extension cord to the AC/DC converter or the battery charger.
Keep tools and other metal objects away from battery terminals. Contact with
tools can cause electrical shock.
Do not allow unsupervised children to play near the scooter while the batteries
are charging.
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Do not place the scooter in freewheel mode when on an incline or decline.
Keep your hands away from the tires when driving. Be aware that loose fitting
clothing can become caught in drive tires.

8www.pridemobility.com Pursuit
II. SAFETY
Battery charger for indoor use only.
Disposal and recycling - Contact your authorized Pride Provider for information on
proper disposal and recycling of your Pride product and its packaging.
Contains Lead.

9
Pursuit www.pridemobility.com
II. SAFETY
GENERAL
MANDATORY! Do not operate your new scooter for the first time without completely read-
ing and understanding this owner’s manual.
Your scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an
extensive variety of products to best fit the individual needs of the scooter user. Please be aware that the
final selection and purchasing decision regarding the type of scooter to be used is the responsibility of the
scooter user, who is capable of making such a decision, and his/her healthcare professional (i.e., medical
doctor, physical therapist, etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted
the scooter to the user and has assisted the prescribing healthcare professional and/or the authorized Pride
Provider in the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the scooter user will need to prac-
tice operating the scooter in the presence of a trained attendant. A trained attendant can be defined as a
family member or care professional specially trained in assisting a scooter user in various daily living
activities.
As you begin using your scooter during daily activities, you will probably encounter situations in which
you will need some practice. Simply take your time and you will soon be in full and confident control as
you maneuver through doorways, on and off elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help you become accustomed
to operating the scooter safely.
MODIFICATIONS
Pride has designed and engineered your scooter to provide maximum mobility and utility. However, under
no circumstances should you modify, add, remove, or disable any feature, part, or function of your scooter.
WARNING! Do not modify your scooter in any way not authorized by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move your scooter by any of its removable parts,
including the armrests, seat, or shroud.
PRE-RIDE SAFETY CHECK
Get to know the feel of your scooter and its capabilities. Pride recommends that you perform a safety check
before each use to make sure your scooter operates smoothly and safely.

10 www.pridemobility.com Pursuit
II. SAFETY
Perform the following inspections prior to using your scooter:
Check for proper tire inflation. Maintain but do not exceed the psi/bar/kPa air pressure rating indicated
on each tire if equipped with pneumatic tires.
Check all electrical connections. Make sure they are tight and not corroded.
Check all harness connections. Make sure they are secured properly.
Check the brakes.
Check battery charge.
If you discover a problem, contact your authorized Pride Provider for assistance.
TIRE INFLATION
If your scooter is equipped with pneumatic tires, you should check or have the air pressure checked at least
once a week. Proper inflation pressures will prolong the life of your tires and help ensure the smooth
operation of your scooter.
WARNING! It is critically important that the psi/bar/kPa air pressure rating indicated on
the tire be maintained in pneumatic tires at all times. Do not underinflate or overinflate
your tires. Low pressure may result in loss of control, and overinflated tires may burst.
Failure to maintain the psi/bar/kPa air pressure rating indicated on the pneumatic tires
at all times may result in tire and/or wheel failure.
WARNING! Inflate your scooter tires from a regulated air source with an available pres-
sure gauge. Inflating your tires from an unregulated air source could overinflate them,
resulting in a burst tire.
WEIGHT LIMITATIONS
Your scooter is rated for a maximum weight capacity. Refer to the specifications table for information.
Keep in mind that the maximum weight capacity includes the combined weight of the user and any acces-
sories mounted to the scooter.
MANDATORY! Stay within the specified weight capacity for your scooter. Exceeding the
weight capacity voids your warranty. Pride will not be held responsible for injuries and/
or property damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your scooter. Carrying passengers on your
scooter may affect the center of gravity, resulting in a tip or a fall.
INCLINE INFORMATION
More and more buildings have ramps with specified degrees of inclination, designed for easy and safe
access. Some ramps may have turning switchbacks (180-degree turns) that require you to have good cor-
nering skills on your scooter.
Proceed with extreme caution as you approach the downgrade of a ramp or other incline.
Take wide swings with your scooter around any tight corners. If you do that, the scooter’s rear wheels
will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing corners.
When driving down a ramp, keep the scooter’s speed adjustment set to the slowest speed setting to
ensure a safely controlled descent.
Avoid sudden stops and starts.
NOTE: If the tire on your scooter lists the psi rating only, use the following conversion formulas to find
the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.

