2 LightSYS Quick Installer Guide
A
B
A
B


LightSYS Quick Installer Guide 3




C
C


4 LightSYS Quick Installer Guide
Table of Contents
Introduction .........................................................................................................................5
Selecting Mounting Location..............................................................................................5
Installing Hardware .............................................................................................................5
Main Unit —BUS Connection........................................................................................ 5
1. Setting Bus Accessory ID Numbers.....................................................................6
2. Zone Inputs Connection......................................................................................7
3. Wiring Auxiliary Devices......................................................................................8
4. Wiring Internal Bell..............................................................................................8
5. Wiring Bell Tamper .............................................................................................8
6. Wiring Utility Output 1 to Activate Self-Power Devices ........................................8
7. Main Unit DIP Switch settings .............................................................................9
Connecting BUS Detectors............................................................................................ 9
GSM Communication Module.......................................................................................10
IP Communication Module ...........................................................................................11
Programming.....................................................................................................................11
Keys Menu Navigation..................................................................................................11
Programming Menu Concept........................................................................................12
Access Installer Programming Menu...........................................................................12
1. First Time Power Up .......................................................................................12
2. Enter Installer Programming Mode ...............................................................12
Identifying the Connected Devices..............................................................................12
1. Automatic Setting ...........................................................................................12
2. Bus Test ...........................................................................................................13
Zones Attributes............................................................................................................13
Wireless Zones..............................................................................................................14
Step 1: Allocate a Wireless receiver ......................................................................14
Step 2: Calibrate the Receiver ...............................................................................14
Step 3: Allocating Wireless Zones .........................................................................15
Bus Detectors................................................................................................................15
1. Programming bus detectors on the main bus .............................................15
2. Programming Bus Detectors on a Bus Expander .........................................16
Communication Method................................................................................................17
Report to Monitoring Station........................................................................................17
Follow Me Destinations ................................................................................................17
General Settings............................................................................................................18
1. Main System Timers .......................................................................................18
2. Set Up Users ....................................................................................................18
Keyfobs..........................................................................................................................18
Exiting Programming Mode..........................................................................................19
User Definitions and System Operation...........................................................................20
Testing the system............................................................................................................20
Technical Specifications................................................................................................... 21

LightSYS Quick Installer Guide 5
Introduction
Thank you for purchasing the LightSYS hybrid security system from RISCO Group. This simple
setup procedure guide covers all common LightSYS installation and programming steps (based on
factory default settings) required in order to set up a working system. For more comprehensive
instructions, refer to the LightSYS Installation and Programming Manual (5IN1482)
Selecting Mounting Location
Decide where to position your LightSYS control panel. A central location is often the best place,
making wiring to expanders and accessories easier. It is advisable to prepare a plan of
expander/accessory physical locations in advance of the installation, as this will determine which
type of expander is required at each location.
The control panel location should:
Be in a dry place near an AC power supply
Have access to the routing of cables for the system from detection devices
Have /IP network
(In case you installed GSM / GPRS module before mounting the system into the desired
position) Ensure a good signal of the GSM network (Advisable to have a level of at least 4 out
of 5).
Installing Hardware
Main Unit —BUS Connection
The set of four terminals on the left of the terminal block represent the expansion bus. These
terminals support the connection of keypads and expansion modules. The connections are terminal-
to-terminal with color-coded wires, as follows:
AUX RED: +12V DC power
BUS YEL: Yellow data
COM BLK: 0V common
BUS GRN: Green data
Connect any/all keypads and expanders/accessories necessary for the installation using the bus
connections.

