Razor Powerwing User manual

OWNER’S MANUAL
Read and understand this entire manual before allowing
child to use this product! For assistance contact Razor.
DO NOT RETURN TO STORE.
NOTE: Manual illustrations are for demonstration purposes only.
Illustrations may not reflect exact appearance of actual product.
Specifications subject to change without notice.
Please have your product along with the 22 character product I.D. code with you
before contacting Razor for warranty assistance and/or replacement parts.
Product I.D. Code: _____________ - ____________ - ____________

CONTENTS
SAFETY WARNINGS
1
Safety Warnings................................................................................................1
Before You Begin...............................................................................................2
Assembly and Set-Up.................................................................................... 3-4
Pre-Ride Checklist and Usage...........................................................................5
PowerWing®Parts ............................................................................................6
Warranty and Contact Information ..................................................................7
AN IMPORTANT MESSAGE TO PARENTS: This manual contains
many warnings and cautions concerning the consequences of failing to
maintain, inspect or properly use your PowerWing. Because any incident
can result in serious injury or even death, we do not repeat the warning of
potential serious injury or death each time such a possibility is mentioned.
WARNING: Riding the PowerWing can be a hazardous activity.
Certain conditions may cause the equipment to fail without fault of the
manufacturer. Like other wheeled products, the PowerWing can and is
intended to move, and it is therefore possible to lose control, fall off and/or
get into dangerous situations that no amount of care, instruction or expertise
can eliminate. If such things occur, your child can be seriously injured or
die, even when using safety equipment and other precautions. USE
COMMON SENSE.
APPROPRIATE RIDER USE AND PARENTAL SUPERVISION
Direct adult supervision is required at all times. This manual contains
important safety information. It is your responsibility to review this
information and make sure that all children obey all warnings, cautions,
instructions and safety topics, and assure that young riders are able to
safely use this product. Razor recommends that you periodically review and
reinforce the information in this manual with young riders, and that you
inspect and maintain your children’s product to ensure their safety.
The recommended rider age of 6 years and older for the PowerWing is
only an estimate, and can be affected by the rider’s size, weight or ability.
Any child unable to fit comfortably on the PowerWing should not attempt
to ride it.
A parent’s decision to allow his or her child to ride this product should be
based on the child’s maturity, skill and ability to follow rules.
Do not exceed 143 lb (65 kg) on the PowerWing.
Rider weight does not necessarily mean a child’s size is appropriate to fit or
maintain control of the PowerWing.
ACCEPTABLE RIDING PRACTICES AND CONDITIONS
Direct parental supervision is required. The PowerWing is meant to be
used only in controlled environments, free of potential traffic hazards and
not on public streets. Do not allow your child to ride the PowerWing in any
areas where vehicle traffic is present. Child must maintain a hold on the
handlebars at all times. Never allow more than one child at a time to ride the
PowerWing. Never use near steps, sloped driveways, hills, roadways, alleys
or swimming pool areas.
Do not ride the PowerWing in wet weather. The PowerWing is intended for
use on solid, flat, clean and dry surfaces, such as pavement or level ground,
without loose debris such as rocks or gravel. Wet, slick or uneven and rough
surfaces may impair traction and contribute to possible accidents. Do not ride
the PowerWing in mud, ice, puddles or water. Avoid excessive speeds that
can be associated with downhill rides. Never risk damaging surfaces, such
as carpet or flooring, by use of a PowerWing indoors. Do not ride at night or
when visibility is impaired.
PROPER RIDING ATTIRE
Always ensure child is wearing proper protective equipment, such as an
approved safety helmet. A helmet may be legally required by local law or
regulation in your area. A child should always wear shoes and keep shoelaces
tied and out of the way of the wheels. Never ride barefooted or in sandals.
WARNING: ALWAYS INSPECT POWERWING PRIOR TO RIDING.
Properly inspecting and maintaining your PowerWing can reduce the risk
of injury. Always inspect your PowerWing before riding and regularly
maintain it.
WARNING: CHECK LOCAL LAWS REGARDING POWERWING USE.
Check local laws and regulations to see where and how you may use your
Razor PowerWing legally. In many states and local areas, PowerWing riders
may be required BY LAW to wear a helmet. Check local laws and regulations
regarding laws governing helmet use and PowerWing operation in your area.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE
WARNINGS FURTHER INCREASES RISK OF SERIOUS INJURY. USE
AT YOUR OWN RISK AND WITH APPROPRIATE AND SERIOUS
ATTENTION TO SAFE OPERATION. USE CAUTION.

