Pride Mobility The Ultimate In Style & Performance User manual

The Ultimate In Style & Performance
®
Owner’s Manual
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX25 5HA
www.pridemobility.com
ATTENTION:
Read everything
in this manual
before operating
your Scooter

2Cyclone
SAFETY GUIDELINES
Please read and follow all instructions in this owners manual before attempting to operate your Scooter
for the first time. If there is anything in this manual you do not understand, or if you require additional
assistance for set-up, contact your authorised Pride provider.
Using your Pride product safely depends upon your diligence in following the warnings, cautions, and
instructions in this owners manual. Using your Pride product safely also depends upon your own good
udgement and/or common sense, as well as that of your provider, caregiver, and/or healthcare profes-
sional. Pride is not responsible for in uries and/or damage resulting from any persons failure to follow
the warnings, cautions, and instructions in this owners manual. Pride is not responsible for in uries and/
or damage resulting from any persons failure to exercise good udgement and/or common sense.
The symbols below are used throughout this owners manual to identify warnings and cautions. It is very
important for you to read and understand them completely.
WARNING! Failure to heed the warnings in this owners manual may result in personal injury.
CAU ION! Failure to heed the cautions in this owners manual may result in damage to your
Scooter.
Copyright © 2001
Pride Mobility Products, Ltd.
INFMANU1547/REV A/APRIL 2001

3
Cyclone
CONTENTS
I. INTRO UCTION......................................................................................................................... 4
II. SAFETY ......................................................................................................................................... 6
III. SPECIFICATIONS ................................................................................................................... 15
IV. YOUR CYCLONE ...................................................................................................................... 1
V. BATTERIES AN CHARGING ............................................................................................ 23
VI. OPERATION ............................................................................................................................... 2
VII. COMFORT A JUSTMENTS................................................................................................ 29
VIII. ISASSEMBLY AN ASSEMBLY ..................................................................................... 32
IX. OPTIONAL ACCESSORIES ................................................................................................. 35
X. BASIC TROUBLESHOOTING ............................................................................................. 36
XI. CARE AN MAINTENANCE ................................................................................................ 38
XII. WARRANTY ............................................................................................................................... 40

4Cyclone
I. INTRODUCTION
Welcome to Pride Mobility Products, Ltd. (Pride). Congratulations on the purchase of your new Pride Scooter.
Your Scooter design combines the most advanced state-of-the-art components with modern, attractive styling.
We are certain that the design features and trouble-free operation will add convenience to your daily living and
ensure complete satisfaction.
At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before
you attempt to operate your Scooter for the first time. These instructions were produced for your benefit.
Your understanding of these instructions is essential for the safe operation of your new Pride Scooter.
Pride is not liable for damage to property or personal injury arising out of the unsafe use of a Pride Scooter. Pride
is also not liable for any property damage or personal injury arising out of the failure of any person and or/user to
following the instructions and recommendations set forth in this manual or any other instructions or recommenda-
tions contained in other Scooter related literature issued by Pride or contained on the Pride Scooter itself.
This owners manual is compiled from the latest specifications and product information available at the time of
publication. We reserve the right to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual and the product you have purchased.
If you experience any problems with your Scooter that you are unable to solve, or if you do not feel capable of safely
following any of the instructions and/or recommendations as contained in this manual, please contact your authorised
Pride provider for assistance.
Once you understand how to operate and take care of your Scooter, we are certain that it will give you years of trouble-
free service and enjoyment.
Information Exchange
We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about the
safety and reliability of your new Pride Scooter and the service you received from your authorised Pride provider.
Please notify us of any change of address so we can keep you apprised of important information about safety, new
products, and new options that can increase your ability to use and enjoy your Pride Scooter. Please feel free to write us
at the address below:
Pride Mobility Products, Ltd.
Unit 106, Heyford Park Camp Road
Upper Heyford, Oxfordshire OX25 5HA