11
Pursuit www.pridemobility.com
II. SAFETY
When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and
then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the
slowest setting and driving in the forward direction only. If your scooter starts to move down the incline
faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control
lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.
WARNING! When on any sort of an incline or decline, never place the scooter in
freewheel mode, especially when seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the
face of the incline. Drive your scooter straight up the incline. This greatly
reduces the possibility of a tip or a fall. Always exercise extreme caution when
negotiating an incline.
WARNING! Do not drive your scooter across the side of an incline or diagonally up
or down an incline; do not stop, if possible, while driving up or down an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e.,
areas covered with snow, ice, cut grass, or wet leaves).
WARNING! Even though your scooter is capable of climbing slopes greater than
those listed in the production specifications, do not, under any circumstances,
exceed the incline guidelines or any other specifications presented in this man-
ual. Doing so could cause instability in your scooter.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do
not necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made,
not designed specifically for scooters.
Tests were conducted with the scooter’s seat in the highest position and adjusted rearward on the seat base
to its farthest rearward position. Use the specification information as a guideline. Your scooter’s ability to
travel up inclines is affected by your weight, your scooter’s speed, your angle of approach to the incline,
and your scooter setup.
WARNING! Any attempt to climb or descend a slope steeper than what is listed in the
product specifications may put your scooter in an unstable position and cause it to tip.
WARNING! Never carry an oxygen tank weighing more than 15 lbs. (6.8 kg). Never fill the
front or rear basket with contents exceeding 15 lbs. (6.8 kg).

12 www.pridemobility.com Pursuit
II. SAFETY
Figure 2. Increased Stability Driving Position
Figure 1. Normal Driving Position
When you approach an incline, it is best to lean forward. See figures 1 and 2. This shifts the center of
gravity of you and your scooter toward the front of the scooter for improved stability.
NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the
powered scooter may "roll back" approximately 1 foot (30.48 cm) before the brake engages. If the
throttle control lever is released while moving in reverse, the powered scooter may "roll back" approx-
imately 3 feet (1 meter) before the brake engages.
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility
of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),
uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction
(such as passing from a grassy area to a paved area – especially at high speed while turning), and abrupt
directional changes. High cornering speeds are not recommended. If you feel that you may tip over in a
corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your scooter
from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable center of
gravity. When using your scooter at higher speeds, do not corner sharply. This greatly
reduces the possibility of a tip or fall.
BRAKING INFORMATION
Your scooter is equipped with these powerful brake systems:
Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the
center/stop position.
Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or
when power is removed from the system for any reason.

13
Pursuit www.pridemobility.com
II. SAFETY
OUTDOOR DRIVING SURFACES
Your scooter is designed to provide optimum stability under normal driving conditions—dry, level sur-
faces composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when
you will encounter other surface types. For this reason, your scooter is designed to perform admirably on
packed soil, grass, and gravel. Feel free to use your scooter safely on lawns and in park areas.
Avoid driving on uneven terrain and/or soft surfaces.
Avoid tall grass that can become tangled in the running gear.
Avoid loosely packed gravel and sand.
Do not use your scooter in fresh or salt water.
Do not use your scooter at the edge of a stream, lake, or ocean
If you feel unsure about a driving surface, avoid that surface.
PUBLIC STREETS AND ROADWAYS
WARNING! You should not operate your scooter on public streets and roadways. Be
aware that it may be difficult for traffic to see you when you are seated on your scooter.
Obey all local pedestrian traffic rules. Wait until your path is clear of traffic, and then
proceed with extreme caution.
STATIONARY OBSTACLES (STEPS, CURBS, ETC.)
WARNING! Do not drive near raised surfaces, unprotected ledges, and/or drop-offs
(curbs, porches, stairs, etc.).
WARNING! Do not attempt to have your scooter climb or descend an obstacle that is
inordinately high.
WARNING! Do not attempt to have your scooter proceed backward down any step, curb,
or other obstacle. This may cause the scooter to tip.
WARNING! Be sure your scooter is traveling perpendicular to any curb you may be
required to ascend or descend. See figures 3 and 3A.
WARNING! Even though your scooter may be capable of handling greater obstacles,
Pride recommends that you do not attempt to negotiate a curb that has a height greater
than 2 in. (5 cm). Doing so could cause instability in your scooter.
Figure 3. Correct Curb Approach Figure 3A. Incorrect Curb Approach

