Reliable HL22 Manual

Model Nominal K-factor
gpm/psi1/2 (L/min/bar1/2)Approvals Sprinkler Identificaiton Number (SIN)
HL22 22.4 (320) cULus, FM, LPCB, VdS RA1011
Model HL22 ESFR Pendent Sprinkler Table A
Model HL22 ESFR Sprinkler
Model HL22 Sprinkler w/
Victaulic® IGS™ Style V9
Sprinkler Coupling
Features
• cULus, VdS, and LPCB listed as an ESFR sprinkler
• FM Approved as a quick-response, storage and non-
storage sprinkler
• Fusible link operating element
Product Description
The Reliable Model HL22 is an Early Suppression
Fast Response (ESFR) Sprinkler with a nominal K-factor of 22.4
(320 metric). The sprinklers use a levered fusible alloy solder
link in either a 165°F (74°C) or a 212°F (100°C) temperature
rating. These sprinklers are designed to respond quickly
to growing fires and will deliver a heavy water discharge to
“suppress” rather than “control” fires.
FM Approvals classifies the Model HL22 as a quick-response
sprinkler, storage and non-storage, when used in accordance
with FM Global Property Loss Prevention Data Sheets.
In addition to the design criteria provided in NFPA 13, the Model
HL22 also has a Specific Application UL listing for 45’ storage
of Class I - IV and cartoned unexpanded Group A plastic in a
48’ building (reference Table C for full details).
The HL22 sprinklers are available with 1” NPT or ISO7 R-1
threads, and also with the Victaulic® IGS™ Style V9 Sprinkler
Coupling*.
*Note: Victaulic® and IGS™ are trademarks of Victaulic
Company.
www.reliablesprinkler.com
Model HL22 ESFR
Pendent Sprinkler
175 psi (12 bar) rated
Bulletin 010 August 2020

Model HL22 ESFR Sprinkler SIN RA1011
Technical Specifications
Style: Pendent
Connection: 1” NPT or ISO7 R-1 threads, IGS™
Style V9 Sprinkler Coupling
Nominal K-Factor: 22.4 (320)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: Beryllium Nickel Solder Link
Sprinkler Frame: Brass Casting
Button: Copper Alloy
Sealing Assembly: Nickel with PTFE
Load Screw: Bronze
Deflector: Bronze
Levers: Stainless Steel
Ejection Spring: Stainless Steel
Sprinkler Finishes
Standard (Brass Only)
Sensitivity
Fast-Response (cULus)
Quick-Response (FM)
Temperature Ratings
Ordinary: 165°F (74°C)
Intermediate: 212°F (100°C)
Guards and Shields (for threaded sprinklers only)
K22 Guard (Intermediate level ONLY)
S-5 Shield (Intermediate level ONLY)
Sprinkler Wrench
Model W5
Listings and Approvals
cULus
FM Approved
LPCB
VdS
Model HL22 Sprinkler Components and Dimensions Figure 1
Model HL22 ESFR Sprinkler with Model 22 Guard (ONLY for intermediate level use on threaded sprinklers) Figure 2
Bulletin 010
August 2020
Page 2 of 5
www.reliablesprinkler.com

Storage Type NFPA FM GLOBAL
Sprinkler Type ESFR Storage
Response Type ESFR Quick Response
System Type Wet Wet
Temperature Rating °F (°C) 165 (74), 212 (100) 165 (74), 212 (100)
Roof Construction See NFPA 13 See FM Global 2-0
Ceiling Slope See NFPA 13 See FM Global 2-0
Maximum Coverage Area See NFPA 13 See FM Global 2-0
Minimum Coverage Area See NFPA 13 See FM Global 2-0
Maximum Spacing See NFPA 13 See FM Global 2-0
Minimum Spacing See NFPA 13 See FM Global 2-0
Minimum Clearance to Commodity See NFPA 13 See FM Global 2-0
Sprinkler Distance to Ceiling See NFPA 13 See FM Global 2-0
Open Frame, Single, Double, Multiple
Row, or Portable Rack Storage of Class
I - IV Commodity and Group A Plastic
See NFPA 13 See FM 2-0 & 8-9
Solid Pile or Palletized Storage of Class
I - IV Commodity and Group A Plastic See NFPA 13 See FM 2-0 & 8-9
Idle Pallet Storage See NFPA 13 See FM 2-0, 8-9 & 8-24
Rubber Tire Storage See NFPA 13 See FM 2-0 & 8-3
Rolled Paper Storage See NFPA 13 See FM 8-21
Flammable Liquid Storage See NFPA 30 See FM 7-29
Aerosol Storage See NFPA 30B See FM 7-31
Auto Components in Portable Racks N/A N/A
Model HL22 ESFR Commodity Selection and Design Criteria Overview Table B
Bulletin 010
August 2020
Page 3 of 5
www.reliablesprinkler.com