5
Cyclone
I. INTRODUCTION
Pride Owners Club
As a Pride product owner, you are invited to register your products warranty and enroll in the Pride Owners Club.
You may do so by filling out and returning your enclosed registration card or by visiting Prides web site at
www.pridemobility.com. As a registered member, each time you visit our site, you will have access to the most
interactive and honest educational venue available today for people with mobility needs, their families, and friends.
From our home page, click on the button that reads Owners Club to enter a page dedicated to current and
potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,
product and funding information, and interactive message boards. These message boards invite you to speak with
other Pride customers as well as Pride representatives who are available to assist you with any questions or
concerns you may have. You will receive a free gift simply for registering with the Pride Owners Club.
My Authorised Pride Provider Is:
Name:_______________________________________________________________________________
Address:_____________________________________________________________________________
Phone Number:________________________________________________________________________
Quic Reference Information:
Scooter Model:________________________________________________________________________
Serial Number:__________________________________________________________________________
Purchase Date:________________________________________________________________________
NOTE: If you ever lose or misplace your warranty card or this owners manual, write to us and we will be
glad to send you a new one immediately.

6Cyclone
II. SAFETY
GENERAL
WARNING! Do not operate your new Scooter for the first time without completely reading and
understanding this owners manual.
Your Scooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an exten-
sive variety of products to best fit the individual needs of the Scooter user. Please be aware that the final selection
and purchasing decision regarding the type of Scooter to be used is the responsibility of the Scooter user who is
capable of making such a decision and his/her healthcare professional (i.e., medical doctor, physical therapist,
etc.).
The contents of this manual are based on the expectation that a mobility device expert has properly fitted the
Scooter to the user and has assisted the prescribing healthcare professional and/or the authorised Pride provider in
the instruction process for the use of the product.
There are certain situations, including some medical conditions, where the Scooter user will need to practice
operating the Scooter in the presence of a trained attendant. A trained attendant can be defined as a family member
or care professional specially trained in assisting a Scooter user in various daily living activities.
As you begin using your Scooter during daily activities, you will probably encounter situations in which you will
need some practice. Simply take your time and you will soon be in full and confident control as you maneuver
through doorways, on and off elevators, up and down ramps, and over moderate terrain.
Below are some precautions, tips, and other safety considerations that will help the user become accustomed to
operating the Scooter safely.
MO IFICATIONS
Pride has designed and engineered your Scooter to provide maximum mobility and utility. A wide range of acces-
sories is available from your authorised Pride provider to further customize your Scooter to better suit your needs
and/or preferences. However, under no circumstances should you modify, add, remove, or disable any feature,
part, or function of your Scooter.
WARNING! Do not modify your Scooter in any way not authorised by Pride. Unauthorised modifica-
tions may result in personal injury and/or damage to your Scooter.

Cyclone
II. SAFETY
PRE-RI E SAFETY CHECK
Get to know the feel of your Scooter and its capabilities. Pride recommends that you perform a safety check
before each use to make sure your Scooter operates smoothly and safely. For details on how to perform these
necessary inspections, see XI. Care and Maintenance.
Perform the following inspections prior to using your Scooter:
nCheck for proper tyre inflation. Maintain 30-35 psi in each tyre (if equipped with pneumatic tyres).
nCheck all electrical connections. Make sure they are tight and not corroded.
nCheck all controller connections to the utility tray. Make sure they are secured properly.
nCheck the brakes.
nCheck battery charge.
WARNING! It is critically important that 30-35 psi tyre pressure be maintained in pneumatic tyres at
all times. Failure to maintain 30-35 psi tyre pressure in pneumatic tyres at all times may result in
catastrophic tyre and/or wheel failure, causing serious personal injury and/or damage to your
Scooter.
WARNING! Do not carry passengers on your Scooter. Carrying passengers on your Scooter may
result in personal injury and/or property damage.
If you discover a problem, contact your authorised Pride provider for assistance.
WEIGHT LIMITATIONS
Your Scooter is rated for a maximum 136-kg. weight limit.
INCLINE INFORMATION
More and more buildings have ramps with specified percents of inclination, designed for easy and safe access.
Some ramps may have turning switchbacks (180-degree turns) that require you to have good cornering skills on
your Scooter.
nProceed with extreme caution as you approach the downgrade of a ramp or other incline.
nTake wide swings with your Scooters front wheel(s) around any tight corners. If you do that, the Scooters
rear wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing
corners.
nWhen driving down a ramp, keep the Scooters speed adjustment set to the slowest speed setting to ensure a
safely controlled descent. See IV. Your Cyclone.
nAvoid sudden stops and starts.
WARNING! Exceeding the weight limit voids your warranty and may result in personal injury and
damage to your Scooter. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.

