Record KEANE MONROE 2000 Series User manual

REGULAR ARM
PARALLEL ARM
PARALLEL ARM / PANIC BREAKAWAY
SLIDE ARM
SERIES 2000
INSTALLATION INSTRUCTIONS
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 1
INSTALLATION INSTRUCTIONS
INDEX and OPERATOR HANDING
INDEX PAGE
HAND OF DOOR IDENTIFICTION…………………………………………………………….1
ELECRTICAL PREPERATION………………………………………………………………....2,3
BACK PLATE INSTALLATION…………………………………………………………………4, 5, 6
OPERATOR INSTALLATION –REGULAR ARM…………………………………………....7
OPERATOR INSTALLATION -PARALLEL & SLIDE ARM………………………………...8
REGULAR ARM INSTALLATION………………………………………………………………9,10
PARALLEL ARM INSTALLATION……………………………………………………………..11,12
MANUAL ROTATION OF OPERATOR PINION………………………………………………13
PARALLEL ARM INSTALLATION WITH PANIC BREAKAWAY…………………………..14,15
PANIC BREAKAWAY ADJUSTMENT………………………………………………………....16
SLIDE ARM INSTALLATION……………………………………………………………………17, 18
ADJUSTMENT AND CHECKOUT……………………………………………………………...19,20,21,22
COVER INSTALLATION………………………………………………………………………….23
THE WORDS “CAUTION”, “NOTE”, AND THE SYMBOL WHERE INDICATED IN THIS
BOOK, MEAN PROPERTY DAMAGE, SERIOUS INJURY OR DEATH COULD RESULT IF PRECAU-
TIONARY DIRECTIONS ARE NOT FOLLOWED.
The sequence of installation and adjustment is in order, however, some sections will not apply. Review
this instruction manual and determine those sections that do apply. Be sure all doors swing freely and
clear all objects before attaching arms. Precaution must be taken with parallel arms and adjacent walls.
HAND OF DOOR IDENTIFICATION
LHR ( RH OUT)
REGULAR ARM RHR ( LH OUT) REGULAR ARM LH ( LH IN ) PARALLEL ARM RH ( RH IN ) PARALLEL ARM
LH ( LH IN )
SLIDE ARM RH ( RH IN ) SLIDE ARM LH PARALLEL
ARM W/PANIC RH PARALLEL ARM W/PANIC
The KM Series 2000 operator has been carefully designed, built, and tested to provide years of service.
The life of this operator package is directly related to how carefully the installation is accomplished and
how accurately the instructions are followed. Installation of this operator package should be done by a
properly trained and knowledgeable installer with a knowledge of local code requirements and the require-
ments of ANSI 156.10 Standards for Power Operated Pedestrian Doors. The authorized service/
installation dealer must perform all measurements for forces, speeds, and times to insure proper and safe
operation.
KM Systems is not responsible for improperly adjusted or maintained automatic doors or activation/safety
systems and assumes no responsibility for damages caused by automatic door systems that have not
been properly installed, tested, and adjusted.
!
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 2.
INSTALLATION INSTRUCTIONS
ELECTRICAL PREPARATION
ELECTRICAL PREPARATION
Before preparing jambs, determine the method and requirements for the electrical wiring
involved and whether mats or other type of activation is used.
For mounting on-off-hold switch proceed to Operator Installation section.
CAUTION -Some local codes require on-off-hold open switches to be installed no higher
than 6’-6” above the floor. A suggested method of installation is to prepare a 1/2” dia. hole
as shown. To install, place switch through top hole (1-1/2” dia.). While holding lead wires,
lower switch to second hole (1/2” dia.) and fish out toggle end of switch.
Install tabbed legend washer with mounting nut and secure with self-tapping screw.
OWNER INFORMATION TO BE PROVIDED BY THE DISTRIBUTOR / INSTALLER
•After the installation instruct the owner on the safe operation of the door.
•Location and proper use of the power switches.
•Location of the main cutoff breaker.
•Necessary warnings not covered in general instructions.
•Owners Manual and Daily Safety Checklist.
