Raven SmarTrax User manual

SmarTrax™ Installation Manual
McCormick MFWD MTX120-155,
XTX 145-215, and TTX 190-230

While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be responsible or liable for incidental or consequential
damages or a loss of anticipated benefits or profits, work stoppage or loss, or
impairment of data arising out of the use, or inability to use, this system or any of
its components. Raven Industries shall not be held responsible for any
modifications or repairs made outside our facilities, nor damages resulting from
inadequate maintenance of this system.
As with all wireless and satellite signals, several factors may affect the availability
and accuracy of wireless and satellite navigation and correction services (e.g.
GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the
accuracy, integrity, continuity, or availability of these services and cannot
guarantee the ability to use Raven systems, or products used as components of
systems, which rely upon the reception of these signals or availability of these
services. Raven Industries accepts no responsibility for the use of any of these
signals or services for other than the stated purpose.
Disclaimer
©Raven Industries, Inc. 2012

Table of Contents
Manual No. 016-5030-017 Rev. A i
Chapter 1 Important Safety Information................................................. 1
Hydraulic Safety ........................................................................................................................2
Electrical Safety ........................................................................................................................2
Chapter 2 Introduction............................................................................. 3
Preparing for Installation ...........................................................................................................3
Recommendations ..............................................................................................................4
Point of Reference ...............................................................................................................4
Updates .....................................................................................................................................4
Kit Contents ...............................................................................................................................5
Chapter 3 Hydraulic System Installation.............................................. 11
Install Fittings in the SmarTrax Valve ......................................................................................12
Install Fittings in the Dual POCI Valve .....................................................................................13
Mount the SmarTrax Valve ......................................................................................................13
Mount the Dual POCI Valve ....................................................................................................15
Install the Left and Right Steering Hoses ................................................................................16
Install the Load Sense Hoses ..................................................................................................19
Install the Pressure and Tank Hoses .......................................................................................20
Hydraulic Diagram ...................................................................................................................23
Chapter 4 Wheel Angle Sensor Installation......................................... 25
Assemble the Wheel Angle Sensor (WAS) .............................................................................25
Mount the WAS .......................................................................................................................26
Chapter 5 Cab Component Installation................................................ 29
Install the SmarTrax Node .......................................................................................................29
Mount the SmarTrax Node ................................................................................................29
Node Mounting Locations ..................................................................................................30
Install the Foot Switch .............................................................................................................31
Install the Node Harness .........................................................................................................32
Install the Valve Harness .........................................................................................................32
Install the Chassis Cable - SmarTrax-Only Systems (If Applicable) ........................................35
Connect SmarTrax to an Existing Chassis Cable (If Applicable) ............................................35
System Diagrams ....................................................................................................................36
Chapter 6 Startup Procedures .............................................................. 41
Verify the SmarTrax System Installation .................................................................................41
Calibrate the SmarTrax System ..............................................................................................42

Table of Contents
ii McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual

CHAPTER
1
Manual No. 016-5030-017 Rev. A 1
C hapt er 1 Important Safety
Information
Read this manual and the operation and safety instructions included with your implement and/or controller
carefully before installing the SmarTrax™ system.
•Follow all safety information presented within this manual.
•If you require assistance with any portion of the installation or service of your Raven equipment, contact
your local Raven dealer for support.
•Follow all safety labels affixed to the SmarTrax system components. Be sure to keep safety labels in good
condition and replace any missing or damaged labels. To obtain replacements for missing or damaged
safety labels, contact your local Raven dealer.
When operating the machine after installing SmarTrax, observe the following safety measures:
•Be alert and aware of surroundings.
•Do not operate SmarTrax or any agricultural equipment while under the influence of alcohol or an illegal
substance.
•Remain in the operator’s position in the machine at all times when SmarTrax is engaged.
•Disable SmarTrax when exiting the operator’s seat and machine.
•Do not drive the machine with SmarTrax enabled on any public road.
•Determine and remain a safe working distance from other individuals. The operator is responsible for
disabling SmarTrax when the safe working distance has diminished.
•Ensure SmarTrax is disabled prior to starting any maintenance work on SmarTrax or the machine.
•When starting the machine for the first time after installing SmarTrax, be sure that all persons stand clear in
case a hose has not been properly tightened.
•The machine must remain stationary and switched off during SmarTrax installation or maintenance.
NOTICE
WARNING

