QDI P5I430TX Titanium IB+ User manual

PENTIUM®
P5I430TX
TITANIUM IB+

Notice
The information in this document is subject to change in order to improve reliability,
design, or function without prior notice and does not represent a commitment on the
part of this company. In no event will we be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or the possibility of such
damages.
All trademarks are the property of their respective owners.
If you need any further information, please visit our web-site: “www.qdigrp.com”.

Declaration of conformity
QUANTUM DESIGNS(HK) LTD.
5/F Somerset House, TaiKoo Place 979 Kings Road,
Quarry Bay, Hong Kong
declare that the product
Pentium® Motherboard
P5I430TX TITANIUM IB+
is in conformity with
(reference to the specification under which conformity is declared in accordance with
89/336 EEC-EMC Directive)
þEN 55022 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
þEN 50081-1 Generic emission standard part 1:
Residual, commercial and light industry
þEN 50082-1 Genetic immunity standard Part 1:
Residual, commercial and light industry
European Representative:
QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S
QDI SYSTEM HANDEL GMBH QDI COMPUTER ( NETHERLANDS) B. V.
QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH
QDI COMPUTER (ESPANA) S.A. QDI COMPUTER (SWEDEN) AB
Signature : Place / Date : HONG KONG /1997
Printed Name : Anders Cheung Position/ Title : President
Declaration of conformity
(EC conformity marking)

Trade Name: QDI Computer ( U. S . A. ) Inc.
Model Name: P5I430TX TITANIUM IB+
Responsible Party: QDI Computer ( U. S. A.) Inc.
Address: 41456 Christy Street
Fremont, CA 94538
Telephone: [phone]
Facsimile: [phone]
Equipment Classification: FCC Class B Subassembly
Type of Product: PCI Pentium Motherboard
Manufacturer:Quantum Designs (HK) Inc.
Address: 5/F, Somerset House, TaiKoo Place 979 Kings
Road, Quarry Bay, HONG KONG
Supplementary Information:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Signature : Date : 1997

CONTENTS
I
SpeedEasy Quick Setup(English)----------------------------------------1
SpeadEasy Schnell-Installation(Deutsch)------------------------------3
Fácil Y Veloz Rápida Instalación(Español)----------------------------5
Facilité de vitesse Initialisation(Francais)-----------------------------7
Setup Della Scheda Speedeasy(Italiano)-------------------------------9
SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎÄ·±Ìå ) ----------------------------------11
SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎļòÌå )---------------------------------13
1. Introduction.......................................................1-1
1.1 Overview......................................................................1-1
1.2 Key Features................................................................1-1
2. Connector Configuration.................................2-1
2.1 Power Connector.........................................................2-1
2.2 Modem Ring On Connector..........................................2-1
2.3 ATX Power Connector.................................................2-1
2.4 Power Switch...............................................................2-2
2.5 Keyboard Connector....................................................2-2
2.6 Hard Disk LED Connector............................................2-2
2.7 Power LED Connector .................................................2-2
2.8 Speaker Connector......................................................2-2
2.9 IrDA Connector............................................................2-3
2.10 Turbo LED Connector.................................................2-3
2.11 Reset Switch...............................................................2-3
2.12 USB1/USB2 Connector..............................................2-3
2.13 FAN Connector..........................................................2-4
2.14 Hardware Green ........................................................2-4

CONTENTS
II
2.15 PS2 Mouse.................................................................2-4
2.16 Sleep LED ..................................................................2-4
2.17 I/O Port Description .................................................. 2-5
2.18 Clear CMOS ..............................................................2-5
2.19 Memory Configuration ............................................... 2-5
3. AWARD BIOS Description................................3-1
3.1 Entering BIOS Setup....................................................3-1
3.2 Standard CMOS Setup ................................................3-2
3.3 SpeedEasy CPU Setup................................................3-4
3.4 BIOS Features Setup...................................................3-5
3.5 Chipset Features Setup ...............................................3-7
3.6 Power Management Setup...........................................3-9
3.7 PNP/PCI Configuration Setup ....................................3-11
3.8 Load Setup Defaults ..................................................3-13
3.9 Integrated Peripherals................................................3-13
3.10 Password Setting.....................................................3-14
3.11 IDE HDD Auto Detection..........................................3-15
3.12 Power-on Boot.........................................................3-17
APPENDIX............................................................. A-1
Appendix A BIOS Utility Diskette....................................... A-1
Appendix B Introducing AMD-K5 CPU markings ............... A-2
Appendix C Introducing AMD-K6 CPU markings............... A-3
Appendix D Introducing Cyrix 6x86 CPU markings............ A-4
Appendix E Introducing Cyrix 6x86MX CPU markings....... A-5

