RAVEN SC1/TC1 INSTALLATION GUIDE FOR CASE IH STEIGER/NH T9.XXX (MY 16 AND NEWER)
RAVEN SC1/TC1 INSTALLATION GUIDE FOR CASE
IH STEIGER/NH T9.XXX (MY 16 AND NEWER)
This quick guide provides the instructions for the installation of SC1/TC1 on:
For calibration and operation information, refer to the Operation Manual (P/N 016-4010-005) included with the kit.
Make Year and Model Serial Number
Case IH 2016 and Newer Steering Ready All
New Holland 2016 and Newer T9.XXX Steering Ready ZFF403001 & Higher

2 Raven SC1/TC1 Installation Guide for Case IH Steiger/NH T9.XXX (MY 16 and Newer)
INSTALLATION DIAGRAM
Refer to Figure 1 on page 2 for a basic overview of the installation of the SC1/TC1 system. The sections that follow
offer more detailed installation procedures.
FIGURE 1. SC1/TC1 Cable Diagram for Case IH Steiger (MY 2016+) (P/N 054-5032-169 Rev. B)

016-5032-169 Rev. A E33370 7/2019 3
RAVEN SC1/TC1 INSTALLATION GUIDE FOR CASE IH STEIGER/NH T9.XXX (MY 16 AND NEWER)
ISOBUS DISPLAY CONNECTION
1. Connect the 12-pin connector of the ISOBUS display adapter cable (P/N 115-7300-126) to the existing mating
connector behind the trim in the rear-right corner post of the cab.
FIGURE 2. ISObus Display Mating Cable
2. Locate the Viper 4 cable (P/N 115-7300-126) or the CR7 cable (P/N 115-7300-092).
3. Connect the round 16-pin connector on the Viper 4 ISO cable (P/N 115-7300-135) or the CR7 cable (P/N 115-
7300-092) to the mating connector on the 115-7300-126 cable.
4. Follow the directions provided with the Viper 4 or CR7 to install the field computer.
5. Route and connect the Viper 4 adapter cable or CR7 adapter cable onto the mating connectors on the field
computer.

4 Raven SC1/TC1 Installation Guide for Case IH Steiger/NH T9.XXX (MY 16 and Newer)
INSTALL THE SC1/TC1 UNIT
1. Locate the instruction seat in the cab.
FIGURE 3. Instruction Seat
2. Remove the instruction seat and compartment wall to access the SC1/TC1 mounting location.
3. Mount the SC1/TC1 node (P/N 063-0174-070) to the mounting studs on the node mounting bracket and secure
using the supplied 1/4” - 20 flanged lock nuts (P/N 312-1001-168).
4. Mount the node and bracket assembly to the floor studs and secure to the floor using the supplied M6 x 1.0mm
nuts (P/N 312-1001-183).
FIGURE 4. Node and Bracket Secured to Floor Studs
5. Route and connect the two rectangular connectors of the cable (P/N 115-4010-123) to the mating ports of the
SC1/TC1 node.

016-5032-169 Rev. A E33370 7/2019 5
RAVEN SC1/TC1 INSTALLATION GUIDE FOR CASE IH STEIGER/NH T9.XXX (MY 16 AND NEWER)
INSTALL THE GPS RECEIVER CABLE
FIGURE 5. GPS Receiver Adapter Cable Connection
1. Locate and remove the existing cabling connecting the GPS receiver and the bulkhead connector to the roof.
2. Connect the two rectangular connectors of the cable (P/N 115-4010-105) to the GPS receiver.
3. Connect the remaining rectangular connector to the roof bulkhead connector.
MACHINE HARNESS CONNECTIONS
1. Locate the 40-pin Deutsch connectors on the floor inside the instructional seat.
2. Connect the 40-pin Deutsch connector to the mating connector on the SC1/TC1 cable (P/N 115-4010-123).
FIGURE 6. ECU Harness Connected to Machine Harness

6 Raven SC1/TC1 Installation Guide for Case IH Steiger/NH T9.XXX (MY 16 and Newer)
FIGURE 7. Machine Bulkhead Connection
3. Disconnect the machine bulkhead connector and tee in the mating connectors on the HDU harness (P/N 115-
4010-123).
OPERATION
Refer to the SC1/TC1 Calibration and Operation Manual (P/N 016-4010-005) for instructions on configuring,
calibrating, and operating SC1/TC1. Please note the location of the master switch and the resume switch on the
machine because they are needed for operation.
FIGURE 8. Master Switch and Resume Switch
Master Switch Resume Switch
