ResMed Flow Generator S8 Elite System User manual

1
S8 Elite™ System
ILLUSTRATIONS
ILLUSTRATIONEN / ILLUSTRATIONS
ILLUSTRAZIONI / FIGURAS
ILUSTRAÇÕES / ILLUSTRATIES
Component of 338112 /1
A
Keypad / Tastenfeld / Clavier /
Tastierino / Teclado / Teclado /
Toetsenpaneel
Carry handle / Tragegriff /
Poignée de transport / Maniglia
da trasporto / Asa para el
transporte / Pega de transporte /
Handvat
Air filter cover / Luftfilterabdeckung /
Couvercle du logement du filtre à air /
Coperchio del filtro dell'aria /
Cubierta del filtro de aire / Tampa do
filtro de ar / Afdekkap luchtfilter
Module / Modul / Module / Modulo /
Módulo / Módulo / Module
DC input / DC-Eingang / Entrée CC /
Ingresso CC / Entrada de CC /
Entrada CC / Gelijkstroom-ingang
AC input / AC-Eingang / Entrée CA / Ingresso CA /
Entrada de CA / Entrada CA / Wisselstroom-ingang
LCD screen / LCD-Display /
Ecran LCD / Schermo a cristalli
liquidi / Visor / Mostrador
LCD / LCD-scherm
Air outlet / Luftauslassöffnung /
Sortie d'air / Presa di uscita
dell'aria / Salida de aire / Saída
de ar / Luchtuitlaat
SYSTEM COMPONENTS / SYSTEMKOMPONENTEN / COMPOSANTS DU
SYSTEME / COMPONENTI DEL SISTEMA / COMPONENTES DEL SISTEMA /
COMPONENTES DO SISTEMA / SYSTEEMCOMPONENTEN
Air inlet / Lufteinlassöffnung / Entrée
d'air / Presa di ingresso dell'aria /
Entrada de aire / Entrada de ar /
Luchtinlaat
2 m
2
34 5
OTHER ACCESSORIES / SONSTIGES ZUBEHÖR / AUTRES ACCESSOIRES / ALTRI
ACCESSORI / OTROS ACCESORIOS / OUTROS ACESSÓRIOS / ANDERE
ACCESSOIRES
C
1
5
D
2
3
4
BINTEGRATED HUMIDIFIER / INTEGRIERTER ATEMLUFTBEFEUCHTER /
HUMIDIFICATEUR INTEGRE / UMIDIFICATORE INTEGRATO / HUMIDIFICADOR
INTEGRADO / HUMIDIFICADOR INTEGRADO / GEÏNTEGREERDE BEVOCHTIGER
32
3 m
1
4
© 2005 ResMed Ltd.
© 2005 ResMed Ltd.
© 2005 ResMed Ltd.
© 2005 ResMed Ltd.
HumidAire 3i™
Note: Some products not available in all regions. Hinweis: Einige Produkte sind nicht in allen Regionen erhältlich. Remarque : certains produits ne sont pas disponibles dans tous les
pays. Nota: Alcuni prodotti non sono disponibili in tutte le regioni. Nota: Algunos productos no están disponibles en todas las regiones. Nota: Alguns produtos não se encontram disponíveis em todas as
regiões. Opmerking: Sommige producten zijn niet in alle regio's verkrijgbaar.
SETTING UP THE S8™/ AUFSTELLEN DES S8™ / INSTALLATION
DE LA S8™/ CONFIGURAZIONE DELL'S8™/ INSTALACIÓN
DEL S8™/ MONTAGEM DO S8™ / OPSTELLEN VAN DE S8™
338112r1 Illos gr1.qxd 06/07/05 9:46 AM Page 1

