RGBlink FLEXpro 8 User manual

FLEXpro 8
Article No: RGB-RD-UM- Flexpro8 E000
Revision No: V1.1
USER MANUAL

Felxpro 8 User Manual
1
CONTENTS
CONTENTS....................................................................................................................................................1
Declarations................................................................................................................................................... 2
FCC/Warranty........................................................................................................................................ 2
Operators Safety Summary.................................................................................................................3
Installation Safety Summary............................................................................................................... 3
Chapter 1 Your Product................................................................................................................................5
1.1 In the Box.........................................................................................................................................5
1.2 Product Overview........................................................................................................................... 6
1.2.1 Front Panel..............................................................................................................................7
1.2.2 Rear Panel............................................................................................................................... 8
1.2.3 Dimension............................................................................................................................... 9
Chapter 2 Install Your Product..................................................................................................................10
2.1 Plug in Signals.............................................................................................................................. 10
2.2 Plug in Main Power...................................................................................................................... 10
2.3 Turn on Your Product.................................................................................................................. 10
2.4 Connect Felxpro 8 and Computer.............................................................................................. 10
Chapter 3 UseYour Product...................................................................................................................... 11
3.1 Install XPOSE 2.0.............................................................................................................................. 11
3.2 XPOSE Controls Felxpro 8................................................................................................................ 15
3.2.1 Login in XPOSE...................................................................................................................... 15
3.2.2 Topology Diagram................................................................................................................. 17
3.2.3 System Settings.....................................................................................................................21
3.2.4 Output|Input |Overview....................................................................................................24
3.2.5 Display System...................................................................................................................... 33
3.2.6 Layer Management...............................................................................................................38
3.2.7 Preset Management............................................................................................................. 43
Chapter 4 Order Codes..............................................................................................................................49
4.1 Product.............................................................................................................................................49
4.2 Options.............................................................................................................................................49
4.2.1 Input Options........................................................................................................................ 49
4.2.2 Output Options..................................................................................................................... 49
4.2.3 Other.....................................................................................................................................49
Chapter 5 Support.......................................................................................................................................50
5.1 Contact Us..................................................................................................................................... 50
Chapter 6 Appendix.................................................................................................................................... 51
6.1 Specification.................................................................................................................................. 51
6.2Terms & Definitions...................................................................................................................... 57
6.3Revision History............................................................................................................................ 64

Felxpro 8 User Manual
2
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and
make use of all the features. Please read all directions and instructions carefully before
using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area may cause harmful
interference, in which case the user will be responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally
stipulated terms of guarantee. On receipt, the purchaser must immediately inspect all
delivered goods for damage incurred during transport, as well as for material and
manufacturing faults. RGBlink must be informed immediately in writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems
and software on the date of commissioning, at latest 30 days after the transfer of risks. In the
event of justified notice of compliant, RGBlink can repair the fault or provide a replacement at its
own discretion within an appropriate period. If this measure proves to be impossible or
unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the
contract. All other claims, in particular those relating to compensation for direct or indirect
damage, and also damage attributed to the operation of software as well as to other service
provided by RGBlink, being a component of the system or independent service, will be deemed
invalid provided the damage is not proven to be attributed to the absence of properties
guaranteed in writing or due to the intent or gross negligence or part of RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by
RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned
operated incorrectly or if, after the transfer of risks, the goods are subject to influences not
agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not
included in the guarantee coverage are system failures which are attributed to programs or
special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as well as
normal maintenance are not subject to the guarantee provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in
this manual must be complied with by the customer.

Felxpro 8 User Manual
3
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose
dangerous voltages. To avoid personal injury, do not remove the top cover. Do not operate the
unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts
rms between the supply conductors or between both supply conductor and ground. A protective
ground connection by way of grounding conductor in the power cord is essential for safe
operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical
shock, plug the power cord into a properly wired receptacle before connecting to the product
input or output terminals. A protective-ground connection by way of the grounding conductor in
the power cord is essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is
in good condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating
characteristics. Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all Felxpro 8 processor installation procedures, please observe the following important safety
and handling rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground
wire provided in the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.

Felxpro 8 User Manual
4
Unpacking and Inspection
Before opening Felxpro 8 processor shipping box, inspect it for damage. If you find any
damage, notify the shipping carrier immediately for all claims adjustments. As you open the box,
compare its contents against the packing slip. If you find any shortages, contact your sales
representative.
Once you have removed all the components from their packaging and checked that all the listed
components are present, visually inspect the system to ensure there was no damage during
shipping. If there is damage, notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your Felxpro 8 should be clean, properly lit, free from
static, and have adequate power, ventilation, and space for all components.

Felxpro 8 User Manual
5
AC Power
Cord
Chapter 1 Your Product
1.1 In the Box
Note:
AC Power Cable supplied as standard according to destination market.
Upgrade tool package and user manual are stored in the USB disk, please keep it.
Network
Cable
HDMI to DVI
Cable
RJ11 to DB9
Serial Cable
Antistatic
Bag
SDI Cable
DVI Cable
USB Disk

Felxpro 8 User Manual
6
1.2 Product Overview
FLEXpro8 is an all new video processing solution for modern large scale display applications. With
support for over 18 mega pixels across eight outputs, FLEXpro8 is designed for professional
applications. Fit up to 16 independent inputs integrating a range of video sources and signals
utilized in commercial display systems.
The innovative RGBlink modular signal system provides native on support for HDBaseT, Fiber and
LED Control signals as well as conventional signals, embracing flexibility while being an efficient
self-contained system.
Whether for integration or proAV FLEXpro8 has the multi-signal, multi-layer technology for
virtually any display application.
Flexpro 8 Application Diagram

Felxpro 8 User Manual
7
1.2.1 Front Panel
1
OLED Panel
Show the input shot and output slot information, device status, COM. Version, IP
address and serial address.
2
POWER
Power button, long push the button, the device can be boot up. Under normal
running state, push the button once, the info shown on OLED can be refreshed
once ; long push the button, the OLED will pop up a confirm box, release the
power button, push the power again before the confirm box disappears, and the
power can be turned off.

