RiverRidge 02-022 User manual

RiverRidge®Horizontal Bookcase
ITEM #: 02-022 White
ITEM #: 02-028 Espresso
ITEM #: 02-148 Gray
ASSEMBLY INSTRUCTIONS
ADULT ASSEMBLY REQUIRED
WARNING
SEE FULL WARNING ON PAGE 2
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
Young children can be seriously injured or killed if furniture tips over.
Don’t use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS.
DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS OR 75 POUNDS TOTAL WEIGHT.
IF OVERLOADED WITH MORE THAN 25 POUNDS PER SHELF OR 75 POUNDS TOTAL WEIGHT,
SHELF MAY TIP FROM THE WALL AND CAUSE SERIOUS INJURY OR DEATH.
This product is suitable for children 3 years and older.

1
6
5
7
8
3
2
4
PARTS LIST
NO QTY DESCRIPTION
1 1PC Top Board
2 1PC Left Side Panel
3 1PC Right Side Panel
4 1PC Bottom Board
5 1PC Shelf
6 1PC Upper Back Panel
7 1PC Bottom Trim
8 1PC Lower Back Panel

TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER(NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
PARTS LIST
NO QTYPARTS DESCRIPTION
A9PCS
Cam Bolt
B12PCS
Cam Lock
C12PCS
Wood Dowel
D
1PC
F
G
H
J
26PCS
1PC
1PC
1PC
Screw (2.5x14mm)
Plastic Anchor
Screw (4x30mm)
Adjustable Anchor Bracket
Screw (4x10mm)

STEP 1
STEP 2
1. Screw 4 cam bolts (B) into cam bolt holes on left side panel (2) and tighten.
2. Screw 4 cam bolts (B) into cam bolt holes on right side panel (3) and tighten.
1. Insert 1 screw (J) through hole on adjustable anchor bracket (F), then tighten to top board (1).
2. Screw 4 cam bolts (B) into cam bolt holes on top board (1) and tighten.
3. Insert 3 wood dowels (A) into bottom board (4).
4. Attach bottom trim (7) to bottom board (4) by inserting dowels into dowel holes on bottom
trim (7).
B
B
B
BB
BB
B
2
3
1
7
4
B
B
B
B
A
A
A
J
F

STEP 3
STEP 4
A
C
C
C
C
C
C C
A
C
1. Insert 1 wood dowel (A) into dowel hole on bottom of right side panel (3).
2. Attach shelf (5) to right side panel (3) by inserting 2 cam bolts into cam lock holes on shelf (5).
3. Insert 2 cam locks (C) into cam lock holes on shelf (5) and rotate clockwise to secure
cam bolts.
4. Attach bottom board (4) to right side panel (3) by inserting 2 cam bolts into cam lock holes
on bottom board (4) and inserting wood dowel into dowel on end of bottom trim (7).
5. Insert 2 cam locks (C) into cam lock holes on bottom board (4) and rotate clockwise to
secure cam bolts.
1. Insert 1 wood dowel (A) into dowel hole on bottom of left side panel (2).
2. Attach left side panel (2) to pre-assembled bookcase by inserting cam bolts (B) into cam lock
holes on shelf (5) and bottom board (4) and inserting wood dowel into bottom trim (7).
3. Insert 2 cam locks (C) into cam lock holes on shelf (5) and rotate clockwise to secure
cam bolts.
4. Insert 2 cam locks (C) into cam lock holes on bottom board (4) and rotate clockwise to secure
cam bolts.
5
2
4
57
7
4
3

STEP 5
STEP 6
1. Place pre-assembled bookcase up right and insert 4 wood dowels (A) into dowel holes on top
of left side panel (2) and right side panel (3).
2. Attach top board (1) to bookcase by inserting cam bolts (B) into cam lock holes on both side
panel (2), (3) and inserting wood dowels (A) into top board (1).
3. Insert 2 cam locks(C) into cam lock holes on right side panel (3) and rotate clockwise to
secure cam bolts.
4. Insert 2 cam locks (C) into cam lock holes on left side panel (2) and rotate clockwise to
secure cam bolts.
1. Attach back panels (6), (8) to back of bookcase, insert 26 screws (D) through holes and
tighten to back of bookcase.
AA
A
A
C
C
CC
1
2
3
D×21 D×5
D
6
8
6
8

STEP 7
ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure youritem is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.
G
H
H
H H
G
G
F
DRYWALL
WALL ANCHOR
WITH SCREW
SCREW
ONLY
DRYWALL
OPTION #2OPTION #1
WOOD
STUD
*Tip: Anchor bracket (F) can be adjusted to correct distance from wall to cabinet as needed. Once
adjusted, be sure to re-tighten bracket inside cabinet for stability.
Option #1: Securing to Drywall
1. Position cabinet against wall in desired location. Using a pencil, make a small mark on wall through
hole on bracket (F). Move cabinet away from wall and screw 1 plastic anchor (G) into wall on pencil mark.
2. Place cabinet against wall, insert 1 screw (H) through hole on bracket (F), then tighten to plastic
anchor (G).
Option #2: Securing to Drywall and Wood Stud
1. Position cabinet against wall in desired location. Insert 1 screw (H) through hole on bracket (F), then
tighten through drywall and into wood stud.

Thank you for purchasing this RiverRidge® Home item. We hope you
enjoy it and consider purchasing other RiverRidge® items.
Enjoy your new RiverRidge®Cabinet!
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
