Resource Swing With Chaise User manual

Assembly
Instructions
Swing With Chaise

WARNING
READ CAREFULLY BEFORE BEGINNING INSTALLATION.
IMPROPER INSTALLATION OF THE PRODUCT MAY CAUSE SERIOUS INJURY
Warranties for all products purchased from Resource Furniture, LLC are
only valid if the product has been properly assembled, Installed by a trained
professional, and operated in accordance with the assembly instructions.
Resource Furniture accepts no responsibility for any damage or injury caused
by Improper Installation.
Installation must be performed by a licensed contractor or a trained
professional, who will ensure proper assembly and installation.
Installation must be performed by at least 2 people.
Improper installation may result in permanent damage to the bed.
Improper installation of this product can cause serious or fatal injury.
All hardware must be properly tightened. No parts of the model should be
left loose or unstable.

SWING MATTRESS SPECIFICATIONS
Recommended weight: ~ 64 lbs
Recommended dimensions: 79 1/2 x 60 x 7” 1
SWING OVERVIEW
02
MATTRESS SWING
Recommended weight: ~ 64Lbs
Recommended dimensions: 79 1/2 x 60 x 7inches
SWING CHAISE
Freestanding
86 5/8
86 5/8
110 5/8
110 5/8
68 1/8
68 1/8
42 1/2
42 1/2
49 1/4
86 5/8
13 3/4
13 3/4

2
SWING OVERVIEW

15 11
14
10
3
SWING OVERVIEW

SWING COMPONENTS
BOISERIE COMPONENTS
CODE QT Y. COMPONENTS
1 1 Right side panel
2 1 Left side panel
3 1 Top horizontal panel
4 1 Base
5 2 Left/Right Small Side Panels (already attached to 1 & 2)
6 1 Right Back Panel
7 1 Left Back Panel
8 1 Bed Frame
9 1 Mattress Support Bar
10 1 Front Shelf
11 1 Sofa Seat & Storage Box
12 1 Sofa Arm Support Bracket
13 1 Sofa Arm
14 1 Sliding Chaise Seat
CODE QT Y. COMPONENTS
15 1 Boiserie Panel
16 3 Shelf
4

SWING STRUCTURAL HARDWARE
CODE QT Y. COMPONENT DESCRIPTION
A 13 7 x 36 6MA Pins
B 13 D15 L17 Cam Connectors
C 7 3.5 x 20 Wood screws for back
panels
D 4 5MA x 50 Machine bolt for side panels
E 6 4MA x 18 Machine bolt for mattress
support bar
F 4 4 x 40 Wood screws for attaching top
panel to back panels
G 1 Spacer for sliding chaise
H 3 8MA x 80
Machine bolt for attaching
sofa arm support bracket to
base
I 4 4 x 25 Machine bolts for front shelf
J 3 8MA Nut for attaching sofa arm
support bracket to base
K 4 D9 x 24 Washer for attaching sofa
arm support bracket to base
L 2 8MA Machine bolt for attaching
sliding chaise to side panel
M 4 6MA x 25 Machine bolts for attaching
storage box to base 5

BOISERIE STRUCTURAL HARDWARE
CODE QT Y. DESCRIPTION
N 6 Metal Shelf Sup-
port
O 12
Machine Bolt to
attach Metal Shelf
support to Boiserie
Panel
P 1 Cleat to attach Boi-
serie Panel to wall
Q 6
Q 6 Wall Anchor
(concrete walls
only)
A proper wall anchor suitable for the wall’s construction
must be selected by the contractor or installer.
08
08
08
08
6

STRUCTURE ASSEMBLY
1
2
Attach the (2) left side panel to the (4) base using 2 (D) screws.
Attach the (7) left back panel to the (2) left side panel using 3 (A) pins and 3 (B) cam connectors.
Attach the (6) right back panel to the (7) left back panel with 3 (A) pins and 3 (B) cam connectors.
7

STRUCTURE ASSEMBLY
B
B
A
A
F
F
3
4
Attach the (3) top horizontal panel to the (2) left side panel with 2 (A) pins and
2 (B) cam connectors, and to the back panels with 4 (F) screws.
Attach the (1) right side panel to the (4) base using 2 (D) screws, and to the top horizontal panel
and back panels with 5 (A) pins and 5 (B) cam connectors. Secure the back panels to the base
using 4 (F) screws. These pieces are pre-assembled.
8

Wand Light Exploded Diagram
Cord Length = 118”
Back
Front
5
OPTIONAL WAND LIGHTING
Drill 1/2” hole at 18 1/8” below upperbed structure panel (from inside) and 1 1/2” in from
the side. Install mounting plate with provided wood screws, aligning the 1/2” drill holes.
9

LEVELING THE STRUCTURE
det.1
4a
6Ensure that the structure is level and plumb. To compensate for any floor unevenness,
use the adjustable feet on the bottom panel (det. 1 4a) to level the structure.
10