P5I430TX Titanium IB+
1
SpeedEasy Quick Setup
Procedures :
1. Correctly insert the CPU.
2. Plug in other configurations and restore the system.
3. Press <Del> key and power on the system to enter BIOS Setup.
4. Enter “SpeedEasy CPU Setup” menu to set up CPU speed.
Note: If CPU speed is not set, your system will run at the
default setting (75MHZfor Pentium and AMD CPU, 100MHZ
for Cyrix etc).
5. Save and exit BIOS Setup, your system will boot successfully
as expected.

SpeedEasy Type introduction
2
SpeedEasy CPU Setup Menu
Select the <SpeedEasy CPU Setup> item from the main menu and enter the
sub-menu:
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure - 1 SpeedEasy CPU Setup Menu
For SpeedEasy mainboard, BIOS will provide you with a set of basic values
for your CPU selection instead of the jumper settings. To make your system
run as fast as possible, you can manually select CPU speed value in “CPU
Speed” item on “SpeedEasy CPU Setup” menu screen.
Note: In addition, if your system can not reboot because of wrong CPU
settings, you can hold down the hot-key<Del> while powering on the
system, the system will reboot and run at the basic values.
Warning:
Do not set CPU frequency higher than its working frequency. We will
not be responsible for any damages caused due to this.

P5I430TX Titanium IB+
3
Schneller Überblick über die
Einstellungen:
Vorgehensweise:
1. Setzen Sie die CPU richtig ein.
2. Stecken Sie weitere Komponenten ein und vervollständigen Sie das
System.
3. Drücken <DEL >oder <ENTF >und schalten Sie das System ein,
um in das BIOS-Setup zu gelangen.
4. Wählen Sie das Menü „Speed Easy CPU Setup“, um die CPU-
Taktfrequenz einzustellen.
Anmerkung: Wenn Sie die CPU-Taktfrequenz nicht einstellen, wird Ihr
System in der Grundeinstellung laufen (75 MHz bei Intel Pentium® und AMD
CPUs, 100 Mhz bei Cyrix 6x86 CPUs usw.).
5. Wählen Sie die Option „Save and Exit BIOS Setup“, um die
vorgenommen Änderungen abzuspeichern. Anschließend können Sie wie
erwartet das System erfolgreich hochfahren.

Installation der Mainboards vom Typ„SpeedEasy“
4
Menü für die SpeedEasy CPU-Einstellungen
Wählen Sie das Menü <SpeedEasy CPU Setup >aus und gehen
Sie in das folgende Untermenü:
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Bild 1 „SpeedEasy CPU Setup Menu“
Beim den SpeedEasy-Mainboard stellt Ihnen das BIOS anstelle von Jumper-
Einstellungen eine Auswahl von Grundeinstellungen zur Verfügung. Um Ihr
System optimal zu betreiben, können Sie von Hand die Werte für die CPU-
Taktfrequenz unter der Option „CPU-Taktfrequenz unter der Option „CPU Speed“
im „SpeedEasy CPU Setup“ Menü einstellen.
Anmerkung: Falls Ihr System aufgrund einer falschen CPU-Einstellung
nicht mehr hochfahren kann, halten Sie beim inschalten des Rechners die
Taste <DEL >bzw. <ENTF >gedrückt. Das System wird dann mit den
Grundeinstellungen neu gestartet.
Warnung: Sie sollten die CPU-Taktfrequenz nicht höher als die
angegebene Arbeitsgeschwindigkeit einstellen. Anderfalls sehen wir
uns für irgendwelche hierdurch hervorgerufene Schäden nicht
verantwortlich.

