RTA Products TECHNI MOBILI RTA-B005 User manual

Scan QR to view full
assembly video
VIDEO
Scan QR to view the
manual in French
FRENCH
Scan QR to view the
manual in Arabic
ARABIC
SIT-TO-STAND ROLLING ADJUSTABLE
LAPTOP CART WITH STORAGE
MODEL RTA-B005
ASSEMBLY INSTRUCTIONS
REV.OL-7284-0423
Thank you for purchasing our product

Do a quick inventory
of all the parts and
hardware listed below.
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
[email protected]
P.1 P.1
RTA-B005
1
x1
2
x1
3-L
x2
4
x1
Left side panel
MAIN PARTS LIST
Right side panel Locking Casters Back panel
5
x1
6
x1
7
x1
8
x1
Front bottom panel Middle lower shelf Bottom base panel Middle upper shelf
9
x2
10
x2
11A
x2
12
x1
Lateral support bar Lifting "T" tube Tightening plastic
cover
Main top panel
13
x1
15
x1
16
x4
17-A
x1
Right tilting
mechanism
Protection rail Tightening screw
knob
Magnet
3-N
x2
Non-Locking
Casters
14
x1
Left tilting
mechanism
17-B
x1
Small steel
plate
18
x1
Shelf door 19
x1
Door handle
Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.

16
P.2 P.2
RTA-B005
PART QTY SIZE
MAIN PARTS LAYOUT (For reference)
HARDWARE LIST
16 M4x14
A
ITEM
3
B
6
C
20
D
8
E
PART QTY SIZE
4M3x15
F
ITEM
1
G
2
H
2
Sets
I
INCLUDED TOOLS
1Phillips Screwdriver
M5x16
M6x35
M6x40
Bolt
M6x12
M4x20
Ø5x17
Ø8x19 Curved
connector
__________
12
13
14
16
8
12
7
5
9
18
11
15
10
10
4
3-L
Ø10x28
Plastic washer

P.3 P.3
RTA-B005
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
M6
30mm
M6x30
• Make sure you understand which
hardware will be used on each step. Using
the wrong size of screw, bolt or pin might
strip the threads or cause damage to the
part in which it is being used.
• To avoid misalignments, always leave the screws
loosely and do not tighten them until all the pieces
are positioned correctly.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes, or get
stuck inside the parts.
• If the hole seems to small for the screw, make sure
you are using the correct size of screw and/or that
you are installing it in the correct hole.
• Sometimes on the wood panels the laminate or
material might be covering the hole partially or
entirely, if there is no visible hole or if it looks too
small, pass and press the tip of your finger over the
area to feel its indentation, and carefully pierce the
laminate to uncover the hole underneath.
√
√
• Please read the assembly instructions throughly and
follow step by step.
• After the item is assembled, you can use rubbing
alcohol to erase or remove the visible part
numbers printed or labeled on the pieces.

P.4 P.4
RTA-B005
1. Screw the bolt into the indicated hole on the
panel indicated in the assembly step.
CAM BOLT AND CAM LOCK TUTORIAL
THE INSTRUCTIONS BELOW
ARE NOT ACTUAL ASSEMBLY STEPS
This unit uses cam bolts and locks (also known as mini fixes).
If you are not familiar with this kind of hardware, the below is a tutorial
that explains how to use them on the steps where they are required.
2. Join the other panel (with the big hole) to the
panel with the bolt. If it comes with the cam
locks already pre-installed, make sure to align
them to receive the bolt's head (refer to point
3). There might be a very small gap between
the panels which is normal.
3. Insert the cam lock on the panel with the big
hole making sure it goes aligned to receive the
bolt's head.
4. Use a Phillips screwdriver to turn the cam
lock clockwise. This will lock the panels
togheter and also will close any gaps.
Cam lock
alignment
If the cam locks come
pre-in stalled, make sure they
are aligned (see point 3).
THE ASSEMBLY STEPS START ON NEXT PAGE
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL
THIS IS ONLY
A TUTORIAL

P.5 P.5
RTA-B005
Attach the magnet 17-A to the bottom surface of the middle upper shelf 8with
screws F.
Attach the small steel plate 17-B to the inside surface of the shelf door 18 with
screws F.
STEP 1
Hardware
FM3x15
4
Pcs
17-A
ASSEMBLY STEPS
1
4
5
6
8
Tools (included)
5
(Bottom face)
(Inside face)
Screw the bolts Dinto panel 1.
Join panel 4to panel 1and turn the cam locks as explained in page 4.
Assemble panel 6to panel 1in the same way making sure the surface with the
cam locks towards the BOTTOM.
Join panel 5to panel 1.
STEP 2
Hardware
DM6x40
4
Pcs
Tools (included)
Attach bolts to 1
(Front)
(Top)
(Front)
(Bottom)
(Top)
(Front)
Assemble 4 to 1
Cam locks
alignment
on 4 and 6
(Front)
Assemble 6 to 1
(Front)
Attach 5 to 1
17-B
18
11
1
(Bottom)
(Top)