•Phone number(s) for the local servicing dealer.
•What to do in the event that a dangerous situation should occur, and how to shut the doors
down and call for service.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 3.
INSTALLATION INSTRUCTIONS
ELECTRICAL PREPARATION (cont.)
CONCEALED
Run flexible conduit or 3-wire cable down
side jamb, through cut-out. Trim sufficient
length of wire and insert into 90 degree con-
nector. Attach connector to bracket and se-
cure with lock nut. Trim wire to proper
length when wiring unit. Secure ground wire
to operator base or control.
ELECTRICAL POWER
SURFACE MOUNT
Connect 90 degree elbow to bracket as
shown, pull sufficient length of wire. Trim
to proper length when wiring unit. Se-
cure ground wire to base or control.
Control
Conduit Bracket
90° Elbow
ELECTRICAL POWER SUPPLY
1. Single Operator (1 Motor)
115-120 Volt, 60 Hertz, 15 Amp.
2. Dual or Pair of Single Operators (2 Motors)
115-120 Volt, 60 Hertz, 20 Amp
3. Pair Dual or Four Single Operators (4 Motors)
115-120 Volt, 60 Hertz, 30 Amp.
Note: All 3-wire Systems (2 wire w/ground).
All fuses & circuit breakers to be Slow Blow Type.
RECOMMENDED WIRE SIZE CHART
Length of Run Wire Size
Distance to
Main Panel Single Oper. (1Motor) Dual Oper. (2Motors) Pair Duals (4Motors)
100' #14 #12 #10
200' #12 #10 #8
300' #12 #8 #6
400' #10 #8 #6
500' #10 #8 #6
BACK PLATE INSTALLATION
Before preparing jamb for back plate, determine the hand of the door. If door hand is LH Regular
or RH Parallel proceed as shown on next page. If the door hand is RH Regular or LH Parallel, re-
verse the back plate end to end so that it is opposite as shown. See Page 1 for Hand of Door
Identification.
MOUNTING BACK PLATE
Mount to prepared jamb using furnished flat head screws suitable for prepared holes.
Note: For swing clear hinges, place end of back plate 1 3/8” beyond the centerline of hinge pin or
order special length back plate and cover (See Installation of Cover and Back Plate of a different
length than door opening).
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 4.
INSTALLATION INSTRUCTIONS
BACK PLATE INSTALLATION
HOLE PREPARATION INSTRUCTIONS
For Metal frames with 1/8” or greater material thickness,
drill #7 hole and tap for 1/4-20 x 3/4” machine screws as
required. For Metal frames with less than 1/8” material
thickness or Wood frames, drill 3/16” pilot hole for #14 x
1 1/4” sheet metal screws as required.
Note:
When door stop is more
than 1/2” high, the back
plate should be lowered
by the amount exceed-
ing 1/2” for Regular.
1”
Top of
Door
14 3/8” (Ref. only)
1/2”
*1 3/8”
*1/2”
Centerline of
Operator Pinion
3”
*Plate Location Dimensions
8” on centers
across as
required
2 3/8”
Top
Of
Door
Note:
LH Regular or RH Parallel shown
RH Regular or LH Parallel Opposite
Slide Arm same as Parallel Arm
All door frames for regular arm and parallel
arm operation must be provided with door
stops.
Doors and frames for parallel operation with
panic breakaway must be center pivoted or
be capable of swinging in both directions
with no stops.
!
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 5.
INSTALLATION INSTRUCTIONS
DUAL BACK PLATE INSTALLATION
Installation of Covers and Back plates of a different length than Door Opening
1. Mounted as is
2. Cut to door size
If no overlap is desired, measure and cut back plate and cover as shown
3. Cut under door size
When the back plate is shorter than the width of the door, an angle bracket should be installed
the full length of the back plate. (less than 1 3/8” overlap)
Back Plate Transom
Angle Bracket
Door Opening + 3” Hinge or
Pivot end
Relocate mounting holes
Hinge or
Pivot end
Door opening + 2 3/4”
Relocate mounting holes Hinge or
Pivot end
Overlap
(See below)
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 6.
