RTA Products TECHNI MOBILI RTA-80X5 User manual

Thank you for purchasing our product.
MODEL RTA-80X5
ASSEMBLY INSTRUCTIONS
REV.122020-1

A
x1
B
x1
C
x1
D
x1
Backrest Seat 5-Leg star
base
Mechanism
MAIN PARTS LIST
E
x1
F
x5
G-L
x1
G-R
x1
Hydraulic gas
lift
Casters Left
armrest
Right
armrest
H
X1
Headrest
LIST OF HARDWARE
PART
QTY ITEM USE IN
I46x25mm Armrests to backrest
J46x20mm Mechanism to seat
K4
sets
6x20mm plus
washer Armrests to seat
L26x30mm Headrest to backrest
M4Hole covers:
2 Oval and 2 round Armrests
N1Allen wrench Steps 2 through 5
P. 1 RTA-80X5 P. 1
A
B
C
DE
F
G
G
H
PARTS LAYOUT (FOR REFERENCE)
Oval:
Round:
Sitting on the chair, not looking at it

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS
AND WARNINGS.
❶Do a quick inventory to
make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost to
you. Please refer to the
last page in this manual.
❸The replacement parts
service is limited to the
continental United States. If
you reside in Hawaii,
Puerto Rico, U.S.
Dependencies or other
countries, please contact
the supplier from where the
unit was purchased.
❹If during assembly
you find an issue or
need clarification,
please contact our
Customer Service for
assistance. Please refer
to the last page in this
manual.
❺On each step read
the instructions and
analyze the
illustrations thoroughly
before proceeding to
do the assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which hardware
will be used on each step.
Using the wrong size of
screw, bolt or pin might
strip the threads or cause
damage to the part in which
it is being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾If the hole seems too big or too small for the
screw, first make sure you are using the correct
size of screw and that it’s been installed in the
correct hole. Test another of the same screw
into the same hole, as well as test the screw
onto different holes for the same part. If the
hole still appears to be too small, do not force
it, it needs replacing.
P. 2 RTA-80X5 P. 2

ASSEMBLY STEPS
Insert the casters Finto the
legs of the base Cusing
pressure, then place the
gas lift Ein the middle of
the base as shown.
P. 3 RTA-80X5 P. 3
STEP 1
C
E
F
Assemble the armrests G
to the seat Bon their
respective sides using
screws and washers Kas
shown.
STEP 3
Hardware
K6x20mm 4
Sets
N
Assemble the mechanism D to the seat Busing screws J.
STEP 2
Hardware
j6x20mm
4
Pcs
N
(Front)
B
I
D
(Front)
B
RIGHT
G-R
LEFT
G-L
N
K
Note the
orientation
of the arms
N

Place the seat over the base
parts making sure the tip of
the gas lift Eenters into the
hole of the mechanism D.
Assemble the headrest Hto the backrest
Ausing screws L, then use Mto cover
the screw holes on the armrests.
P. 4 RTA-80X5 P. 4
STEP 4
ALL DONE! Give yourself a nice pat on the back. You did a great job!
H
L
STEP 6
Hardware
L6x30mm
2
Pcs
M4
Pcs
N
Assemble the armrests Gto the
backrest Aon their respective
sides using screws I.
STEP 5
Hardware
I6x25mm
4
Pcs
N
A
M
LEFT
G-L
RIGHT
G-R
Top holes: Oval caps.
Lower holes: Round caps.
NOTE: If the holes don’t
want to align, loosen up the
screws under the seat
(from step 3). When finished,
re-tighten those screws.
󰐙(Front)
󰐚
A
N

