Risco Lights Plus Instruction manual

Lights Plus
Quick User Guide
Full (“Away”) Arming
❖Quick mode:
❖High Security mode: Code ➢
❖Quick mode: .
❖High security mode:
➢code or use Proximity
tag
❖Quick mode:
❖High Security mode: Code ➢
to apply to all partitions,
or slide a specific partition to
the right under .
❖Quick mode: .
❖High security mode: Code ➢
Press
Full Arm all: Security ➢
Press
❖Quick mode: .
❖High Security mode: ➢code

02/2022
Page 2
5IN2931 B
Partial (“Stay”) Arming
❖Quick mode:
❖High Security mode: Code ➢
❖Quick mode: .
❖High security mode:
➢code or use Proximity
tag
❖Quick mode:
❖High Security mode: Code ➢
to apply to all partitions,
or slide a specific partition to
the left under .
❖Quick mode: .
❖High security mode: Code ➢
Press
Partial Arm all: Security ➢press
Press or large rounded
button (installer-defined)
❖Quick mode: .
❖High Security mode: ➢code

02/2022
Page 3
5IN2931 B
Partition & Group Arming
❖Full partition arming:
Code ➢“Security” menu ➢“Partitions” tab ➢select All or specific partition
number/s ➢
❖Partial partition arming:
Code ➢“Security” menu ➢“Partitions” tab ➢select All or specific partition
number/s ➢
Group Arming: “Groups” tab ➢press group letter
❖Full partition arming:
Code ➢➢select All or specific partition number/s ➢
❖Partial partition arming:
Code ➢➢select All or specific partition number/s ➢
Group Arming: Press group letter
❖Full partition arming:
Code ➢➢select All or specific partition number/s ➢
❖Partial partition arming:
Code ➢➢select All or specific partition number/s ➢
Group Arming: Press group letter
Note: Supports up to 3 partitions. Does not support Group arming.
❖Full partition arming:
•Quick mode: Partition number ➢
•High Security mode: Partition number ➢➢code or use Proximity tag
❖Partial partition arming:
•Quick mode: Partition number ➢
•High Security mode: Partition number ➢➢code or use Proximity tag

02/2022
Page 4
5IN2931 B
System Disarming
Code ➢“Security” menu ➢
➢code or use Proximity
tag
Code ➢
to disarm all partitions, or
slide a specific partition to the
center under ➢enter code
Code ➢
Press
Disarm all: Security ➢➢code ➢
press Disarm
Disarm all: Press
❖Quick mode: .
❖High security mode: ➢code
Partition & Group Disarming
Code ➢“Security” menu ➢“Partitions” tab ➢select the Partitions to Disarm
➢
Partition disarming: Code ➢➢select
All or specific partition number(s)
Partition disarming:
Partition number ➢
➢code
Partition disarming: Code ➢➢select All or specific partition
number(s)

02/2022
Page 5
5IN2931 B
Duress Disarming
Duress code ➢
Note: Panel is silent (no alarm siren)
➢duress code
Note: Panel is silent
(no alarm siren)
Duress code ➢
Note: Panel is silent (no alarm siren)
Bypassing & Un-bypassing Zones
Code ➢“Security” menu ➢“Detectors” tab ➢select a detector (zone) ➢
slide switch to the right to bypass
➢code ➢scroll to Activities menu ➢Bypass ➢Zones
➢scroll to select a bypass option .
➢code ➢scroll to Activities menu ➢Bypass ➢Zones
➢scroll to select a bypass option
Viewing System Troubles
Code ➢from the Top Bar, press to view troubles
➢code ➢scroll to View menu ➢Trouble ➢scroll to view
troubles
➢code ➢scroll to View menu ➢Trouble ➢scroll to
view troubles

02/2022
Page 6
5IN2931 B
Viewing Last Alarm / Event Log
Code ➢“History” menu ➢press “All” to view all events, or search an event
Note: You can filter the search according to specific types of events:
All / Alarms / Troubles / Smart Home / Media Events
➢code ➢scroll to Event Log ➢scroll to view events
➢code ➢scroll to Event Log ➢scroll to view events
Viewing System Status
for 2 seconds
❖Quick mode:
for 2 seconds
❖High Security mode:
for 2 seconds ➢
code or use
Proximity tag
Press
Press
❖Quick mode: for 2 seconds
❖High Security mode: for 2 seconds ➢code

02/2022
Page 7
5IN2931 B
Activating Output
Code ➢
“Security” menu
➢
“Utiltiy Output”
tab ➢select
relevant Utility
Output button,
√
➢code ➢
scroll to
Activities menu,
➢scroll to
Utility Output
menu ➢enter
Utility Output
number .
Note: Must be
installer-defined
❖Quick mode:
Press button (1—3)
for 2 seconds
❖High security
mode: Press
button (1—3) for 2
seconds ➢code or
use Proximity tag.
Note: Must be
installer-defined
➢code ➢scroll to Activities menu, ➢scroll to Utility Output
menu ➢enter Utility Output number .
Note: Must be installer-defined
❖Quick mode: Press button (1—3) for 2 seconds
❖High security mode: Press button (1—3) for 2 seconds ➢enter code.
Note: Must be installer-defined
Activating a Panic Alarm
Press the Emergency button (located at the top of the Lock Screen or at
the end of the main menu) ➢➢press and together for 2
seconds.
Press and together for at least 2
seconds
Press and
together for 2
seconds
Press and together for at least 2 seconds
Press and simultaneously
Press and together for 2 seconds.