6 LightSYS Quick Installer Guide
Notes:
1. The parallel wiring system supports parallel connections from any point along the wiring.
2. The maximum wire run permitted is 300 meters (1000 feet) for all legs of the bus.
3. In case of bus communication problems, connect two 2.2Kdata
bus terminals, between the green and yellow wires.
4. If connecting remote power supplies, do NOT connect the Red wire (+12v) between the Power
Supply Unit and LightSYS.
5. For long cable runs, please use the correct cable as stated on Appendix A of the Installation Manual.
1. Setting Bus Accessory ID Numbers
For most devices, a DIP switch number must be set to identify its ID category number.
has sequential identification numbers
which are set by the DIP switches. 
setting the dipswitches as follows:
ID
DIP switches
ID
DIP switches
1
2
3
4
5
1
2
3
4
5
01
OFF
OFF
OFF
OFF
OFF
17
OFF
OFF
OFF
OFF
ON
02
ON
OFF
OFF
OFF
OFF
18
ON
OFF
OFF
OFF
ON
03
OFF
ON
OFF
OFF
OFF
19
OFF
ON
OFF
OFF
ON
04
ON
ON
OFF
OFF
OFF
20
ON
ON
OFF
OFF
ON
05
OFF
OFF
ON
OFF
OFF
21
OFF
OFF
ON
OFF
ON
06
ON
OFF
ON
OFF
OFF
22
ON
OFF
ON
OFF
ON
07
OFF
ON
ON
OFF
OFF
23
OFF
ON
ON
OFF
ON
08
ON
ON
ON
OFF
OFF
24
ON
ON
ON
OFF
ON
09
OFF
OFF
OFF
ON
OFF
25
OFF
OFF
OFF
ON
ON
10
ON
OFF
OFF
ON
OFF
26
ON
OFF
OFF
ON
ON
11
OFF
ON
OFF
ON
OFF
27
OFF
ON
OFF
ON
ON
12
ON
ON
OFF
ON
OFF
28
ON
ON
OFF
ON
ON
13
OFF
OFF
ON
ON
OFF
29
OFF
OFF
ON
ON
ON
14
ON
OFF
ON
ON
OFF
30
ON
OFF
ON
ON
ON
15
OFF
ON
ON
ON
OFF
31
OFF
ON
ON
ON
ON
16
ON
ON
ON
ON
OFF
32
ON
ON
ON
ON
ON
Notes:
Most accessories have four DIP switches, while bus detectors have five DIP switches
IDs 932 are only available for bus detectors.
If a DIP switch is changed on any device, it is necessary to shut down the device’s power and
then re-power it.
The first module in each category is defined as ID= 1.
Families that have sequential ID numbers are:
Keypads (LCD, LCD with proximity and wireless keypad)
Zone Expanders (8 zones expander, bus zone expander)
Outputs (4 relay output expander, 8 open collector output expander, 2 relay output expander
on 3A power supply, 2 relay output expander on Wireless zone expander, X-10 Outputs)
Power Supplies (3A switching mode power supply)
Bus Zones
WL Zone Expanders

LightSYS Quick Installer Guide 7
Notes:
1. The main unit can support a maximum load of 1.4 Amp. If more current is required install
additional power supply modules (3 Amp max.).
2. On 3 AMP supervised power supplies and on the wireless expander, there are two
These
outputs have dedicated DIP switches that identify the OUTPUT ID.
Maximum number of devices possible:
Total
Wired / BUS Expanders
3
BUS Zones
32
WL Zone Expanders
2
BUS Zones Expanders
4
Outputs Expanders
4
Keypads
4
3A Power Supply
4
BUS Sirens (ProSound / Lumin8)
4
2. Zone Inputs Connection
The following diagrams illustrate the various possible zone connections to the main unit or to
the 8 wired zones expander.
END OF LINE ZONE
(N.O CONTACT)
zone com
ALARM
2.2 K
DETECTOR
NORMALLY OPEN ZONE
CONFIGURATION
ALARM
zone com
DETECTOR
NORMALLY CLOSED
ZONE CONFIGURATION
ALARM
zone com
DETECTOR
END OF LINE ZONE
(N.C CONTACT)
2.2 K
zone com
ALARM
DETECTOR
DOUBLE END OF LINE
ZONE CONFIGURATION
com
2.2 K
ALARM TAMPER
zone
2.2 K
DETECTOR
Notes:
1. For a zone with a tamper switch, you can use a double end-of-line resistor to save additional main
panel connections.
2. It is recommended that you use an end-of-line resistor at the far end of each hardwired zone (16 x
2.2K resistors are supplied).
3. In the LightSYS you have the ability to define separately the end-of-line resistance of the zones on
the main unit and of the wired zones for each eight-unit expander block (Quick key ).
Selection is done by the software with the following available options:
ID EOL DEOL ID EOL DEOL
0 Customized 7 4.7K 4.7k
1 2.2K 2.2K (Default) 8 3.3K 4.7K
2 4.7K 6.8K 9 1K 1K
3 6.8K 2.2K 10 3.3K 3.3K
4 10K 10K 11 5.6K 5.6K
5 3.74K 6.98K 12 2.2K 1.1K
6 2.7K 2.7K 13 2.2K 4.7K