Attach bolts to 2
(Top)
(Front)
P.6 P.6
RTA-B005
Insert the metal pin Hinto the corresponding hole on panel 1.
Attach the door panel 18 to the pin H, making sure the metal plate is visible as
shown.
STEP 3
Hardware
HDouble
sided pin
1
Pc
(Front)
(Bottom face)
3-N
H
Non-Locking
go at the back
46
7
18
Tools (included)
1
H
Attach the bolts Dto the right side panel 2into the indicated holes.
Insert the metal pin Hinto the door 18.
Assemble panel 2to panels 4, 5, 6 and 18 as shown and as explained in page 4.
STEP 4
Hardware
DM6x40
Bolt
4
Pcs
Tools (included)
X2
X2
HDouble
sided pin
1
Pc
Insert H into 18
H
18
Attach 2 to 4, 5, 6
2
2
5
Cam locks
alignment
on 4 and 6
18
Use screws Ato assemble the casters 3to the bottom surface of the bottom
base panel 7in the following positions:
The Locking casters 3-L go at the front of the panel.
The Non-locking casters 3-N go at the back of the panel.
STEP 5
Hardware
AM4x14
16
Pcs
Tools (included)
Locking
go at the front
3-L

Screw the bolts Dinto the indicated holes on the top surface of pa
nel 7.
Join the main frame to the base and lock the pieces together by turning the
cam locks on panels 1, 2 and 4 as shown and as explained in page 4.
STEP 6
Hardware
DM6x40
6
Pcs
Tools (included)
Attach bolts to 7
P.7 P.7
RTA-B005
(Front)
1
4
8
9
Cam locks
alignment
on 1, 2 & 4
7
2
Screw the bolts Dto the middle upper shelf 8.
Assemble the shelf 8to panels 1, 2and 4as explained in page 4.
STEP 7
Hardware
DM6x40
6
Pcs
Tools (included)
Attach bolts to 8
8
1
4
2
Assemble the lateral support bars 9to the base panel 7with screws C from
underneath. The screws go through the base panel and into the bars.
Assemble the bars 9to the side panels 1and 2with screws Cfrom the side.
The screws go through the bars and into the side panels.
STEP 8
Hardware
CM6x35
6
Pcs
Tools (included)
9
7
12
9
9
(Front)
(Front)
Cam locks
alignment
on 1, 2 & 4

Secure all pieces
by tightening the
screw knob 16
into the tube 10
P.8 P.8
RTA-B005
Place the curved connectors I over the threaded holes of the lifting tubes 10.
Place the washer I over the connector I.
Connect the right tiltilg mechanism 13 to the tube 10.
Insert and screw the screw knob 16 into the tube 10. The screw knob goes
through the mechanism 13, the washer I, the connector I and into the tube 10.
Repeat the procedure for the left tilting mechanism 14.
THE SOFT PLASTIC WASHER MUST GO IN BETWEEN THE CONNECTOR
AND THE MECHANISM, AS IT PURPOSE IS TO CREATE THE NECESSARY
FRICTION THAT KEEPS THE MECHANISM FIRM WITHOUT MOVING.
DO NOT PLACE THE WASHER OVER THE MECHANISM, IT MUST GO
UNDER IT.
IF THE SOFT PLASTIC WASHER IS MISSING, DO NOT REPLACE IT WITH
ANY OTHER KIND; DO NOT USE METAL OR HARD PLASTIC WASHERS.
STEP 9
Hardware
I
Connector 2
Sets
I
10
14
Soft plastic
washer
REPEAT THE
PROCEDURE FOR
MECHANISM 14
EXTREMELY IMPORTANT!
Follow this step EXACTLY as instructed! An incorrect assembly leaves
the tilting mechanism and main panel prone to moving or sliding, and
even might flip down forwards unexpectedly under any weight.
Place Connector I
over tube 10
I
10
Place Washer I
over connector I
The washer goes OVER
THE CONNECTOR, NOT
over the mechanism.
10
Connect mechanism
13 to tube 10
If the soft plastic washers are
missing, DO NOT replace them
with metal or hard plastic washers.
13
16
16
I: Connector
I: Washer
10
Hollow
end
Tilting direction
13

Do not
tighten
P.9 P.9
RTA-B005
Assemble the tilting mechanisms 13 and 14 to the main panel 12 in their
respective sides with screws E.
STEP 10
Hardware
EM6x12
8
Pcs
12
13 14
16
Tools (included)
Hole facing to
the outside
(Front)
(Left)
(Right)
Place the plastic covers 11 over the lateral bars 9with their threaded holes
facing towards the outside.
Slide the lifting tubes 10 through the plastic covers 11 and into the bars 9.
Insert the screw knobs 16 into the plastic covers 11, but do not tighten yet.
STEP 11
11
9
9
10
16
9
(Front)