14 www.pridemobility.com Pursuit
INCLEMENT WEATHER PRECAUTIONS
Exposure of your scooter to inclement weather conditions should be avoided whenever possible. If sud-
denly caught up in rain, snow, severe cold or heat while operating your scooter, proceed to shelter at the
earliest opportunity. Thoroughly dry your scooter before storing, charging, or operating your scooter.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery sur-
faces can cause damage to the scooter and electrical system. Maintain and store your
scooter in a dry and clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of
upholstered and non-upholstered items on the scooter, possibly resulting in skin irrita-
tion. Exercise caution when using your scooter in extremely hot or cold conditions or
when exposing your scooter to direct sunlight for prolonged periods of time.
FREEWHEEL MODE
Your scooter is equipped with a manual freewheel lever that, when engaged, allows the scooter to be
pushed. For more information about how to place your scooter into and out of freewheel mode, see III.
“Your Scooter.”
WARNING! When your scooter is in freewheel mode, the braking system is disengaged.
 Disengage the drive motors only on a level surface.
 Ensure the key is removed from the key switch.
 Stand to the side of the scooter to engage or disengage freewheel mode. Never sit on a
scooter to do this.
 After you have finished pushing your scooter, always return it to the drive mode to lock
the brakes.
An added feature built into the scooter is “push-too-fast” protection which safeguards the scooter against
gaining excessive speed while in freewheel mode.
“Push-too-fast” operates differently depending on which of two conditions exists:
If the key is switched “off” while in freewheel mode, the scooter’s controller activates regenerative
braking when the scooter is pushed faster than a maximum threshold which has been preprogrammed.
In this case, the controller is acting as a speed governor.
If the key is switched “on” while in freewheel mode, you will encounter considerable resistance at any
speed. This prevents the scooter from gaining unwanted momentum should the manual freewheel lever
inadvertently be released while driving the scooter.
STAIRS AND ESCALATORS
Scooters are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! Do not use your scooter to negotiate steps or escalators.
DOORS
Determine if the door opens toward or away from you.
Use your hand to turn the knob or push the handle or push-bar.
Drive your scooter gently and slowly forward to push the door open. Or drive your scooter gently and
slowly backwards to pull the door open.
II. SAFETY

15
Pursuit www.pridemobility.com
II. SAFETY
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the door(s).
If you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge
or allow the rubber door edge to contact the scooter and the door will reopen.
Use care that pocketbooks, packages, or scooter accessories do not become caught in elevator doors.
NOTE: If your scooter’s turning radius is greater than 60 in. (152.4 cm) it may be difficult to maneuver
in elevators and building entrances. Use caution when attempting to turn or maneuver your scooter in
small spaces, and avoid areas that might pose a problem.
LIFT SYSTEMS/ELEVATION PRODUCTS
If you will be transporting your scooter during travel, you may find it necessary to use a vehicle-mounted
lift system or elevation product to aid in transportation. Pride recommends that you closely review the
warnings, instructions, specifications, and safety information set forth by the manufacturer of the lift/
elevation product before using that product.
WARNING! Not all lift systems/elevation products are rated for use with an occupied
mobility device. Pride recommends that you do not remain seated in your scooter when
it is being used in connection with any type of lift system/elevation product unless:
 That product is rated for occupied use by the manufacturer.
You are able to occupy your mobility device in strict conformity with the warnings,
instructions, specifications, and safety guidelines set forth by the manufacturer.
WARNING! Always turn off the power to the scooter when you are being transferred via
an elevation product. Failure to do so may result in accidental throttle control lever con-
tact, resulting in unintended movement and personal injury or product damage.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information.
MANDATORY! Battery posts, terminals, and related accessories contain lead
and lead compounds. Wear goggles and gloves when handling batteries and
wash hands after handling.
WARNING! Scooter batteries are heavy. See specifications table. If you are
unable to lift that much weight, be sure to get help. Use proper lifting techniques
and avoid lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen
battery. Charging a frozen battery may result in damage to the battery.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables
must be connected to positive (+) battery terminals/posts. BLACK (-) cables must
be connected to negative (-) battery terminals/posts. Protective caps should be
installed over all battery terminals. REPLACE cables immediately if damaged.
BATTERY DISPOSAL AND RECYCLING
If you encounter a damaged or cracked battery, immediately enclose it in a plastic bag. Contact your local
waste disposal agency or your authorized Pride Provider for instructions on disposal and battery recycling,
which is our recommended course of action.
PREVENTING UNINTENDED MOVEMENT
WARNING! If you anticipate being seated in a stationary position for an extended period
of time, turn off the power. This will prevent unexpected motion from inadvertent throttle
control lever contact.

