Qlight Q100L User manual

Q100L/Q100LP/Q100LW
Thank you for purchasing QLight products. Please read this manual
carefully before installing this product for safe and long use.
▪Having long life of light source by adopting high-brightness LED
and suitable for machines having lots of vibration and impact with
high durability.
▪Excellent in diffusing effect by employing our own unique direct-
diffusion system.
▪Possible to select suitable operation by using built-in
steady/flashing selection switch according to the purpose of use.
▪Possible to install various way according to installing condition.
Q100LW: Wall mounting type, Q100LP: Pole mounting type
▪Material : Lens-PC, Body-ABS, PIPE-AL, BRACKET-ABS
▪Flashes(when flashing) : 60~80/min.
▪BUZZER : 80±3dB at 1M (it is optional item)
▪Protection : IP65
Model
Voltage
Current
Weight
Flashes
Color
Q100L
DC12V
0.235A
0.20Kg
60~80/min.
Red-R
Amber-A
Green-G
Blue-B
DC24V
0.130A
0.20Kg
AC110V
0.062A
0.22Kg
AC220V
0.042A
0.22Kg
Q100L
Q100LW
Q100LP
Power line UL1015-NO.18 (0.75sq) x 2C 400mm comes out from the
product.
▪In case of product using AC voltage, connect the line without
Polarity(wire color).
▪In case of product using DC voltage, black line is negative(-).
▪If possible, please mount as the direction of vertical and at the
place where low vibration and low impact.
▪Please make a suitable hole on the place where the product will
be mounted by a Drill by referring to dimension on the below
drawing.
▪In case of direction mounting type, fix the product by using
Nuts(M4-3EA) attached on mounting bolt on the bottom of the
product.
▪In case of pole mounting type, mount it by using nuts attached
on the Pole.
▪Mount it by using mounting bolts M8-2EA for L-type bracket and
mount it by using another mounting bolts M5-4EA for Wall
mounting type and round type bracket.
OPERATING MANUAL
LED Steady/Flashing Light

■Direct mounting type
Q100L Series
PCD 60, Ø5x3
▪fix the product by using Nuts(M4-3EA) attached on mounting bolt
on the bottom of the product.
■Wall mounting type
Q100LW Series
PCD 55, Ø6x4
■POLE mounting type
Division
Q100LP Series
Standard
SCREW & NUT 18mm
L-type bracket
LB24
Wall bracket
LW24
Round Bracket
SZ24
Folding round Bracket
SL24
■POLE mounting type detailed specification
In case of pole mounting method, there are mainly 5 types
according to purpose or condition of mounted place. And
please mount it according to the kinds of mounting bracket by
refer to below contents.
Model
Dimension
24mm
SCREW & NUT
(Standard types)
LB24
LW24
SZ24
SL24
There is built-in Switch to select Steady/Flashing operation on the
assembling circuit board for convenience of user. Refer to the
following drawing and explanation for right operation.
1) Lens Removal
Remove lens by turning it counterclockwise and make sure
related parts on the assembling board.
2) Selecting Steady/Flashing Type
Choose steady light or flashing light by using Steady/Flashing
Selecting switch(1)- SELECTOR(1). “L” mode of the switch is for steady
type and “LF” mode is for flashing type.
3) Lens Assembling
Assemble the product in reverse order of separating.
▪If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem on
Selecting Steady/Flashing Type

product operating. Make sure the using voltage does not exceed +/-
5% of the rated voltage.
▪If lens or body of the product is contaminated by chemicals such as
thinner, benzene, the product can be damaged, discolored or
deformed. Please be careful.
▪Do not give strong impact to the product. It can be a reason of wire
disconnection or short circuit.
▪Do not strongly pull the wire out from the product. It can cause a
disorder.
Situation
Main reason
Solution
Non- Lighting Partly
LED is partly damaged,
supplying higher voltage
then rated voltage.
Making Sure Using
Voltage
Feeble Lighting
Supplying Voltage Lower
Than Rated Voltage
Making Sure Using
Voltage
Lighting but
Non-Flashing
Wrong Operating L/LF
Selection Switch
Convert L/LF Selection
Switch
Problem L/LF Selection
Switch
Contact QLight or Their
Agent
Neither Lighting nor
Flashing
Wrong Wiring
Making Sure Wiring
No Power Supply
Making Sure Power Supply