8Cyclone
II. SAFETY
When climbing an incline, try to keep your Scooter moving. If you must stop, start up again slowly, and then
accelerate cautiously. When driving down an incline, do so by setting the throttle control on the slowest setting and
driving in the forward direction only. If your Scooter starts to move down the incline faster than you anticipated or
desired, allow it to come to a complete stop by releasing the throttle control lever. Then push the throttle control
lever forward slightly to ensure a safely controlled descent.
WARNING! Any attempt to climb or descend a slope steeper than shown in figures 1 and 2 may put
your Scooter in an unstable position and cause it to tip, resulting in personal injury.
8.7%
10.5%
12.3%
14.1%
68 kg/
11 stone 90 kg/
14 stone 113 kg/
18 stone 136 kg/
21 stone
FIGURE 2. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 4-WHEEL CYCLONE
FIGURE 1. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 3-WHEEL CYCLONE
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your Scooter straight up the incline. his greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the Scooter in freewheel mode
while seated on it or standing next to it.
Handicap public access ramps are not subject to government regulation in all countries, and therefore do not
necessarily share the same standard percent of slope. Other inclines may be natural or, if man-made, not designed
specifically for Scooters. Figures 1 and 2 illustrate your Cyclones stability and its ability to climb grades under
various weight loads and under controlled testing conditions.
These tests were conducted with the Cyclones seat in the highest position and adjusted backward on the seat base
to its farthest rearward position. Use this information as a guideline. Your Cyclones ability to travel up inclines is
affected by your weight, your Scooters speed, your angle of approach to the incline, and your Scooter setup.
10.5%
90-113 kg
14-18 stone
12.3%
68 kg
11 stone
8.7%
136 kg
21 stone

9
Cyclone
FIGURE 4. INCREASED STABILITY DRIVING POSITION
FIGURE 3. NORMAL DRIVING POSITION
When you approach an incline, it is best to lean forward. See figures 3 and 4. This shifts the center of gravity of you
and your Cyclone toward the front of the Scooter for improved stability.
WARNING! Do not exceed the incline guidelines or any other specifications presented in this
manual.
II. SAFETY
CORNERING INFORMATION
Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility of
tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning), uneven road
surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction (such as passing
from a grassy area to a paved area  especially at high speed while turning), and abrupt directional changes. High
cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and
steering angle (i.e., lessen the sharpness of the turn) to prevent your Scooter from tipping.
WARNING! When cornering sharply, reduce your speed. When using your Scooter at higher
speeds, do not corner sharply. his greatly reduces the possibility of a tip or fall. o avoid personal
injury or property damage, always exercise common sense when cornering.

10 Cyclone
BRAKING INFORMATION
Your Scooter is equipped with two powerful brake systems:
1. Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/
stop position; and
2. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or when
power is removed from the system for any reason.
Brake engagement is far more abrupt at higher speeds. It is important that you know when the brakes will engage,
and that you are braced for the resulting deceleration.
WARNING! Your Scooter can decelerate very quickly. Do not decelerate or turn abruptly when
traveling at high speed unless absolutely necessary. If it is absolutely necessary to decelerate or
turn abruptly when traveling at high speed, brace yourself by gripping the tiller tightly and planting
your feet firmly against the floorboard. Users who cannot grip the tiller tightly and/or plant their feet
firmly against the floorboard should avoid decelerating from or turning abruptly at high speed, and
therefore should avoid traveling at high speed. Serious personal injury and property damage can
result from falling forward as your Scooter decelerates quickly unless you brace yourself firmly.
STATIONARY OBSTACLES (STEPS, KERBS, ETC.)
Proceed with extreme caution when driving near raised surfaces, unprotected ledges and/or drop-offs (kerbs,
porches, stairs, etc.).
WARNING! Do not attempt to have your Scooter climb or descend an obstacle that is inordinately
high. Serious personal injury and/or damage may result.
WARNING! Do not attempt to have your Scooter proceed backward down any step, kerb, or other
obstacle. his may cause the Scooter to tip and cause personal injury.
OUT OOR RIVING SURFACES
Your Scooter is designed to provide optimum stability under normal driving conditionsdry, level surfaces com-
posed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you will encoun-
ter other surface types. For this reason, your Scooter is designed to perform admirably on packed soil, grass, and
gravel. Feel free to use your Scooter safely on lawns and in park areas.
nReduce your Scooters speed when driving on uneven terrain and/or soft surfaces.
nAvoid tall grass that can become tangled in the running gear.
nAvoid loosely packed gravel and sand.
nIf you feel unsure about a driving surface, avoid that surface.
II. SAFETY