02/2022
Page 8
5IN2931 B
Activating a Fire Alarm
Press the Emergency button (located at the top of the Lock Screen or at
the end of the main menu) ➢➢press and together for
2 seconds.
Press and together for at least 2 seconds.
Press +
together for 2
seconds
Press and together for at least 2 seconds
Activating an Auxiliary Emergency Alarm
Press the Emergency button (located at the top of the Lock Screen or at
the end of the main menu) ➢➢press and together for 2
seconds.
Press and together for at least 2 seconds.
Press +
together for 2
seconds
Press and together for at least 2 seconds.

02/2022
Page 9
5IN2931 B
SMS Commands
NOTES: Command words are not case sensitive. A separator between command words
may be used (or not). To receive an acknowledgement reply, add RP to the end of an SMS
command.
Full Arm: code + A (Example: 1234A)
Get system status: code + ST
Home Arm: code + H
Bypass Zone: code + B + zone number
Group Arm: code + G + select group A--D
Un-bypass Zone: code + UB + zone
number
Full Disarm: code + D
View last alarm : code + AL
Partition Full Arm: code + A: + partition number
Change FM number: code +
FMPHONE + FM serial number +
NEW + new phone number
Partition Home Arm: code + H: + partition number
Multiple Partition Full/Home Arm: code + A/
H: + partition number A, + partition number B, +
partition number C, etc.
Activate Output: code + UOON + UO
number
Partition Disarm: code + D: + partition number
Deactivate Output: code + UOOFF +
UO number
Multiple Partition Disarm: code + D: + partition
number A, + partition number B, + partition
number C, etc.
Get SIM credit level: code + CR
Icons –Elegant Keypad
Power
On: Power OK.
Off: No power
Rapid flash: System trouble.
Slow flash: System is
programming
Ready
On: Ready to arm
Off: Not ready to arm
Slow flash: Ready to arm
while entry/exit zone is
open
Arm
On: System in fully armed
mode
Off: System disarmed
Rapid flash: Alarm
Slow flash: System in Exit
Delay
Partial Arm / Bypass
On: System in partially-
armed or zone-bypassed
mode
Off: No bypassed zones
Tamper
On: Tamper alarm
Off: No tamper alarm
Fire
On: Fire alarm
Off: No fire alarm
Flash: Fire circuit trouble

02/2022
Page 10
5IN2931 B
LED Indicators –2-Way Remote Control
Operation
Send
command*
Receive
Status
Full Arm
Green
Red
Partial Arm
Green
Orange
Disarm
Green
Green
Alarm
Green
Flashing LED
* If the LED changes to orange, it indicates a low battery condition.
Defining User Codes –Elegant Keypad
1. ➢Grand master code (default = 1234)
2. to scroll to Codes/Tags ➢press twice.
3. to scroll to the user (index number) for defining ➢press twice.
4. Enter (or re-enter) a 4—6 digit code ; the system beeps and ACCEPTED displays
Defining User Codes –Panda Keypad
1. ➢Grand master code (default = 1234)
1. to scroll to Codes/Tags ➢press twice.
2. to scroll to the user (index number) for defining ➢press twice.
3. Enter (or re-enter) a 4—6 digit code ; the system beeps and ACCEPTED
displays

02/2022
Page 11
5IN2931 B
Registering to the RISCO Cloud
Note: Before registering, consult with your Installer to check if you were previously
registered:
If you were previously registered:
a. If you are a RISCO Cloud End-User, accept the invitation sent to your Inbox and
then Login to the RISCO Cloud / Web User Application.
b. If you are not a RISCO Cloud End-User, accept the invitation sent to your Inbox
and then follow the instructions to finalize the creation of your account.
If you were not previously registered:
1After the RISCO Cloud has been enabled by your system installer, go to
www.riscocloud.com and press Register.
2Fill in your first and last name.
3Enter your e-mail address as the Login Name (required for 1st-time activation).
4Define password (minimum of 8 characters, including at least one small case, one
upper case and one special character), and then confirm.
5Enter the 15 digits Panel ID as it appears as printed on the postcard packaged
with the main panel. You can also view it on the keypad (see the LightSYS Plus
User Manual).
6Complete registration form including Site Name, Time Zone and Equipment ID
and then press Create.
7To complete the registration procedure, open the e-mail received at the email
account you had defined as the Login Name in step 3, and then click the link to
activate your registration to the Cloud.
Logging in to the RISCO Cloud / Accessing the Web User Application
1Go to www.riscocloud.com
2Enter your user name and password (as defined during the registration process).
3Click Login.
4Select the Site and then enter the system PIN code (user code).
5Click Login.
iRISCO Smartphone App
Download the iRISCO Smartphone app from the Apple App store or the Android Play
Store.

02/2022
Page 12
5IN2931 B
For additional information see the LightSYS Plus User Manual, available on our website:
www.riscogroup.com
© RISCO Group 2022. All rights reserved.