Bulletin 010
August 2020
Page 4 of 5
www.reliablesprinkler.com
Model HL22 Commodity Selection and Design Criteria Overview Specific Application Listing (UL) Table C
Description UL Specific Application Criteria
Sprinkler Type ESFR
Temperature Rating °F (°C) 212 (100)
Response Type ESFR
System Type Wet
Maximum Area of Coverage See NFPA 13
Minimum Area of Coverage See NFPA 13
Maximum Slope Ceiling See NFPA 13
Maximum Spacing See NFPA 13
Minimum Spacing See NFPA 13
Deflector Distance from Walls See NFPA 13
Deflector to Top of Storage See NFPA 13
Deflector to Ceiling Distance 6"- 14" (150-350mm)
Maximum Ceiling Height 48ft (14.6m)
Maximum Storage Height 43ft (13.1m)
Storage Arrangement Single and double row rack storage, palletized and solid
pile storage. No open top containers or solid shelves.
Commodity Class I-IV commodities, encapsulated or nonencapsulated,
and Cartoned Group A Unexpanded plastics
Sprinkler System Design 55 PSI (3.8 bar) design pressure,12 sprinklers in remote area
Obstruction Criteria See NFPA 13
Minimum Aisle Width 8ft (2.4m)
Hose Stream Allowance and Duration See NFPA 13

Installation
Model HL22 sprinklers are intended for installation in
accordance with NFPA 13 and FM Loss Prevention Data Sheets
2-0 and 8-9, as well as the requirements of any Authorities
Having Jurisdiction. See Table B for information on NFPA and
FM Global design criteria for the Model HL22 sprinklers.
For threaded sprinklers only, use the Model W5 sprinkler
wrench for removal and installation (Figure 3). Any other type of
wrench may damage the sprinkler. A grooved wrench boss is
provided on the sprinkler to limit the potential for the wrench to
slip during installation.
Model HL22 sprinklers should be tightened between 14 - 40
lbs-ft (19 - 54 N.m) torque. Do not tighten sprinklers over the
maximum recommended torque. Exceeding the maximum
recommended torque may cause leakage or impairment of the
sprinklers.
For grooved sprinklers, push the IGS™ Style V9 Sprinkler
Coupling onto the grooved outlet until contact with the center
leg of the gasket occurs. Align the sprinkler frame arms and
the pads of the coupling with the sprinkler piping and tighten
the coupling until the pads of the coupling meet. For additional
information, please reference Victaulic® technical bulletin I-V9.
Caution: When handling sprinklers, hold sprinklers only by the
frame arms and do not apply any force on the link assembly.
Damaged sprinklers must be replaced immediately.
Maintenance
Reliable Model HL22 sprinklers should be inspected and the
sprinkler system maintained in accordance with NFPA
25, as well as the requirements of any Authorities Having
Jurisdiction.
Prior to installation, sprinklers should remain in the original
cartons and packaging until used. This will minimize the
potential for damage to sprinklers that could cause improper
operation or non-operation.
Do not clean sprinklers with soap and water, ammonia liquid or
any other cleaning fluids. Remove dust by gentle vacuuming
without touching the sprinkler.
Replace any sprinkler which has been painted (other than
factory applied). A stock of spare sprinklers should be
maintained to allow quick replacement of damaged or operated
sprinklers.
Failure to properly maintain sprinklers may result in inadvertent
operation or non-operation during a fire event.
Guarantee
For the Reliable Automatic Sprinkler Co., Inc. guarantee, terms,
and conditions, visit www.reliablesprinkler.com.
Note: 1” S/142 IGS™ grooved welded
outlets are also available from Reliable.
Ordering Information
Specify:
• Sprinkler: [HL22]
• Temperature Rating: [165°F (64°C)] [212°F (100°C)]
• End Connection: [1” NPT] [ISO7 R-1]
[Victaulic® IGS™ Style V9 Sprinkler Coupling]
Victaulic® IGS™ Style V9
Sprinkler Coupling installation
bit - One bit provided in each
box of 25 sprinklers.
Model W5 Sprinkler Wrench Figure 3
Bulletin 010
August 2020
Page 5 of 5
www.reliablesprinkler.com
P/N 9999970287
