ASSEMBLY INSTRUCTIONS
RiverRidge® Ashland Tall Cabinet
ITEM#: 06-082 White
ITEM#: 06-083 Gray
ITEM#: 06-124 Espresso
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

THIS CABINET WILL HOLD UP TO 20 POUNDS PER SHELF AND 10 POUNDS PER DRAWER
OR A TOTAL OF 130 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS
OR THE DRAWER WITH MORE THAN 10 POUNDS. OVERLOADING THE CABINET MAY
CAUSE DAMAGE TO THE CABINET OR CAUSE SERIOUS INJURY OR DEATH.

PARTS LIST
NO
QTY
DESCRIPTION
1
1PC
Top Board
2
1PC
Lower Left Side Panel
3
1PC
Lower Right Side Panel
4
1PC
Lower Back Panel
5
1PC
Upper Cross Bar
6
1PC
Adjustable Shelf
7
1PC
Bottom Board
8
1PC
Decorative Panel
9
1PC
Door
10
1PC
Drawer Back Board
11
2PCS
Drawer Side Panel
12
1PC
Drawer Bottom Board
13
1PC
Drawer Front Board
14
1PC
Upper Left Side Panel
15
1PC
Upper Right Side Panel
16
2PCS
Fixed Shelf
17
1PC
Upper Back Panel
18
1PC
Middle Connection Board

NO
PARTS
QTY
DESCRIPTION
A
18PCS
Cam Bolt
B
18PCS
Cam Lock
C
26PCS
Wood Dowel
D
14PCS
Screw (3x10mm)
E
2PCS
Drawer Holder
F
8PCS
Screw (3.5x25mm)
G
24PCS
Screw (2.5x12mm)
H
2PCS
Drawer Plastic Stopper
I
2PCS
Metal Hinge
J
1PC
Knob
K
1PC
Machine Screw (4x18mm)
L
1PC
Magnet Plate
M
1PC
Magnet
N
2PCS
Screw (3x14mm)
O
4PCS
Shelf Holder
P
1PC
Adjustable Anchor Bracket
Q
1PC
Screw (4x10mm)
R
1PC
Plastic Anchor
S
1PC
Screw (4x30mm)
U
4PCS
Screw (4x40mm)
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
To order replacement parts at no cost to you, email [e-mail], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.

STEP 1
1. Screw 2 cam bolts (A) in cam bolt holes on upper left side panel (14).
2. Screw 2 cam bolts (A) in cam bolt holes on upper right side panel (15).
STEP 2
1. Insert 8 wood dowels (C) into wood dowel holes on upper left side panel (14) and upper
right side panel (15).
2. Attach upper right side panel (15) to fixed shelf (16) by inserting cam bolts (A) into cam lock
holes on end of open shelf (16) and inserting wood dowels (C) into wood dowel holes on
fixed shelf (16).
3. Insert 2 cam locks (B) into cam lock holes on end of fixed shelf (16), rotate clockwise to
secure cam bolts (A) in place.
4. Repeat above steps to assemble upper left side panel (14) to fixed shelf (16).

STEP 3
1. Insert 1 screw (Q) through hole on adjustable anchor bracket (P), then tighten to top board (1).
2. Screw 4 cam bolts (A) into cam bolt holes on top board (1).
3. Insert 4 wood dowels (C) into wood dowel holes on top board (1).
4. Attach top board (1) to upper left side panel (14) and upper right side panel (15) by
inserting cam bolts (A) into cam lock holes and inserting wood dowels (C) into wood dowel
holes on end of upper left side panel (14) and upper right side panel (15).
5. Insert 4 cam locks (B) into cam lock holes on upper left side panel (14) and upper right
side panel (15), rotate clockwise to secure cam bolts (A) in place.
STEP 4
1. Screw 4 cam bolts (A) into cam bolt holes on middle connection board (18).
2. Attach middle connection board (18) to upper left side panel (14) and upper right side
panel (15) by inserting 4 screws (U) through holes on middle connection board (18) and
tighten to upper left side panel (14) and upper right side panel (15).