7
8
BED FRAME ASSEMBLY
det.5a
Unscrew the safety plates fixed to the (4) base, as shown in det. 5a. The safety plates
must be securely reattached after the levers are inserted. (see next page for details)
Position the (8) bed frame within the structure as shown. Place the levers located near the head
of the bed frame into their slots as shown in det. 6a, and re-attach the safety plates from Image 5.
Ensure that pins on the bedframe slide into the base of the structure as shown in det. 6b.
Note: It is recommended to USE proper floor protection around the work area, under the bed
frame, so that the metal feet do not scratch the floor.
det.6b
det.6a
11

BED FRAME ASSEMBLY
9Attach the (9) mattress support bar to the bed frame using six (E) machine bolts.
12

10
11
FRONT SHELF INSTALLATION
BED OPERATION
17
Installing the shelf
IMG.9: Attach the shelf to the feet of the bedframe, as shown, using 4 (I) screws.
OPENING THE BED
IMAGE 10:
Grasp the handle in the center of the shelf and pull down the bed, gently accompanying the
bed with both hands until it reaches the ground.
Attach the shelf to the feet of the bed frame, as shown, using 4 (I) screws.
Grasp the handle in the center of the shelf and pull down the bed, gently accompanying
the bed with both hands until it reaches the ground.
13

MATTRESS & HEADBOARD INSTALLATION
12 Attach the headboard (if purchased by client) to the back of the structure. Secure the
mattress to the bedframe by fastening the two buckled straps.
14

BED FRAME ADJUSTMENT
18
ADJUSTING THE TENSION ON THE BED FRAME SPRINGS
IMAGE 12
To balance the bedframe, adjust the spring tension controllers with the 8mm allen wrench
provided. Turn clockwise to adjust the tension in order to close the bed with ease. Ensuring that
each side of the bedframe is adjusted equally.
Note: An excessive number of turns may damage the cable.
ASSEMBLY OF THE BED & HEADBOARD
IMAGE 11
Attach the headboard (if purchased by client) to the back of the structure.
Secure the mattress to the bedframe by fastening the two buckled straps.
13 To balance the bedframe, adjust the spring tension controllers with the 8mm allen
wrench provided. Turn clockwise to adjust the tension in order to close the bed with
ease. Ensuring that each side of the bedframe is adjusted equally.
Note: An excessive number of turns may damage the cable.
15

BOISERIE PANEL ASSEMBLY
14
15 16
Installing the boiserie panel: Insert and fasten the M metal shelf pins into the holes on the (15)
boiserie panel using 2 (O) bolts each.
Place the boiserie panel next to the bed and
ensure panel is level and plumb. Attach the (P)
wall : bracket to the wall using the proper wall
anchor suitable for the wall construction. Then,
hang the (15) boiserie panel on the bracket.
Slide the boiserie shelves (16) over the
(N) metal shelf pins.
15
16
Installing the boiserie panel:
IMG.15
using 2
:
(O) bolts each.
Insert and fasten the M metal shelf pins into the holes on the (15) boiserie panel
IMG.16 Place the boiserie panel next to the bed and ensure panel is level and plumb.
Attach the (P) wall
: bracket to the wall using the (Q) wall anchors provided. (anchors for
concrete walls only) Then, hang the (15) boiserie panel on the bracket.
IMG.17: Slide the boiserie shelves (16) over the (N) metal shelf pins.
ASSEMBLY OF THE BOISERIE PANELS
20
16

OPTIONAL SOFA ARM INSTALLATION
Installing the sofa arm support
IMG.20: attach the sofa arm support bracket (12) to the base (4) using machine bolts n°3
8MAx80, n°3 washers D8-24 and nut 8MA, as shown in the image below;
IMG.21: Insert the sofa arm (13) into the sofa arm support bracket (12).
20
SWING MODEL WITH SOFA ARM
21
Installing the sofa arm support
IMG.20: attach the sofa arm support bracket (12) to the base (4) using machine bolts n°3
8MAx80, n°3 washers D8-24 and nut 8MA, as shown in the image below;
IMG.21: Insert the sofa arm (13) into the sofa arm support bracket (12).
20
SWING MODEL WITH SOFA ARM
21
17
18
To attach the sofa arm support bracket (12) to the base (4) using machine bolts n°3
8MAx80, n°3 washers D8-24 and nut 8MA, as shown in the image below;
Insert the sofa arm (13) into the sofa arm support bracket (12).
17

SOFA SEAT & STORAGE BOX INSTALLATION
19 Attach the sofa storage box (11) to the base (4) using (M) machine bolts.
Installing the sofa seat and storage box
IMG.22: Attach the sofa storage box (11) to the base (4) using (M) machine bolts..
22