P.10 P.10
RTA-B005
Lift the main panel 12 about 6inches and tighten the screw knobs 16.
Assemble the protection rail 15 to the main panel 12 with its curvature towards
the front with screws Bfrom underneath.
STEP 12
Hardware
BM5x16
3
Pcs
Tighten 16
12
15
18
19
Tools (included)
Assemble the handle 19 to the door 18 with screw G.
STEP 13
Hardware
GM4x20
1
Pc
Tools (included)
Lift 12
Curvature
towards
the front

P.11 P.11
RTA-B005
FUNCTIONS / ADJUSTMENTS
ROLLING: Unlock the front casters to allow free movement.
LIFTING: Loosen the screw knobs to lift, then tighten again.
TILTING: Loosen the screw knobs to tilt, then tighten again.
• If you have objects or devices on or
under the main panel, use caution
when adjusting the height.
• Do not overtighten the screw knobs.
• Do not use the unit if the plastic
covers or screw knobs look cracked or
if they are stripped.
• Make sure the tilting mechanisms
are properly assembled as instructed
in step 9. An incorrect assembly will
result in the main top panel flippling
down forwards unexpectedly.
• Use caution when adjusting the
tilting angle when you have objects
or devices on it, and check if the
protection rail can retain them, but if
it seems that they might slip or tip
over, reduce the tilting angle.
• Before moving the unit, unlock the
front casters and secure or remove
any object that might fall off while the
unit is rolling.

P.12 P.12
RTA-B005
WEIGHT LIMITS
20 Lbs
(9.1 Kg)
20 Lbs
(9.1 Kg)
20 Lbs
(9.1 Kg)
• Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
• If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
• Every 4 months, inspect the unit completely and make sure that all screws are tighten.
• When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
CARE AND MAINTENANCE
WARNINGS
• Do not exceed the indicated weight limits.
• Make sure that the tilting mechanisms are properly assembled as instructed in step 9. An
incorrect assembly leaves the tilting mechanism unsecured, and the main top panel will not hold
enough weight on it and even might flip down forwards unexpectedly.
• It is recommended to first tilt the main panel, then place the objects or devices, but pay attention
to if they will be properly retained by the protection rail. If the object or device seems that might
tip over, reduce the tilting angle.
• If you have objects or devices on or under the main panel, use caution when adjusting the height
or tilting angle.
• Do not overtighten the screw knobs.
• Do not use the unit if the plastic covers or screw knobs look cracked or if they are stripped.
• Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
• Do not use solvents or abrasive materials to clean the unit.
• Do not climb on the base of the unit.
• Do not allow small children to play with the unit.
• Before moving the unit, unlock the front casters and secure or remove any object that might fall
off while the unit is rolling.
• The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability
for damages or consequences due to accidents, incorrect assembly, negligence, improper use,
modifications, or not heeding the above warnings.

P.13 P.13
RTA-B005
TECHNI MOBILI WARRANTY
RTA Products, LLC warrants to the Original Purchaser who acquired a new product from RTA
Products or its authorized resellers that this product will be free from defects in its workmanship
and materials, under normal use and service conditions, as described herein. "Defects" as used
in this warranty, is defined as any imperfections that impair the use of the furniture or product.
RTA Products LLC will replace any defective part, at its discretion, and without charge to the
original purchaser other than the freight from the end consumer to RTA Products.
Replacement parts can only be supplied if parts are available. Items out of production may be
unavailable. This warranty will be effective for the applicable time period beginning the date of
purchase on your original sales receipt. RTA product’s obligation under this warranty is limited to
repairing or replacing products or parts as provided herein. This product has been designed for
and is intended for office and home-office use only. This warranty is Original Purchaser’s sole
remedy for product defects, and this warranty does not extend to any product, or damage to any
product, caused by or attributed to abuse or misuse, products used for commercial or rental
purposes, use modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or implied,
including without limitations any implied warranty or merchantability or of fitness for a particular
purpose. Please note, all desks made with PVC Laminate surface should not be exposed to
direct sunlight, as it may damage the material. Damage of this nature is not covered under this
warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential damages.
This warranty is limited to merchandise purchased in the Continental United States, excludes
AK, HI and PR. Some States do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights. You may also have other rights that may vary from state
to state.
To file a Claim within the 48 contiguous United States:
Email us to [email protected] to explain the defect and provide your name, address,
phone number, model number of our product, date and place, and proof of purchase. Please
provide pictures of the damage or defect.If we determine that a replacement will remedy the
situation, and in order to determine the extent or the cause of the defect, purchaser may be
requested to send the part in question at purchaser’s expense. Once we receive the part, we will
examine it and determine whether the claim is valid (or not), and then proceed to send the
replacement. We will ship the replacement at our expense.
Replacement Parts for International Customers & AK-HI-PR orders:
RTA Products will replace the part free of charge, while the customer is responsible for
shipping costs plus any International local taxes or duties.
.
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