DATA CARD MODULE / DATENKARTENMODUL / MODULE DE CARTE
DE DONNEES / MODULO PER DATA CARD / MÓDULO TARJETA DE
DATOS / MÓDULO DE CARTÕES DE DADOS / DATA CARD-MODULE
G
12
© 2005 ResMed Ltd.
HUSING THE DATA CARD / GEBRAUCH DER DATENKARTE / UTILISATION DE LA
CARTE DE DONNEES / USO DELLA DATA CARD / USO DE LA TARJETA DE
DATOS / COMO USAR O CARTÃO DE DADOS / GEBRUIK VAN DE DATA CARD
1
3
2
© 2005 ResMed Ltd.
Note: Some products not available in all regions. Hinweis: Einige Produkte sind nicht in allen Regionen erhältlich. Remarque : certains produits ne sont pas disponibles dans tous les pays.
Nota: Alcuni prodotti non sono disponibili in tutte le regioni. Nota: Algunos productos no están disponibles en todas las regiones. Nota: Alguns produtos não se encontram disponíveis em todas as regiões.
Opmerking: Sommige producten zijn niet in alle regio's verkrijgbaar.
HumidAire 3i
EHUMIDAIRE 3i AND S8 / HUMIDAIRE 3i UND S8 / HUMIDAIRE 3i ET S8 /
HUMIDAIRE 3i E S8 / HUMIDAIRE 3i y EL S8 / HUMIDAIRE 3i E S8 /
HUMIDAIRE 3i EN S8
© 2005 ResMed Ltd.
BLANK MODULE / MODULSCHACHTABDECKUNG / MODULE VIERGE /
FALSO MODULO / MÓDULO EN BLANCO / MÓDULO EM BRANCO /
LEGE MODULE
F
12
© 2005 ResMed Ltd.
Data communications port /
Datenkommunikations-
anschluss / Port de
communication de
données / Porta dati /
Puerto de comunicación
de datos / Dados
comunicações porta /
Data communicatie poort
338112r1 Illos gr1.qxd 06/07/05 9:46 AM Page 2

USER’SMANUAL 1
MANUEL UTILISATEUR 89
BEDIENUNGSANLEITUNG 43
MANUALE DELL’UTENTE 135
S8 ELITE™SYSTEM
ENGLISHDEUTSCHITALIANO FRANÇAISESPAÑOLPORTUGUÊS
NEDERLANDS
MANUAL DEL USUARIO 179
MANUAL DO UTILIZADOR 223
HANDLEIDING VOOR DE GEBRUIKER 267
338112r1front.book Page iii Friday, June 24, 2005 5:00 PM

Manufactured by:
ResMed Ltd 1 Elizabeth MacArthur Drive Bella Vista NSW 2153 Australia
Tel: [phone] or 1 800 658 189 (toll free) Fax: [phone] Email: [e-mail]
ResMed Offices:
ResMed Corp 14040 Danielson Street Poway CA 92064-6857 USA
Tel: [phone] or 1-800-424-0737 (toll free) Fax: [phone] Email: [e-mail]
ResMed (UK) Ltd 65 Milton Park Abingdon Oxfordshire OX14 4RX UK
Tel: [phone] Fax: [phone] Email: [email protected].uk
ResMed Asia Pacific Ltd 97 Waterloo Road North Ryde NSW 2113 Australia
Tel: [phone] or 1 800 991 900 (toll free) Fax: [phone] Email: [e-mail]
ResMed BV Nieuwe Parklaan 86, 2587 BV Den Haag Nederland
Tél: [phone] Fax: [phone] Email: [email protected]
ResMed Finland Niittykatu 6 FIN 02200 Espoo Suomi
Puh: [phone] Faksi: [phone] Sähköposti: [e-mail]
ResMed Gmb H & Co. KG Fraunhoferstraße 16 82152 Martinsried Deutschland
Tel: +49 (0) 89 / 99 01 - 00 or [phone] (gebührenfrei) Fax: +49 (0) 89 / 99 01 - 10 55
Email: [e-mail]
ResMed Hong Kong Ltd Room 1714 Miramar Tower 132-134 Nathan Road Tsim Sha Tsui Hong Kong
Tel: [phone] Fax: [phone] Email: [e-mail]
ResMed Japan Nihonbashi Hisamatsu Bldg. 4F 2-28-1 Nihonbashi-Hamacho Chuo-Ku, Tokyo 103-0007 Japan
Tel: [phone] Fax: [phone]
ResMed Malaysia Sdn Bhd Suite E-10-20, Plaza Mon’t Kiara No. 2, Jalan 1/70C Mon’t Kiara 50480 Kuala Lumpur
Malaysia Tel: [phone] Fax: [phone] Email: [email protected]y
ResMed NZ Ltd PO Box 51-048 Pakuranga Auckland New Zealand
Tel: [phone] (NZ toll free) or [phone] Fax: [phone] (NZ toll free) or [phone]
Email: [e-mail]
ResMed SA Parc de la Bandonnière 2 rue Maurice Audibert 69800 Saint-Priest France
Tel: [phone] Fax: [phone] Email: rec[email protected]
ResMed Singapore Pte Ltd 238A Thomson Road # 12-03/04 Novena Square Tower A Singapore 307684
Tel: [phone] Fax: [phone] Email: [email protected]
ResMed Spain SL C/ Arturo Soria, 245 28033 Madrid España
Tel: [phone] Fax: [phone] Email: [e-mail]
ResMed Sweden AB Industrigatan 2 S-461 37 Trollhättan Sverige
Tel: [phone] Fax: [phone] Email: recept[email protected]
Labhardt AG Thannerstrasse 57 CH-4054 Basel Schweiz
Tel: [phone] Fax: [phone] Email: [email protected]
US DESIGNATED AGENT: ResMed Corp
EU AUTHORISED REPRESENTATIVE: ResMed (UK) Ltd
www.resmed.com
Protected by patents: AU 697652, EP 0661071, US 4944310, US 5199424, US 5522382, US 6240921, US 6705315. Other
patents pending.
Design registrations pending.
S8, S8 Elite, Activa, HumidAire, HumidAire 3i, Mirage, Mirage Swift, Mirage Vista, ResScan and Ultra Mirage are
trademarks of ResMed Ltd. Papillon is a trademark of MAP Medizin-Technologie GmbH.
© ResMed Ltd 2005.
338112r1front.book Page iv Friday, June 24, 2005 5:00 PM