INSTALLATION INSTRUCTIONS
OPERATOR INSTALLATION -REGULAR ARM
Backplate Standoff
Control
Base
#8-32x1/4” Mach. Screw
#8 Lockwasher
Mount control unit to backplate using 4 -#8-32
machine screws with standoffs and washers.
Mounting On-Off–Hold Open Switch
And Control Unit
Disassemble On-Off-Hold Open switch and mount
to connector bracket as shown.
Caution–Some local electrical codes require the
switch to be located higher than 6’-6” above floor.
See Electrical Preparation Page 2.
Mounting Operator
Right Hand Shown, Left Hand Opposite
Connector Bracket
1/4-28x3/8” fillister Hd. Mach. Screw
1/4” Lockwasher (Both ends)
Note: Where space between end brackets
and wall does not allow installation of switch
as shown, refer to alternate position, page 6.
Mount operator to backplate using 1/4-28 fillister head screws with lockwashers as shown.
Mount connector brackets to each end of backplate using 1/4-28 screws and lockwashers also.
1/4-28x3/8” Fillister Hd. Mach. Screw
1/4” Lockwasher #8-32x1/4” Pan Hd. Mach. Screw #8 Internal Tooth Lockwasher & Nylon Standoff
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 7.
INSTALLATION INSTRUCTIONS
OPERATOR INSTALLATION PARALLEL & SLIDE ARM
Mounting On-Off–Hold Open Switch
And Control Unit
Disassemble On-Off-Hold Open switch and mount
to connector bracket as shown.
Caution–Some local electrical codes require the
switch to be located higher than 6’-6” above floor.
See Electrical Preparation Page 2.
Mount control unit to backplate using 4 -#8-32
machine screws with standoffs and washers.
#8-32x1/4” Mach. Screw
#8 Lockwasher
Control
Base
Standoff
Backplate
Note: Where space between end brackets
and wall does not allow installation of switch
as shown, refer to alternate position, page 6.
Connector Bracket
1/4-28x3/8” fillister Hd. Mach. Screw
1/4” Lockwasher (Both ends)
#8-32x1/4” Pan Hd. Mach. Screw
#8 Internal Tooth Lockwasher & Nylon Standoff
1/4-28x3/8” Fillister Hd. Mach. Screw
1/4” Lockwasher
Mount operator to backplate using 1/4-28 fillister head screws with lockwashers as shown.
Mount connector brackets to each end of backplate using 1/4-28 screws and lockwashers also.
Mounting Operator
Right Hand Shown, Left Hand Opposite
1/4-28X1 1/4” Truss Hd. Mach. Screw
1/4” Flat washer
1/4” Lockwasher
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 8.
INSTALLATION INSTRUCTIONS
REGULAR ARM INSTALLATION
Regular Arm Installation
!
Door must have Door Stop
Door Preparation for Regular Arm
Centerline
of Hinge Pin
Centerline of
Center Pivot
Inside Face of Door
14 1/4” for Butt or Swing Clear
14 1/2” for Offset
17 3/8” for Center
18 3/8” for Center Pivot
With 1” Fingerguard
2 1/4”
See Hole Instructions
1 5/16”
Hole Instructions
For Metal Doors with 1/8’ surface thickness
drill #7 hole and tap for 1/4-20 x 5/8” Mach.
screw (2 holes). For Metal Doors with less
than 1/8” surface thickness or Wood Doors
drill 3/16” pilot hole for #14x1 1/4” sheet
metal screw (2 holes).
Note: All hole locations shown above are located from centerline of pivot hinge.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 9.
INSTALLATION INSTRUCTIONS
REGULAR ARM INSTALLATION (CONT’D.)
Main Arm
Rod End
Sleeve
Secondary Rod
Rod End
Shoe
1/4-20x5/8” Rd.Hd. Mach. Screw
Or #14x1 1/4” Rd. Hd. Sht. Mtl. screw
Main Arm
Indexing
Pinion Shaft
Cut
Here 17 1/8”
Example for 6” Reveal
Note: Lengths are from cntrline. of rod end
Mounting Regular Arm
1. Assemble the secondary sleeve onto rod end which is
attached to main arm, screw all the way in.
