Replas PREMIER SETTING 1.8m In Ground User manual

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
PREMIER
SETTING
1.8m
InGround
1.PlaceTable&Benchtopsfacedownonaflatsurface.
2.Placesupportsinsidemetalframe.
3.Usinga3.5mmdrillbit,drillintothesupportthroughthepilotholeinthemetalframe.
4.Usingthe40mmHexScrewssupplied,screwsupportontoframe.

Installation

Oncethesettinghasbeenisassembled,drillordigholesasperinstallationdiagram.

Placethesupportsoftheassembledsettingintotheholes.Positionthesettingandensurethatitiswell
bracedtopreventmovementandsagging.Atthisstageitisimportanttouseaspiritleveltocheckthatthe
topishorizontalandthesupportsarevertical.

Oncesatisfiedthatthesettingispositionedcorrectly,filltheholeswithconcrete,makingsureitispacked
firmlyaroundthesupports.

Oncetheconcretehasset,removethebracing.
TABLE:

1XTableTop‐pre‐assembled
2XTableSupports
16X12gx40mmHexScrews
COMPONENTSLIST
BENCHES:

2XBenchTops‐pre‐assembled
4XBenchSupports
24X12gx40mmHexScrews

Ifyourequirefurtherinstallation
assistance,pleasecontactyoursupplier.

670 mm 670 mm
Ground L evel
Ground L evel
740 mm
815 mm
440 mm
280 mm
640 mm
700 mm
1320 mm
490 mm
SIDE VIEW
END VIEW
WITH BENCHES
PRS-1800IG
PREMIER
I N GROUND
SETT ING
1800 mm
25 x 40 x 3mm Frame