8 LightSYS Quick Installer Guide
3. Wiring Auxiliary Devices
Use the Auxiliary Power AUX (+) COM (-) terminals to power PIRs, glass-break detectors (4-wire
types), smoke detectors, audio switches, photoelectric systems and/or any device that requires a 12V
DC power supply.
The total power from the AUX terminals should not exceed 800mA.
Note:
If the auxiliary outputs are overloaded (exceed 800mA) and are shut down, you must disconnect all
loads from the outputs for a period of at least 10 seconds before you reconnect any load to the
auxiliary outputs.
4. Wiring Internal Bell
The Bell/LS terminal provides power to the internal siren. When connecting an internal sounding
device, pay attention to the polarity.
It is important to position the BELL/LS Dip Switch SW1 correctly. The position varies depending on
the type of internal siren.
A maximum of 800mA may be drawn from this terminal.
Note:
To avoid bell loop trouble, if no connections are made to an internal siren, use a 2.2Kresistor in its
place.
5. Wiring Bell Tamper
Connect the bell tamper to the BELL TMP and COM terminals on the main panel using 2.2K
resistors in serial.
Important:
If you DO NOT use the terminal TMP BELL, remember to connect a 2.2K
resistor (Resistor colors: Red, Red, Red) between TMP and COM.
6. Wiring Utility Output 1 to Activate Self-Power Devices
Utility output 1 can be used to activate a self-powered siren or any other self-powered device.
PROSYS MAIN PANEL
BELL
TMP COM
2.2 K EOL
RESISTOR
BELL TAMPER

LightSYS Quick Installer Guide 9
7. Main Unit DIP Switch settings
DIP Switch
SW1
Status
1: Bell
ON: Bell: For bell or electronic siren with a built-in siren driver.
OFF (Default): For loudspeaker without a built-in sound driver.
2: Default
ON: Resets installer, sub-installer and grand master codes to their
default factory values and bypasses main unit front tamper alarm.
OFF (Default): Codes preserve their set values.
3: Not used
4: Back Tamper
Bypass
ON: Back tamper bypass is in effect. Use this setting during
programming and if no back tamper has been connected to PLUG 2.
OFF (Default): No tamper bypass is in effect
Connecting BUS Detectors
Up to 32 addressable bus detectors can be assigned to the LightSYS. Bus detectors can be wired to
the main bus or to a Bus Zone Expander (BZE).
For full installation instructions refer to the instructions supplied with each bus detector.
Connecting BUS Detectors to the Main LightSYS BUS:
1. Set the bus detector ID number (1-32) using the detector's DIP switches.
Note:
For WatchOUT, LuNAR, and WatchIN set the switch that defines the detector operation
mode to bus mode.
2. Wire the bus terminals AUX(RED), COM (BLK), BUS (YEL) and BUS (GRN) to the
LightSYS Bus.
Note:
For maximum operation stability, it is best NOT to exceed a total 300 meters (1000 feet)
of wiring from the bus detector to the LightSYS panel.
Connecting Bus Detectors using a Bus Zone Expander (BZE):
Important Note:
Connecting bus zones to the LightSYS using the bus zone expander can only be done using
Bus Zone Expander version B and later, PN RP128EZB000B.
1. Set the BZE ID number (1-3) using the DIP switches SW1 1-3.
2. Set the BZE SW2-3 to ON position.
3. Wire the BZE terminals marked as TO PANEL to the LightSYS Bus.
4. Set the bus detector ID number (1-32) using the detector's DIP switches.
Note:
Do not repeat the same ID twice on the same BZE.
5. Wire each detector's bus terminals to the relevant BZE's terminals marked as TO
DEVICE.(see figure below)