CHAIR’S FUNCTIONS
①To raise or lower the chair’s height, pull UP the lever that is under the seat. The chair
goes down while sitting on it, or up if you lift your body.
②To make the chair tilt freely, pull the same lever OUT horizontally to unlock this
function. When the chair is in the normal position, push the lever IN to lock again.
③To adjust the tension for the tilting function, turn the mechanism’s knob in either
direction to apply more or less tension. With less tension, the tilting will feel easier.
④To use the chair as if it was armless, just flip the arms up.
⑤To adjust the headrest’s height, pull the knob located on the front and at the same
time lower or raise the headrest; release the knob when the desired height is reached.
WARNINGS
• Do not exceed the indicated weight limit.
• Do not stand up on the chair or use it as ladder.
• Use the chair to seat only one person at a time.
• Do not use the chair if parts are damaged or if screws are loose or missing.
• Do not sit near the edge of the seat and always sit properly on the chair to avoid going
beyond your balance point and fall off the chair.
• The chair is intended for teenagers and adults. If small children are using the chair,
please keep close observation on them.
• Do not allow small children to play with the chair.
• Not paying attention to these warnings could result in severe injuries.
•To clean the chair it is recommended to use a soft cloth lightly damped in a solution of
smooth soap and water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean any part of the chair.
•Before applying a cleaning agent, test on a small hidden area of the chair, like
underneath the seat.
•Do not expose the product to direct sunlight or to extreme environmental conditions.
•Every 4 months, inspect the chair completely and make sure that all screws are
tighten.
CARE AND MAINTENANCE
P. 5 RTA-80X5 P. 5
5
4
3
2
1

TECHNI MOBILI CHAIR WARRANTY
TASK/KID'S CHAIR: 1-YEAR WARRANTY
EXECUTIVE/MANAGER CHAIR: 2-YEAR WARRANTY
1.RTA Products, LLC has warranted the Techni Mobili office chairs to the original purchaser
who acquired a new product from RTA Products or its authorized resellers of the product
against defects in material or workmanship.
2.This warranty is expressly limited to the repair or replacement (at its option) of defective
chair components or materials that fails under normal use as a result of a defect in materials
or workmanship. This warranty is limited to merchandise purchased in the Continental United
States. No assembly labor is included. The word "defects" as used in this warranty, is defined
as imperfections that impair the utility of the product.
3.This warranty applies under conditions of normal use, but does not apply to defects that
result from intentional damage, negligence, unreasonable use or exposure.
4.Liability for consequential damages is excluded to the extent exclusion is permitted by law.
This warranty gives you specific legal rights, and you may have other rights that vary from
State to State.
5.RTA Products does not warrant: a) natural variations in character marks b) changes in
surface finishes due to aging or exposure to light c) marks, scars, or wrinkles occurring
naturally in leather d) failure resulting from normal wear and tear e) the matching of colors,
grains, or textures of natural materials f) the colorfastness or the matching of textiles,
including an exact match to cuttings or to swatch cards g) damage, marking, or staining of
veneer surfaces due to contact with rubber or similar compounds, damage from sharp objects
or imprinting from writing instruments, or prolonged exposure to direct sunlight h) we do not
warrant products that are exposed to extreme environmental conditions or that have been
subject to improper storage.
6.RTA Products shall not be liable for loss of time, inconvenience, commercial loss, or
incidental or consequential damages.
7.Any modification to the original product voids the warranty. We do not warrant the
performance of the product when used in combination with other than original products.
8.This product has been designed for and is intended for office and home-office use only.
This warranty is Original Purchaser’s sole remedy for product defects, and this warranty does
not extend to any product, or damage to any product, caused by or attributed to abuse or
misuse, products used for commercial or rental purposes, use modifications of, or
attachments to the product, and products or parts not used, maintained, or extended
hereunder is in lieu of any and all other warranties, express or implied, including without
limitations any implied warranty or merchantability or of fitness for a particular purpose.
9.Report any defects to RTA Products, LLC together with your sales receipt or other proof of
purchase. If the chair is defective within the terms of the warranty, RTA Products, LLC will
furnish a replacement chair (at its option) at no cost of equal or similar value and design.
10.RTA Products will advise you of the procedure to follow in making warranty claims. The
following are the procedures for warranty claims:
a) Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain the
defect and give your name, address and phone number. Please have ready the model
number of our product, date and place of purchase. You can also write to us by e-mail
to [e-mail] and include the same information.
b) If we determine that replacement will remedy the situation, and in order to determine the
extent or the cause of the defect, purchaser will need to send the part in question at
purchaser’s expense. Once we receive the part, we will examine it and determine whether the
claim is valid (or not), and then proceed to send the replacement. We will ship the
replacement at our expense.
P. 6 RTA-80X5 P. 6

FOR SEVERAL HELP OPTIONS
INCLUDING REPLACEMENT PARTS ORDERS
_________________________________________________________________
VISIT: WWW.TECHNIMOBILI.COM
CLICK ON SUPPORT TAB
Scan QR Code to order replacement parts
OR EMAIL US: [e-mail]
P. 7 RTA-80X5 P. 7