2. Place main arm on pinion shaft of operator indexing as
shown. Replace locking pinion nut, then tighten.
3. Mount shoe to door using furnished screws suitable for
prepared holes. Note: The keyed hole (with the flat
spot) must be down.
4. Determine depth of reveal. Using Table, cut secondary
rod to proper length, see example. Insert rod into sec-
ondary sleeve, bottom and finger tighten set screw
with 3/16” Allen wrench.
5. Slide rod end of secondary arm into shoe. Drop sex
bolt through hole in shoe and rod end, and align flats.
Insert screw into bottom of sex bolt, tighten.
Adjustment
With door against door stop and set screw in sleeve loos-
ened, rotate main arm 7° as shown. Tighten set screw.
Table for cutting Rod Length
Reveal Center Pivot Butt Hinge Offset Pivot
0 to 2-7/8” 12-7/8” 11-1/8” 11-3/8”
3” to 5-7/8” 15-1/2” 14-1/8” 14-3/8”
6” to 8-7/8” 18-3/8” 17-1/8” 17-7/8”
9” to 11-7/8” 21-1/4” 20-1/8” 20-3/8”
12” to 12-1/4” 21-3/8”
12” to 13” 21-3/8” 21-3/8”
Note: Any reveal greater than these require special parts and
instructions. Contact KM marketing department.
D
O
O
R
Operator
Reveal
7° (1 1/4”)
Main Arm
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 10.
INSTALLATION INSTRUCTIONS
PARALLEL ARM INSTALLATION
Parallel Arm Installation
!
Caution: Before proceeding with preparation of door, determine
the depth of reveal. See Table below.
!Door Frame must have door stop.
Door Preparation for Parallel Arm
RH shown, LH opposite.
Depth of
Reveal Center pivot Center Pivot w / 1” Fingerguard Butt Hinge Offset Pivot Door Bracket Length
0 to 1” 9-1/2” 9-1/2” 10-1/16” 10-1/16” 7”
1-1/16” to 2-1/2” 9-1/2” 9-1/2” 10-1/4” 10-3/8"
2-9/16” to 4” 6-7/8” 6-7/8” 8-1/8” 8-1/8”
4-1/16” to 5” 6-3/4” 6-5/8” 8-1/8” 8-1/8” 11”
5-1/16” to 6” 6-1/2” 6-3/8” 8” 8”
See Table
See Table
3/4”
3/4”
5
-
1/4”
Inside Face of Door
Centerline of
Center Pivot
Centerline of
Hinge pin or
Offset Pivot
Hole Instructions
For Metal Doors with 1/8” surface thickness,
drill #7 hole and tap for 1/4-20x5/8” machine
screw (4 holes). For Metal Doorswith less than
1/8” surface thickness or Wood Doors, drill
3/16” pilot hole for #14x1 1/4” sheet metal screw
(4 holes).
Note: All hole locations shown above are lo-
cated from centerline of pivot or hinge.
Operator
Reveal
Door Bracket
Length
D
o
o
r
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 11.
INSTALLATION INSTRUCTIONS
PARALLEL ARM INSTALLATION (CONT.)
Depth of Reveal Center Pivot Center Pivot
w / 1” Fingerguard Butt Hinge Offset Pivot Door Bracket Length Used
0 to 2-1/2” 6” 5” 7-3/4” 7-1/4” 7”
2-9/16” to 6” 9” 8” 10-1/4” 9-1/2” 11”
Mounting Parallel Arm
1. Assemble secondary sleeve onto rod end which is attached
to main arm, screw all the way in.
2. To install main arm, pinion must be rotated. See page 13
for rotating operator pinion manually. Place arm on pinion
shaft of operator, indexing as shown. Replace locking pin-
ion nut, then tighten.
3. Mount door bracket to door using furnished screws suitable
to prepared holes. See table in “Door Preparation” (page
10) for proper door bracket.