10 LightSYS Quick Installer Guide
Note:
For maximum operation stability, it is best NOT to exceed a total of:
300 meters (1000 feet) of wiring from the BZE to the LightSYS panel.
300 meters (1000 feet) of wiring from the BZE to the last bus detector.
GSM Communication Module
The GSM Module provides voice and data communication on the LightSYS over the cellular
network
1. Power down the LightSYS.
2. Plug in the GSM module to the LightSYS main board.
3. Insert the dedicated SIM card and, if required, enter the enabling PIN code or disable the
SIM PIN Code in advance by placing it in a cell phone and disabling the code.
4. Attach the antenna plate and slide it into its right-wall housing. (See figure , page 3)
5. Power up the LightSYS. The green LED should flash for thirty seconds, indicating the
network signal strength, and then steadily stay lit.
6. Perform manual setting for the GSM module. From the main installer programming menu
select [ ]. Select Type GSM and press to confirm.
Note:
To establish GPRS communication set up the APN (Access Point Name) and Email
according to the details instructed by the cellular provider. (Quick programming key
)

LightSYS Quick Installer Guide 11
IP Communication Module
The IP module provides data communication on the LightSYS over the TCP/IP network.
1. Power down the LightSYS.
2. Plug in the IP module to the LightSYS main board.
3. Connect the incoming LAN cable in order to enable IP Communication. Make sure that the
cable is connected to the network.
4. Power up the LightSYS and refer to the Programming IP section.
5. Perform manual setting for the IP module. From the main installer programming menu
select [ ]. Select Type IPC and press to confirm.
Note:
For IP communication set to dynamic IP (Quick programming key  )
Programming
Keys Menu Navigation
This manual explains how to program the LightSYS from the keypad. The following table describes
the uses of the keypad keys during programming:

1. To enter numeric values where required.
2. For quick key programming. Press the number keys to access a
programming option.
3. To edit labels and names.
To go back (up) .
Enter / Save (to move into the displayed menu or to save the data
that you have changed).
or
Used to scroll through the menu listing.
Used to NY-
versa.
Used to increase or decrease selected screen digital values.
If you do not know where you are in the menu structure, press repeatedly to return to the
main menu.
Entering Text Descriptions (Labels):
Key 
= 1,'?!"–()@/:_+&*#
Key 
= 2abcABC
Key = 8tuvTUV
Key 
= 3defDEF
Key =
9wxyzWXYZ
Key 
= 4ghiGHI
Key =0
Key 
= 5jklJKL
Key 
= 6mnoMNO
Key 
= 7pqrsPQRS
Key
= Move cursor left

12 LightSYS Quick Installer Guide
Key
= Move cursor right
Key
= Save
Programming Menu Concept
The LightSYS programming menu is a dynamic menu that adjusts itself to the system hardwired
devices. For example, in order to see menu option regarding wireless zones or keyfobs, first you
must add a wireless expander to the system.
Access Installer Programming Menu
1. First Time Power Up
1. Disconnect all power from the main panel
2. Set SW1 2 (Default) to ON position.
3. Set SW1 4 (Bypass Tamper) to ON position.
4. Connect power to the assembled mounted unit.
5. Press the key.
6. Select language. Scroll through the options and press .
Note:
Changing the language can be done also in regular operation mode by pressing +
simultaneously
7. Enter the Installer code (default: ) and press .
8. Correct the time and date and confirm by pressing .
9. The system automatically enters the automatic accessories settings process option.
10.Move to the section "Identifying the connected devices" as described below.
2. Enter Installer Programming Mode
1. From the main display press .
2. Enter the Installer code (default: ) and press .
3. Select [1] Programming and press .
4. You are now in Installer Programming mode. Move to the section "Identifying the
connected devices" described below
Identifying the Connected Devices
1. Automatic Setting
Note:

