Qlight S100R User manual

S100R / S100UR / S100U / S100UA
Thank you for purchasing QLight product. Please read this manual
carefully before installing this product for safe and long use.
▪A patented special power transmission system makes superior
durability of revolving and minimize noise and wear
▪The vacuum coated reflector has a fine light diffusing effectiveness
▪Buzzer volume(optional): Max 90dB/m
▪RPM: 120~140RPM. (Controllable)
▪Material: Lens- AS, Body- ABS, Reflector- Thermostable ABS
▪Protection Class: IP44
1) S100R / S100UR
▪ General Specification
Model
Voltage
Current
Bulb
Weight
Color
S100R
S100UR
DC12V
0.966A
12V10W
T16x35 15S
9
0.37Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
DC24V
0.566A
24V10W
T16x35 15S
10
AC110V
0.130A
12V10W
T16x35 15S
9
0.60Kg
AC220V
0.065A
12V10W
T16x35 15S
9
▪External View Drawing
S100R S100UR
2) S100U / S100UA
▪ General Specification
Model
Voltage
Current
Bulb
Weight
Color
S100U
S100UA
DC12V
0.966A
12V10W
T16x35 15S
9
0.38Kg
RED-R
AMBER-A
GREEN-G
BLUE-B
DC24V
0.566A
24V10W
T16x35 15S
10
AC110V
0.130A
12V10W
T16x35 15S
9
0.62Kg
AC220V
0.065A
12V10W
T16x35 15S
9
▪External View Drawing
S100U S100UA
Power line UL1015-NO. 18(0.75sq) x 2C 400mm comes out from the
product.
▪In case of product using AC voltage, connect the line without Polarity
(wire color).
▪In case of product using DC voltage, black line is negative (-).
Indoor Outdoor
▪This product is manufactured for indoor use. Installing in any direction
is okay for indoor use.
▪Outdoor use is limited at places where no water or very little water
percolates. Mounting also should be done only on the vertical
standing direction.
OPERATING MANUAL
Bulb Revolving Warning Light

▪Mount at the place where exists low vibration, low impact, low moisture
and low dust as long as possible.
▪Please drill holes where you need to attach the product and refer to
picture below for the hole size. (Please check the position of PCD
from external view drawing.)
▪Fix the product by using nuts (M4-3EA) originally equipped on
mounting bolt on the bottom of the product.
This product has VOLTAGE SELECTOR (2) to change voltages and
SPEED CONTROLLER (1) to control revolving speed on an
assembling board. Please kindly see drawings and explanation below
carefully.
1) Lens Removal
Remove lens by turning it counterclockwise. Please make sure any
related parts are on the assembling board.
2) Control the Revolving Speed
▪This product built-in a volume for revolving speed control. Turn it
clockwise for increasing revolving speed and turn it counterclockwise for
decreasing revolving speed.
▪Put too much forces, the volume may be broken. Please be careful.
3) AC Voltage Selection
▪You can choose one voltage between AC110V and AC220V by using
voltage selection switch (2). The default setting is AC220V.
※Warning!
▪Before you convert the voltage, you MUST cut off the power supply.
Otherwise electricity on the wire might cause a short circuit.
4) Bulb Change
※Warning!
If you want to replace a bulb, you MUST cut the power supply before
you do it. Please leave the product turned off at least 1 minute and
then change the bulb.
▪Please check the rated voltage and wattage of the bulb. If the bulb
gets higher voltage than the rated one, it will lead the life of product
reduced and cause damage on the lens and reflector. Therefore,
please use the bulb which has the same or lower rated voltage and
wattage.
▪Bulb Removal: Press the bulb slightly downward and turn it
counterclockwise for removing.
▪Bulb Fitting: Press the bulb slightly into the socket with a little pressure
and turning it clockwise for fitting.
Bulb removal Bulb fitting
▪If it is used with seriously higher or lower than rated voltage, it can
reduce the self-life of the product or can cause a problem on the
operating. Please make sure the voltage does not exceed +/-5% of the
rated voltage.
▪If lens or body of the product contacts to the chemicals such as thinner
or benzene, the product is contaminated, discolored or deformed. Please
be careful.
▪Do not give strong impact on the product. It can be a reason of wire

disconnection or short circuit.
▪Do not strongly pull out the wire from the product. It can cause a
disorder.
Situation
Main reason
Solution
Partially Lighting
Wire disconnection
of Bulb
Wire re-connection or
Bulb Change
Feeble Lighting
Low Revolving Speed
Supplying voltage
Lower than rated
Voltage
Check the Voltage
Choose the wrong voltage
from the selection switch
(AC type)
Check the Voltage
Wrong setting for the
revolving speed
Make revolving speed
higher
Short Self-Life of Bulb
Supplying voltage
higher than the rated
voltage
Check the voltage
Bulb overheating makes
lens shape change
Using the high voltage
bulb
Use the right voltage
bulb
Defect of transformer
(AC Voltage Type)
Non Revolving
Problem with Motor
Contact QLight
or
The Agent
Neither Lighting Nor
Revolving
No Power Supply
Check the power supply
Wrong Wiring
Check the Wiring
