Qlight QWT Series User manual

1
Wall Mount LED Signal Tower with Built-in Audible Alarm
QWT
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
54
-30~+50
85d B
QWTL - 3 - 110/220 - RAG
[Model number] [Layer] [Voltage] [Color]
| | | |
• QWTL
• QWTL - BZ
• QWTLF
• QWTLF - BZ
• 1-1Layer
• 2-2Layers
• 3-3Layers
• 4-4Layers
• 5-5Layers
• 12 - DC12V
• 24 - DC24V
• 110/220 - AC110V-220V
R-Red
A-Amber
G-Green
B-Blue
W-White
QWT
Please scan the QR
code for more detailed
product information.
www.qlight.com
Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o󰘯 the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci󰘰cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, 󰘰re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, and or malfunction of
the product that would void the warranty.
1. During wiring or maintenance, please completely turn o󰘯 the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a 󰘰re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to 󰘰re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to 󰘰re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, 󰘰re, electric shock and loss of life.)
■
Warning and Caution
Ordering Specication

2
70
L
41
40 40
54
269
43 41 41 41 41
76
70
6-Ø4 HOLES
Ø13
CABLE ENTRY
21
8
27.5
Ø70
LAYER L
1 121
2 162
3 203
4 244
5 285
Dimensions
QWT
Specication
• Protection rating : IP54
• Ambient operating temperature : -30°C to +50°C
Current Specications
Voltage
Condition AC/DC12V AC/DC24V AC110-220V
Light
(per Layer) 0.065A 0.050A Max 0.025A
Buzzer 0.034A 0.078A Max 0.016A
※AC type model has a free-voltage range of AC100V-240V.
Model
Number
Layer Voltage Current Certicate Weight Color
QWTL
Steady type
QWTL - BZ
Steady type with
built-in buzzer
QWTLF
Steady/Flashing
type
QWTLF - BZ
Steady/ Flashing
type with built-in
buzzer
1
AC/DC12V 0.065A
DC only
DC24V
only
0.34kg
R-Red AC/DC24V 0.050A 0.34kg
AC110V-220V Max. 0.025A 0.36kg
2
AC/DC12V 0.130A 0.41kg
R-Red
G-Green
AC/DC24V 0.100A 0.41kg
AC110V-220V Max. 0.050A 0.43kg
3
AC/DC12V 0.195A 0.48kg
R-Red
A-Amber
G-Green
AC/DC24V 0.150A 0.48kg
AC110V-220V Max. 0.075A 0.50kg
4
AC/DC12V 0.260A 0.55kg
R-Red
A-Amber
G-Green
B-Blue
AC/DC24V 0.200A 0.55kg
AC110V-220V Max. 0.100A 0.57kg
5
AC/DC12V 0.325A 0.62kg
R-Red
A-Amber
G-Green
B-Blue
W-White
AC/DC24V 0.250A 0.62kg
AC110V-220V Max. 0.125A 0.64kg
Installation Environment and Protection Rating
• This product is designed for indoor use with an enclosure ingress protection rating of IP54.
• If the product is installed in locations with excessive dust or water other than the designated IP protection rating indicated (IP54),
it may cause malfunction or damage to the product.
• For further information, please visit our website at http://www.qlight.com.
(Unit : mm)

