ReelCraft 7600 User manual

Form No: 1003-1099
Rev: 1/06/a
SAFETY
I. Do not use reels at higher pressures or temperatures than
listed on the back of this bulletin.
II. Remove all spring tension before beginning disassembly
process.
HOSE REEL
OPERATING INSTRUCTIONS & PARTS LIST
MEDIUM PRESSURE
MODEL
7600 OMB55
INSTALLATION: A flexible hose connection must be used between the hose reel inlet and the source of supply to prevent possible
misalignment and binding.
The hose reel is equipped with a universal mounting bracket so that it can be mounted on the floor, wall or ceiling;
whichever place is convenient. The hose guide arm can be moved to the position desired by removing the nuts
fastening the guide bracket to the reel base. Shift the guide arm bracket so the hose comes off the reel at the desired
position and replace the nuts.
LUBRICATION: Hose reel spring and bearings are packed with grease and require no further lubrication.
REPLACING
HOSE:
1. Wind spool flange clockwise-facing swivel-until spring is tight.
2. Back off two turns and latch.
3. Insert hose through roller guide and hole in spool flange.
4. Connect hose fitting to swivel joint and secure hose with clamp.
ADJUSTMENTS: To adjust spring tension, add or remove wraps of hose from the spool, one wrap at a time until desired tension is
obtained.
REPAIRS:
INSTRUCTIONS
Extensive repairs should be performed only by an authorized serviceman or factory to avoid damage which may void
your warranty. Remove all spring tension before beginning disassembly process.
FOUR 1/2" DIA. MOUNTING HOLES
Reelcraft Industries, Inc. • [phone] / [phone] • Fax: [phone]
E-mail: [email protected] • Internet: www.reelcraft.com
A20¼”
B19”
C7 7/8”
D3 7/8”
E6¾”