1
USER’S MANUAL
English
S8 Elite™System
ENGLISH

2

3
ENGLISH
CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
YOUR RESPONSIBILITY 5
MEDICAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ABOUT THE S8 ELITE 5
CONTRAINDICATIONS 5
WARNINGS 6
CAUTIONS 7
ADVERSE EFFECTS 7
THE S8 ELITE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
S8 ELITE 9
MASKS 9
HUMIDIFIER 10
RESSCAN DATA CARD MODULE 10
ACCESSORIES 10
HOW TO USE THE S8 ELITE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
SET UPTHE S8 ELITE 11
ASSEMBLE THE MASK 11
START TREATMENT 12
STOPPING TREATMENT 12
USING THE MASK-FITTING FEATURE 13
HOW TO ATTACH AHUMIDIFIER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
ATTACH AHUMIDAIRE 3IHUMIDIFIER 14
HOW TO USE THE KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
HOW TO CHANGE THE SETTINGS 16
HOW TO USE THE STANDARD MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
HOW TO USE THE DETAILED MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
SETTINGS MENU 20
RESULTS MENU 21
OPTIONS MENU 21
SERVICING MENU 21
MESSAGES ON THE S8 ELITE LCD 22
S8 MODULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
USING ABLANK MODULE 23
USING ARESSCAN DATA CARD MODULE 23
CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
DAILY CLEANING 25
CONTENTS

4
WEEKLY CLEANING 25
PERIODIC CLEANING 25
REPLACING THE AIR FILTER 26
SERVICING 26
FREQUENTLY ASKED QUESTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
SYSTEM SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
S8 ELITE (NO ACCESSORIES) 33
ACCESSORIES 33
ALL DEVICES (WHERE APPLICABLE) 34
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