11
Cyclone
FREEWHEEL MO E
Your Scooter is equipped with a manual freewheel lever that when pulled up allows the Scooter to be pushed. For
more information about how to place your Scooter into and out of freewheel mode, see IV. Your Cyclone.
TYRE INFLATION
If your Scooter is equipped with pneumatic tyres, you should check or have the air pressure checked at least once
a week. Proper inflation pressures will prolong the life of your tyres and help ensure the smooth operation of your
Scooter.
WARNING! You should not operate your Scooter on public streets and roadways. Be aware that it
may be difficult for traffic to see you when you are seated on your Scooter. Obey all local pedestrian
traffic rules. Wait until your path is clear of traffic, and then proceed with extreme caution.
PUBLIC ROA S AN PARKING LOTS
NOTE: afety accessories like reflectors, fluorescent flags, and various lighting packages are available to
order from your authorised Pride provider.
II. SAFETY
WARNING! It is critically important that pneumatic tyres be inflated to 30-35 psi. Do not
underinflate or overinflate your tyres. Improper tyre pressure may result in catastrophic tyre and/or
wheel failure. Serious personal injury and/or property damage may result.
WARNING! Inflate your Scooter drive tyres from a regulated air source with an available pressure
gauge. Minimum air pressure for Scooter drive tyres is 30-35 psi. Inflating your tyres from an un-
regulated air source could overinflate them, resulting in a burst tyre and/or personal injury.
WARNING! Do not use your Scooter in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your Scooter in freewheel mode while seated on it.
Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your Scooter in freewheel mode while on an incline. he Scooter could
roll uncontrollably on its own, causing personal injury.
INCLEMENT WEATHER PRECAUTIONS
WARNING! Pride recommends that you do not operate your Scooter in icy or slippery conditions or
on salted surfaces (i.e., walks or roads). Such use may result in an accident, personal injury, or
adversely affect the performance and safety of your Scooter.
WARNING! Pride recommends that you do not expose your Scooter to any type of moisture at any
time (rain, snow, mist, or wash). Such exposure can damage your Scooter. Never operate your
Scooter if it has been exposed to moisture until it has dried thoroughly.

12 Cyclone
OORS
nDetermine if the door opens toward or away from you.
nUse your hand to turn the knob or push the handle or push-bar.
nDrive your Scooter gently and slowly forward to push the door open. Or drive your Scooter gently and slowly
backward to pull the door open.
ELEVATORS
Modern elevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or
allow the rubber door edge to contact the Scooter and the door will reopen.
nUse care that pocketbooks, packages, or Scooter accessories do not become caught in elevator doors.
LIFT/ELEVATION PRO UCTS
If you will be traveling with your Scooter, you may find it necessary to use a lift/elevation product to aid in transpor-
tation. Pride recommends that you closely review the instructions, specifications, and safety information set forth
by the manufacturer of the lift/elevation product before using that product.
II. SAFETY
WARNING! Do not use your Scooter to negotiate steps or escalators. You may cause injury to
yourself and to others and damage your Scooter.
STAIRS AN ESCALATORS
Scooters are not designed to travel up or down stairs or escalators. Always use an elevator.
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. his will prevent unexpected motion from inadvertent throttle control lever
contact. Failure to do so may result in personal injury.
WARNING! Scooter batteries weigh 11 kg (32 AH) or 14 kg (40 AH) each. If you are unable to lift
that much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
BATTERIES
In addition to following the warnings below, be sure to comply with all other battery handling information. For
more information about your Scooters batteries, see V.  Batteries and Charging.
PREVENTING UNINTEN E MOVEMENT

