Before you operate this system, read the operation and setup manual. This will help you
to become familiar with the product and ensure successful operation.
If any questions or problems arise, contact PVA’s Customer Service Department for
support.
PVA Contact Information2.1
Main Office PVA
One Mustang Drive
Cohoes, NY 12047
Tel [phone]
Fax [phone]
Website http://www.pva.net
Email mailto: [e-mail]
Technical Support
Tel [phone]
Email mailto: [email protected]
Document History2.2
Revision
Revision Date
Reason for Changes
REV A
April 2014
Initial Release
NOTE: All photographs and CAD model representations in this document are a
“general representation” of the valve and its components. The actual
appearance of the valve and its components can differ based upon customer
specific configuration.
REVISION A (2014)5 of 50

SB300-C
PVA
Safety2.3
Certain warning symbols are affixed to the machine and correspond to notations in this
manual. Before operating the system, identify these warning labels and read the
notices described below. Not all labels may be used on any specific system.
Always wear approved safety glasses when you operate or
work near the workcell.
Before you operate the system, read and understand the
manuals provided with the unit.
Never put hands or tools in areas with this symbol when the
machine is in operation. A dangerous condition may exist.
Read and understand the manuals provided with the unit
before any repairs or maintenance is done. Only a qualified
individual should do service.
Use caution when there are pressurized vessels. Find and
repair any leaks immediately. Always wear appropriate safety
equipment when you work with pressurized vessels or vessels
that contain chemicals.
Shear hazard from moving parts. Avoid contact.
REVISION A (2014)6 of 50

SB300-C
PVA
Theory of Operation2.4
The SB300-C is a high pressure valve with a low maintenance design. It dispenses a high
flow of medium to high viscosity material with adjustable snuff back. There are two
main versions of this valve, one with the 1/4” NPT end fitting and one with a luer outlet.
Personal Protective Equipment2.5
Operators must use eye protection because material contents are under pressure.
Always wear gloves when handling materials and solvents. Refer to MSDS sheets on the
material being dispensed for other precautions.
Waste Disposal2.6
Dispose of all used parts and materials in accordance with local laws and regulations.
Necessary Tools2.7
PVA offers tools and cleaning accessories to maintain the SB300-C valve.
Part Number
Description
02506
Hook and Pick Set
9463-K33
Lubricant for O-ring seals
B62-2048
2.5cc Silicone Grease
B62-0752
Mineral Oil Lubricant
REVISION A (2014)7 of 50

SB300-C
PVA
Setup3.
Before you operate the valve, know the valve components. Do the steps instructed
below for safe and correct operation.
1. Make sure your valve is correctly connect to the dispense system. Refer to your
fluid schematic.
2. Make sure you know the valve specifications and do not operate the valve
outside of the specifications.
Overview3.1
Figure 1: Valve Components
REVISION A (2014)8 of 50

SB300-C
PVA
Operation4.
NOTE: Refer to Section 6 for part reference numbers. All part numbers refer to
the NPT version of the valve (drawing 112-07519) unless otherwise specified.
NOTE: Use only compatible solvents and materials or the seals and O-rings will
be damaged.
Operation Notes:
The sections that follow are in the recommended order to operate the valve. To operate
the valve, do every sub-section in Section 4, in the order shown.
1. Set the operating air pressure to 60-100 psi.
2. Cycle the valve. Make sure the piston can be heard going up and down.
3. Make sure the fluid delivery system is correctly connected and pressurized as
necessary.
Bleed the Valve4.1
1. Use the purge button on the teach pendant to purge the valve. Push the purge
button through step 4.
2. As material dispenses, turn the stroke adjust clockwise until it is fully engaged.
3. Then, turn the stroke-adjust counterclockwise to loosen it until the material
dispenses without any breaks in the flow of material.
4. Release the purge button.
NOTE: If the material has drips or strings after dispensing there is still air in
the valve and it must be bled again.
5. After the valve has been correctly bled, continue with normal operation.
NOTE: If the stroke adjust is down too far, the valve will not close and the valve
will continue to dispense or leak.
Adjust Snuff Back4.2
Snuff back stops material from dispensing after the valve closes. The stroke adjust (9) is
used to change snuff back. The snuff back setting will be different for each dispense
procedure, the steps below are for a general setting. It may be necessary to continue to
adjust snuff back to get the correct results for your procedure.
1. To set or reset your snuff back, turn the stroke adjust (9) clockwise until it is
fully engaged.
REVISION A (2014)9 of 50

SB300-C
PVA
2. Turn the stroke adjust (9) counterclockwise for two full turns.
Figure 2: Turn the Stroke Adjust Two Full Turns
3. Operate the valve at this stroke adjust (9) setting. Adjust as necessary for your
application.
NOTE: Turn the stroke adjust counterclockwise to increase snuff back and turn
the stroke adjust clockwise to decrease snuff back.
4. If you cannot get the necessary results, turn the stroke adjust counterclockwise
until it is fully loosened. Some applications work best this way. Decrease the
snuff back as necessary.
Figure 3: Stroke Adjust Fully Loosened
Shutdown4.3
1. Release the pressure in the system, refer to the workcell manual.
2. Open the valve and let any material dispense until the system pressure is close
to zero.
