Puretec 2CI-C User manual

2CI Commercial CFS / IRS / IRX / SFS Water
Treatment System User Guide
WATER TREATMENT
2CI-C

2 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
What's Inside
What's Inside
Puretec Customer Service ............................................................................................................................3
Installation Record ............................................................................................................................................4
Before Installation..............................................................................................................................................5
Parts Diagram ......................................................................................................................................................8
Individual Model Information.......................................................................................................................9
Installation Procedure...................................................................................................................................29
Programming .....................................................................................................................................................32
Advanced Programming...............................................................................................................................34
DP Switch Programming (optional) .......................................................................................................34
Start-Up ................................................................................................................................................................40
Regeneration......................................................................................................................................................40
Media Replacement........................................................................................................................................40
Replace the Backup Battery.......................................................................................................................41
Troubleshooting Guide..................................................................................................................................42
Warranty...............................................................................................................................................................46
WMTS103
Licence No. WM 74593
Pro-Switch Pty Ltd
DO NOT OVERTIGHTEN.
DO NOT USE
LIQUID SEALANTS.
SURGE PROTECTION

3Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Puretec Customer Service
Thank you for purchasing a Puretec Water Treatment System. Your system is a proven
performer manufactured from only quality materials and components. It will give years
of reliability and trouble free operation if maintained properly.
This user guide is designed for Puretec 2CI Water Treatment Systems. Be careful to
ensure the information and illustration is applicable to your particular unit.
Caution: Do not use with water that is microbiologically unsafe or without
adequate disinfection before or aer the system.
The systems are designed for metropolitan supply water but can be used in other
situations. For other types of water supply, please contact your local Puretec dealer.
Puretec 2CI Water Treatment Systems are designed to run economically for many years,
dependent on the initial installation and periodic maintenance.
Flush system for 5 minutes or more, aer any period of non-use, more than 2 weeks.
Puretec Customer Service

4 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Installation Record
Product Information
Model Number:
Serial / Batch Number:
Purchased from:
Date of Installation:
Installer / Plumber Details:
Regen Frequency: ________ Days
Water Analysis Information
Hardness: ___________ ppm / mg/L
Iron: ___________ ppm / mg/L
Manganese: ___________ ppm / mg/L
pH: ___________
TDS (Total Dissolved Salts): ___________ ppm / mg/L
Conductivity: ___________ EC / uS/cm
Chloride: ___________ ppm / mg/L
Sodium: ___________ ppm / mg/L
Tannin: ___________ NTU
Colour: ___________ HU
Installation Record
For future reference, fill in the following data:

5Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Before Installation
Before Installation
Installation Note: A water filter system/tap, like any product, has a limited life and may
eventually fail. Also sometimes failure happens early due to unforeseen circumstances.
To avoid possible property damage, this product should be regularly examined for
leakage and/or deterioration and replaced when necessary. A drain pan, plumbed to an
appropriate drain or outfitted with a leak detector, should be used in those applications
where any leakage could cause property damage, and/or the water supply should be
turned off if no one is home/present.
Professional Installation Required
• Installation requires shutting water off to home, cutting home water supply pipe
and using a welding torch to add piping and fittings. Specialised tools and skills are
required, this must be completed by a qualified tradesperson.
Make Sure Your Water Has Been Thoroughly Tested
• An analysis of your water should be made prior to the selection of your water
conditioning equipment. Your dealer will generally assist with this service for
you, and may send a sample to an independent laboratory for analysis and
recommendations. Enter your analysis information on page 3 for your permanent
record.
Install Water Treatment Equipment Correctly
Select the location of your water filter system with care. Various conditions which
contribute to proper location are as follows:
• Install as close as possible to a drain.
• Install in correct relationship to other water treatment equipment. Contact Puretec
for assistance.
• Install the system in the supply line BEFORE the water heater. Temperatures above
40°C (104°F) will damage the system and void the warranty.
• DO NOT install the system in a location where freezing temperatures occur. Freezing
may cause permanent damage and will also void the warranty.