Chapter 1
2McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
Hydraulic Safety
•Raven Industries recommends that appropriate protective equipment be worn at all times when working on
the hydraulic system.
•Never attempt to open or work on a hydraulic system with the equipment running. Care should always be
taken when opening a system that has been previously pressurized.
•When disconnecting the hydraulic hoses or purging is required, be aware that the hydraulic fluid may be
extremely hot and under high pressure. Caution must be exercised.
•Any work performed on the hydraulic system must be done in accordance with the machine manufacturer’s
approved maintenance instructions.
•When installing SmarTrax hydraulics or performing diagnostics, maintenance, or routine service, ensure
that precautions are taken to prevent any foreign material or contaminants from being introduced into the
machine’s hydraulic system. Objects or materials that are able to bypass the machine’s hydraulic filtration
system will reduce performance and possibly damage the SmarTrax valve.
Electrical Safety
•Always verify that the power leads are connected to the correct polarity as marked. Reversing the power
leads could cause severe damage to the equipment.
•Ensure that the power cable is the last cable to be connected.
CAUTION

CHAPTER
2
Manual No. 016-5030-017 Rev. A 3
C hapt er 2 Introduction
Congratulations on your purchase of the SmarTrax system! This system is designed to provide cutting-edge,
hands-free steering of the machine via Global Positioning System (GPS) coordinates.
This manual applies to the following machines:
MAKE: McCormick
MODEL: MFWD MTX Series: MTX120, MTX135, MTX145, MTX150, and MTX155
MFWD XTX Series: XTX145, XTX165, XTX185, XTX200, and XTX215
MFWD TTX Series: TTX190, TTX210, and TTX230
FIGURE 1. McCormick XTX145
Preparing for Installation
Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the
machine and leave it turned off for the duration of the installation process. Bleed pressure from the hydraulic
system by loosening the hydraulic fittings slowly, where applicable.

Chapter 2
4McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
During the installation process, follow good safety practices. Be sure to carefully read the instructions in this
manual as you complete the installation process.
Recommendations
Raven Industries recommends the following best practices when installing or operating the SmarTrax system
for the first time, at the start of the season, or when moving the SmarTrax system to another machine:
•Install the GPS antenna in the recommended location. Refer to the following table for the machine-specific
antenna mounting location.
Note: If your machine is not listed, install the antenna on the front-center of the cab.
Note: The units in the table below are measured in inches. To convert the values to centimeters, multiply
the listed value by 2.54.
Note: The values in the table below must be converted into feet or meters before being entered into the
field computer.
○To convert the values to feet, divide the listed value by 12.
○To convert the values to meters, multiply the listed value by 0.0254.
•Ensure the machine’s hydraulic filters have been recently changed and there are no issues with the
machine’s hydraulic system (e.g., pump issues, faulty hydraulic motors, fine metal deposits in the hydraulic
hoses, etc.).
•Ensure the machine’s hydraulic system is using fresh oil and debris is flushed from the hydraulic hoses,
valves, and filters.
Raven Industries recommends the following best practices when installing the SmarTrax system:
•Use part numbers to identify the parts.
•Do not remove the plastic wrap from a part until it is necessary for installation.
•Do not remove plastic caps from a part until it is necessary for installation.
Point of Reference
The instructions in this manual assume that you are standing behind the machine, looking toward the cab.
Updates
Software and manual updates are available on the Raven Applied Technology website:
http://www.ravenhelp.com
Machine Preset
Antenna X Position
(left to right) Antenna Y Position (from the rear wheel
axle to the antenna
position on the cab
in inches)
Antenna Z Position
(ground to top of
antenna in inches)
McCormick MTX/XTX/TTX Centered 58 108