BEFORE YOU BEGIN
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
2
WARNING: DO NOT
USE NON-RAZOR PRODUCTS
WITH YOUR POWERWING. The
PowerWIng has been built to
certain Razor design specifications.
The original equipment supplied at
the time of sale was selected on
the basis of its compatibility with
the frame, fork and all other parts.
Certain aftermarket products may
not be compatible and will void
the warranty.
Remove contents from box and check parts against part diagram below. Remove the separators that protect the
components from damage during shipping. Inspect the contents of the box for scratches in the paint, dents or kinked
cables that may have occurred during shipping. Because the PowerWing is partially assembled and packed at the
factory, there should not be any problems even if the box has a few scars or dents.
Estimated Assembly and Set-Up Time
Allow up to 15–20 minutes for assembly. Razor recommends assembly by an adult.
Product ID Locations:
(See locations to the left)
1. Side of frame
2. Barcode on side of box
(not shown)
Box Contents:
• PowerWing
• Allen Wrenches
• Owner’s Manual
Required Tool
Two (2) 5 mm Allen Wrenches
(Included)
Brake Lever
Collar Clamp
Handlebar Stem
Rear Caster
Rear Wheel
Front Wheel
1.
Right Platform
Left Platform
Frame

53 mm 21 mm
ASSEMBLY AND SET-UP
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
3
Attaching the Platforms
Required Tools: Two (2) 5 mm Allen Wrenches
Attaching the Handlebars
Required Tool: 5 mm Allen Wrench
1Using two (2) 5 mm Allen
wrenches, remove the two coupling
bolts from the frame.
Note: If necessary, carefully tap the coupling bolt with a rubber mallet until
it is all the way through the other side of the frame.
1Place the handlebar stem onto
the front fork.
2Align the holes on the right and
left platforms with the holes on
the frame.
2With the front wheel pointed
straight ahead, the handlebars
square to the front wheel and the
Razor logo facing the front, use a
5 mm Allen wrench to tighten
the two (2) bolts on the collar
clamp. The collar clamp is properly
tightened when the handlebars
cannot be twisted out of alignment
with the front wheel. Note: The cable assembly from the
handlebar must not wrap around
the handlebar stem. Sharp bends
or twisting of the brake cable can
cause the brake to malfunction.
3Re-insert coupling bolt (A) first,
then re-insert coupling bolt (B).
Tighten using two (2) 5 mm Allen
wrenches.
Note: The platforms should be snug
against the frame.
A
B

ASSEMBLY AND SET-UP
4
Adjusting the Brake
Required Tools: 3 mm Allen Wrench and 8 mm Allen Wrench
1To adjust the brake cable wire,
thread the brake lever adjuster in or
out 1/4 to 1/2 turn until the desired
cable tension is attained.
2Squeeze the brake lever to test
the brake to make sure it is working
properly. The front fender should
clamp down and rub against the
front wheel. If brake is not working
properly, proceed to the next step.
3If the brake is too tight or too
loose, use a 8 mm wrench and
a 3 mm Allen wrench to adjust
as needed.

