Replas Big Bench User manual

Big Bench
1800 mm x 900 mm In Ground
www.replas.com.au
IMPORTANT:
Please read carefully before assembling.
.
1. Place bench tops face down on a flat surface.
.
Assembly Instructions:
Note: Big Bench is despatched with temporary legs attached
.
2. Remove temporary legs from underside of bench.
Note: keep screws that are removed, as they will
be used to secure new legs in place.
3. Place Corner Supports (x4) into position as per attached drawing- Detail 1.
4. Using a 4.5 mm drill bit, drill pilot hole through the screw hole and into the support. Using 75 mm bugle screw
attach the leg to the bench frame.
Note: Ensure leg is square before drilling pilot holes.
5. Place Centre Supports (x2) into position as per attached drawing- Detail 2.
6. Using a 4.5 mm drill a bit, drill pilot hole through the screw holes on the support foot and into the bearer.
Using 75 mm bugle head screws, attach the leg to the bench frame.
7. Once all screws have been tightened, turn setting over and place into position.
Components List:
If you require further installation assistance, please contact your supplier.
1 x Bench Top - pre-assembled
12 x 14 g x 75 mm Bugle Head Screws (attached to temp legs)
4 x Corner Supports
2 x Centre Supports

Big Bench 1.8 m Free Standing
www.replas.com.au
IMPORTANT:
Please read carefully before assembling.
.
1. Place bench tops face down on a flat surface.
.
Assembly Instructions:
.
2. Remove temporary legs from underside of bench.
Note: keep screws that are removed, as they will
be used to secure new legs in place.
3. Place Outside Supports (x6) into position as per attached drawing- Detail 1.
4. Using a 4.5 mm drill bit, drill pilot hole through the screw hole and into the support. Using 75 mm bugle screw
attach the leg to the bench frame.
Note: Ensure leg is square before drilling pilot holes.
5. Place Outside Centre Supports (x2) into position as per attached drawing- Detail 2.
6. Using a 4.5 mm drill a bit, drill pilot hole through the screw holes on the support foot and into the bearer.
Using a 75 mm bugle head screws, attach the leg to the bench frame.
7. Place Centre Supports (x1) into position as per attached drawing  Detail 3.
Components List:
If you require further installation assistance, please contact your supplier.
2 X Bench Supports  Outside Centre
12 X 14g x 75mm Bugle Head Screws (attached to the temp legs)
8. Once all screws have been tightened, turn setting over and place into position.
1 X Bench Top  preassembled
6 X Bench Supports  Outside
1 X Bench Supports  Centre
8 X 14g x 75mm Bugle Screws