LightSYS Quick Installer Guide 13
By default, when entering Installer mode with the default DIP Switch 2 in ON position , the
system will take you immediately to Auto Settings. If the keypad is already showing BUS
SCANNING, skip to step 2 below.
1. Enter the programming key sequence  (Install, BUS Devices, Automatic).
2. Press to begin the automatic BUS SCANNING (the Auto Settings process) in which it
identifies all the devices on the bus.
3. Verify that the keypad displays all the devices you have connected. If a device does not
appear, ensure that 
4. Press to accept what is being displayed, to progress through configuration screens
and to advance on to the next device found.
5. Repeat steps 3 and 4 until the presence of all devices has been confirmed and all
parameters configured.
Note:
1. When adding a zone expander you should define the zones expander resistance
compatibility, depending on the detectors you intend to connect to the expander. By
default the resistance is set to 2.2K for EOL and DEOL termination.
2. When adding a wireless expander, dBypass Box Tampereless
expander is mounted inside the LightSYS housing and not in its own.
2. Bus Test
The bus test (Quick key ) sends multiple test commands to each device connected to the
system to ensure reliable connectivity.
Press to begin the automatic BUS TEST in which every device is tested to report if
connections are 99% or higher.
Note:
If a low reading is experienced, check connections with the device and repeat the bus test.
Zones Attributes
The LightSYS supports up to 32 zones. Each zone can be defined to be a wired zone, a wireless
zones or a bus 
or type of bus zone).
You can define the basic parameters fOne By One
all attributes using the zones category (Quick key ).
1. From the main Installer Programming menu select  (Zones, Parameters)
2. Select [One By One] and press .
3. Using the numeric keys, enter the desired zone number and press .
Important
The display next to the selected zone number defines the type of zone and its location in the
system in the format XY:ZZ
X: Zone physical type (E=Wired zone, W=Wireless zone, B=Bus zone, I=Input zone)
bus, for example:
E0:04 refer to wired zone 04 on the main board.
B0:15 refers to BUS zone 15 on the main BUS.

14 LightSYS Quick Installer Guide
ZZ The serial zone number in the system (01-32)
4. Set the zones parameters as follows:
Labels: Zone description text to give it a meaningful name. Use the numeric keys as
 (see page 11)
Partitions: Using the numeric keys, select or deselect the relevant partitions to which
this zone will belong to and using the , , or , keys, select the
partition groups. To confirm press .
Zone Type: Using the Up/Down keys, select the required zone type and press .
Zone Sound: Select the required zone sound while the system is armed in Away,
Armed at Stay or Disarmed.
Note:


when the zone is opened/causes an alarm condition.
keypad(s).
Zone Termination (Only applicable for hard-wired zones). Using the Up/Down keys,
select the required zone termination type (NO,NC, EOL, DEOL) and press .
Zone Response: Using the Up/Down keys, select the required response time and press
.
Advanced: Includes advanced attributes for a zone such as supervision for wireless
zones, bus zone parameters, forced arming and more. .
Wireless Zones
Each of the 32 zones in the LightSYS can be defined as a wireless zone.
Step 1: Allocate a Wireless receiver
1. From the Installer menu, select  (Install, Bus Device, Manual,
WL Expander)
2. Set the receiver ID (1 or 2) and using , set the type to WL and press .
3. If the receiver is mounted inside the LightSYS box select Yto bypass the box tamper. Press
and move to step 2.
Step 2: Calibrate the Receiver
For successful communication, strength of the signal should be higher than the noise threshold level,
measured in a process termed calibration.
1. From the Installer menu, select  (Install, WL Device, RX Calibration)
2. Select the wireless receiver and press .
3. Using the key, choose [Y]-
to confirm.
Explanation:
The c


LightSYS Quick Installer Guide 15
devices of another system or other devices operating on the same frequency nearby. These are
Light
The threshold (set above) is the absolute minimum signal strength needed to be heard from a
wireless device in order for the receiver to ef
Step 3: Allocating Wireless Zones


