Reison 10-567 Installation instructions

1
Warning! This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2021-04-16
Document number: M10-567EN rev.01
Pubis support 10-567
ENGLISH

2
Intended use
Pubis support intended for support and positioning of a patient in side position, on the operating
table, during surgery. The product is to be used by medical professionals within a medical facility.
Safety regulation
Maximum load: 25 kg, corresponding to a patient weight of 175 kg, according to EN 60601-1 and EN
60601-2.
Before use, ensure correct function!
When loosening the lock lever or knobs to adjust the position, support underneath the pubis support,
to prevent it from uncontrolled descend into the bottom position.
Service and preventive maintenance shall be performed by authorized personnel.
MAX 25 kg (MAX 175 kg )

3
User instruction
Installation
Position adjustment
C.
B.
A.

4
Maintenance
Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel
only. Altering the construction without a written consent from the manufacturer, is strictly forbidden.
Cleaning
Clean with antiseptic detergent with pH 6 –8 and warm water. Ethanol can be used on metal surfaces.
Wipe dry with soft cloth. Do not use strong acidic or alkaline detergent.
Control
Check that there are no loose parts and that there is no damage to any part. Check that the cushion is
clean and is not damaged.
Annual service
Once a year the Pubis support shall be carefully cleaned, moving parts shall be lubricated, the locking
functions shall be tested.

5
Spare parts
Description
Pcs.
Article no.
1.
Post
1
10123
2.
Stay
1
10416
3.
Support
1
11865
4.
Spring
1
2547
5.
Knob
2
11473
6.
Washer BRB 10,5x20x2 nylon
2
-
7.
Pad
1
11870
8.
Screw MKFX M5x12 A2
4
-
9.
Spring
1
1602
10.
Gear ring
1
11163
11.
Washer
1
10119
Technical specification
Maximum workload
25 kg, corresponding to a patient weight of 175 kg, according to EN 60601-1
and EN 60601-2
Weight
2,2 kg
Dimension (H x W x L)
450 x 105 x 315 mm
Lateral adjustment
150 mm
Material Pubis support
Stainless steel
Polyurethane
UDI-DI
07350111831714

6