3
Wiring Instructions
• QWT series can be wired with either an external contact or a transistor.
• When using a transistor, please choose the NPN transistor or PNP transistor which best matches the voltage and product type, then
connect them correctly according to the wiring diagram below.
• For QWTDLF model, user can choose light function between steady and ashing mode through wiring conguration.
• DC Steady type : Power/ Signal line specication : UL1007 AWG22 (0.3sq) 400mm
• AC Steady type, AC/ DC Steady/ Flashing type : Power line specication : UL1015 AWG18 (0.75sq)X2C 400mm
Signal line specication : UL1007 AWG22 (0.3sq) 400mm
External Contact Transistor
DC
Steady
QWTL-DC QWTL-DC
DC
Steady/
Flashing
QWTLF-DC QWTLF-DC
AC
Steady
QWTL-AC QWTL-AC
AC
Steady/
Flashing
QWTLF-AC QWTLF-AC
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
External Transistor-PNP
External Transistor-PNP
External Transistor-PNP
External Transistor-PNP
1
2
3
4
5
Buzzer
Buzzer Buzzer
Buzzer
Buzzer
1
2
3
4
5
Fuse
Fuse
Fuse
Fuse Fuse
Fuse
Fuse
Fuse
Fuse
Steady
Steady
Steady
Steady
Steady
Steady
Steady
Steady
Power
Power Power
Power
Power
Common
Common
Common
Common
Common
Common
Common
Common
Common
Common
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
Flash
External Contact
External Contact
External Contact
External Contact
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Brown(BN)
Black(BK)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Black(BK)
Brown(BN)
Black(BK)
Black(BK)
White(W)
Black(BK)
Black(BK)
White(W)
Black(BK)
Black(BK)
Gray(GR)
White(W)
Black(BK)
Black(BK)
White(W)
Black(BK)
Black(BK)
White(W)
Black(BK)
External Transistor-NPN
Layer1
Layer1 Layer1
Layer1
Layer1
Layer1
Layer2
Layer2 Layer2
Layer2
Layer2
Layer2
Layer3
Layer3 Layer3
Layer3
Layer3
Layer3
Layer4
Layer4 Layer4
Layer4
Layer4
Layer4
Layer5
Layer5 Layer5
Layer5
Layer5
Layer5
Buzzer
Buzzer Buzzer
Buzzer
Power
Power Power
Power
Layer1
Layer1 Layer1
Layer1
Layer1
Layer2
Layer2 Layer2
Layer2
Layer2
Layer3
Layer3 Layer3
Layer3
Layer3
Layer4
Layer4 Layer4
Layer4
Layer4
Layer5
Layer5 Layer5
Layer5
Layer5
Common
Steady
Flash
Red(R)
Amber(A)
Green(G)
Blue(B)
White(W)
Brown(BN)
Gray(GR)
Black(BK)
White(W)
Black(BK)

①
②
③ ④
4
Replacing/ Rearranging LED Lens Units
1. Remove the head cover (
②
) by loosening the xing screw (
①
).
2. Remove the LED unit by pulling it (
③
) upward.
3. Replace or rearrange the LED units.
4. Assemble in the reverse order of removing the LED units, Be
careful not to let the rubber ring(
④
) tted on the top of each unit
come off.
①
②
③
④
Parts Denition
Screw(M4×25mm)
Rubber Backing
(PVC)
Mounting Bracket
(SPCC)
Head Cover(ABS)
LED Unit (PC)
Please ensure the power is off
before replacing or rearranging
the LED units. Please carefully
follow the following instructions.
Installation
• The mounting bracket needs to be installed on the mounting surface before xing the product body onto the mounting bracket.
• Drill the proper number of mounting holes in accordance with the number of LED lens units, refer to the installation diagrams below.
① Remove the mounting bracket from the product by removing two M4
screws from the speaker unit.
② Mount the mounting bracket to the mounting surface.
③ Hook the rear of the head cover to the upper bracket, then push the
body against the mounting bracket.
④ After tightly attaching the product body to the mounting bracket, tighten
the two M4 screws removed in step ① at the bottom of the speaker unit.
M4-25 BOLT
M4-25 BOLT
M4-25 BOLT
M4-25 BOLT
41414141
43
21
4141
414321
4141
43
21
41
43
21
4321
2-Ø4 HOLES
Ø13 CABLE
ENTRY
3-Ø4 HOLES
4-Ø4 HOLES
5-Ø4 HOLES
6-Ø4 HOLES
Ø13 CABLE
ENTRY
Ø13 CABLE
ENTRY
Ø13 CABLE
ENTRY
Ø13 CABLE
ENTRY
Product Operation Inquiry / Customer Support [phone]
You can expect prompt service if you have exact information such as model name, symptom, telephone number and address.
※ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
Head office : A-412, 579 Kyungin-Ro, Guro-Gu, Seoul, Korea (Postal Code : 08212)
Factory : 185-25, Mukbang-Ro, Sangdong-Myeon, Gimhae-Si, Gyeongsangnam-Do, Korea (Postal Code : 50805) www.qlight.com
EN-1712A