13
Cyclone
WARNING! Do not sit on your Scooter while it is in a moving vehicle. Personal injury and/or property
damage may result.
WARNING! Always be sure your Scooter and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your Scooter.
MOTOR VEHICLE TRANSPORT
Currently, there are no standards approved for tie-down systems in a moving vehicle of any type to transport a
person while seated in a Scooter.
Although your Scooter may be equipped with a positioning belt, this belt is not designed to provide proper restraint
during motor vehicle transport. Anyone traveling in a motor vehicle should be properly secured in the motor
vehicle seat with safety belts fastened securely.
GETTING ONTO AN OFF OF YOUR SCOOTER
Getting onto and off of your Scooter requires a good sense of balance. Please observe the following safety tips
when getting onto and off of your Scooter:
nPower down your Scooter. See VI. Operation.
nEnsure that your Scooter is not in freewheel mode. See IV. Your Cyclone.
nMake certain that the seat is locked into place and the key is removed from the key switch.
nThe seat armrests can be flipped up to make getting on and off the Scooter easier.
WARNING! Position yourself as far back as possible in the Scooter seat to prevent the Scooter from
tipping and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the
Scooter to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the floorboard. Such use may cause the Scooter to
tip and cause personal injury.
II. SAFETY
POSITIONING BELTS
Your authorised Pride provider, therapist(s), and other healthcare professionals are responsible for determining
your requirement for a positioning belt in order to operate your Scooter safely.
WARNING! If you require a positioning belt to safely operate your Scooter, make sure it is fastened
securely. Serious personal injury may result if you fall from the Scooter.

14 Cyclone
II. SAFETY
REACHING AN BEN ING
Avoid reaching or bending while driving your Scooter. When reaching, bending, or leaning while seated on your
Scooter, it is important to maintain a stable center of gravity and keep the Scooter from tipping. Pride recommends
that the Scooter user determine his/her personal limitations and practice bending and reaching in the presence of a
qualified healthcare professional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the Scooter and cause your Scooter to tip, possibly resulting in
personal injury. Keep your hands away from the tyres when driving.
PRESCRIPTION RUGS/PHYSICAL LIMITATIONS
The Scooter user must exercise care and common sense when operating his/her Scooter. This includes awareness of
safety issues when taking prescribed or over-the-counter drugs or when the user has specific physical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or if
you have certain physical limitations. Some medications and limitations may impair your ability to
operate your Scooter in a safe manner.
ALCOHOL
The Scooter user must exercise care and common sense when operating his/her Scooter. This includes awareness
of safety issues while under the influence of alcohol.
WARNING! Do not operate your Scooter while you are under the influence of alcohol, as this may
impair your ability to drive safely.
REMOVABLE PARTS
WARNING! Do not attempt to lift or move a Scooter by any of its removable parts. Personal injury
and damage to the Scooter may result.

15
Cyclone
FIGURE 5. CYCLONE DIMENSIONS
III. SPECIFICATIONS
61 cm
162,5 cm
122 cm
48 cm
44 cm
61- 73 cm
127 cm
131 cm
4-WheelTurning Radius
4-Wheel Length
3-Wheel Length
3-WheelTurning Radius
9 cm
90˚,100˚
102˚,105˚
67 - 73 cm
Adjustable
20 - 30 cm
122- 132 cm
42 - 52 cm

