ResMed AcuCare F1-0 User manual

Hospital masks
User guide
English | Français | Español | Português
608359 AMER Covers.indb 1 6/10/2016 9:43 am

AcuCare F1-0 AcuCare F1-1 AcuCare F1-4
1 2
4 5
3
ii
608359 AMER Covers.indb 2 6/10/2016 9:43 am

iii
1 Port / Port / Puerto / Porta
2 Valve (AcuCare F1-1 and AcuCare F1-4 only) /
Valve (AcuCare F1-1 et AcuCare F1-4 uniquement) /
Válvula (solo AcuCare F1-1 e AcuCare F1-4) /
Válvula (só AcuCare F1-1 e AcuCare F1-4)
3 Quick release clip/ Clip de retrait rapide / Broche de liberación rápida /
Clipe de libertação rápida
4 Vent (AcuCare F1-4 only)/ Orifice de ventilation (AcuCare F1-4 uniquement) /
Ventilación sólo AcuCare F1-4) / Respiradouro (só AcuCare F1-4)
5 Connector 22M - 22M (AcuCare F1-4 only) /
Raccord 22M - 22M (AcuCare F1-4 uniquement) /
Raccordo 22M - 22M (sólo AcuCare F1-4) / Connector 22M - 22M (só AcuCare F1-4)
S: Small/ Petit / Pequeña / Pequena
M: Medium/ médium / mediana / média
L: Large/ Grand / Grande / Grande
608359 AMER Covers.indb 3 6/10/2016 9:43 am

iv
Fitting / Mise en place / Colocación / Ajuste
F1-0 F1-1
F1-4
123
4A 4B
4C 5
Removal / Retrait / Remoción / Remoção
21
608359 AMER Covers.indb 4 6/10/2016 9:43 am

English 1
ENGLISH
Hospital full face masks
Thank you for choosing the AcuCare range.
This guide covers the following variants, which are shown at the front of
the guide:
AcuCare F1-0 Hospital non-vented full face mask (blue elbow to
indicate that the mask does not include its own passive venting
mechanism or an AAV)
AcuCare F1-1 Hospital non-vented full face mask with AAV (clear
elbow with "NV" blue dot to indicate that the mask does not
incorporate its own passive venting mechanism)
AcuCare F1-4 Hospital vented full face mask (clear elbow to indicate
that the mask incorporates a built-in passive venting mechanism and
an AAV).
Using this guide
Please read the entire guide before use. When following instructions,
refer to the images at the front of the guide.
Intended Use
Intended use for AcuCare F1-0
The AcuCare F1-0 mask is a non-invasive accessory used for channeling
airflow to a patient from an active-exhaust-valve ventilator system.
The mask is:
to be used on patients weighing >66 lb (30 kg), for whom non-invasive
positive airway pressure therapy has been prescribed.
a disposable device, intended for short-term treatment (up to 7 days)
of a single patient, in the hospital environment only.
intended to be used with breathing circuits or positive pressure
ventilation (PPV) devices that provide their own method of venting
expired or supplemental gasses.

2

Intended use for AcuCare F1-1
The AcuCare F1-1 mask is a non-invasive accessory used for channelling
airflow to a patient from a positive airway pressure (PAP) device.
The mask is:
to be used on patients weighing >66 lb (30 kg), for whom non-invasive
positive airway pressure therapy has been prescribed.
a disposable device, intended for short-term treatment (up to 7 days)
of a single patient, in the hospital environment only.
intended to be used with breathing circuits or positive pressure
ventilation (PPV) devices that provide their own method of venting
expired or supplemental gasses.

Intended use for AcuCare F1-4
The AcuCare F1-4 mask is a non-invasive accessory used for channelling
airflow to a patient from a positive airway pressure (PAP) device.
The mask is:
to be used on patients weighing >66 lb (30 kg), for whom non-invasive
positive airway pressure therapy has been prescribed.
a disposable device, intended for short-term treatment (up to 7 days)
of a single patient, in the hospital environment only.
GENERAL WARNINGS
As with all masks, some rebreathing may occur at low pressures.
The mask must not be used without qualified supervision for
patients who are unable to remove the mask themselves.
This mask is not for use on patients with impaired laryngeal
reflexes or other conditions predisposing to aspiration in the
event of regurgitation or vomiting.
The mask should not be worn unless the ventilator system is
turned on and operating properly.
Follow all precautions when using supplemental oxygen.
Oxygen supports combustion. Oxygen must not be used while
smoking or in the presence of an open flame. Only use oxygen in
well ventilated rooms.

