Replas LYREBIRD LBS-1800FS User manual

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
LYREBIRD
SETTING
1.8m
FreeStanding
TABLE:
1.PlaceTabletopfacedownonaflatsurface.

2.Placesupportsintoposition.Ensurethatthetablelugsontheoutsidesupportsarefacingtowards
thecentreofthetable.

3.Securetablesupportstothe40x200mmplanksusingthe65mmhexscrews.
NOTE:Donotfullytightenscrewsuntilallareinposition.

4.Insertcrossarmintothesupportlugs.Then,usingapprox4.5mmdrillbit,drillapilotholeinto
crossarmandsecureusing65mmHexscrew.
NOTE:Ensurethatalllegsaresquarebeforedrillingpilothole.

BENCHES:
1.Placebenchslatsfacedownonaflatsurface.

2.Usingthe75mmHexscrewssupplied,secureeachbenchsupporttotheslats.

3.Onceallscrewshavebeentightened,turnsettingoverandplaceintoposition.
TABLE:

1XTableTop‐pre‐assembled
3XTableSupports
1XTableCrossarm
30X14gx65mmHexHeadscrews
COMPONENTSLIST
BENCHES:

2XBenchTops‐pre‐assembled
6XBenchSupports
36X14gx75mmHexHeadScrews
Ifyourequirefurtherinstallationassistance,pleasecontactyoursupplier.

4 x (40x200x1800mm)
Ground L evel
Ground L evel
60 x 110 x 1475 Cross Arm
810 mm
740 mm
1800 mm
815 mm
430 mm
180
710 mm 710 mm
310 mm
700 mm
SIDE VIEW
END VIEW
WITH BENCHES
TOP VIEW
1800 mm
180
LBS-1800FS
LYREBIRD
FREE STANDING
SETTING