6 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Before Installation
• DO NOT install where water hammer conditions may occur without installing an
arrestor.
• Protect from pressure vacuum with a suitable vacuum breaker.
• Allow sufficient space around the installation for easy servicing. Provide a non-
switched 240V power source for the control valve.
• Protect from pressure vacuum with a suitable vacuum breaker.
• Where line pressure exceeds 500 kPa, an approved pressure limiting device must be
installed to comply with Australian & New Zealand Plumbing Standards. (Ref. AS/NZS
3500.1:2021, Clause 3.3.4).
• For point of entry installations an approved backflow prevention device must be
installed.
Things to Remember While Planning Your Installation:
• All installation procedures MUST conform to local plumbing codes.
• If lawn sprinklers, a swimming pool, or geothermal heating/cooling or water for
other devices/activities are to be treated by the filter system, a larger model MUST
be selected to accommodate the higher flow rate, treated water volume, plus the
backwashing requirements of the filter system. Contact Puretec for assistance.
• It is essential that pumped water is available whenever the system calls for
backwash/regeneration. For example, if the supply pump is managed by a level
switch in a tank, relay outputs on the Puretec control valve will need to be utilised
with a pump-start relay. Where possible, use a pressure-operated pump set (i.e.
pump starts when line pressure reduces) to ensure optimum performance of the
water treatment system.

7Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Before Installation Warnings
• The control valve, fittings and/or bypass are designed to accommodate minor plumbing
misalignment but are not designed to support the weight of a system or the plumbing.
• Do not use petroleum jelly, oils, other hydrocarbon lubricants or spray silicone anywhere.
A silicone lubricant may be used on the black O-rings but it is not necessary.
• Do not use pipe dope or other sealants on threads. Thread seal tape is the preferred
sealant but is not necessary on the nut connection or caps because of O-ring seals.
• All plumbing should be done in accordance with local plumbing codes. The pipe size for
the drain line should be a minimum of 1”.
• Avoid getting primer and solvent cement on filter system.
• Install grounding strap on metal pipes if required.
• Ensure the system is protected against high pressure and extreme temperatures.
• Inadequate or infrequent backwashing may result in permanent damage to the filter
media.
WARNINGS
Note: Solder joints must be done prior to connecting to the valve fittings. Leave at least
6” between the fitting and solder joints when soldering pipes. Failure to do this could cause
heat damage to the fittings.
This should be carried out by a qualified tradesperson.

8 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Parts Diagram
(W)
(H)
Exploded Diagram
or
1½" Drain Line Flow Controller
(see individual model information pages)
with washer/s pre-installed
1" Drain Line Flow Controller
(see individual model information pages)
with washer/s pre-installed
Valve Cover
Flow Meter
Optional (sold separately)
Automatic Time Valve
Transformer
Spanner
Pressure Tank
Riser Pipe
(pre-installed)
Top Screen
Pressure Tank
UV Shield

9Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
CFS100-2CI Model Information
Kit Type Part no. Description Qty
Tank Kit
(WTP2460-K)
WTP2460 Pressure Tank with Base (16x65) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3000 Top Mount 50mm, suits 14-16" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC15)
WTV7350 Washer for Drain Line Flow Connector, 56lpm
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 1
WTM1000-10L Water Filtration Carbon 10L 10
Assembly & ID Kit
(WTI-CFS100)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
CFS100-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 406 mm (W) x 1980 mm (H)
Vessel Media Filling Order
1st 2nd
1 x WTM7550-15L 10 x WTM1000-10L

10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
CFS140-2CI Model Information
CFS140-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 533 mm (W) x 2040 mm (H)
Vessel Media Filling Order
1st 2nd
2 x WTM7550-15L 11 x WTM1000-15L
Kit Type Part no. Description Qty
Tank Kit
(WTP2600-K)
WTP2600 Pressure Tank with Base (21x62) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3010 Top Mount 50mm, suits 18-24" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC25)
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 2
WTM1000-15L Water Filtration Carbon 15L 11
Assembly & ID Kit
(WTI-CFS140)
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1

11Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Kit Type Part no. Description Qty
Tank Kit
(WTP2640-K)
WTP2640 Pressure Tank with Base (24x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3010 Top Mount 50mm, suits 18-24" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC34)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
1
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7150 1.5" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 3
WTM1000-15L Water Filtration Carbon 15L 15
Assembly & ID Kit
(WTI-CFS180)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
CFS180-2CI Model Information
CFS180-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 610 mm (W) x 2230 mm (H)
Vessel Media Filling Order
1st 2nd
3 x WTM7550-15L 15 x WTM1000-15L

12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Kit Type Part no. Description Qty
Tank Kit
(WTP2680-K)
WTP2680 Pressure Tank with Base (30x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3020 Top Mount 50mm, suits 30" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC52)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
3
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7150 1.5" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 4
WTM1000-15L Water Filtration Carbon 15L 22
Accessories & ID Kit
(WTI-CFS220)
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
CFS220-2CI Model Information
CFS220-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 762 mm (W) x 2170 mm (H)
Vessel Media Filling Order
1st 2nd
4 x WTM7550-15L 22 x WTM1000-15L

13Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Kit Type Part no. Description Qty
Tank Kit
(WTP2700-K)
WTP2700 Pressure Tank with Base (36x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3030 Top Mount 50mm, suits 36" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC79)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
6
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7150 1.5" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 5
WTM1000-15L Water Filtration Carbon 15L 34
Accessories & ID Kit
(WTI-CFS320)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
CFS320-2CI Model Information
CFS320-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 914 mm (W) x 2338 mm (H)
Vessel Media Filling Order
1st 2nd
5 x WTM7550-15L 34 x WTM1000-15L

14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
IRS70-2CI Model Information
Kit Type Part no. Description Qty
Tank Kit
(WTP2460-K)
WTP2460 Pressure Tank with Base (16x65) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.65m
WTD3000 Top Mount 50mm, suits 14-16" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC15)
WTV7350 Washer for Drain Line Flow Connector, 56lpm, 1"
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 1
WTM3000-15L Iron Removal Media 15L 7
Assembly & ID Kit
(WTI-IRS70)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRS70-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 406 mm (W) x 1980 mm (H)
Vessel Media Filling Order
1st 2nd
1 x WTM7550-15L 7 x WTM3000-15L

15Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
IRS100-2CI Model Information
Kit Type Part no. Description Qty
Tank Kit
(WTP2600-K)
WTP2600 Pressure Tank with Base (21x62) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe 50mm HDPE Black (pre-installed) 1.65m
WTD3010 Top Mount 50mm, suits 18-24" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC25)
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 2
WTM3000-15L Iron Removal Media 15L 13
Assembly & ID Kit
(WTI-IRS100)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRS100-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 533 mm (W) x 2040 mm (H)
Vessel Media Filling Order
1st 2nd
2 x WTM7550-15L 13 x WTM3000-15L

16 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
IRS150-2CI Model Information
IRS150-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 610 mm (W) x 2230 mm (H)
Vessel Media Filling Order
1st 2nd
3 x WTM7550-15L 18 x WTM3000-15L
Kit Type Part no. Description Qty
Tank Kit
(WTP2640-K)
WTP2640 Pressure Tank with Base (24x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 2m
WTD3010 Top Mount 50mm, suits 18-24" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 2CI 1
DLFC Kit
(WTV-DLFC34)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
1
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7150 1½" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 3
WTM3000-15L Iron Removal Media 15L 18
Assembly & ID Kit
(WTI-IRS150)
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1

17Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
Kit Type Part no. Description Qty
Tank Kit
(WTP2680-K)
WTP2680 Pressure Tank with Base (30x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.6m
WTD3020 Top Mount 50mm, suits 30" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC52)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
3
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7150 1½" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 4
WTM3000-15L Iron Removal Media 15L 26
Accessories & ID Kit
(WTI-IRS250)
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRS250-2CI Model Information
IRS250-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 762 mm (W) x 2170 mm (H)
Vessel Media Filling Order
1st 2nd
4 x WTM7550-15L 26 x WTM3000-15L

18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
Kit Type Part no. Description Qty
Tank Kit
(WTP2700-K)
WTP2700 Pressure Tank with Base (36x72) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black 1.6m
WTD3030 Top Mount 50mm, suits 36" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC79)
WTV5310 Washer for Drain Line Flow Connector, 34lpm, ¾"
(pre-installed)
6
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1" ¾"
(pre-installed)
1
WTV7150 1.5" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 5
WTM3000-15L Iron Removal Media 15L 40
Accessories & ID Kit
(WTI-IRS350)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRS350-2CI Model Information
IRS350-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1½"
Dimensions: 914 mm (W) x 2338 mm (H)
Vessel Media Filling Order
1st 2nd
5 x WTM7550-15L 40 x WTM3000-15L

19Copyright © Puretec Pty Ltd 2023 2CI Commercial Filter Series User Guide
IRX70-2CI Model Information
Kit Type Part no. Description Qty
Tank Kit
(WTP2460-K)
WTP2460 Pressure Tank with Base (16x65) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.6m
WTD3000 Top Mount 50mm, suits 14-16" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC15)
WTV7350 Washer for Drain Line Flow Connector, 56lpm, 1"
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 1
WTM3200-15L Katamax Pro Media 15L 7
Assembly & ID Kit
(WTI-IRS70)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRX70-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 406 mm (W) x 1980 mm (H)
Vessel Media Filling Order
1st 2nd
1 x WTM7550-15L 7 x WTM3200-15L

20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2023
IRX100-2CI Model Information
Kit Type Part no. Description Qty
Tank Kit
(WTP2600-K)
WTP2600 Pressure Tank with Base (21x62) 1
WTV3040 Pressure Tank UV Collar Shield 1
WTD3320 Riser Pipe, 50mm HDPE Black (pre-installed) 1.6m
WTD3010 Top Mount 50mm, suits 18-24" Tanks 1
Filter Kit
(WTV7000-K)
WTV5135 Transformer & Lead, suits Auto Valve 1
WTV7200 2CI Valve Cover 1
WTV5180 Spanner, suits E1, E3, NTS Systems 1
WTV7000 2CI Filter Valve, Backwash Only 1
WTD3100 Top Screen Distributor Stack 1
DLFC Kit
(WTV-DLFC25)
WTV5395 Washer for Drain Line Flow Connector, 94lpm, 1"
(pre-installed)
1
WTV7330 1" Drain Line Flow Connector 1
Media Kit
WTM7550-15L Multi-media High Performance Medium 15L 2
WTM3200-15L Katamax Pro Media 15L 13
Assembly & ID Kit
(WTI-IRX100)
PMD-DECAL3 Puretec Logo Label (126x420) 1
LBL-METALLICBLANK Metallic Silver Model Label (60x100) 1
UG-2CI-C Commercial 2CI WTS User Guide (CFS/IRS/IRX/SFS) 1
WTV1600 Media Funnel 1
IRX100-2CI Model Information
System Inclusions - Kits & Components
Specifications
Operating Pressure Min/Max: 138 - 862 kPa
Operating Temperature Min/Max: 0 - 40 °C (protect from freezing)
Electrical Connection: 240V / 50 Hz
Inlet/outlet Connection: 2"
Drain: 1"
Dimensions: 533 mm (W) x 2040 mm (H)
Vessel Media Filling Order
1st 2nd
2 x WTM7550-15L 13 x WTM3200-15L