ENGLISH
5
INTRODUCTION
INTRODUCTION
Thank you for choosing the S8 ELITE™ flow generator. The S8 ELITE is a compact,
all-in-one package with an inbuilt power supply and the option of integrated data
management and humidification.
This user manual contains the information you need for the correct use of your
S8 ELITE.
YOUR RESPONSIBILITY
The owner or user of this system shall have sole responsibility and liability for any injury
to persons or damage to property resulting from:
•operation which is not in accordance with the operating instructions supplied
•maintenance or modifications carried out unless in accordance with authorised
instructions and by authorised persons.
Please read this manual carefully before use.
This manual contains special terms and icons that appear in the margins to draw your
attention to specific and important information.
•Warning alerts you to possible injury.
•Caution explains special measures for the safe and effective use of the device.
•Note is an informative or helpful note.
MEDICAL INFORMATION
ABOUT THE S8 ELITE
The S8 ELITE continuous positive airway pressure (CPAP) system is indicated for the
treatment of obstructive sleep apnoea (OSA) in adult patients.
The S8 ELITE CPAP system is intended for home and hospital use.
CONTRAINDICATIONS
The S8 ELITE is not a life support device and may stop operating during power failure
or certain fault conditions. It should not be used by patients who are dependent on
continuous therapy.
Positive airway pressure therapy may be contraindicated in some patients with the
following pre-existing conditions:
•severe bullous lung disease
•pneumothorax
•pathologically low blood pressure
•dehydration
•cerebrospinal fluid leak, recent cranial surgery or trauma.

6
WARNINGS
•The entire manual should be read before using the S8 ELITE.
•Advice contained in this manual should not supersede instructions given by the
prescribing physician.
•A patient should not connect a device to the data communication port unless
instructed to do so by their health care provider or physician. Only ResMed
products are designed to be connected to the data communication port.
Connecting other devices could result in injury, or damage to the S8 ELITE device.
•The S8 ELITE should only be used with masks (and connectors)*recommended by
ResMed, or by a physician or respiratory therapist. A mask should not be used
unless the S8 ELITE device is turned on and operating properly. The vent hole or
holes associated with the mask should never be blocked.
Explanation: The S8 ELITE is intended to be used with special masks (or
connectors)*which have vent holes to allow continuous flow of air out of the
mask.
When the device is turned on and functioning properly, new air from the device
flushes the exhaled air out through the mask vent holes. However, when the
device is not operating, insufficient fresh air will be provided through the mask, and
the exhaled air may be rebreathed. Rebreathing of exhaled air for longer than
several minutes can, in some circumstances, lead to suffocation. This applies to
most models of CPAP devices.
•In the event of power failure or machine malfunction, remove the mask.
•The S8 ELITE can be set to deliver pressures up to 20 cm H2O. In the unlikely event
of certain fault conditions, pressures up to 30 cm H2O are possible.
•If oxygen is used with this device, the oxygen flow must be turned off when the
device is not operating.
Explanation: When the CPAP device is not in operation and the oxygen flow is
left on, oxygen delivered into the air delivery tubing may accumulate within the
CPAP machine enclosure and create a risk of fire. This applies to most types of
CPAP machines.
•Oxygen supports combustion. Oxygen should not be used while you are
smoking or in the presence of an open flame.
•Always ensure airflow is being generated by the device before the oxygen
supply is turned on.
•Always turn the oxygen supply off before stopping the airflow from the device.
Note: At a fixed rate of supplemental oxygen flow, the inhaled oxygen concentration
will vary, depending on where the oxygen is introduced, the pressure settings, patient
breathing pattern, mask selection and leak rate.
•Do not use the S8 ELITE if there are obvious external defects or unexplained
changes in performance.
* Ports may be incorporated into the mask or in connectors that are near the mask.

ENGLISH
7
MEDICAL INFORMATION
•Do not open the S8 ELITE case. There are no user serviceable parts inside. Repairs
and internal servicing should only be performed by an authorised service agent.
•Explosion hazard—do not use in the vicinity of flammable anesthetics.
CAUTIONS
•At low pressures, the flow through the exhalation ports of your mask may not
clear all exhaled gas from the tubing. Some rebreathing may occur.
•The airflow for breathing produced by this device can be as much as 6°C higher
than the temperature of the room. Caution should be exercised if the room
temperature is warmer than 32°C.
•When AC mains power (100–240V AC) is not available, always use a ResMed
DC-12 converter. (The DC-12 converter is available as an optional accessory.)
•If supplied, the RESSCAN™ Data Card module is designed for use with specific
ResMed devices.
•Only use the RESSCAN Data Card module (if supplied) as specified in this manual.
Note: The above are general warnings and cautions. Specific warnings, cautions and notes
appear with the relevant instructions in the manual.
ADVERSE EFFECTS
Patients should report unusual chest pain, severe headache or increased breathlessness
to their prescribing physician. An acute upper respiratory tract infection may require
temporary discontinuation of treatment.
The following side effects may arise during the course of therapy with the S8 device:
•drying of the nose, mouth or throat
•nosebleed
•bloating
•ear or sinus discomfort
•eye irritation
•skin rashes
•chest discomfort.

