Ronbow Signature series Assembly instructions

INSTALLATION AND CARE GUIDE
UNITY VANITY
E042031
E042047

161020ronbow.eu | ronbow.comINSTALLATION SHEET
1
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Tools Required
PRE-INSTALLATION
Materials Included
1 pair of wall brackets
6 hex bolts
6 bolt caps
1 allen wrench
10 hex screws
10 short screws
Materials Required
1 2x6 beam cut to size

161020ronbow.eu | ronbow.comINSTALLATION SHEET
2
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Figure 1.
Figure 2.
Step 2:
Step 5:
Install the wall brackets to the wall and
fasten with the hex bolts.
Place the metal caps over the
bolt heads.
Slide the vanity over the wall brackets
and secure the brackets to the vanity
with short screws.
Step 3:
Step 6:
Step 4:
Step 7:
Cut a rough opening for an electrical
box to hard wire to the house.
It is highly recommended to attach the
vanity to the wall using wood screws
to prevent vanity from shifting
over time.
Remove the drawer.
Refer to page 5.
Re-install the drawer.
Refer to page 5.
Determine the ideal location of your
new vanity.
NOTE: the location needs at least two
studs. Front notch the studs and install
the 2x6 horizontal beam 30-3/4” from
the floor.
See Figure 1.
See Figure 2.
Step 1:
INSTALLATION - WALL MOUNT

161020ronbow.eu | ronbow.comINSTALLATION SHEET
3
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Figure 3.
Step 2: Remove the drawer.
Refer to page 5.
Step 3:
Step 4:
Step 5:
Install the legs to the vanity.
Secure the vanity to the horizontal
beam using wood screws. This will add
extra stability for the vanity.
Re-install the drawer.
Refer to page 5.
Determine the ideal location of your
new vanity.
NOTE: the location needs at least two
studs. Front notch the studs and install
the 2x6 horizontal beam 30-3/4” from
the floor.
See Figure 3.
Step 1:
INSTALLATION - FREE-STANDING

161020ronbow.eu | ronbow.comINSTALLATION SHEET
4
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Figure 4.
Step 2: Place the sinktop on the vanity.
Clean any excess silicone immediately.
Follow the directions on the silicone to
allow for ample drying time.
Step 3: To install the plumbing the drawers
would need to be removed.
Refer to page 5 to remove / re-install
the drawer.
Clean the top surface of the vanity
with a clean damp cloth.
Apply a thin bead of silicone around
the top surface.
See Figure 4.
Step 1:
INSTALLING THE SINKTOP

161020ronbow.eu | ronbow.comINSTALLATION SHEET
5
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Figure 5.
Step 2: Slide and lift up the drawer box.
Pull the release latches located
underneath the drawer.
Slide drawer box in until secured by
rail hook.
See Figure 6.
See Figure 5.
See Figure 7.
Step 1:
Step 1:
REMOVE DRAWER
REINSTALL DRAWER
Figure 6.
Figure 7.
Hook
https://youtu.be/4DdK3cj3sTU

161020ronbow.eu | ronbow.comINSTALLATION SHEET
6
UNITY Vanity
Model : E042031
E042047
Designed By: KURZ KURZ DESIGN | GERMANY
Wood Surfaces
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Pledge Orange Oil, or similar
• Orange-Glo Wood Cleaner
DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their
original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may
be significant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,
household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].