PRE-RIDE CHECKLIST
USAGE
5
Loose Parts
Check and secure all fasteners before every ride. Make sure
the steering bolts and foot platforms are tight. There should
not be any unusual rattles or sounds from loose parts or
broken components. If you are not sure, call 1-866-467-2967
for assistance.
Replacement Parts
Replace worn or broken parts immediately.
Call 1-866-467-2967 for parts or visit www.razor.com.
Brake
Check the brake for proper function. When you squeeze the
brake lever, the brake should provide positive braking action.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames
are rare, it is possible for an aggressive rider to run into a curb
or wall and wreck, bend or break a frame. Get in the habit of
inspecting yours regularly.
Safety Gear
Always wear proper protective equipment, such as an approved
safety helmet, elbow pads and kneepads. Always wear shoes
(lace-up with rubber soles) and keep shoelaces tied and out of
the way of the wheels. Never ride barefooted or in sandals.
How to Ride
Place both hands on the handlebars. Place one foot on the platform directly above the caster. Push off with the other
foot then place foot on the other platform directly above the caster. Slightly bend knees. With handlebars straight,
swing hips and legs side to side. Shifting weight on the platforms from right to left in sync with hips and legs. The
side to side motion acts to self propel the PowerWing. No pushing required.
How to Stop
Apply hand brake by squeezing brake lever.
Note: Do not step off of
platforms until unit has come to
a complete stop.

1
3
3
4
5
6
7
8-1
10
11
12
12-1
13
14
11-1
8-2
8-2
9
8
8-3
2
12-1
POWERWING PARTS
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
6
Keep your PowerWing working for years with genuine Razor parts. Visit our website www.razor.com to purchase replacement parts.
(Specifications subject to change without notice.)
1. Handlebar Stem
2. Handlebar Grip (x2)
3. Handlebar End Caps
4. Brake Lever Assembly
5. Brake Cable Guide
6. Collar Clamp
7. Headset Bearings (Upper/Lower)
8. Front Wheel
8-1 Front Wheel Washer
8-2 Front Wheel Bearing (x2)
8-3 Front Wheel Spacer
9. Front Axle Bolt
10. Front Fork with Fender Assembly
11. Platforms (Right/Left)
11-1 Platform Coupling Bolt (x2)
12. Stability Bar (Right/Left)
12-1 5 mm Hexagonal Bolt (x4)
13. Caster (Right/Left)
14. 64 mm Rear Wheel (Right/Left)

WARRANTY
7
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing
defects for a period of 6 months from date of purchase. This Limited
Warranty does not cover normal wear and tear, wheels, or any damage,
failure or loss caused by improper assembly, maintenance, storage or use of
the Razor PowerWing.
This Limited Warranty will be void if the product is ever:
• used in a manner other than for recreation or transportation;
• modified in any way;
• rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
Razor does not offer an extended warranty. If you have purchased
an extended warranty, it must be honored by the store at which it
was purchased.
For your records, save your original sales receipt with this manual and write
the serial number below.
__________________________________________
CUSTOMER SERVICE CONTACT INFORMATION
Need Help? Visit our website for product support, a list of authorized service centers in the US and customer service contact information at
www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed below:
AMERICAS
Razor USA LLC
P.O. Box 3610
Cerritos, CA 90703
USA
[phone]
Monday - Friday
8:00 AM - 5:00 PM Pacific Time
[e-mail]
EUROPE, MIDDLE EAST, AFRICA
Razor USA LLC (Europe)
Handelsweg 2
2742 RD Waddinxveen
Netherlands
[phone]
[e-mail]
ASIA
Razor USA LLC (Asia)
P.O. Box 3610
Cerritos, CA 90703
USA
[phone]
[e-mail]
UNITED KINGDOM AND IRELAND
Razor USA LLC (UK)
Unit 20
Hartnoll Business Centre
Post Hill, Tiverton
Devon EX16 4NG
UK
[phone]
[e-mail]
DISTRIBUTED IN AUSTRALIA BY:
Funtastic Limited
Suite 2.01, Level 2
315 Ferntree Gully Road
Mount Waverley Vic 3149,
Australia
[phone]
[e-mail]
US Patent No. 7,597,334 B2, 7,681,895 B2 & 7,784,803 B2
Printed in China for Razor USA LLC.
Copyright © 2003-2020 Razor USA, LLC. All rights reserved. Razor®and the Razor logo design are among the registered trademarks of Razor USA LLC in the United States and/or select foreign countries. PowerWing®and the
PowerWing logo design are trademarks of Razor USA LLC.
US_200713