P5I430TX Titanium IB+
5
Setup Rápido
Procedimiento:
1. Insertar la CPU correctamente.
2. Insertar otros dispositivos en el sistema.
3. Presionar la tecla <Del> y arrancar el sistema para entrar en BIOS
setup.
4. Seleccionar el menu “SpeedEasy CPU setup” para seleccionar la
velocidad de la CPU.
Nota: si no selecciona la velocidad de la CPU, el sistema
funcionará a la velocidad por defecto (75 Mhz para Pentium y
AMD, 100 MHz para Cyrix 6x86, etc.)
5. Grabar y salir de BIOS Setup, entonces el sistema arrancará y
funcionará como Ud. espera.

Introducción a SpeedEasy
6
Configuración de la CPU en el menu SpeedEasy
Seleccione <SpeedEasy CPU setup> en el menu principal para entrar en el
siguiente menu:
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure -1. SpeedEasy CPU Setup Menu
Para la placa base SpeedEasy, la BIOS proporciona un juego de valores
básicos para seleccionar el tipo de CPU, en lugar de los jumpers. Para hacer
que su sistema funcione lo más rapidamente posible, Ud. puede manualmente
aumentar el valor de la velocidad de frecuencia en “CPU Speed” en el menu
<SpeedEasy CPU setup>.
Nota: por lo tanto, si su sistema no puede rearrancar de nuevo tras haber
variado la frecuencia de trabajo de la CPU por una incorrecta, Ud. puede
arrancar manteniendo apretada la tecla <Del> mientras conecta su
equipo. El sistema arrancará con los valores básicos.
Aviso: es recomendable no seleccionar una frecuencia superior para la
CPU a la que esta fue diseñada. En caso contrario, no nos hacemos
responsables de los posibles daños que esto pueda causar.

P5I430TX Titanium IB+
7
Mise en marche rapide
Démarche à suivre:
1) Insérer correctement le Processeur.
2) Assembler les autres éléments et mettez le système en place.
3) Appuyer sur la touche <Del> (Efface) et mettre le système en
marche afin d’accéder à la configuration du BIOS.
4) Accédez au menu “SpeedEasy CPU Setup “ pour mettre au point la
fréquence du processeur.
Remarque : Si vous ne réglez pas la vitesse du processeur, votre
système va fonctionner à la fréquence par défaut, (75Mhz pour les
processeurs Pentium d’Intel et d’ AMD , 100Mhz pour les
processeurs 6X86 de Cyrix etc... )
5) Sauvegarder la configuration et sortir du BIOS , alors votre système
peut démarrer comme vous le voulez.

SpeedEasy
8
Menu de configuration de processeur de SpeedEasy
Sélectionnez <SpeedEasy CPU Setup> du menu principal et accédez au sous-
menu comme suit :
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figure -1. SpeedEasy CPU Setup Menu
Pour les cartes mère SpeedEasy , le BIOS va vous procurer un ensemble de
paramètres de base pour le choix de votre processeur au lieu de placer des
cavaliers ( Jumpers ). Pour faire fonctionner votre système à la plus haute
fréquence possible , vous pouvez augmenter manuellement les valeurs de
fréquence du processeur dans “CPU Speed” sur l’écran menu “SpeedEasy CPU
Setup”.
Remarque : En plus si votre système ne peut pas redémarrer à cause du
mauvais réglage du processeur, vous pouvez appuyer sur la touche clé
<Del> ( ou Efface ) pendant que vous remettiez le système en marche. Le
système va redémarrer et va fonctionner avec les paramètres de base.
Avertissement : Vous avez intérêt à ne pas mettre la fréquence du
processeur plus haute que celle indiquée par le manufacturier.Sinon, nous ne
pourrions pas être tenu responsables des dégâts que cela peut causer.