Felxpro 8 User Manual
8
1.2.2 Rear Panel
Chassis Module Structure
1
2 slots for input modules, support
DVI, HDMI and SDI optional
module
4
Communication
2
2 slots for output modules,
support DVI, HDMI, SDI, HDBaseT
and Subito Sender optional
modules
5
Genlock
3
Independent PVW output ports
6
PSU Module

Felxpro 8 User Manual
9
1.2.3 Dimension
Following is the dimension of Felxpro 8 for your reference:

Felxpro 8 User Manual
10
Chapter 2 Install Your Product
2.1 Plug in Signals
Connect signals to the product (ensure all the device are all power off first).Tighten
connector screws/locks where provided.
2.2 Plug in Main Power
Connect IEC cable to device and plug into wall socket. Turn on power at wall socket.
2.3 Turn on Your Product
Turn on the power switch on the real panel.
OLED display will show as below,completing initialization before loading the latest settings
and input/output configuration.
The system begins to work,and the OLED module shows the input slot and output slot
information, device status, COM. Versions. IP address and serial number.
2.4 Connect Felxpro 8 and Computer
Use network cable to connect the Felxpro 8 and computer with USBA-B cable from In the
Box.
Set the IP address of the computer and make sure the computer and the device are in
same network range. IP address of the device is available on the OLED screen after it is
powered on. For example if the IP of the device is 192.168.110.1, just make sure the IP of
the computer is in 192.168.xxx.x, but not exact the same as the device.

Felxpro 8 User Manual
11
Chapter 3 Use Your Product
3.1 Install XPOSE 2.0
Environment Requirements:
Window
Processor: 1 GHz or above 32 bit or 64 bit processor
Memory: 4 GB or more
Graphics: Support DirectX 9 128M or above (open AERO effect)
Hard disk space: Above 16G (primary partitions, NTFS format)
Monitor: Resolution must be 1920x1080 pixel or above (it can not display normally if the
resolution is lower than 1920x1080)
Operating system: Windows 7 or above (full version, not Ghost version or compact version)
CPU:i5 and above
Mac
Monitor: Resolution must be 1680x1050 pixel or above (it can not display normally if the
resolution is lower than 1680x1050)
CPU:i5 and above
Double click ,it will pop-up the installer language box, select the language, for
example, select “English”, and click “OK” to confirm.
Click “Next” to install:

Felxpro 8 User Manual
12
Click “Browse...” to select the XPOSE software install location:
Click “Install”:
During installation, it will pop up the window of Install Shield Wizard for Virtual Com port:

Felxpro 8 User Manual
13
If user install the XPOSE software for the first time, click “Next
Then click “Install", as shown in the figure below:

Felxpro 8 User Manual
14
Click “Finish” and complete the installation, as shown in the figure below:
Click “Finish” and is ready to run the XPOSE :

Felxpro 8 User Manual
15
3.2 XPOSE Controls Felxpro 8
3.2.1 Login in XPOSE
Double click this icon ,and enter the log on interface as follow
The initial language of XPOSE 2.0 is self adjusted based on the operation system language of the
computer. Click Register and fill in the blank with first name, last name, email, company and
country and then click Register Now.
Please note that the email shall be invalid and complete otherwise Registration&Activation code
cannot be received.
Click Activate and scan the QR code
an email from RGBlink Registrations will be sent to the Register email address.
Type in the activate code and confirm

Felxpro 8 User Manual
16
then enter the login interface.
Keep the user name as “Admin” and password blank and then click Start Now.
Note: If exact Name and Password are needed, users can set up them in Authorization Setting
under System Setting.
After login, users can find the management including:Topology Diagram,Search,Display System,
Layer Management, Preset Management, Keyboard Settings. The details of each hierarchy will be
described hereafter.
In the following text, we are going to show how to use XPOSE 2.0 to control Flexpro 8.

Felxpro 8 User Manual
17
3.2.2 Topology Diagram
XPOSE 2.0 offers the feature of making topology diagram which can assist users to import the
actual input and output connection into XPOSE control.
1. Drag device, input source device and output device from the list on the left based on the field
application. For example, drag Flexpro 8 from Device, Laptop from Input and LDC from Output list
as follows:
2. Click the icon at the right bottom corner and open the setting interface as following:
3. After Flexpro 8 is dragged into the topology diagram interface, users can find how many
Flexpro 8 devices currently linked in the same network from the drop-down arrow after SN.

Felxpro 8 User Manual
18
After one of the device is chosen, the device on the topology diagram shows the SN and IP
address of the chosen one.
4. Choose board type of In and Out according to the actual input and output modules
configuration user want. For example, set the first input board as DVI module as the following
Select IN|OUT: In, Model:Universal, Signal:DVI, Port:any figure from 1 to 4, click ADD to
finish
If the input module is formed by different signal input ports, choose the Model as Typical, it will
allow users to set port type one by one.
.

Felxpro 8 User Manual
19
The chosen port of board of In and Out indicated by red dot as below:
5. After choosing board type, users can check the state in Input and Output and change the
connection port if needed.
6. If there are not enough devices in the device list on the left column, users can select and load
more devices to the list from the Library.