4. Determine depth of reveal. Using table, cut secondary rod
to proper length, see example. Insert rod into secondary
sleeve, bottom and finger tighten set screw with 3/16” Allen
wrench.
5. Place rod end onto stud on door bracket, insert screw,
tighten.
Main Arm Door Bracket
Stud Screw Rod End
Secondary Rod
Sleeve Rod End
Indexing
Pinion Shaft
Main Arm
6”
Example for 6” Reveal
Cut here
Note: Lengths are from center of rod end
Table for cutting Rod Lenghth
Note: any reveal greater than 6” requires a special bracket
and special instructions. Contact KM technical department.
Adjustments
With door against door stop and set screw in sleeve loos-
ened, rotate main arm to 1 3/4” from back plate as shown.
Tighten set screw.
Use this
hole step 5 Door Bracket
1 3/4”
Main Arm
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 12.
INSTALLATION INSTRUCTIONS
MANUAL ROTATION OF OPERATOR PINION
Manual Rotation of Operator Pinion
PinionSweep Valve
1. Using the main arm or an open end wrench, rotate pinion of
operator approximately 1/4 turn, hold in that position.
2. Using a 3/16” narrow blade screwdriver, turn sweep valve
clockwise until it bottoms on the seat. DO NOT TIGHTEN
VALVE AGAINST SEAT.
3. Remove main arm or open end wrench and proceed to install
main arm.
4. After installation of arm to door, return sweep valve to approxi
mate original position. Final adjustment will be made in
“Adjustments and checkout procedures”
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 13.
INSTALATION INSTRUCTIONS
PARALLEL ARM INSTALLATION W/ PANIC BREAKAWAY
Parallel Arm Installation with Panic Breakaway
!
!
Caution: Before proceeding with preparation of door,
determine the depth of reveal. See Table below.
Door must be center pivoted or be capable of swinging
in both directions.
Depth of
Reveal Dim. “A” Door Bracket Length Used
0 to 2-1/2” 9-3/4” 7”
2-9/16” to 4” 7-1/8”
4-1/16” to 5” 7” 11”
5-1/16” to 6” 6-3/8”
Table for Hole Location
Note: Any reveal greater than 6” requires a special
bracket and special instructions. Contact the KM
Technical department. Reveal
Door-
Bracket
length
Operator
Panic Breakaway
6” 7-3/4”
Dim. “A”
3/8”
1-7/16”
Centerline of
Center Pivot
See Hole Instructions
Inside Face of Door
Hole Instructions
For Metal Doors with 1/8” surface thickness, drill #7 hole and tap for 1/4-
20x5/8” machine screw (4 holes). For Metal Doors with less than 1/8” surface
thickness or Wood Doors, drill 3/16” pilot hole for #14x1 1/4” sheet metal screw
(4 holes).
Note: All hole locations shown above are located from centerline of pivot .
D
o
o
r
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 14.
INSTALLATION INSTRUCTIONS
PARALLEL ARM INST. W/PANIC BREAKAWAY(CONT.)
Panic Breakaway Main Arm
Door Bracket
Stud Screw
Rod End
Secondary Rod
Sleeve
Rod End
Mounting Panic Breakaway
Mount to prepared door using 1/4-20x3/4” flat head
machine screws or #14x1 1/4” flat head sheet metal
screws suitable for prepared holes.
Mounting Parallel Arm
1. Assemble secondary sleeve onto rod end which
is attached to main arm, screw all the way in.
2. To install main arm, pinion must be rotated. See
page 12 for rotating operator pinion manually.
Place main arm on pinion shaft of operator, in-
dexing as shown. Replace locking pinion nut
and tighten.
3. Mount door bracket to panic breakaway using
1/4-20x5/8” round head machine screws. See
Table in “Door Preparation” for proper bracket.
4. Determine depth of reveal. Using table, cut sec-
ondary rod to proper length, see example. In-
sert rod into sleeve, bottom and finger tighten
set screw with 3/16” Allen wrench.
5. Place rod end onto stud on door bracket, insert
screw, tighten.