P5I430TX Titanium IB+
9
Setup Rapido
Procedure:
1. Inserire la CPU correttamente.
2. Inserire gli altri componenti e ricomporre il systema.
3. Premere il tasto <Del> e accendere il sistema per entrare nel
setup del Bios.
4. Entrare nel menu “SpeedEasy CPU Setup” per impostare la
velocita` della CPU.
Nota: Se la velocita` di CPU non viene impostata, il sistema
lavorera` alla velocita` di default (75Mhz per CPU Pentium e AMD,
100 Mhz per Cyrix 6 x 86 CPU ecc.).
5. Salvare e uscire dal Setup del Bios. Il sistema si riavviera` alla
velocita` voluta.

Introduzione al Tipo SpeedEasy
10
Menu SpeedEasy per l`impostazione della CPU
Selezionare <SpeedEasy CPU Setup> dal menu principale ed entrare nel
seguente sottomenu:
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
Figura 1: Menu SpeedEasy per l`impostazione della CPU
Per una mainboard SpeedEasy, il BIOS fornisce una serie di valore base per la
specifica CPU, invece di dover impostarli via jumpers. Per far lavorare il
sistema in modo ottimale, si puo` impostare la velocita` di CPU manualmente,
alla voce “CPU Speed” del menu “SpeedEasy CPU Setup”.
Nota: Se il sistema non completa il boot per impostazioni errate della
CPU, riaccendere tenendo premuto il tasto <Del>. Il sistema si riavviera`
con I valori di base.
Attenzione: QDI declina ogni responsabilita` per eventuali danni
causati alla CPU da una impostazione della velocita` piu` alta di
quanto indicato dal produttore della CPU stessa.

P5I430TX Titanium IB+
11
¿ìËÙÉèÖõIJ½Öè
1¡¢ÕýÈ·°²×° CPU¡£
2¡¢°²×°ºÃϵͳ, ×¼±¸¿ª»ú¡£
3¡¢°´Ï <Del> ¼ü±£³Ö²»¶¯£¬ È»áῪ»ú½øÈë BIOS ÉèÖóÌÐò¡£
4¡¢½øÈë “SpeedEasy CPU Setup”Ŀ¼ÉèÖà CPU Ëٶȡ£
×¢Ò⣺Èç¹ûÓû§²»ÉèÖÃCPU Ëٶȣ¬ Ôòϵͳ»á
ÓÃÔ-É趨ֵÔËÐÐ (Intel ±¼ÌÚºÍ AMD K5 CPU »áÓÃ75HMz
ÔËÐУ¬Cyrix 6x86 CPU »áÓÃ100MHz ÏÂÔËÐÐ)¡£
5¡¢±£´æ¼°Í˳öBIOSÉèÖóÌÐò£¬È»ááϵͳ¾Í¿ÉÔÚÉ趨µÄËÙ¶ÈÏ
Â
˳ÀûÔËÐС£

SpeedEasy ·½Ê½½éÉÜ
12
SpeedEasy CPU ÉèÖÃĿ¼
ÔÚ BIOS ÉèÖóÌÐòÖ÷Ŀ¼ÖÐÑ¡Ôñ <SpeedEasy CPU Setup> Ò»Ï
½ø ÈëÈçÏÂ×ÓĿ¼£º
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
ͼ£-1 SpeedEasy CPU ÉèÖÃĿ¼
¶ÔÓÚ SpeedEasy Ö÷°å£¬BIOS Ϊ CPUÔ¤ÉèÁË Ò»Ì×»ù±¾²ÎÊý¶ø ÎÞÐëÉèÖÃ
ÈκÎÌøÏß¡£ÎªÁËʹϵͳÔËÐÐÓÚCPU±ê×¢µÄƵÂÊ£¬Óû§¿ÉÒÔÔÚ
"SpeedEasy CPU Setup" Ŀ¼ÆÁÄ»ÉÏ×ÔÐÐÐÞ¸ÄCPU µÄËٶȡ£
×¢Ò⣺
Èç¹ûϵͳÒòΪÓû§ÉèÖôíÎóµ¼ÖÂϵͳ²»ÄÜÔÙÆô¶¯£¬Ôò¿ÉÒÔ°
´ÏÂÈÈ ¼ü <Del> ±£³Ö²»¶¯£¬È»áῪ»ú £-ϵͳ»á
ÒÔÔ¤ÉèµÄ»ù±¾²ÎÊýÆô¶¯ ¼° ÔË ÐС£
¾¯¸æ£º
²»Òª½«CPUµÄ¹¤×÷ƵÂÊÉèÓڸ߳öÆä±êʶµÄƵÂÊ£¬·ñÔòÎÒ
ÃǶÔÓÉ´Ë
ÒýÆðµÄË𺦸Ų»¸ºÔð¡£

