Razor C25 User manual

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
1
WARNING
Step 1 Step 2
Required Tools: (Not included)
A. 4 mm Allen wrench
B. Flat screwdriver
C. 5 mm Allen wrench
CAUTION: To avoid potential shock or other injury, turn power switch OFF and disconnect
charger before conducting any assembly or maintenance procedures. Failure to follow these
steps in the correct order may cause irreparable damage.
Using a 4 mm Allen wrench, loosen and remove the four
(4) bolts that attach the t-bar to the stem.
Remove the t-bar from the stem being careful not to
damage the wires. Using both hands disconnect the plug
from the t-bar.
C25/C25 SLA
FOLDING MECHANISM - STEM REPLACEMENT
PART # W13113290055

Need Help? Visit our website at www.razor.com or call toll-free at 866-467-2967 Monday - Friday 8:00am - 5:00pm Pacific Time.
2
Step 3
Step 5
Step 7
Step 4
Step 6
Using a flat screwdriver, remove the grommet at the
bottom of the stem.
Using a 5 mm Allen wrench, loosen the two (2) bolts that
clamp the folding mechanism onto the front fork.
Reverse the steps.
ATTENTION: Charge battery 8 hours before using.
Fold the stem by pressing the folding latch button and
pulling the lever.
Loosen and remove the bolt and top cap, slide the folding
mechanism up and out from the fork.