16 www.pridemobility.com Pursuit
II. SAFETY
MOTOR VEHICLE TRANSPORT
Pride recommends that you do not remain seated in your scooter while traveling in a motor vehicle. The
scooter should be stowed in the trunk of a car or in the back of a truck or van with the batteries removed
and properly secured. In addition, all removable scooter parts, including the armrests, seat, and shroud
should be removed and/or properly secured during motor vehicle transport.
WARNING! Although your scooter may be equipped with a positioning belt, this belt is not
designed to provide proper restraint during motor vehicle transport. Anyone traveling in
a motor vehicle should be properly secured in the motor vehicle seat with safety belts
fastened securely.
WARNING! Do not sit on your scooter while it is in a moving vehicle.
WARNING! Always be sure your scooter and its batteries are properly secured when it is
being transported. Batteries should be secured in an upright position and protective caps
should be installed on the battery terminals. Batteries should not be transported with any
flammable or combustible items.
GETTING ONTO AND OFF OF YOUR SCOOTER
Getting onto and off of your scooter requires a good sense of balance. Please observe the following safety
tips when getting onto and off of your scooter:
Remove the key from the key switch.
Ensure that your scooter is not in freewheel mode. See III. “Your Scooter.”
Make certain that the seat is secured into place.
Pivot the armrests up to make getting onto and off of the scooter easier.
WARNING! Position yourself as far back as possible in the scooter seat to prevent the
scooter from tipping.
WARNING! Avoid putting all of your weight on the scooter armrests and do not use the
armrests for weight bearing purposes, such as transfers. Such use may cause the
scooter to tip, resulting in a fall from the scooter and personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the
scooter to tip.
REACHING AND BENDING
Avoid reaching or bending while driving your scooter. Bending forward creates the risk of accidental
throttle control lever contact. Bending to the side while seated creates the risk of tipping. It is important to
maintain a stable center of gravity and keep the scooter from tipping. Pride recommends that the scooter
user determine his/her personal limitations and practice bending and reaching in the presence of a qualified
attendant.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
scooter deck or from either side of the scooter. Movements such as these may change
your center of gravity and the weight distribution of the scooter and cause your scooter
to tip.
PROHIBITED! Keep your hands away from the tires when driving. Be aware that loose
fitting clothing can become caught in drive tires.

17
Pursuit www.pridemobility.com
II. SAFETY
POSITIONING BELTS
Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for deter-
mining your requirement for a positioning belt in order to operate your scooter safely.
WARNING! If you require a positioning belt to safely operate your scooter, make sure it
is fastened securely.
PRESCRIPTION DRUGS/PHYSICAL LIMITATIONS
The scooter user must exercise care and common sense when operating his/her scooter. This includes
awareness of safety issues when taking prescribed or over-the-counter drugs or when the user has specific
physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medi-
cation or if you have certain physical limitations. Some medications and limitations may
impair your ability to operate your scooter in a safe manner.
ALCOHOL/SMOKING
The scooter user must exercise care and common sense when operating his/her scooter. This includes
awareness of safety issues while under the influence of alcohol or while smoking.
WARNING! Do not operate your scooter while you are under the influence of alcohol, as
this may impair your ability to drive safely.
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in
your scooter, although the scooter has passed the necessary testing requirements for
cigarette smoking. You must adhere to the following safety guidelines if you decide to
smoke cigarettes while seated in your scooter.
 Do not leave lit cigarettes unattended.
 Keep ashtrays a safe distance from the seat cushions.
 Always make sure cigarettes are completely extinguished before disposal.