16 Cyclone
III. SPECIFICATIONS
Model Numbers Three-Wheel: SPSCUK4000CRED (Candy Apple Red), SPSCUK4000VBLU (Viper Blue),
SPSCUK4000FGRE (Forest Green), SPSCUK4000OBLK (Onyx Black),
Four-Wheel: SPSCUK4400CRED, SPSCUK4400VBLU, SPSCUK4400FGRE, SPSCUK4400OBLK
Length 127 cm (3-Wheel), 131 cm (4-Wheel)
Width 61 cm
Tyres Type: Pneumatic; Front: 8 cm x 25.5; Rear: 10 cm x 25.5 cm
Weight Capacity 136 kg Maximum
Battery Type Two 12-volt, 32 AH, U-1 type, SLA (sealed lead-acid) or two 12 volt, 40 AH, SLA
Horsepower 2 hp (peak)
Charger Onboard 3-amp charger
Speed (max) Variable up to 8.4 km/hr (12 km/hr with Turbo mode)
Maximum Grade Variable (refer to figures 1 and 2)
Range, Maximum (12V, 40 AH batteries) Up to 32-49 km
(12V, 32 AH batteries) Up to 32-40 km
Turning Radius 3-Wheel: 122 cm; 4-Wheel: 162,5 cm
Body Colours Painted: Candy Apple Red, Viper Blue, Forest Green, and Onyx Black
Seating Standard Option Seating Style: Sport Scooter high back with headrest and sliders mounted on a standard
seat post
Standard Seating Features:
•Adjustable armrest height, width, and angle
•Four adjustable seatback angles
•Five position seat height adjustment
Dimensions: 48 cm width x 44 cm depth (usable) x 67 cm - 73 cm height (usable)
Material: Vinyl: Grey, Beige, Black
Fabric: Grey, Gold
Armrests: Upholstered, matching vinyl or fabric with cosmetic edge guards
Adjustable seat height from Scooter deck: variable between 42 cm to 52 cm
Included Features Full directional lighting package with front “running lights”; deluxe motorcycle-style rearview mirror (can be
installed on left or right side of tiller); lighted touch pad control console; front basket; user adjustable sliding
seat; full “soft-ride” shock absorber-equipped suspension; four-position adjustable seat-back angle;
adjustable armrest width, height & angle; dual microprocessor-based motor controller system; modular
controller/charger assembly; infinitely adjustable tiller with auto-leveling console and shock dampening
action; standard front & rear integrated bumpers; easily accessible charger port receptacle, circuit breaker
and freewheel lever; standard non-marring, high density polyurethane bumper(s); battery well accepts
32 AH or 40 AH batteries; standard battery fixation straps; diagnostic beep codes; Turbo function; speed
control technology (SCT); brushless motor/controller
Brakes Electronic disc, manual freewheel
Rear Wheel Drive Sealed Transaxle - 24V
Wheels Pride Micro-Mag aluminum alloy wheels in Red/Black/or Gold
Tiller Type Infinitely adjustable with auto-leveling console
Freewheel Mechanism Availability Lever at lower right portion of rear shroud
Weight of Scooter TOTAL Weight of Cyclone (with two 12V, 40 AH batteries) = 96 kg (3-Wheel); 103 kg (4-Wheel)
TOTAL Weight of Cyclone (with two 12V, 32 AH batteries) = 90 kg (3-Wheel); 97 kg (4-Wheel)
Component breakdown:
Front section: 20.5 kg(3-Wheel), 28 kg (4-Wheel)
Rear section (without batteriesor rear shroud): 29 kg
Rear plastic shroud: 1.8kg
Seat: 18.5 kg
Batteries (note: two batteries are required per Scooter): 12V, 40 AH 14 kg (each)
12V, 32 AH11 kg (each)
Basket: 0.6 kg
Front-to-Rear Lockup Dual lock pins & camlock levers
Ground Clearance 9 cm
Accessories Rear basket; cup holder; portable canopy; safety flag; lap belt

