Replas KOOKABURRA SETTING User manual

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
KOOKABURRA
SETTING
850square
SLABMOUNT
1.PlaceTable&Benchtopsfacedownonaflatsurface.

2.Placetablesupportinsidemetalframe.
NOTE:Ensurethatthemarkingsonthetablesupportarealignedtothemarkingsonthetable
frame.

3.Usingthe40mmHexscrewssupplied,fitsupporttotable.

4.Usingthe65mmHexscrewssupplied,fitbenchsupportstothebenches.

5.Onceallscrewshavebeentightened,turnsettingoverandplaceintoposition.
NOTE:Onceinpositionpleaseensurethatthesettingissecurelyboltedtotheground.
TABLE:

1XTableTop‐pre‐assembled
1XTableSupport
10X12gx40mmHexscrews

COMPONENTSLIST
BENCHES:

4XBenchTops‐pre‐assembled
8XBenchSupports
40X14gx65mmHexScrews

Ifyourequirefurtherinstallation
assistance,pleasecontactyoursupplier.

850
145 x 145 Central Support
Metal Support F rame
440
280
Concrete Slab
740
670
150550150
150 550 150
670
SIDE VIEW
KBS-850FS/SQ
KOOKABURRA
SQUARE SETTING
SLAB MOUNT