2
Manual No. 016-5030-017 Rev. A 5
Introduction
Kit Contents
This section contains a list of the components that are included in the SmarTrax kit. Before beginning the
SmarTrax installation, compare the items in the kit with the components on this list. If you have questions about
the kit, contact your Raven dealer.
At Raven Industries, we strive to make your experience with our products as rewarding as
possible. One way to improve this experience is to provide us with feedback on this manual.
Your feedback will help shape the future of our product documentation and the overall service
we provide. We appreciate the opportunity to see ourselves as our customers see us and are
eager to gather ideas on how we have been helping or how we can do better.
To serve you best, please send an email with the following information to
[email protected]
-McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™
Installation Manual
-Manual No. 016-5030-017 Rev. A
-Any comments or feedback (include chapter or page numbers if applicable).
-Let us know how long have you been using this or other Raven products.
We will not share your email or any information you provide with anyone else. Your feedback
is valued and extremely important to us.
Thank you for your time.
TABLE 1. SmarTrax Installation Kit (P/N 117-5030-017)
Picture Item Description Part Number Qty.
Not Pictured Manual - McCormick MFWD MTX, TTX, and
XTX Series SmarTrax Installation 016-5030-017 1
Valve - Dual POCI 334-003-030 1
Valve - SmarTrax Hydraulic 334-0003-088 1
Bracket - Slotted Linear Wheel Angle Sensor
(WAS) Mounting 107-0172-076 1

Chapter 2
6McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
Bracket - 90° Formed Wheel Angle Sensor
Mounting 107-0172-077 1
Bracket - Node Mounting 107-0172-128 1
Bracket - POCI Valve Mounting 107-0172-136 1
Bracket - Valve Mounting 107-0172-215 1
Cable - Valve Harness 115-4001-096 1
Sensor - 250 mm Non-Contact Linear Wheel
Angle 063-0181-017 1
Mount - M10 Stud Linear Sensor 103-0001-030 2
Clamp - 1-3/8” U-Bolt Muffler 435-3003-054 1
Spacer - 0.406” ID x 0.75” OD x 1” Long 107-0172-038 1
Transducer - 0-3000 PSI Pressure 422-0000-086 1
Bolt - 1/4”-20 UNC x 1” Hex 311-0050-105 2
TABLE 1. SmarTrax Installation Kit (P/N 117-5030-017)
Picture Item Description Part Number Qty.

2
Manual No. 016-5030-017 Rev. A 7
Introduction
Bolt - 1/4”-20 UNC x 2” Hex 311-0050-109 2
Bolt - 5/16”-18 UNC x 3/4” Hex 311-0052-103 2
Bolt - 5/16”-18 UNC x 1” Hex 311-0052-105 2
Bolt - 5/16”-18 UNC x 2-1/2” Hex 311-0052-111 2
Nut - 1/4”-20 Flanged Lock 312-1001-168 4
Nut - 5/16”-18 UNC Flanged Lock 312-1001-169 2
Nut - M10 x 1.5 x 5 mm Thick Jam 312-1002-035 2
Nut - M10 x 1.35 Nylon Insert Lock 312-4000-208 2
Nut - 5/16”-18 Thin Nylon Insert Lock 312-4001-107 2
Nut - 3/8”-16 Thin Nylon Insert Lock 312-4001-109 3
Washer - 5/16” Split Lock 313-1000-019 4
TABLE 1. SmarTrax Installation Kit (P/N 117-5030-017)
Picture Item Description Part Number Qty.