English 3
If oxygen is used with the ventilator, the oxygen flow must be
turned off when the ventilator is not operating, so that unused
oxygen does not accumulate within the device enclosure and
create a risk of fire.
At a fixed rate of supplemental oxygen flow (if used), the inhaled
oxygen concentration varies depending on the pressure settings,
patient breathing pattern, mask size selection and leak rate.
The technical specifications of the mask are provided so you can
check that they are compatible with the ventilator. If used outside
specification or if used with incompatible devices, the seal and
comfort of the mask may not be effective, optimum therapy may
not be achieved, and leak, or variation in the rate of leak, may
affect the ventilator function.
Discontinue using this mask if the patient has ANY adverse
reaction to the use of the mask.
Using a mask may cause tooth, gum or jaw soreness or aggravate
an existing dental condition. If symptoms occur, consult a dentist.
Refer to your ventilator manual for details on settings and
operational information.
Do not expose the mask to direct sunlight.
Remove all packaging before using the mask.
(AcuCare F1-1 and AcuCare F1-4 only) The elbow and valve
assembly have specific safety functions. The mask should not be
worn if the valve is damaged as it will not be able to perform its
safety function. The mask should be replaced if the valve is
damaged, distorted or torn.
(AcuCare F1-4 only) The vent holes must be kept clear.
Using your mask
The masks in this guide incorporate:
a standard female 22mm tapered fitting for external connection to the
ventilator
a standard Luer port for pressure sampling or supplemental oxygen if
required.

4
Fitting
Notes:
A sizing template is located on the mask packaging to help you
determine the correct mask size.
Inspect the mask before use and replace it if any parts are damaged.
Do not overtighten the straps, as air fills the dual-wall cushion and
provides a comfortable seal.
For the best seal, the side straps should be tighter than the top strap.
1. Position the mask cushion over the patient's nose and mouth and pull
the headgear over their head.
2. While holding the mask against the patient's face, pull each of the
side straps back along the side of the patient's face. The straps should
pass below the patient's ears. The side arms on the mask should
bend back as you tighten the straps.
3. Gently adjust the top strap.
4. Start ventilation according to the ventilator system operating
instructions and connect the mask to the ventilator system.
5. If air leaks around the cushion, reposition the mask on the patient's
face to achieve a better seal. You may also need to readjust the
headgear straps.
Removal
1. Unclip the headgear from the mask using the quick release clip.
2. Pull the mask and headgear up over the patient's head.
Cleaning
WARNING
Always follow cleaning instructions. Some cleaning products may
damage the mask, its parts and their function, or leave harmful
residual vapours.

English 5
CAUTION
Do not expose any part of the mask or tubing to direct sunlight as
it may deteriorate.
If any visible deterioration of a mask system component is
apparent (cracking, discoloration, tears etc.), the mask system
should be discarded and replaced.
Discard the mask (and headgear) if heavily soiled, particularly if
the vent holes are blocked.
The mask (with headgear) is disposable and should be discarded if heavily
soiled. If the inside of the mask is lightly soiled, it may be cleaned by
wiping with a clean cloth and water. Do not disassemble the mask.
Troubleshooting
Problem/possible cause Solution
Mask is uncomfortable
Headgear straps are too tight. The cushion membrane is designed to
inflate against the patient's face to provide
a comfortable seal with low headgear
tension. Adjust straps evenly. Ensure that
the headgear straps are not too tight and
that the cushion is not crushed or creased.
Mask could be the wrong size. Check the patient's size against the fitting
template located on the mask packaging.
Mask leaks around the face.
Cushion membrane is creased or folded. Refit the mask according to the instructions.
Ensure that you position the cushion
correctly on the patient's face before pulling
headgear over their head. Do not slide the
mask down the patient's face during fitting
as this may lead to folding or curling of the
cushion.
Mask could be the wrong size. Check the patient's size against the fitting
template located on the mask packaging.

6
Technical Specifications
The following general specifications are applicable to all masks in this
guide.
General specifications
Environmen
t
al
conditions
Operating temperature: 41°F to 104°F (+5°C to +40°C)
Operating humidity: 15% to 95% non-condensing
Storage and transport temperature: 4°F to 140°F (-20°C to +60°C)
Storage and transport humidity: up to 95% non-condensing
Gross
dimensions
Not including
headgear
Small:
5.82" (H) x 8.70" (W) x 4.01" (D)
(148 mm (H) x 221 mm (W) x 102 mm (D))
Medium:
6.22" (H) x 9.05" (W) x 4.13" (D)
(158 mm (H) x 230 mm (W) x 105 mm (D))
Large:
6.49" (H) x 9.21" (W) x 4.21" (D)
(165 mm (H) x 234 mm (W) x 107 mm (D))
Compatibility For a full list of compatible devices for this mask, see the
Mask/Device Compatibility List on www.resmed.com on the Products
page under Service & Support. If you do not have internet access,
please contact your ResMed representative.
Technical Specifications: AcuCare F1-0
Pressure (cm H20)
0 to 20
20 to 40
Flow (L/min)
<6
<12
Therapy pressure 0 to 40 cm H20
Dead space
information
Physical dead space (mask and elbow) using the large cushion is
342 mL.
Resistance Drop in pressure measured
(nominal)
at 50 L/min: 0.4 cm H2O
at 100 L/min: 1.2 cm H2O