1
Cyclone
Your Cyclone is a motorized electric Sport Scooter meant for indoor/outdoor use. The Scooter is designed to
travel primarily on smooth surfaces such as pavement, roads, parking lots, floors, and driveways. For easy
transportation or storage, you can disassemble your Cyclone into seven components. See figure 6.
IV. YOUR CYCLONE
CONTROL CONSOLE ASSEMBLY
The control console assembly houses all of the controls you need to drive your Cyclone, including the speed adjustment
buttons, throttle control levers, battery condition LED, maximum speed LED, on/off indicator LED, clock, running
lights button, headlight button, headlight status LED, horn buttons, turn indicator buttons, hazard light button, Turbo
button, and the Turbo ready indicator LED. See figure .
FIGURE 7. CONTROL CONSOLE ASSEMBLY
BATTERY CONDITION LED
HORN
BUTTON
SPEED ADJUSTMENT BUTTON
THROTTLE CONTROL LEVER (REVERSE)
HORN
BUTTON
CLOCK
HA ARD LIGHT BUTTON
LEFT TURN INDICATOR BUTTON
HEADLIGHT BUTTON
RIGHT TURN INDICATOR
BUTTON
THROTTLE CONTROL LEVER (FORWARD)
ON/OFF INDICATOR LED
RUNNING LIGHTS BUTTON
HEADLIGHT
STATUS LED
MAXIMUM SPEED LED
SPEED ADJUSTMENT BUTTON
TURBO BUTTON
TURBO READY
INDICATOR LED
Handbrake Lever (Not shown)
Your Scooter is equipped with a handbrake lever, located on the tiller handle. This lever provides you with
additional stopping power.
nRelease the throttle and gently squeeze the handbrake lever to come to a stop.
FIGURE . CYCLONE COMPONENTS
BATTERIES
REAR SECTION
FRONT SECTION
SEAT
REAR SHROUD
BASKET

18 Cyclone
WARNING! Do not expose the control console assembly to moisture. In the event that the console
does become exposed to moisture, do not attempt to operate your Cyclone until the console has
thoroughly dried.
Key Switch (not shown)
nFully insert the key into the key switch and turn it clockwise to power up (turn on) your Cyclone.
IV. YOUR CYCLONE
nTurn the key counterclockwise to power down (turn off) your Cyclone.
Speed Adjustment Buttons
These adjustment buttons enable you to pre-select and limit your Cyclones top speed.
nPress the image of the tortoise to decrease the Cyclones pre-selected maximum speed.
nPress the image of the hare to increase the Cyclones pre-selected maximum speed.
Maximum Speed LE
The LED lights up to display the maximum speed you have pre-selected with the speed adjustment buttons.
NOTE: The more green bars that are lit on the maximum speed LED, the faster your pre-selected maxi-
mum speed will be.
Throttle Control Lever
This lever allows you to control the forward speed and the reverse speed of your Cyclone up to the maximum
speed you pre-select with the speed adjustment buttons.
nPlace your right hand on the right handgrip and your left hand on the left handgrip.
nUse your right thumb to push the right side of the lever to disengage your Cyclones brakes and move forward.
nRelease the lever and allow your Cyclone to come to a complete stop before pushing the other side of the lever
to move in reverse.
nWhen the throttle control lever is completely released, it automatically returns to the center stop position and
engages your Cyclones brakes.
Battery Condition LE
When the key is turned to the on position, this LED gives an approximate reading of your Cyclones battery
voltage level.
nGreen indicates the Cyclones batteries are fully charged.
nYellow indicates that the Cyclones battery voltage level is getting low and will require a charge soon.
nRed indicates that your Cyclones battery voltage level is very low, and the batteries should be recharged as
soon as possible.
Running Lights Button
This button controls your Cyclones running lights.
nPress the button once to turn on your Cyclones running lights.
nPress the button again to turn off your Cyclones running lights.
Headlight Status LE
The green LED will light when your Cyclones headlight is turned on.
WARNING! If the key is moved to the off position while your Cyclone is in motion, the electronic
brakes engage and your Cyclone comes to an abrupt stop!