8

ENGLISH
9
THE S8 ELITE SYSTEM
THE S8 ELITE SYSTEM
The S8 ELITE device is part of a system that consists of five elements:
•S8 ELITE flow generator
•Mask
•Humidifier
•Data management products
•Accessories.
S8 ELITE
Please refer to the illustrations in section Aof the illustration sheet.
FRONT VIEW (A-1)
Shows the keypad and LCD screen, and the air outlet.
REAR VIEW (A-2)
Shows where the module attaches, and the location of the air filter and power sockets.
POWER CORD (A-3)
Power cord to attach the S8 ELITE to the AC (mains) power.
CARRY BAG (A-4)
The S8 ELITE carry bag contains two pouches: one for storing the S8 device, the other
for storing the integrated humidifier. When storing the humidifier, always put it in the
larger, mesh pouch.
AIR TUBING (A-5)
The 2 m air tubing connects the S8 ELITE to your mask.
MASKS
You will also need a ResMed mask system (supplied separately).
The ResMed mask systems that are recommended for use with the S8 ELITE are:
NASAL MASKS
•MODULAR NASAL MASK
•MIRAGE VISTA™ NASAL MASK
•ULTRA MIRAGE™ NASAL MASK
•MIRAGE™ NASAL MASK
•MIRAGE ACTIVA™ NASAL MASK
•PAPILLON™
NASAL PILLOWS SYSTEMS
•MIRAGE SWIFT™ NASAL PILLOWS SYSTEM

10
FULL FACE MASKS
•MIRAGE™ FULL FACE MASK
•MIRAGE™ FULL FACE MASK SERIES 2
•ULTRA MIRAGE™ FULL FACE MASK
Note: Not all masks are available in all regions.
!
WARNING
Only ResMed mask systems are compatible for use with the S8 Elite. Please refer
to “Warnings” on page 6.
HUMIDIFIER
Please refer to the illustration in section B of the illustration sheet.
A humidifier may be required if you are experiencing dryness of the nose, throat or
mouth. The S8 ELITE is compatible for use with the HUMIDAIRE 3i integrated heated
humidifier (B-1).
RESSCAN DATA CARD MODULE
The RESSCAN™Data Card module and RESSCAN Data Card (C-1) may be used with
the S8 ELITE either to help your clinician to monitor your treatment or to provide you
with updates to your device settings. See “Using a ResScan Data Card Module” on
page 23 for information about how to use the Data Card module and Data Card.
ACCESSORIES
Please refer to the illustrations in section Cof the illustration sheet.
Other accessories for use with the S8 ELITE:
•Front cap (not available in all regions) (C-2)
•Air tubing (3 m) (C-3)
•DC-12 converter (C-4)
•Blank module (C-5).
Note: ResMed regularly releases new products. Please check our website at
<www.resmed.com>.