unique serial code into the system. Enrollment can be done locally using the keypad or remotely
using the configuration software. The following steps describe quick enrollment by RF signal using a
keypad.
1. From the Installer menu, select  (Install, WL Device, Allocation)
2. Select 1) By RF and press .
3. Select the receiver to be used for the registration mode.
4. Select 1) Zone category and press .
5. Using the numeric keys, enter the desired zone number and press
6. The WL Receiver is in learn mode. Send a write message from your wireless zone as
shown in the table below:
Wireless Device
Sending Write Message
Detector/Contacts/Flood/Shock
Press and hold the tamper switch for 3 seconds.
Smoke Detector
Insert battery. Write message is sent automatically
within 10 seconds.
Gas, CO detectors
Press and hold the test button for 3 seconds.
2 Panic Button Key fob
Press and hold both buttons for at least 7 seconds.
7. Using the arrow keys, select [SUPERVISED] or [NONE SUPERVISED] for the wireless
zone and press .
8. Repeat steps 3 to 6 until all required wireless zones have been enrolled.
9. Continue entering the wireless zones attributes section.(see page 13)
Bus Detectors
The following section describes the flow of adding bus detectors to the LightSYS. Bus detectors can
be programmed to the main unit or to a bus zone expander.
1. Programming bus detectors on the main bus
Step 1: Adding Bus Detector to the Main Unit
Note:
If you have already performed Auto Settings, skip to Step 2 below: Assign Bus Detectors to a
Zone ID and set basic parameters.
1. From the main installer menu press  to access the bus Zone category.
2. Press to move the cursor to the ID field.
3. Type the bus detector ID number as set by the detector's DIP switches (01-32)

16 LightSYS Quick Installer Guide
Note:
The display "(x:yy) Type: None" represent the BUS detector location in the system. In the
0:yy designation, the 0 denotes that the bus detector is on the main unit and is not
assigned to a bus zone expander. The yy represents the bus detector ID number (up to
32) as set by the detector's DIP switches.
4. Using the arrow keys move to the Type field. Use the key to select the detector's
type.
5. Repeat steps 2 - 4 for other bus detectors.
Step 2: Set Bus Zone Basic Attributes
Refer to section Programming Zones Attributes to define the zone parameters. (see page 13)
Step 3: Programming the Bus Detectors Advanced Parameters
1. From the main Installer menu select [2] Zones > [1] Parameters > [2] By Category > [7]
Advanced > [4] BZ Parameters .
2. Select the zone number that the bus zone was assigned to and press .
3. Configure the parameters for the relevant bus detector.
2. Programming Bus Detectors on a Bus Expander
Using bus expanders you can create a separate bus loop that is used only for the bus
detectors connected to it. The separate bus loop increases the total system security in case a
certain bus detector is sabotaged. Up to four bus expanders can be added to the LightSYS
Step 1: Adding the Bus Expander to LightSYS
Note:
If you already performed Auto Settings skip to Step 2 below: Assign Bus Detectors to a Zone ID
and set basic parameters.
1. From the main installer menu press  to enter the Bus Expander menu.
2. Using the arrow and numeric keys select a bus zone expander ID.
3. Using the arrow keys move to TYPE. Use the key to select a BZE32 and press
.
Step 2: Adding Bus Detector
Refer to section Step 1: Adding Bus Detector to the Main Unit to assign a bus detector to the
system.
Note
When the bus zone is connected to a BUS expander, you should define the Xin the (x:yy)
display as the BUS expander ID (1,2,3 or 4). The yy represents the bus detector ID number
(up to 32) as set by the detector's DIP switches.
Step 3: Set Bus Zone Basic Attributes
Refer to section Programming Zones Attributes to define the zone parameters.
Note:
In the zone designation XY:ZZ the X represent the Bus Expander ID as set by its dip switches.

LightSYS Quick Installer Guide 17
Step 4: Programming the Bus Detectors Advanced Parameters
1. From the main Installer menu select [2] Zones > [1] Parameters > [2] By Category > [7]
Advanced > [4] BZ Parameters .
2. Select the zone number that the bus zone was assigned to and press .
3. Configure the parameters for the relevant bus detector.
Communication Method
1. From the main installer programming menu select 5) Communication menu and select 1)
Method.
2. Select each method (PSTN, IP and/or GSM) and define its parameters.
Note:
1. -board
2. To establish GPRS communication set up the APN (Access Point Name) and Email
according to the details instructed by the cellular provider.
3. For IP communication set to dynamic IP (Quick key )
Report to Monitoring Station
You can define up to three MS accounts and several associated parameters that define the nature of
communication, event reporting and confirmation between the system and the MS.
1. From the main installer programming menu select 5) Communication menu and select 2) MS.
2. Select the 1) Report type (Voice, SMS, IP/GPRS) for each MS and define its parameters.
3. Select 2) Account number and define an account number for each MS.
4. Select 3) Comm format to define the transmission format, SIA or Contact ID.
5. Go through the menus to program any other parameters for the communication with the
monitoring station.
Follow Me Destinations
Now that you have set up the methods for LightSYS to communicate with the MS and the owner,
you can define the destinations to which event notifications will be sent. Up to 16 follow me
destinations can be defined in the system.
1. From the main installer programming menu select 5) Communication menu and select 4)
Follow Me.
2. Under 1) Define FM 
Report Type (SMS, Email, Voice)
Partitions: Specify the partitions that will initiate the Follow Me report due to a certain
event that occurred in the assigned partitions
The events that will be sent, organized by category (Alarms, Arm/Disarm, Troubles,
GSM, Environmental, Miscellaneous)
The restore events that will be sent
The operations the user will be able to perform through remote connection via phone or
SMS
Note:
The actual destinations (telephone numbers, email addresses) are not defined within the
Programming menu.

