Ronbow VENTO SIGNATURE Series Assembly instructions

INSTALLATION AND CARE GUIDE
30” VENTO VANITY
E094130

161018ronbow.eu | ronbow.comINSTALLATION SHEET
1
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Tools Required
PRE-INSTALLATION
Materials Included
6 long screws
6 metal washers
6 metal caps
2 wall brackets
10 wood screws
Materials Required
1 2x6 beam cut to size
Install 2x6 backing material behind the finished wall to
properly secure the vanity.
• To properly secure the vanity, the middle of the required
2x6 backing material must be 27-1/2” (70cm) from the
finished floor.
• Extend the backing material beyond the width of the
vanity to the nearest stud. This will ensure proper support
for the vanity.
• Front-notch the studs to ensure the 2x6 backing
material is flush against the studs.
• Secure the 2x6 backing material to the studs with
framing nails.
• Rough-in the water supply and drain lines into the
rough-in plumbing areas of the vanity.
INSTALLING SUPPORT FOR THE VANITY
2” x 6”
backing material
27-1/2” (70cm)*

161018ronbow.eu | ronbow.comINSTALLATION SHEET
2
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Figure 1.
Figure 2.
Step 2:
Step 3:
The distance of the wall brackets is
28-1/2” (72.4cm).
Verify the markings in step 1 are level.
Drill 5/16” pilot holes, then push the
anchors into each pilot hole.
Mark the location of the wall brackets.
Step 1:
INSTALLATION
Step 4:
Place one wall bracket against the wall
and fasten the bolts to each anchor.
Place the bolt caps over each bolt.
Repeat the installation for the other
wall bracket.
See Figure 1.
See Figure 2.
Remove the drawer from the vanity.
Refer to page 5 to remove and install
the drawer.
Slide the vanity over the wall brackets.
Verify the vanity is level.
28-1/2” (72.4cm)

161018ronbow.eu | ronbow.comINSTALLATION SHEET
3
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Figure 3.
Step 5: Secure the vanity to the wall bracket
using the wood screws provided.
Each bracket requires five
wood screws.
See Figure 3.

161018ronbow.eu | ronbow.comINSTALLATION SHEET
4
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Figure 4.
Figure 5.
Step 2:
Step 3:
Place the vanity top on the vanity.
Verify the top is level with the vanity.
The pressure of the vanity top will
cause the silicone to spread. Clean
o any excess silicone with a damp
cloth immediately.
Install the faucet and drain per
manufacturer’s instructions.
Attach the drawer to the vanity by
following the instructions on page 5.
Clean the top surface of the vanity
with a damp cloth.
Apply a thin bead of silicone where
the vanity top will sit on the vanity.
See Figure 4.
See Figure 5.
Step 1:
INSTALLING THE SINKTOP

161018ronbow.eu | ronbow.comINSTALLATION SHEET
5
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Figure 6.
Step 2: Slide and lift up the drawer box.
Pull the release latches located
underneath the drawer.
Slide drawer box in until secured by rail
hook.
See Figure 7.
See Figure 6.
See Figure 8.
Step 1:
Step 1:
REMOVE DRAWER
REINSTALL DRAWER
Figure 7.
Figure 8.
Hook
https://youtu.be/4DdK3cj3sTU

161018ronbow.eu | ronbow.comINSTALLATION SHEET
6
VENTO 30” Vanity
Model : E094130 Designed By: PININFARINA | ITALY
Wood Surfaces
Recommended Products
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
PRODUCT CARE AND MAINTENANCE
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
• Pledge Orange Oil, or similar
• Orange-Glo Wood Cleaner
DISCLAIMERS: Wood naturally ages, darkens and changes color over time due to several environmental conditions that may cause materials to vary from their
original color and/or to warp, split or crack. These variations are considered to be the nature of the material in relation to their environmental exposure and may
be significant over a long period of time. The eectiveness of cleaning Ronbow product is dependant on various factors that include sunlight, smoke, moisture,
household cleaners and/or amount of cleaning product used over time. Ronbow cannot guarantee that the above Product Care & Maintenance methods will
eectively clean your product.
• Install 2x6 backing material behind the finish wall to properly secure the vanity.
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at [phone].