ENGLISH
11
HOW TO USE THE S8 ELITE
HOW TO USE THE S8 ELITE
Please refer to the illustrations in section Dof the illustration sheet.
SET UPTHE S8 ELITE
1Place the S8 ELITE on a table near the head of your bed.
!
CAUTION
Be careful not to place the device where it can be bumped or where someone is
likely to trip over the power cord.
Note: You can also place your S8 Elite on the floor beside or underneath your bed. Ensure
that the area is free from dust and clear of bedding, clothes or any other objects that could
block the air inlet.
2Connect the power cord to the socket at the rear of the flow generator (D-1). Plug
the other end of the power cord into the power outlet.
!
WARNING
Make sure the power cord and plug are in good condition and the equipment is not
damaged.
3Connect one end of the air tubing firmly onto the air outlet (D-2).
!
WARNING
•Only ResMed air tubing should be used with your flow generator. A different
type of air tubing may alter the pressure you actually receive, reducing the
effectiveness of your treatment.
•Blocking the air inlet or tubing while in operation could lead to overheating of
the device.
•In the clinical environment any personal computer that is used with your CPAP
system must be at least 1.5 m away from, or at least 2.5 m above, the patient. It
must also comply with the relevant test standard. For personal computers the
international standard is IEC 60950 or equivalent.
ASSEMBLE THE MASK
1Assemble your mask system according to the mask user instructions.
2Connect your mask system to the free end of the air tubing (D-3).
3Check that the mask setting on the MASK screen is the one recommended for the
mask you are using (see the table in “How to Select the Mask Type” on page 20).
The S8 ELITE is now ready for use (D-4).

12
START TREATMENT
1Make sure the power is on.
A welcome message is displayed briefly on the LCD screen, then the standby (Ramp)
screen appears. The key and LCD backlights also turn on.
2Lie down and arrange the air tubing so that it is free to move if you turn in your sleep.
!
CAUTION
•Do not leave long lengths of air tubing around the top of your bed. They could
twist around your head or neck while you are sleeping.
•Make sure the area around the flow generator is dry and clean. It should also be
clear of bedding, clothes and other potential blockages.
3Alter the ramp time if required (see “How to Change the Ramp Time” on page 16).
To start treatment, press the Start/Stop key, unless your clinician has set up your
device to start delivering therapy automatically. If so, your device will start when you
breathe into your mask (see “SmartStart” for details).
4Fit your mask as described in the mask user instructions.
!
WARNING
A mask should not be used unless the S8 Elite device is powered and operating
properly.
5When ramping begins, the LCD will display the word "RAMPING", with the current
pressure indicated as dashes. Each dash is approximately equivalent to 2 cm H2O. For
example, 6 dashes represents approximately 12 cm H2O pressure.
SMARTSTART™
The S8 ELITE has a function called SmartStart™that your clinician can enable. If
SmartStart is enabled, your device will start automatically when you breathe into your
mask, and will stop automatically when you take your mask off. This means you do not
have to press the Start/Stop key to begin or end treatment.
Note: Do not use SmartStart when using a mask with an anti-asphyxia valve, such as the
Mirage Full Face Mask.
STOPPING TREATMENT
To stop treatment at any time, remove your mask and press the Start/Stop key
or
if your clinician has enabled SmartStart, simply remove your mask and treatment will
end.

ENGLISH
13
HOW TO USE THE S8 ELITE
USING THE MASK-FITTING FEATURE
You can use the S8 ELITE mask-fitting feature to help you fit your mask properly. This
feature delivers air pressure for a three-minute period, prior to starting treatment,
during which you can check and adjust your mask fit to minimise leaks.
Note: Make sure that the mask setting on the MASK screen is the same as the mask you
are using.
To use the mask-fitting feature:
1Fit your mask as described in the mask user instructions.
2Hold down the Start/Stop key for at least three seconds until air pressure delivery
starts.
The following display will appear on the LCD screen indicating that the mask-fitting
feature is operating. Your S8 device will ramp to the mask-fit pressure and will remain
at this pressure for three minutes.
The LCD also displays a mask-fit star rating. See Table 1, “Definitions of Mask-Fit Star
Rating,” on page 14.
Note: The mask-fit star rating display disappears after three minutes.
The mask-fitting feature can only be started from the RAMP screen.
The mask-fit pressure is the set treatment pressure or 10 cm H20, whichever is greater.
3Adjust your mask, mask cushion, and headgear until you have a secure and comfortable
fit.
Once you have a secure and comfortable fit, check your mask-fit star rating on the
LCD screen. Table 1 explains the mask-fit star ratings.
Note: If there is another person nearby to check your mask-fit star rating, you can adjust
your mask, mask cushion and headgear while lying down.
4After three minutes, the pressure reverts to the set pressure and treatment will begin.
•If you do not wish to wait three minutes, hold down the Start/Stop key for at
least three seconds to start treatment immediately.
•If you press the Start/Stop key for less than three seconds, the unit will return
to standby mode (the RAMP screen is displayed).
MASK FIT: *****
excelnt
mask-fit star rating

