Ronbow Signature series Assembly instructions

INSTALLATION AND CARE GUIDE
VANITY
E010127

170425ronbow.eu | ronbow.comINSTALLATION SHEET
1
Stack 27” Vanity
Model : E010127 Designed By: PHOENIX DESIGN | GERMANY
Tools Required
PRE-INSTALLATION
Materials Included
1 set of stainless steel legs
10 allen screws
1 allen wrench
4 stainless steel leg levelers
Materials Required
3 wood screws
1 2x6 beam cut to size

170425ronbow.eu | ronbow.comINSTALLATION SHEET
2
Stack 27” Vanity
Model : E010127 Designed By: PHOENIX DESIGN | GERMANY
Figure 1.
Step 2: Install each of the stainless steel legs to
the bottom of the vanity by using the
allen screws provided.
Step 3: Verify the vanity is level.
Determine the ideal location of your
new vanity.
Check if the location has at least
two studs for the 2x6 horizontal beam
to sit in place and attach the vanity for
safety purposes.
See Figure 1.
Step 1:
INSTALLATION
Step 4: If adjustments are needed, turn
the levelers counter-clockwise
or clockwise.
Figure 2.
See Figure 2.
Leveler
Step 5: It is highly recommended to attach
the vanity to the wall using wood
screws to prevent vanity from
shifting over time.

170425ronbow.eu | ronbow.comINSTALLATION SHEET
3
Stack 27” Vanity
Model : E010127 Designed By: PHOENIX DESIGN | GERMANY
Figure 3.
Step 2: Place the sinktop on the vanity.
Clean any excess silicone immediately.
Follow the directions on the silicone to
allow for ample drying time.
Step 3: To install the plumbing the drawers
would need to be removed.
Refer to page 4 to remove / re-install
the drawer.
Clean the top surface of the vanity
with a clean damp cloth.
Ensure the surface is completely dry
before applying the silicone.
Apply a thin bead of silicone around
the top surface.
See Figure 3.
Step 1:
INSTALLING THE SINKTOP

170425ronbow.eu | ronbow.comINSTALLATION SHEET
4
Stack 27” Vanity
Model : E010127 Designed By: PHOENIX DESIGN | GERMANY
Figure 4.
Step 2: Slide and lift up the drawer box.
Pull the release latches located
underneath the drawer.
Slide drawer box in until secured by rail
hook.
See Figure 5.
See Figure 4.
See Figure 6.
Step 1:
Step 1:
REMOVE DRAWER
REINSTALL DRAWER
Figure 5.
Figure 6.
Hook
https://youtu.be/4DdK3cj3sTU

170425ronbow.eu | ronbow.comINSTALLATION SHEET
5
Stack 27” Vanity
Model : E010127 Designed By: PHOENIX DESIGN | GERMANY
Wood Surfaces
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Pledge Orange Oil, or similar
• Orange-Glo Wood Cleaner
DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their
original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may
be significant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,
household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].