STEP 5
1. Screw 3 cam bolts (A) into cam bolt holes on lower left side panel (2).
2. Attach drawer holder (E) to lower left side panel (2) by inserting 2 screws (D) through holes
on drawer holder (E) then tighten to lower left side panel (2).
3. Attach magnet (M) to lower left side panel (2) by inserting 2 screws (N) through holes on
magnet (M), then tighten to lower left side panel (2).
4. Screw 3 cam bolts (A) into cam bolt holes on lower right side panel (3).
5. Attach drawer holder (E) to lower right side panel (3) by inserting 2 screws (D) through
holes on the drawer holder (E) then tighten to lower right side panel (3).
STEP 6
1. Insert 10 wood dowels (C) into wood dowel holes on lower left and right side panels (2)
and (3).
2. Attach lower left side panel (2) to upper cross bar (5), bottom board (7) and decorative
panel (8) by inserting cam bolts (A) into cam lock holes and inserting wood dowels (C) into
wood dowel holes on end of upper cross bar (5), bottom board (7) and decorative panel (8).
3. Insert 3 cam locks (B) into cam lock holes on upper cross bar (5) and bottom board (7),
rotate clockwise to secure the cam bolts (A) in place.
4. Repeat above steps to assemble lower right side panel (3) to upper cross bar (5), bottom
board (7) and decorative panel (8).

STEP 7
1. Insert 4 wood dowels (C) into wood dowel holes on middle connection board (18).
2. Attach upper pre-assembled unit to lower pre-assembled unit by inserting wood dowels (C)
into wood dowel holes and inserting cam bolts (A) into cam lock holes on end of lower side
panels (2) and (3).
3. Insert 4 cam locks (B) into cam lock holes on lower side panels (2) and (3), rotate clockwise
to secure cam bolts (A) in place.
STEP 8
1. Attach upper back panel (17) and lower back panel (4) to back of cabinet by inserting 24
screws (G) through holes on upper back panel (17) and lower back panel (4) then tighten
to back of cabinet.

STEP 9
1. Attach 1 drawer side panel (11) to drawer back board (10) by inserting 2 screws (F) through
holes on drawer side panel (11), then tighten to drawer back board (10).
2. Repeat above step to assemble another drawer side panel (11) to drawer back board (10).
3. Slide drawer bottom board (12) into grooves on both drawer side panels (11).
4. Attach drawer front board (13) to drawer side panels (11) and drawer bottom board (12) by
inserting drawer bottom board (12) into groove on drawer front board (13), then inserting 4
screws (F) through holes on drawer side panels (11) and tighten to drawer front board (13).
5. Slide drawer into pre-assembled drawer holders.
6. Insert 2 drawer plastic stoppers (H) to prevent drawer from pulling out.

STEP 10
1. Attach magnet plate (L) to door (9) by inserting 2 screws (D) through holes on magnet plate
(L), then tighten to door (9).
2. Attach 2 metal hinges (I) to door (9) by inserting 4 screws (D) through holes on metal
hinges (I), then tighten to door (9).
3. Attach knob (J) to door (9) by inserting 1 machine screw (K) through hole on door (9), then
tighten to knob (J).
4. Attach metal hinges (I) to lower right side panel (3) by inserting 4 screws (D) through holes
on metal hinges (I), then tighten to lower right side panel (3).
5. Insert 4 shelf holders (O) into holes on lower left side panel (2) and lower right side panel
(3) at desired shelf height.
6. Place adjustable shelf (6) onto shelf holders (O).

STEP 11
Option #1: Securing to Drywall
1. Position cabinet against wall in desired location. Using a pencil, make small mark on wall
through hole on bracket (P). Move cabinet away from wall and screw 1 plastic anchor (R) into
wall on pencil mark.
2. Place cabinet against wall, insert 1 screw (S) through hole on brackets (P), then tighten to
plastic anchor (R).
Option #2: Securing to Drywall and Wood Stud
1. Position cabinet against wall in desired location. Insert 1 screw (S) through hole on bracket (P),
then tighten through drywall and into wood stud.
*Tip: Anchor bracket (P) can be adjusted to correct distance from wall to cabinet as needed. Once adjusted,
be sure to re-tighten bracket inside cabinet for stability.

ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure your item is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

Enjoy your new RiverRidge® Cabinet!
Thank you for purchasing this RiverRidge® Home item. We hope you
enjoy it and consider purchasing other RiverRidge® items.
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