6. Mount Arm / door stop to back plate temporarily
using 1/4-20x1 3/4” round head screws.
Note: Stop Block is tapered to match contour of
main arm.
Adjustments
Loosen set screw, center door in frame with main
arm in contact with stop block, tighten set screw.
Main arm may require final adjustment after installa-
tion of cover. See page 15 for panic breakaway for
adjustment.
Use this hole-Step 3
Indexing
Pinion
shaft
Main Arm
5”
Example for 1” reveal
Note: Lengths are from center of rod end
Table for cutting rod length.
Reveal Cut rod length
0 to 2 1/2” 5”
2 9/16” to 6” 8 1/4”
Door/Arm Stop
Main Arm
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 15.
INSTALLATION INSTRUCTIONS
PANIC BREAKAWAY ADJUSTMENT & CHECK
Panic Breakaway
Adjustment and Checkout
Tension Preset
The tension on the panic breakaway assy. has been pre-adjusted at the factory before shipment.
After the operation of the door has been checked out, the breakaway of the panic assembly must
be checked for operation and tension. The tension of breakaway must be tested and if necessary,
be reset to meet local codes.
To test
With a compression scale, press against the lock stile of the door 30” to 36” from the floor until the
door breaks into panic. Observe the point at which the breakaway occurs on the scale.
Adjustment Screw
Tension settings of the panic breakaway assembly varies in
accordance with local codes. Check local requirements.
Some recognized codes are as follows.
Underwriters Laboratory 50 lbs. max.
State of California 40 lbs. max.
New York State 20 lbs. max.
Pennsylvania State 50 lbs. max.
NFPA 50 lbs. max.
New York City 15 lbs. max.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

Hinge
Stile
Dim. “A” 11-1/2” 11-1/2”
11/16”
7/8” See Hole Instructions
Inside Face of Door
SERIES 2000 PAGE 16.
INSTALLATION INSTRUCTIONS
SLIDE ARM INSTALLATION
Slide Arm Installation
!Door frame must have door stop
Door preparation for Slide Arm
RH shown, LH opposite
Door opening width Dim. “A”
30” to 35 1/4” 5 3/4”
35 1/2” to 48” 11”
Hole Instructions
For Metal Doors with 1/8” surface thickness, drill #7 hole and tap for 1/4-20x5/8” machine
screw ( 6 holes ).
For Metal Doors less than 1/8” surface thickness or Wood Doors drill 3/16” pilot hole for
#14x1 1/4” sheet metal screw ( 6 holes ).
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 17.
INSTALLATION INSTRUCTIONS
SLIDE ARM INSTALLATION CONT’D
Pinion Shaft Main Arm Slide Track Assy. Drive Roller
Mounting Slide Arm
1. Insert stud into drive roller, screw stud into threaded hole
in slide arm as shown on opposite side of the bend in the
arm. Stake with a center punch or use liquid thread
locker.
2. To install slide arm, rotate pinion. See page 12 for rotat-
ing pinion manually. Place slide arm on pinion shaft of
operator indexing as shown. Replace locking pinion nut
and tighten.
3. Slide track assy. onto drive roller. Mount track assy. to
door using furnished screws suitable for prepared holes.
Slide arm may need field alignment to relieve any
strain or excess rubbing of roller or arm on track.
!
Drive
Roller
Slide arm
Stud
R
L
Indexing
Pinion
Shaft
Slide arm
1”
Operator
D
o
o
r
Reveal
See note
Dim.”B”
Slide track must be flush w/top of door
Reveal Door Opening Width Slide Kit Number Angle Bracket Overall Arm Length
0 to 1/2” 30” to 35-1/4” 4-20-0057 2” x 2” 17-1/2”
0 to 1/2” 35-1/2” to 48” 4-20-0054 2” x 2” 20-1/2”
9/16” to 1-1/2” 30” to 35-1/4” 4-20-0052 3” x 2” 17-1/2”
9/16” to 1-1/2” 35-1/2” to 48” 4-20-0055 3” x 3” 20-1/2”
Table for Slide kit selection
Note: Dim “B” is the amount of reveal plus 1”.
