Replas LYREBIRD SETTING User manual

ASSEMBLY INSTRUCTIONS
IMPORTANT: Please read carefully before assembling.
LYREBIRD
SETTING
1.8m Free Standing
Wheel Chair Access
TABLE:
1. Place table top face down on a flat surface.
2. Place Table supports inside metal frame.
Note: Ensure that the table legs have the lugs facing towards the centre of the table.
4. Using a 3.5mm drill bit, drill into the support through the pilot holes in the metal frame.
5. Using the 40mm Hex Screws supplied, screw support onto frame, taking care not to over tighten as this
could strip the thread in the support.
NOTE: Use a spirit level to ensure that all legs are square before drilling pilot holes.
6. Insert crossarm into the support lugs. Then, using approx 4.5mm drill bit, drill a pilot hole into crossarm
and secure using 65mm bugle screw.
NOTE: Use a spirit level to ensure that all legs are square before drilling pilot holes.
BENCHES:
1. Place bench slats face down on a flat surface.
2. Attach bench supports to the 40x90mm slats using the 75mm hex head screws.
3. Once all screws have been tightened, turn setting over and place into position.
TABLE:
1 X Table Top - pre-assembled
2 X Table Supports
1 X Table Crossarm
16 X 12g x 40mm Hex Head screws
4 X 14g x 65mm Hex Head screws
COMPONENTS LIST
BENCHES:
2 X Bench Tops - pre-assembled
6 X Bench Supports
36 X 14g x 75mm Hex Head Screws
If you require further installation
assistance, please contact your supplier.
www.replas.com.au

25 x 40 x 4.5
Table frame
4 x (40 x 200 x 1800mm)
Ground L evel
Ground L evel
60 x 110 x 880mm
Cross Arm
740 mm
815 mm
830 mm
440 mm
180 180
680 mm
310 mm
700 mm
SIDE VIEW
END VIEW
LBS-1800FS/WCA
WHEELCHAIR ACCESS
LYREBIRD
FREE STANDING
SETTING WITH
1800 mm

ASSEMBLYINSTRUCTIONS
IMPORTANT:Pleasereadcarefullybeforeassembling.
LYREBIRD
SETTING
1.8mInGround
WheelChairAccess
TABLE:
1.Placetabletopfacedownonaflatsurface.
2.PlaceTablesupportsinsidemetalframe.
3.Usinga3.5mmdrillbit,drillintothesupportthroughthepilotholesinthemetalframe.
NOTE:Useaspiritleveltoensurethatalllegsaresquarebeforedrillingpilotholes.
5.Usingthe40mmHexScrewssupplied,screwsupportontoframe,takingcarenottoovertightenasthiscouldstripthethreadin
thesupport.

BENCHES:
1.Placebenchslatsfacedownonaflatsurface.
2.Attachbenchsupportstothe40x90mmslatsusingthe65mmhexheadscrews,takingcarenottoovertightenasthis could
stripthethreadinthesupport.

Installation
Oncethesettinghasbeenisassembled,drillordigholesasperinstallationdiagram.

Placethesupportsoftheassembledsettingintotheholes.Positionthesettingandensurethatitiswellbracedtopreventmovement
andsagging.Atthisstageitisimportanttouseaspiritleveltocheckthatthetopishorizontalandthesupportsarevertical.

Oncesatisfiedthatthesettingispositionedcorrectly,filltheholeswithconcrete,makingsureitispackedfirmlyaroundthesupports.

Oncetheconcretehasset,removethebracing.

SUGGESTION:
WheninstallingInͲGroundfurnitureitisagoodideatonailsometimberbracingacrossthebackofallsupports.Thiswillensureall
supportsarekeptparallelandinalignment,aswellaspreventinganysaggingoftheseatduringinstallation.Donotremovebracing
untilafterconcretehasset.
TABLE:

1XTableTopͲpreͲassembled
2XTableSupports
16X12gx40mmHexHeadscrews
COMPONENTSLIST
BENCHES:

2XBenchTopsͲpreͲassembled
6XBenchSupports
30X14gx65mmHexHeadScrews
Ifyourequirefurtherinstallationassistance,pleasecontactyoursupplier.

1800
4 x (40x200x1800)
20 x 40 x 4.5mm Frame
710 mm 710 mm
SIDE VIEW - Table only
LBS-1800IG/WCA
LYREBIRD
IN GROUND
SETTING WITH
WHEELCHAIR ACCESS
630 mm
740 mm
640 mm
700 mm
685 mm
880 mm
685mm
Ground L evel
Ground L evel
Ground L evel
815 mm
440 mm
310 mm
490 mm
END VIEW
1800
3 x (40x90x1800)
SIDE VIEW - Bench only