19
Cyclone
Headlight Button
If more light is needed in addition to the running lights, use the headlight.
NOTE: In order for the headlight to work, you must first have the running lights on.
nPress the button once to turn on the Cyclones headlight.
nPress the button again to turn off the Cyclones headlight.
Horn Button
The key must be inserted and turned to the on position for the horn to be operational.
nThis button activates a warning horn.
nDo not hesitate to use the warning horn when its use could prevent accident or injury.
Hazard Light Button
This button activates the 4-way yellow flashers on your Sport Scooter.
nPress the button once to turn on the flashers.
nPress the button again to turn off the flashers.
Turn Indicator Buttons
nPress the appropriate turn indicator button once to activate it.
nYour Cyclones turn indicators are timed to shut off automatically.
On/Off Indicator LE
When the key of the Cyclone is turned to the on position, the green on/off indicator LED will light to indicate that
your Cyclone is powered up (on).
Clock
NOTE: For safe shipping, the clock is packed separately.
Remove the clock from its packing, set the time (see below), then insert it into its place in the control console
assembly. See figure .
Setting the Time
The time is set in the same manner as a wristwatch.
nPull the crown out.
nRotate the crown to set the time, then push the crown back in.
Battery Removal and Replacement
NOTE: If you dont feel confident in replacing the clock battery, please take the clock to any watch retailer
to perform this service.
1. Remove the clock from the control console assembly.
2. Remove the rear cover of the clock.
3. Remove the battery from the clock.
4. Replace the clock battery with type SR626SW. Batteries can be purchased at a retail outlet.
5. Place a new battery (+ sign up) in the battery compartment.
6. Replace the battery compartment lid.
IV. YOUR CYCLONE

20 Cyclone
IV. YOUR CYCLONE
TURBO FUNCTION
The Turbo mode provides the option of increasing the Sport Scooter speed up to 12 km/hr by simply pressing and
holding in the Turbo button while driving a straight course on flat and smooth terrain. This beneficial feature allows
the user to travel greater distances in less time as compared to the conventional Sport Scooter speed mode.
The Turbo function will engage whenever the maximum speed LED is lit to more than 3/4 of the Sport Scooters
top speed when the throttle control lever is fully depressed.
When the Turbo button is released, the Sport Scooter then returns to the normal maximum Sport Scooter speed
mode speed of approximately 8 km/hr (depending upon where the maximum speed LED is set).
Turbo Ready Indicator LE
The yellow Turbo ready indicator LED illuminates when the Sport Scooter is in Turbo Ready mode. The Turbo
function will become inactive (yellow indicator will turn off) and the vehicle speed will decrease (to the speed
preset with the speed adjustment buttons) whenever:
nthe Sport Scooter is descending an incline exceeding approximately 12.3%.
nthe Sport Scooter is driven on a lateral bank (leftward or rightward incline) exceeding approximately 12.3%.
nthe Sport Scooter is steered more than one-eighth (1/8) of a turn to the left or the right (i.e., approximately
over the 11 oclock or 1 oclock positions when seated on the Sport Scooter).
SPEE CONTROL TECHNOLOGY (SCT)
The Cyclone Sport Scooter features our exclusive patent-pending Speed Control Technology (SCT ) as an added
safeguard. SCT senses incline conditions and vehicle direction through its four sensors to automatically disable the
Turbo mode during cornering, steep descents, or extreme lateral banking. This provides the user the added confi-
dence of knowing that his/her driving skills are supplemented by a state-of-the-art system that reduces speed in
situations that require greater caution.
NOTE: The additional margin of safety provided by CT should only be considered a supplement to safe
driving habits and thorough practice in operating the port cooter in strict compliance with all conditions
outlined in this owners manual.
WARNING! In the event the urbo button sticks or malfunctions when you try to use it, Pride
recommends that you release the throttle control lever to stop your Sport Scooter. Set the speed
adjustment buttons to under 3/4 full speed to disable the urbo feature, then notify your authorised
Pride provider immediately.
WARNING! Your Sport Scooters urbo mode has been engineered to function safely while driving
a straight course on flat and smooth terrain. o eliminate the possibility of injury, Pride recom-
mends that you adhere to the following rules for engaging and disengaging the urbo mode.
nDo not press the urbo button while turning the Sport Scooter.
nDo not press the urbo button while driving on inclines or declines of any type.
nDo not press the urbo button while driving on uneven, bumpy terrain.
nRelease the urbo button before entering a turn, an incline, decline, or uneven terrain of any
type.