The 1” dimension must be maintained from the
centerline of the slide track to the back of the
operator back plate. If necessary, the angle
mounting must be shimmed to maintain this
dimension.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 18.
INSTALLATION INSTRUCTIONS
SPEED AND PRESSURE ADJUSTMENT
Adjustment and Checkout
Speed and Pressure
Important
Test all functions of the operator using operational switching devices such as sensors, press wall
switches, or mats and the On/Off/Hold Open switch. As the unit warms up to operating temperature,
operating speeds will increase; the speed must be set slower than normally desired.
Timing of Door Swing
The time of swing for an average size and weight door
(80 to 150 lbs.) from moment of start and until the door
reaches the back check position shall not be less than
1 1/2 seconds and it shall not be less than 1 3/4
seconds to full 90° opening. Doors larger and heavier
should be set to operate slower in opening and closing
cycles. 0 sec.
1 1/2 sec.
1 3/4 sec.
Minimum opening time
B
a
c
k
c
h
e
c
k
Cap Nut Allen Set Screw
Speed Adjustment
Adjustment
To adjust opening speed / pressure, remove hex cap nut with 1/2” box end wrench or socket. Turn
counterclockwise. Using 3/16” Allen wrench, turn Allen set screw clockwise to increase speed /
pressure. Turn counterclockwise to decrease speed / pressure.
Notes:
1. When making opening speed / pressure adjustment on operator, it is not necessary to replace
the hex cap nut after each adjustment attempt. After the proper speed has been achieved,
replace cap nut and tighten ( do not over tighten ). Be sure that the cap nut does not bottom
out on the adjustment screw.
2. If it was necessary to increase the speed / pressure, make sure that the unit is not over adjusted
and overloads the motor. To check for overloading, block or hold the door in a half open position
(approx. 45°), with the operator turned on. If the motor lopes, jerks, or growls, the pressure has
been raised too high. Decrease the speed / pressure until the motor runs smoothly.
3. If it was necessary to increase the pressure to obtain the desired door speed, be sure the door is
not dragging or binding on the butts or pivots. Recheck these points.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937

SERIES 2000 PAGE 19.
INSTALLATION INSTRUCTIONS
LIMIT SWITCH ADJUSTMENT & CHECKOUT
Limit Switch Adjustment and Checkout
Function of Limit Switch
The operation of the motor is to open the door, not to hold it open. The limit switch is used to shut
off the motor after opening the door through the back check zone, thus allowing the door energy to
be quenched before the 90° stop position. The actual point of shutoff will vary depending on the
weight of the door and the degree of back check.
Brass plug Limit Switch adjustment
Adjustment
To adjust, turn the adjustment screw on the limit switch counterclockwise to decrease motor run
time, clockwise to increase motor run time. It may be necessary to adjust the back check and
pressure when adjusting the limit switch.
Note:
Cam follower and limit switch must have free movement before accurate adjustment can be
attained. Also, with the door opened to a full 90° and motor off, the main and secondary arms
should form a slight dog leg. If there is no dog leg in the arms, readjust the secondary arm.
Caution: With an improper adjustment of the limit switch and an overrun of the motor, the piston
of the operator may travel too far to the end of the cylinder and bottom out. This condition may
cause too much pressure against the solenoid valve. Should the door not close, the solenoid
valve is locked. Caution -Do not force the door closed. Should the solenoid lock, do the fol-
lowing. Support the body of the solenoid valve and turn the 3/4” brass plug at bottom of valve and
turn counterclockwise not more than 1 1/2 turns. This will permit the pressure in the valve to drop
sufficiently to let the door close. Retighten.
After the door is closed, readjust the limit switch turning the screw counterclockwise to turn the
motor off sooner. Also the pressure must be readjusted by turning the adjustment screw counter-
clockwise to reduce the pressure.
Note: For older units with the Brunswick valve, there is a set screw located under the brass body
of the valve. To release the pressure, turn the screw counterclockwise, but do not remove.
KEANE MONROE
a member of the record group
MONROE, NC, USA 28111 800 438 1937
