Roger IOS-1 User manual

Roger Access Control System
IOS-1
Input-output simulator
User Manual
Product version v1.0
Document version: Rev. A

IOS-1 input-output simulator Rev.A.doc 2/21/2011
Strona 2z 4
General
IOS-1 module enables simulation of NO/NC input lines as well as visualization of status at output
lines (both relay and transistor types). The module can be used for education, testing or
demonstration in regard of alarm and access control devices. IOS-1 does not require power supply.
Circuit for input simulation and circuit for visualization of output status are independent of each
other.
Operation
General diagram of operation and exemplary application of IOS-1 are shown in figure below.
Z and COM terminals are used for simulation of input line. Input line can be configured by means of
jumpers as NO (Normally Open) or as NC (Normally Close). In case of NO setting, pressing TRIG.
button results in activation of Q1 output transistor and consequently shorting of Z terminal with
GND. In case of NC setting, output transistor is normally activated, Z and COM terminals are shorted
and pressing of TRIG. button results in deactivation of output transistor and consequently
disconnection between Z and GND terminals.
Note: COM terminal must be connected to lower potential than Z terminal. Typically COM terminal at
IOS-1 module is connected to GND or COM terminal of the tested device.
+12V and GND terminals enable visualization of status at output line. Voltage feeding in range of
5..15V between mentioned terminals results in LED lighting up on board. LED activation can be
caused by negative voltage at GND terminal or positive voltage at +12V terminal. Typically, such
solution enables signaling of status for any relay or transistor output line with negative or positive
output voltage.

IOS-1 input-output simulator Rev.A.doc 2/21/2011
Strona 3z 4
Technical Specification
Parameter Characteristics
Environmental class
(according to EN
50131-1)
Class I, indoor conditions, temperature range: +5°C to +40°C, relative
humidity: 0 to 95% (non condensing)
Module dimensions 35 X 43 mm
Module weight ~ 10g
Certificates CE
Product History
Hardware Firmware Date Description
v1.0 - Initial version of the product

IOS-1 input-output simulator Rev.A.doc 2/21/2011
Strona 4z 4
Ordering information
IOS-1 I/O Simulator module (electronic module only)
This symbol placed on a product or packaging indicates that the product should
not be disposed of with other wastes as this may have a negative impact on the
environment and health. The user is obliged to deliver equipment to the
designated collection points of electric and electronic waste. For detailed
information on recycling, contact your local authorities, waste disposal company
or point of purchase. Separate collection and recycling of this type of waste
contributes to the protection of the natural resources and is safe to health and
the environment. Weight of the equipment is specified in the document.
Contact
Roger sp.j.
82-400 Sztum
Gościszewo 59
Tel.: [phone]
Fax: [phone]
Tech. support: [phone]
E-mail: [e-mail]
Web: www.roger.pl