18 www.pridemobility.com Pursuit
II. SAFETY
ELECTROMAGNETIC AND RADIO FREQUENCY INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency
waves can have an adverse effect on the performance of electrically-powered mobility
vehicles.
Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile
two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters,
wireless computer links, microwave signals, paging transmitters and medium-range mobile transceivers
used by emergency vehicles. In some cases, these waves can cause unintended movement or damage to
the control system. Every electrically-powered mobility vehicle has an immunity (or resistance) to EMI.
The higher the immunity level, the greater the protection against EMI. This product has been tested and
has passed at an immunity level of 20 V/M.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio
transmitters may cause unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these items while operating your
mobility vehicle and avoid coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobil-
ity vehicle can increase the susceptibility of the vehicle to EMI. Do not modify your
scooter in any way not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance
of other electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your scooter off as soon as it is safe to do so. Contact
your authorized Pride Provider to report the incident.

19
Pursuit www.pridemobility.com
III. YOUR SCOOTER
TILLER CONSOLE
The tiller console houses all of the controls needed to drive your scooter, including the speed adjustment
dial, key switch, battery condition meter, horn buttons, turn signal buttons, tiller adjustment lever, and the
throttle control lever. See figure 4.
PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller
console does become exposed to moisture, do not attempt to operate your scooter until
the tiller console has dried thoroughly.
Figure 4. Tiller Console Components
SPEED ADJUSTMENT DIAL
HORN BUTTON
BATTERY CONDITION METER
THROTTLE
CONTROL
LEVER
Speed Adjustment Dial
This dial allows you to preselect and limit your scooter’s top speed.
The image of the tortoise represents the slowest speed setting.
The image of the hare represents the fastest speed setting.
Key Switch
Insert the key into the key switch and turn it clockwise to power up (turn on) your scooter.
Turn the key counterclockwise to power down (turn off) your scooter.
WARNING! If the key is turned to the “off” position while your scooter is in motion, the
electronic brakes will engage and your scooter will come to an abrupt stop!
Battery Condition Meter
When the key is fully inserted and turned clockwise to power up your scooter, this meter indicates the
approximate battery voltage strength. For further information on battery charging, see IV. “Batteries and
Charging.”
RIGHT TURN SIGNAL BUTTON
KEY SWITCH
THROTTLE
CONTROL
LEVER
HORN BUTTON
RIGHT TURN SIGNAL INDICATOR
LEFT TURN SIGNAL INDICATOR
LIGHTS SWITCH
HAZARD LIGHTS SWITCH
LEFT TURN SIGNAL BUTTON
TILLER ADJUSTMENT LEVER
STATUS LED
HI-LOW SWITCH

20 www.pridemobility.com Pursuit
III. YOUR SCOOTER
Status LED
The status LED alerts you to electrical problems that may occur with the scooter. The LED remains con-
stantly lit while your scooter is on. If your scooter develops an electrical problem, the status LED will flash
a code. See VIII. “Basic Troubleshooting” for flash codes.
Horn Buttons
These buttons activate a warning horn. Your scooter must be powered up for the horn to be operational.
Do not hesitate to use the warning horn when doing so may prevent accident or injury.
Turn Signal Buttons
Use these buttons to turn on the left and right turn signal (amber) lights.
Push the left button to activate the left turn signal light. The turn signal indicator LED located in the
battery condition meter will flash.
Push the right button to activate the right turn signal light. The turn signal indicator LED located in the
battery condition meter will flash.
The turn signals are timed to shut off automatically.
Hazard Lights Switch
This switch activates the 4-way flashers on your scooter.
Toggle the hazard lights switch forward to turn on the flashers.
Toggle the hazard lights switch rearward to turn off the flashers.
Throttle Control Lever
This lever allows you to control the forward speed and the reverse speed of your scooter up to the maxi-
mum speed you preset with the speed adjustment dial.
To Move Forward, use either of the following:
Use your left thumb to push the left side of the throttle control lever.
Use your right hand fingers to pull back on the right side of the throttle control lever.
To Move Rearward, use either of the following:
Use your right thumb to push the right side of the throttle control lever.
Use your left hand fingers to pull back on the left side of the throttle control lever.
Release the throttle control lever and allow your scooter to come to a complete stop before engaging the
other side of the lever. When the throttle control lever is completely released, it automatically returns to
the center “stop” position and engages your scooter’s brakes.
Lights Switch
This switch controls your scooter’s lighting system.
Toggle the switch forward to turn on the front lower light.
Toggle the switch rearward to turn off the front lower light.
WARNING! Scooter users are required to use their lights when visibility is restricted—day
or night.