14
Table 1: Definitions of Mask-Fit Star Rating
HOW TO ATTACH AHUMIDIFIER
ATTACH AHUMIDAIRE 3 i HUMIDIFIER
Please refer to the illustration in section Eof the illustration sheet, and your HumidAire 3i
manual.
The HUMIDAIRE 3
i attaches to the front of the S8 ELITE to provide heated
humidification. No other accessories are required for its use.
Notes:
a. Make sure the water chamber of the HumidAire 3i is empty before you attach or
detach the humidifier.
b. Remove the connector plug on the S8 Elite before you attach the HumidAire 3i.
Reattach the connector plug firmly after you detach the humidifier.
STORING THE HUMIDAIRE 3 i
Store the HUMIDAIRE 3 i in the larger, mesh-top pouch of the S8 ELITE carry bag when
not in use.
Star rating Definition
***** Excellent
****- Very good
***-- Good
**--- Adjust mask
*---- Adjust mask
----- Adjust mask

ENGLISH
15
HOW TO USE THE KEYPAD
HOW TO USE THE KEYPAD
The control panel of the S8 ELITE includes an LCD screen and keypad for navigating
through the menus and delivering treatment.
LCD SCREEN
The LCD screen displays the menus and treatment screens.
The LCD backlight turns off after two minutes of inactivity. It turns back on when you
press a key.
KEYPAD KEYS
The S8 ELITE keypad has the following keys:
When the S8 device is in standby mode all keys remain lit. During therapy, the keypad
backlight turns off after two minutes of inactivity and the Start/Stop key dims.
LCD screen
Left key
Up key
Right key
Start/Stop key
Down key
Key Function
Start/Stop • Starts or stops treatment.
• Extended hold (for at least three seconds) starts the
mask-fitting feature.
Up • Allows you to scroll through the S8 Elite menus and
submenus, and increase the setting options.
Down • Allows you to scroll through the S8 Elite menus and
submenus, and decrease the setting options.
Left • Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes menu,
change and apply.
Right • Performs the function indicated by the guiding text displayed
above it on the LCD screen. Guiding text includes exit and
cancel.

16
HOW TO CHANGE THE SETTINGS
You can change settings on the S8 ELITE by using the keypad and LCD. When the
S8 ELITE is in standby mode you can display a series of screens (a menu) on the LCD
screen in order to view and change the settings for a particular function.
Your clinician will preset the menu to either a standard view or a detailed view.
See “How to Use the Standard Menu” on page 17 and “How to Use the Detailed
Menu” on page 19 for more information.
HOW TO ENTER THE MENU SCREENS
When the S8 ELITE standby (RAMP) screen is displayed you will see the word ‘menu’
in the left-hand corner. To select an S8 ELITE menu, press the Left key.
HOW TO SCROLL THROUGH THE MENU
When you are in the menu, scroll through items by pressing the Up or Down keys.
HOW TO CHANGE ASETTING OPTION
When you have scrolled to the item you require:
1. Press the Left key (Change).
2. Press the Up or Down keys until you see the setting option that you require.
3. Press the Left key (Apply) to select the setting option.
If you wish to exit without changing the option, press the Right key (Cancel).
HOW TO EXIT OUT OF AMENU
Press the Right key (Exit). This will take you back to the standby (RAMP) screen.
HOW TO EXIT OUT OF AN ITEM WITHIN THE MENU
Press the Right key (Exit).
HOW TO CHANGE THE RAMP TIME
During ramp time, the pressure increases from a low pressure to the prescribed
treatment pressure. You can set the ramp time in 5-minute intervals, from 0 minutes
(OFF) up to a maximum ramp time set by your clinician.
The standby screen displays the current ramp time in the right-hand corner. To change
the ramp time, press the Up or Down key until the desired ramp time appears.
Once a ramp time is selected, begin therapy by pressing the Start/Stop key.