P5I430TX Titanium IB+
13
¿ìËÙÉèÖõIJ½Öè
1¡¢ÕýÈ·°²×° CPU¡£
2¡¢°²×°ºÃϵͳ, ×¼±¸¿ª»ú¡£
3¡¢°´Ï <Del> ¼ü±£³Ö²»¶¯£¬ È»ºó¿ª»ú½øÈë BIOS ÉèÖóÌÐò¡£
4¡¢½øÈë “SpeedEasy CPU Setup”Ŀ¼ÉèÖà CPU Ëٶȡ£
×¢Ò⣺Èç¹ûÓû§²»ÉèÖÃCPU Ëٶȣ¬Ôòϵͳ»á
ÓÃÔ-É趨ֵÔËÐÐ (Intel ±¼ÌÚºÍ AMD K5 CPU »á ÓÃ75HMz
ÔËÐУ¬ Cyrix 6x86 CPU »á Óà 100MHz ÏÂÔËÐÐ)¡£
5¡¢±£´æ²¢Í˳öBIOSÉèÖóÌÐò£¬È»ºóϵͳ¾Í¿ÉÔÚÉ趨µÄËÙ¶ÈÏÂ
˳ÀûÔËÐС£

SpeedEasy ·½Ê½½éÉÜ
14
SpeedEasy CPU ÉèÖÃĿ¼
ÔÚ BIOS ÉèÖóÌÐòÖ÷Ŀ¼ÖÐÑ¡Ôñ <SpeedEasy CPU Setup> Ò»Ï
½ø ÈëÈçÏÂ×ÓĿ¼£º
ROM PCI/ISA BIOS (2A59IQ1G)
SPEEDEASY CPU SETUP
QDI Innovative Technology
CPU Model : Intel Pentium MMX
Speed Mode : SpeedEasy
CPU Speed : 233MHZ
Warning: Be sure your selection
is right. CPU over speed
will be dangerous!
CPU Voltage Ctrl : Auto
CPU I/O Voltage : 3.3V
CPU Core Voltage : 2.8V
ESC:Quit ↑↓→←:Select Item
F1: Help PU/PD/+/-: Modify
(Shift) F2: Color
ͼ£-1 SpeedEasy CPU ÉèÖÃĿ¼
¶ÔÓÚSpeedEasyÖ÷°å£¬BIOSΪCPUÔ¤ÉèÁËÒ»Ì×»ù±¾²ÎÊý¶øÎÞÐëÉèÖÃÈκÎ
ÌøÏß¡£ÎªÁËʹϵͳÔËÐÐÓÚCPU±ê×¢µÄƵÂÊ£¬Óû§ ¿É ÒÔÔÚ"SpeedEasy
CPU Setup" Ŀ¼ÆÁÄ»ÉÏ×ÔÐÐÐÞ¸ÄCPU µÄËٶȡ£
×¢Ò⣺
Èç¹ûϵͳÒòΪÓû§ÉèÖôíÎóµ¼ÖÂϵͳ²»ÄÜÔÙÆô¶¯£¬Ôò¿ÉÒÔ°
´ÏÂÈÈ ¼ü <Del> ±£³Ö²»¶¯£¬È»ºó¿ª»ú £- ϵͳ»á
ÒÔÔ¤ÉèµÄ»ù±¾²ÎÊýÆô¶¯ ¼° ÔË ÐÐ.
¾¯¸æ£º
²»Òª½«CPUµÄ¹¤×÷ƵÂÊÉèÓڸ߳öÆä±êʶµÄƵÂÊ£¬·ñÔòÎÒ
ÃǶÔÓÉ´Ë
ÒýÆðµÄË𺦸Ų»¸ºÔð¡£