Chapter 2
8McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
Washer - 5/16” Steel Flat 313-2300-011 2
Washer - 7/16” Steel Flat 313-2300-015 2
TABLE 2. Hydraulic Installation Kit (P/N 117-0199-127)
Picture Item Description Part Number Qty.
Fitting - -4 ORFS M/F 90° Swivel Elbow 333-0012-023 1
Fitting - -8 ORFS M/M/F Swivel Run Tee
Adapter 333-0012-028 2
Fitting - -4 SAE O-Ring Internal Hex Plug 333-0012-051 1
Fitting - -8 ORFS M/F 90° Elbow 333-0012-067 4
Fitting - -8 ORFS M/M Straight Adapter 333-0012-070 1
Fitting - -8 ORFS M/F 45° Swivel Elbow 333-0012-102 2
Fitting - -8 ORFS (M) to -8 SAE O-Ring (M)
Straight Adapter 333-0012-168 8
Fitting - -4 ORFS (M) to -6 SAE O-Ring (M)
Straight Adapter 333-0012-195 2
TABLE 1. SmarTrax Installation Kit (P/N 117-5030-017)
Picture Item Description Part Number Qty.

2
Manual No. 016-5030-017 Rev. A 9
Introduction
Note: The node installation kit is sold separately.
Fitting - -8 ORFS (M) to -10 SAE O-Ring (M)
Straight Adapter 333-0012-304 2
Hydraulic Hose - -4 ORFS (F) 90° to -4
ORFS (F) - 24” 214-1000-969 1
Hydraulic Hose - -8 ORFS (F) 90° to -8
ORFS (F) - 36” 214-1000-970 3
Hydraulic Hose - -8 ORFS (F) 90° to -8
ORFS (F) - 28” 214-1000-971 3
Hydraulic Hose - -8 ORFS (F) to -8 ORFS (F)
- 21” 214-1000-972 1
TABLE 3. Node Mounting Kit (P/N 117-5030-005)
Picture Item Description Part Number Qty.
Not Pictured Manual - SmarTrax and SmartSteer
Calibration & Operation 016-0171-277 1
Node - SmarTrax 3D CAN Control 063-0173-228 1
Harness - SmarTrax Node 115-4001-109 1
Assembly - SmarTrax Enable Foot Switch 063-0172-470 1
TABLE 2. Hydraulic Installation Kit (P/N 117-0199-127)
Picture Item Description Part Number Qty.

Chapter 2
10 McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual

CHAPTER
3
Manual No. 016-5030-017 Rev. A 11
C hapt er 3 Hydraulic System
Installation
WARNING
Hydraulics are under pressure. Care should
always be taken with a system that has been
pressurized.
Before beginning the SmarTrax hydraulic
installation, turn off the machine and relieve
pressure by turning the steering wheel left and
right.
Never work on a hot machine. Always allow it to
cool before performing diagnostics,
maintenance, or routine service.
When disconnecting or purging hydraulic
hoses, be aware that the hydraulic fluid within
the machine’s system may be extremely hot
and under high pressure.
Tampering with hydraulic valves may cause
serious injury or death, and will void the
warranty.
CAUTION
When installing SmarTrax hydraulics or
performingdiagnostics,maintenance,or routine
service, ensure precautions are taken to
prevent any foreign material from being
introduced into the machine’s hydraulic system.
Objects or materials that are able to bypass the
machine’s hydraulic filtration system will reduce
performance and possibly damage the
SmarTrax hydraulic valve.

Chapter 3
12 McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
Install Fittings in the SmarTrax Valve
Before mounting the SmarTrax valve (P/N 334-0003-088) on the machine, install the proper fittings in the
valve. This prepares the valve for installation and simplifies the hose connection process later in the procedure.
FIGURE 1. Fittings Installed in the SmarTrax Valve
NOTICE
The appearance of the SmarTrax hydraulic
valve may vary slightly from the images
contained in this manual. However, the fittings,
hose connections, and cable connections
remain the same.
Fitting Part Number Port
Fitting - -8 ORFS (M) to -8 SAE O-Ring (M) Straight Adapter 333-0012-168 P, T
Fitting - -8 ORFS (M) to -10 SAE O-Ring (M) Straight Adapter 333-0012-304 A, B
Fitting - -4 ORFS (M) to -6 SAE O-Ring (M) Straight Adapter 333-0012-195 LSPV,
LS STEER
Transducer - 0-3000 PSI Pressure 422-0000-086 PS

