INSTALLATION AND CARE GUIDE
BRIT TALL SIDE CABINET
E026117

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
1
Designed By: DANELONMERONI | UNITED KINGDOM
Tools Required
PRE-INSTALLATION
2 set of anti-tipping hardware
4 short screws
4 long screws
8 shelf clips
4 anchors
Materials Included

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
2
Designed By: DANELONMERONI | UNITED KINGDOM
Step 1:
Figure 1.
INSTALLING ANTI-TIPPING HARDWARE
Determine the ideal location of your
new side cabinet.
Mark the location of x, y on the wall.
Then use the anti-tipping hardware
base plate (shown on the right) as a
guide to mark the anchor location.
Drill 1/4” anchor holes and screw into
the drywall.
Secure the anchors into the wall, and
then fasten the long screws provided
into the anchor to secure the base
plate.
Secure the matching plate to the
cabinet with the screws provided.
See Figure 1.
Step 2:
Step 3:
Step 4:
Y
Y

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
3
Designed By: DANELONMERONI | UNITED KINGDOM
Figure 2.Slide the zip ties provided
through the loop and secure the
cabinet to the wall.
Note: Some minor adjustments
may be needed to level the side
cabinet to
the floor.
Turn the leg levelers at the
bottom of each leg to ensure the
side cabinet
is level.
Verify with a level.
See Figure 2.
Step 5:
Leveler
Finished Wall
12

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
4
Designed By: DANELONMERONI | UNITED KINGDOM
See Figure 4.
See Figure 3.
Step 1: Unhinge the door by popping o the
hinge from the base of the cabinet.
Figure 3.
Step 2: Unscrew the hinge plate from the base
of the cabinet.
Measure the distances of the existing
screw holes and copy that to the
opposite side.
Figure 4.
Step 3:
Step 4:
Install the hinge plate.
REVERSE DOOR OPENING FOR INVERTED INSTALLATION
Bracket
Hook
Install the door to the base of the
cabinet. Push the hinge until you hear
a click to lock the hinge into place.
Cup

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
5
Designed By: DANELONMERONI | UNITED KINGDOM
See Figure 5.
Step 1: Unhinge the door by popping o the
hinge from the base of the cabinet.
See page 3.
Figure 5.
Step 2: Unscrew the shelf clip from
the under-side.
Remove the glass shelf.
REMOVE GLASS SHELVES

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
6
Designed By: DANELONMERONI | UNITED KINGDOM
Figure 6.
Locate the screw nearest the hinge
cup and rotate clockwise or counter-
clockwise to move the door from side
to side.
Locate the screw furthest away from
the hinge cup and turn the screw
clockwise or counter-clockwise to
move the door from front to back.
Locate the screw pictured in Figure 6.
Turn the screw clockwise or counter-
clockwise to move the door from top
to bottom.
ADJUST DOOR HINGE
Figure 7.
Figure 8.
NOTE: When adjusting the door hinges keep in mind
to adjust the other hinges.
Side to Side
Front to Back
Top to Bottom
See Figure 6.
See Figure 7.
See Figure 8.
Side
Depth
Height

BRIT 71” Tall Side Cabinet
Model : E026117
170710ronbow.eu | ronbow.comINSTALLATION SHEET
7
Designed By: DANELONMERONI | UNITED KINGDOM
Wood Surfaces
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Pledge Orange Oil, or similar
• Orange-Glo Wood Cleaner
DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their
original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may
be significant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,
household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].