18 LightSYS Quick Installer Guide
General Settings
There are several system-wide parameters that define how the LightSYS works. All these
parameters are set with default values that apply for most installations. If you wish to modify the
default settings, go through the menus to program any other system parameter.
1. Main System Timers
1. From the main installer programming menu select 1) System 1)Timers
2. Select options 01 and 02 to define exit entry times.
3. Select option 03 to define siren duration time.
4. Scroll through the other options of the menu.
2. Set Up Users
r) will be allowed to
subsequently set their code.
1. From the main installer programming menu select 4) Codes.
2. Under the 1) User option define for each user its authority level and the partitions it can
control with his code.
3. Change the default installer code under the option 3) Installer.
Keyfobs
Each keyfob can be set up to perform different system operations. Each user can be assigned with
a single keyfob.
Step 1: Allocating Keyfobs
After the WL receiver is allocated and calibrated as described in Wireless Zones section (page
14), perform the following steps:
1. From the Installer menu, select  (Install, WL Device, Allocation)
2. Select 1) By RF and press .
3. If two receivers are allocated in the system select the receiver to be used for the
registration mode.
4. Select 2) Keyfobs category and press .
5. Select the user that the keyfob should belong to and press .
6. Press thebutton on the keyfob for at least 2 seconds, until a confirmation beep is
heard.
7. Repeat the above steps to assign additional keyfobs.

LightSYS Quick Installer Guide 19
Step 2: Setting Keyfobs Parameters
1. From the installer menu select 8) Devices > 2) Keyfob.
2. Select the user that the keyfob belongs to and press .
3. Use the arrow keys to scroll between menus and the key to select menu options:
.
.
.
.
Note:
The label and partition of a key fob are the ones defined for a user.
Exiting Programming Mode
1. Set SW1 2 (Default) to OFF position.
2. Close the main box in order to prevent Front Tamper Alarm.
3. 
4. Press > to Exit and SAVE your settings.
Note:
The system will not allow exit from the 
condition exists. Correct any tamper and/or system fault conditions before attempting to exit
the Installer mode.

20 LightSYS Quick Installer Guide
User Definitions and System Operation
1. Instruct the user to define the actual user codes. Advise the user to change the default Grand
Master code. Help the user enroll proximity tags.
2. Instruct the user on defining and editing the Follow Me destinations.
3. Instruct the user on the following operations, performed from the keypad or keyfobs:
Away (Full) Arm
Stay (Home) Arm
Disarm
Disarm under duress
Send a panic event
Check the system status
Operate a utility output
Use the voice menu for remote operation
Use SMS for remote operation
Testing the system
Before leaving the site, it is important to fully test the system. LightSYS has several testing tools that
help you feel confident the system will operate optimally, including relieving any concerns you may
have about the wireless communication.
From the Installer menu, go through the tests under the 2) Testing menu:
Main Unit noise level, buzzer, speaker and battery.
You can test each device for communication and perform a battery test.
For zones you can perform a Walk Test 
from each detector, (User Menu > Maintenance > Walk test).
GSM signal strength.
Perform a test to ensure follow me is working (User Menu > Follow Me > Test FM).
The system is now programmed and ready for use.
For more comprehensive and detailed instructions, please refer to the LightSYS Installation and
Programming Manual (5IN1482).
For User Functions, please refer to the LightSYS User Manual (5IN1427).