3
Manual No. 016-5030-017 Rev. A 13
Hydraulic System Installation
Install Fittings in the Dual POCI Valve
1. Remove the fittings that were pre-populated in the dual POCI valve (P/N 334-0003-030).
Note: These fittings are not used in the SmarTrax system installation.
FIGURE 2. Fittings Installed in the Dual POCI Valve
2. Refer to Figure 2 and the table above to install the proper fittings in the dual POCI valve.
Mount the SmarTrax Valve
FIGURE 3. Valve Mounting Location
1. Identify the valve mounting location along the left side of the tractor and in front of the cab, on top of the rear
hood mount.
Fitting Part Number Port
Fitting - -4 SAE O-Ring (M) Plug 333-0012-051 PS
Fitting - -8 ORFS (M) to -8 SAE O-Ring (M) Straight Adapter 333-0012-168 A, B, A1
B1, A2, B2

Chapter 3
14 McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
FIGURE 4. Machine’s Hood Mounting Bolts
2. Remove the existing bolts used to secure the hood mount to the machine’s frame.
FIGURE 5. Mounting Bracket Positioning
3. Align the valve mounting bracket (P/N 107-0172-215) over the holes in the machine’s frame.
FIGURE 6. Valve Bracket Installed
4. Reinstall the hood mounting bolts, securing the valve mounting bracket to the frame.

3
Manual No. 016-5030-017 Rev. A 15
Hydraulic System Installation
FIGURE 7. SmarTrax Valve Installed
5. Secure the SmarTrax valve (P/N 334-0003-088) to the valve mounting bracket by installing two 5/16”-18
UNC x 3/4” hex bolts (P/N 311-0052-103) and two 5/16” lock washers (P/N 313-1000-019) in the two holes
nearest to the machine’s cab.
Mount the Dual POCI Valve
FIGURE 8. Dual POCI Valve Installed
1. Install the dual POCI valve mounting bracket (P/N 107-0172-136) on the two remaining holes in the
SmarTrax valve mounting bracket (P/N 107-0172-215) using two 5/16”-18 UNC x 1” hex bolts (P/N 311-
0052-105) and two 5/16” lock washers (P/N 313-1000-019).
Note: The bolts will secure the other side of the SmarTrax valve to the valve mounting bracket when
installed.
2. Secure the dual POCI valve (P/N 334-0003-030) to the underside of the dual POCI valve mounting bracket
using two 5/16”-18 x 2-1/2” bolts (P/N 311-0052-111) and two 5/16” -18 UNC flanged lock nuts (P/N 312-
1001-169).
Note: The hole in the dual POCI valve mounting bracket should align with the -4 SAE O-ring (M) plug
fitting (P/N 333-0012-051) installed in the PS port of the dual POCI valve.

Chapter 3
16 McCormick MFWD MTX120-155, XTX145-215, and TTX190-230 Series SmarTrax™ Installation Manual
Install the Left and Right Steering Hoses
1. Install a -8 ORFS M/F 45° swivel elbow fitting (P/N 333-0012-102) on the fitting in Port A2 of the dual POCI
valve (P/N 334-0003-030).
FIGURE 9. Machine’s Left Steering Hose on Steering Orbital
2. Disconnect the machine’s left steering hose from the steering orbital.
FIGURE 10. Machine’s Left Steering Hose Connected to Dual POCI Valve
3. Connect the left steering hose to the elbow fitting installed in Port A2 of the dual POCI valve.
4. Install a -8 ORFS M/F 45° swivel elbow fitting (P/N 333-0012-102) on the fitting in Port B2 of the dual POCI
valve.
